Black Diamond Equipment GUIDE BT User manual

EN
GUIDE BT
RECON BT
INSTRUCTIONS
08/2018
Firmware v1
M13107_A
Guide BT Recon BT

EN

Table of Contents
1. Introduction.......................................................................................................................................................3
1.1 Markings............................................................................................................................................................................ 4
1.2 Liability .............................................................................................................................................................................. 4
1.3 Warranty conditions ......................................................................................................................................................... 5
1.4 Manufacturer address & support ..................................................................................................................................... 5
1.5 Intended use ..................................................................................................................................................................... 5
1.6 Target group and previous knowledge............................................................................................................................. 5
1.7 Essentials........................................................................................................................................................................... 6
1.8 Technical specifications .................................................................................................................................................... 6
2. Safety.................................................................................................................................................................6
2.1 Signal words used in the safety instructions .................................................................................................................... 6
2.2 General safety rules and obligations ................................................................................................................................ 7
2.3 Residual risks | Warnings.................................................................................................................................................. 7
3. Packaging...........................................................................................................................................................8
4. General description ............................................................................................................................................8
4.1 Structure ........................................................................................................................................................................... 8
4.2 Carrying system................................................................................................................................................................. 9
4.3 Switching on | Self-Check | Send mode ........................................................................................................................... 9
4.4 Group check ....................................................................................................................................................................10
4.5 Helpful background features ..........................................................................................................................................12
4.5.1 Interference protection ..................................................................................................................................................12
4.5.2 PIEPS iPROBE-Support..................................................................................................................................................... 12
4.6Send Search ................................................................................................................................................................12
4.7 Search Send ................................................................................................................................................................12
4.7.1 Secondary avalanche | Auto-Search-to-Send ................................................................................................................. 12
4.8 Search mode | Search strategy.......................................................................................................................................13
4.8.1 In case of emergency....................................................................................................................................................... 13
4.8.2 Signal search ...................................................................................................................................................................14
4.8.3 Coarse search..................................................................................................................................................................15
4.8.4 Fine search ...................................................................................................................................................................... 15
4.8.5 Pinpointing ...................................................................................................................................................................... 16
4.8.6 Multiple burials | MARK function ................................................................................................................................... 16
4.9 GUIDE BT features...........................................................................................................................................................17
4.9.1 Vibra support................................................................................................................................................................... 17
4.9.2 Extended group check & pro-mode.................................................................................................................................17
4.9.3 Mark range settings........................................................................................................................................................ 17
4.9.4 Inclinometer ....................................................................................................................................................................18
4.9.5 SCAN & victim selection ..................................................................................................................................................18
4.9.6 Analog mode ................................................................................................................................................................... 19
4.9.7 TX600 mode .................................................................................................................................................................... 19
5. Device management with the PIEPS APP ...........................................................................................................19
6. Troubleshooting, maintenance, storage, disposal...............................................................................................20
6.1 Troubleshooting..............................................................................................................................................................20
6.2 Battery replacement .......................................................................................................................................................21
6.3 Cleaning...........................................................................................................................................................................22
6.4 Storage ............................................................................................................................................................................ 22
6.5 Disposal...........................................................................................................................................................................22
7. Conformity.......................................................................................................................................................22

Manual BLACK DIAMOND GUIDE BT/RECON BT | Firmware v1.0 | 08/2018 3 / 23
1. INTRODUCTION
Thank you for purchasing a BLACK DIAMOND GUIDE BT/RECON BT!
The BLACK DIAMOND GUIDE BT/RECON BT is an easy to use avalanche transceiver with reliable high performance.
The BLACK DIAMOND GUIDE BT/RECON BT comes with all tried and tested beacon features:
•3 antenna technology
•Big, circular receiving range for a quick and stable signal detection
•Perfect signal processing, even in difficult situations (multiple burials)
•Mark function
•Comprehensive self-check
•Easy to use group check
•Automatic interference protection
•Auto search-to-send
•iPROBE support
•Device management via PIEPS APP
The GUIDE BT provides additional functionality for maximum support in professional use:
•SCAN function
•Analog mode
•Victim selection
•Group check pro-mode
An avalanche beacon does not protect against avalanches! Detailed knowledge of avalanche prevention is as
indispensable as regularly practicing victim searches in an emergency. The following procedures and tips relate
only to special usage in conjunction with the BLACK DIAMOND GUIDE BT/RECON BT. The basic line of action in an
emergency –as explained in specialist publications and material from avalanche courses –must be followed.
With the BLACK DIAMOND GUIDE BT/RECON BT you have a product that is state of the art in terms of safety and
user-friendliness. Despite this, the BLACK DIAMOND GUIDE BT/RECON BT can pose risks if used inappropriately or
incorrectly. We refer to possible hazards in chapter 2 and with safety notes placed throughout the operating
manual.
This operating manual is intended to ensure the safe use of the BLACK DIAMOND GUIDE BT/RECON BT. The safety
instructions in this document must be followed at all times.
Before you use the BLACK DIAMOND GUIDE BT/RECON BT, you must have read and understand this operating
manual.
Black Diamond Equipment is not liable for technical or printing errors in this operating manual, neither is any
liability accepted for damage caused directly or indirectly by the delivery, performance or use of this operating
manual.
Copyright© Black Diamond Equipment, 07/2018

Manual BLACK DIAMOND GUIDE BT/RECON BT | Firmware v1.0 | 08/2018 4 / 23
This translation of the original manual is protected by copyright. All rights, especially the rights of reproduction,
distribution and translation, are reserved. No part of this document may be reproduced or stored, processed,
duplicated or distributed using electronic systems in any form (photocopy, microfilm or other method) without
the written consent of Black Diamond Equipment. Violations may incur criminal penalties.
1.1 MARKINGS
In accordance with applicable regulations, the following marks may be found on the BLACK DIAMOND GUIDE
BT/RECON BT or/and on the packaging:
CE mark of conformity: indicating the fulfillment of the following standards: EMV 2014/30/EU,
RED 2014/53/EU, RoHS 2011/65/EU.
Dustbin symbol: advising users to dispose of waste electrical and electronic equipment
separately from unsorted municipal waste.
FCC ID
FCC ID: indicating the compliance with Part 15 of the FCC Rules.
IC ID
IC ID: indicating the compliance with Industry Canada’s licence-exempt RSS standard(s).
Bluetooth® logo: The Bluetooth® word mark and logos are registered trademarks owned by the
Bluetooth SIG, Inc. and any use of such marks by Black Diamond Equipment is under license.
Other trademarks and trade names are those of their respective owners.
SN
12 digit serial number: identifying the device and is used for device registration. The first 4 digits
indicate year and week of manufacturing.
Recycling symbol.
Battery symbol: indicating battery type and correct position.
Instruction pictogram: advising users to read the instructions and warnings.
Black Diamond brand name.
Black Diamond logo.
PRO BT
Example of the model name.
1.2 LIABILITY
The information contained in this operating manual describes but does not guarantee the features of the product.
No liability is accepted for damage caused by:
•improper use,
•failure to follow the operating manual,
•unauthorized modifications of the BLACK DIAMOND GUIDE BT/RECON BT,
•improper work on and with the BLACK DIAMOND GUIDE BT/RECON BT,
•continuing to use the BLACK DIAMOND GUIDE BT/RECON BT despite evidence of wear and tear,
•unauthorized, improperly carried out repairs,
•emergencies, external influences or force majeure.
NOTICE
Alterations or modifications not explicitly approved by the manufacturer will result in you no
longer being allowed to use the device.

Manual BLACK DIAMOND GUIDE BT/RECON BT | Firmware v1.0 | 08/2018 5 / 23
1.3 WARRANTY CONDITIONS
The manufacturer provides a 2-year warranty covering manufacturing and material defects of the BLACK
DIAMOND GUIDE BT/RECON BT from the date of purchase. Exceptions are the battery, carrying system, hand-loop
and bag as well as any damage caused by improper use or dismantling of the device by unauthorized persons. Any
other warranties and liability for consequential damage are expressly excluded. For warranty claims, please take
proof of purchase and a description of the fault to the point of sale.
Register your BLACK DIAMOND GUIDE BT/RECON BT in the PIEPS APP (iOS, Android) or at my.pieps.com and get:
•a warranty extension from 2 to 5 years!
•important information on software updates!
1.4 MANUFACTURER ADDRESS & SUPPORT
Black Diamond Equipment, Ltd. 2084 East 3900 South, Salt Lake City, UT 84124
Europe: Black Diamond Europe Hans-Maier-Straße 9, 6020, Innsbruck, Austria
For technical problems, please contact the support: blackdiamondequipment.com
1.5 INTENDED USE
The BLACK DIAMOND GUIDE BT/RECON BT serves as an avalanche victim search device (avalanche transceiver) for
the localization of buried persons and must only be used as intended. Any other use requires the written consent
of Black Diamond Equipment. Improper use can put individuals at risk and result in the device being damaged.
The BLACK DIAMOND GUIDE BT/RECON BT is not an automatically functioning device with partly automated
functionalities –for this reason, the BLACK DIAMOND GUIDE BT/RECON BT may only be commissioned after
having read and understood the documentation. Failure to use the device as intended will result in all liability and
warranty claims being rejected. The BLACK DIAMOND GUIDE BT/RECON BT is to be operated only under the
conditions of use described in the documentation.
1.6 TARGET GROUP AND PREVIOUS KNOWLEDGE
An avalanche beacon should be part of the avalanche emergency equipment of everyone who ventures off from
the secured piste into open, unsecured terrain (e.g. ski touring, freeriding, mountain rescue operations, etc.).
Users of the BLACK DIAMOND GUIDE BT/RECON BT must meet the following conditions:
•Read and understand this operating manual.
•Users with impaired vision must ensure that they can read the labelling and displays on the device as well
as the instructions in the documentation without problem.
•If users with impaired hearing are unable to hear the acoustic signal, they must ensure that they can
correctly interpret the display indications in accordance with the instructions in the operating manual.
•Regular training ensures safe and efficient use of the BLACK DIAMOND GUIDE BT/RECON BT.

Manual BLACK DIAMOND GUIDE BT/RECON BT | Firmware v1.0 | 08/2018 6 / 23
1.7 ESSENTIALS
The BLACK DIAMOND GUIDE BT/RECON BT meets the current state of technology and the applicable health and
safety regulations. However, incorrect operation or misuse can give rise to hazards for:
•the life and health of the users or third parties,
•the BLACK DIAMOND GUIDE BT/RECON BT and property of the user,
•the efficient use of the BLACK DIAMOND GUIDE BT/RECON BT.
1.8 TECHNICAL SPECIFICATIONS
Name
BLACK DIAMOND GUIDE BT/RECON BT
Transmission frequency
457 kHz
Field strength
max. 7 dBµA/m (2,23 µA/m) at a distance of 10 m
Power supply
3x Alkaline (AAA) LR03 1.5 V or 3x Lithium (AAA) FR03 1.5V
Battery lifetime
400/200 h (Alkaline) 600/300 h (Lithium)
Maximum range
60 m
Search strip width
60 m
Dimensions (LxWxH)
118 x 76 x 29 mm
Weight
230/220 g (incl. battery)
Temperature range
-20°C to +45°C (-4°F to +113°F)
Storage temperature range
-25° C to +70° C (-13° F to +158° F)
2. SAFETY
This operating manual is structured in accordance with the applicable EU regulations and contains safety
instructions. Each individual is personally responsible for complying with the safety instructions. This chapter
contains all safety-related information.
Should anything be unclear or difficult to understand, please contact our support team.
2.1 SIGNAL WORDS USED IN THE SAFETY INSTRUCTIONS
DANGER
Imminent threat to the life of individuals
A safety instruction with the signal word DANGER indicates an imminent threat to the life and
health of individuals!
WARNING
Risk of personal injury (serious injuries) and possible material damage
A safety instruction with the signal word WARNING indicates a dangerous situation which
could affect the health of individuals.
CAUTION
Risk of material damage and possible minor risk of injury
A safety instruction with the signal word CAUTION indicates a possibly dangerous situation
which could primarily result in material damage.
NOTICE
This symbol with the text NOTICE indicates supporting information.

Manual BLACK DIAMOND GUIDE BT/RECON BT | Firmware v1.0 | 08/2018 7 / 23
2.2 GENERAL SAFETY RULES AND OBLIGATIONS
The following safety rules and obligations apply in general for using the BLACK DIAMOND GUIDE BT/RECON BT:
•The BLACK DIAMOND GUIDE BT/RECON BT must only be used in perfect condition.
•It is forbidden to alter or change the BLACK DIAMOND GUIDE BT/RECON BT without the written
permission of Black Diamond Equipment.
•Do not attempt to repair damage or malfunctions without authorization. Instead, contact our support,
who will tell how to proceed. The BLACK DIAMOND GUIDE BT/RECON BT must not be used until the
damage/malfunction has been repaired.
•The safety and operating instructions in the operating manual must be followed at all times.
2.3 RESIDUAL RISKS | WARNINGS
Even though the BLACK DIAMOND GUIDE BT/RECON BT has been designed with maximum care and all safety-
related facts have been taken into consideration, residual risks may exist and must be evaluated by means of a
risk assessment. All residual risks and warnings from the risk assessment are listed in this chapter.
DANGER
Risk of device loss
Always carry the device in the included carrying system or an approved apparel pocket!
Always leave the device cord-secured!
DANGER
Risk of a not transmitting device due to enabled Bluetooth
The Bluetooth mode is supposed for device management and training mode only! Never use
the Bluetooth mode in avalanche terrain!
DANGER
Risk of device loss during slope angle measurement
Although the GUIDE BT keeps transmitting while the inclinometer is active, the function
should only be used for training reasons. Never use the inclinometer function in avalanche
terrain!
DANGER
Risk of battery explosion due to improper battery types or damaged batteries
Only use batteries of type “Alkaline (AAA) LR03 1.5 V or 3x Lithium (AAA) FR03 1.5V“!
Never use damaged batteries!
The use of Lithium batteries must be confirmed in the PIEPS APP!
DANGER
Risk of incorrect battery capacity reading due to improper battery types
Only use batteries of type “Alkaline (AAA) LR03 1.5 V or 3x Lithium (AAA) FR03 1.5V“!
The use of Lithium batteries must be confirmed in the PIEPS APP!
WARNING
Risk of hearing damage due to the high noise level
Never hold the device directly next to your ear! A minimum distance of 50 cm is recommended.
CAUTION
Risk of crushing
Be aware of a crushing risk when using the sliders!

Manual BLACK DIAMOND GUIDE BT/RECON BT | Firmware v1.0 | 08/2018 8 / 23
CAUTION
Risk of device malfunction or damage due to extreme temperatures
Do not expose the device to extreme temperatures outside of the operating limits! Store the
device protected from direct sunlight! Extreme temperatures can result in malfunction or
damage!
NOTICE
The user must read the operating manual!
3. PACKAGING
•1x BLACK DIAMOND GUIDE BT/RECON BT
•3x Alkaline battery (in battery compartment)
•1x BLACK DIAMOND GUIDE BT/RECON BT carrying system
•1x Hand loop
•1x Quick Start Guide
Check that the contents are complete and undamaged after unpacking. If necessary, contact your point of sale or
our support team.
A correct disposal of the packaging is an environmentally friendly manner (paper to paper, plastic to plastic, etc.).
4. GENERAL DESCRIPTION
4.1 STRUCTURE
GUIDE BT RECON BT
(1A) LCD display (backlight)
(1B) Slider OFF/SEND/SEARCH
(1C) Slider lock
(1D) Button MARK
(1E) Button SCAN*
(1F) Speaker
(1G) Transmit control LED
(1H) Battery compartment

Manual BLACK DIAMOND GUIDE BT/RECON BT | Firmware v1.0 | 08/2018 9 / 23
(2A) Direction indication
(2B) Distance indication
(2C) Transmit symbol
(2D) Battery capacity/type
(2E) MARK (marking possible)
(2F) Active transmitting antenna
(2G) Number of burials (1-3)
(2H) Number of burials (4 or
more)
(2J) Transmitter marked
(2K) Bluetooth active
(2L) Inclinometer mode*
(2M) TX600 mode*
(2N) SCAN mode*
(2P) Analog mode*
(2Q) Meter symbol for SCAN /analog
mode*
* GUIDE BT only
4.2 CARRYING SYSTEM
BLACK DIAMOND recommends using the included carrying system
(3A) or an approved apparel pocket. In order to protect the
beacon’s display, carry the beacon with its display facing inwards
(3B). The transmit control LED (1G) is visible in the pouch´s window
(3C).
The included hand loop is intended to be used for training sessions.
DANGER
Risk of device loss
Always carry the device in the included carrying system or an approved apparel pocket!
Always leave the device cord-secured!
4.3 SWITCHING ON | SELF-CHECK | SEND MODE
Switching on: Move the slider lock (1C) to the left and the slider (1B) upwards into the position SEARCH. Then
release the slider lock (1C) and move the slider (1B) downwards, until it locks in the position SEND.
The display shows firmware version, battery capacity, self-check progress (4A), self-check result (4B), group check
countdown (4C) and finally the send display with the active transmitting antenna (4D).
The device is now in send mode, the transmit control LED (1G) is blinking.
NOTICE
A minimum distance of 5 m from other devices and all electronic, magnetic and metallic sources
of interference should be kept during the self-check.
If the self-check is successful, “OK” is indicated on the display (4B). In the event of a device warning, an alert signal
sounds and the display indicates “E” in combination with a number (4E). For error codes, see chapter 6.1.

Manual BLACK DIAMOND GUIDE BT/RECON BT | Firmware v1.0 | 08/2018 10 / 23
Firmware version
Battery capacity/type
(AL=Alkaline,
LI=Lithium)
Self-check OK
Group check
countdown
SEND display
Self-check error
Send-Vibra
Additionally, the GUIDE BT provides haptic send mode confirmation (10x vibration).
This feature is enabled by default and can be disabled in the PIEPS APP device manager.
4.4 GROUP CHECK
Despite a comprehensive self-check, a beacon check (transmit check and receive check) is obligatory prior to
every tour! The BLACK DIAMOND GUIDE BT/RECON BT provides a group check function. In group check mode the
receiving range is limited to 1 m.
Group check regular
BLACK DIAMOND GUIDE BT/RECON BT
Check: frequency
Group check extended
GUIDE BT only
Check: frequency/pulse/period
Start
Press and hold the button MARK (1D)
during the group check countdown (CH)
Press and hold the button SCAN (1E)
during the group check countdown (CH)
Result
•“Distance indication“ = OK
•“ER“ = error (frequency not
according to standard)
•“OK“ = OK
•“ER“ = error (one or more transmit
parameters not according to standard)
End
Release button
The Regular group check is sufficient for checking modern, digital devices with 3 antennas.
The Extended group check is recommended for checking old devices (analog single-antenna devices).
Regular group check display readings
Device not transmitting or
distance too big (> 1 m)
Distance reading: device
transmitting and
Device transmitting but
frequency not according
to standard
4A
4B
4C
4D
4E

Manual BLACK DIAMOND GUIDE BT/RECON BT | Firmware v1.0 | 08/2018 11 / 23
frequency according to
standard
Extended group check display readings
Device not transmitting
or distance too big (> 1
m)
Distance reading: device
transmitting and all
transmit parameters
according to standard
Device transmitting but
one or more transmit
parameters not according
to standard
More than one signals
within 1 m range
=> increase distance
Continuous wave indication | old-device-indication (see chapter 4.8.6)
Group check pro-mode
The GUIDE BT additionally provides a pro-mode. The pro-mode allows a transmit check as well as a receive check
without exiting the group check mode. By default, it is disabled and can be enabled in the PIEPS APP device
manager.
•Tip the GUIDE BT downwards to transmit in group check mode
•Tip the GUIDE BT upwards to receive in group check mode
Pro-mode SEARCH
Pro-mode SEND
(example image)
The full avalanche beacon check with pro-mode
(1) Receive check
Group leader => pro-mode SEND: device transmitting?
All others => search mode: devices receiving?
(2) Transmit check
Group leader => pro-mode SEARCH: device receiving?
All others => send mode: devices transmitting?
NOTICE The receive check can be combined with a range
test by choosing a large distance (50 m).

Manual BLACK DIAMOND GUIDE BT/RECON BT | Firmware v1.0 | 08/2018 12 / 23
4.5 HELPFUL BACKGROUND FEATURES
Maximum background support in send mode and search mode!
4.5.1 Interference protection
•Auto-Antenna-Switch | Protection in send mode
If the transmitting antenna is impacted by external interference, the other antenna will take over the
transmit function. The BLACK DIAMOND GUIDE BT/RECON BT always transmits with the strongest
possible signal!
•Signal Verification | Protection in search mode
Only a verified 457kHz signal is indicated. The BLACK DIAMOND GUIDE BT/RECON BT doesn´t confuse
ghost signal indication!
External interference and distance recommendations
All beacons are very sensitive to electrical and magnetic sources of interference. Due to this, all manufacturers
recommend keeping a minimum distance from electronic, magnetic and metallic sources of interference (mobile
phone, radio, keys, magnetic closures, etc.):
Minimum distance in send mode: 20 cm | Minimum distance in search mode: 50 cm
4.5.2 PIEPS iPROBE-Support
Beacons with iPROBE-support* get automatically deactivated when probing with the electronic probe PIEPS
iPROBE. This prevents signal overlaps and the next-strongest signal is automatically shown on the display of the
receiving beacon. Maximum support in multiple burials!
* Beacons with iPROBE-Support: BLACK DIAMOND GUIDE BT/RECON BT, PIEPS PRO BT/POWDER BT, PIEPS MICRO,
PIEPS DSP PRO/SPORT/PRO ICE, PIEPS DSP STANDARD/TOUR ≥ v5.0, PIEPS FREERIDE.
4.6 SEND SEARCH
Move the slider lock (1C) to the left and the slider (1B) upwards in the position SEARCH.
4.7 SEARCH SEND
Move the slider (1B) downwards, until it locks in the position SEND.
4.7.1 Secondary avalanche | Auto-Search-to-Send
The BLACK DIAMOND GUIDE BT/RECON BT provides the feature Auto-Search-to-Send. By default, it is disabled
and can be enabled in the PIEPS APP device manager. Once enabled, the device switches from search mode to
send mode automatically after a certain time without motion (burial).
The function provides the following characteristics:
•Motion-controlled initialization
•Short switching timeout
•Long warning phase with alert and countdown prior to switching
•Continued alert, also after switching

Manual BLACK DIAMOND GUIDE BT/RECON BT | Firmware v1.0 | 08/2018 13 / 23
Beacon
function
SEARCH
WARNING
SEND
Display
indication
Search display
Sound
Search sound
Manual abort
Turn device or press MARK button
Turn device off or into send mode
START WARNING
Setting 1 (60 s) 0:30 min
Setting 2 (90 s) 1:00 min
Setting 3 (120 s) 1:30 min
SWITCHING TO SEND
1:00 min
1:30 min
2:00 min
4.8 SEARCH MODE | SEARCH STRATEGY
4.8.1 In case of emergency
A buried person has the greatest chance of being rescued by an efficient companion rescue. In the event of an
accident, the following applies: KEEP CALM, OBSERVE, ALERT, ACT WITH COORDINATION!
(1) Keep calm & get an overview
•Are there any other risks?
•How many victims?
•Determine the primary search area!
(2) Make a brief emergency call
•EU 112, AT 140, CH 1414, IT 118, FR 15, NA 911
(3) Burial search
•Signal search (eyes + ears, beacon)
•Coarse search (starting with initial signal)
•Fine search (closer than 5 m on the surface)
•Pinpointing (systematic probing)
(4) Systematic digging
(5) First Aid
(6) Rescue

Manual BLACK DIAMOND GUIDE BT/RECON BT | Firmware v1.0 | 08/2018 14 / 23
4.8.2 Signal search
Start searching in the primary search area for the initial signal detection as well as for visual/acoustic signals. The
BLACK DIAMOND GUIDE BT/RECON BT has a circular receiving range that allows a correct indication of direction
and distance from the point of initial signal detection –a specific method such as turning/rotating is not
necessary. All signals of the burials that are within the maximum receiving range are received simultaneously.
Walk the search strip width in the search
area quickly. The recommended search strip
width for the BLACK DIAMOND GUIDE
BT/RECON BT is 60 m. The display shows “no
signal”.
One rescuer with skis
for signal search
One rescuer by foot
for signal search
More rescuers
for signal search
d = search strip width
Point of impact
Point of disappearance
Primary
Search area
SIGNAL SEARCH
COARSE SEARCH
FINE SEARCH
PINPOINTING
Result Accuracy
Search Speed

Manual BLACK DIAMOND GUIDE BT/RECON BT | Firmware v1.0 | 08/2018 15 / 23
NOTICE
All participants, observers included, must switch their devices to search mode (or to standby
mode)! Also follow the external interference distance recommendations!
As soon as signals are received, the distance and direction to the strongest signal are shown on the display. The
number of victims located within the receiving range is indicated by the number of human figures.
one
two
three
four or more
Vibra on initial signal detection
The GUIDE BT provides additional haptic support by vibration on initial signal
detection. This lets rescuers focus on the visual surface search during the signal
search.
4.8.3 Coarse search
Follow the directional arrow quickly and check for a decreasing distance reading. Change the search direction by
180° in case of an increasing distance reading.
Turn left
Move straight ahead
Turn right
NOTICE Work calmly and with concentration in search
mode.
Avoid hasty movements!
4.8.4 Fine search
From a distance of 5 m, the search speed should be notably reduced (50 cm/s). At the same time, start working
close to the surface of the snow. To prevent confusion during the fine search, the direction indication disappears
below a distance of 2 m. Reduce the search speed again and find, by cross-like movements, the position of the
lowest distance reading. A dynamic acoustic signal output supports the fine search: the closer the higher/faster.

Manual BLACK DIAMOND GUIDE BT/RECON BT | Firmware v1.0 | 08/2018 16 / 23
Do an accurate direction adjustment before the
direction arrow disappears! You are then moving to
the transmitting beacon in best coupling position and
save time during the cross-like movements.
Move your beacon at a slow, steady speed of about 10
cm/s, keep it leveled close to the surface and do not
rotate your device. Search along the Y axis, determine
the lowest distance value, then follow along the X
axis. Always move past the point of the lowest
distance to verify the distance tendency. Mark the
point of the lowest distance reading and start
pinpointing.
4.8.5 Pinpointing
Begin at the point of the lowest distance indicated.
Always probe perpendicular to the surface. Use your
lower hand as a “probe guide” to ensure the probe
follows a steady path. Follow a proven system until
you have a hit. Communicate a hit clearly to
companions. Leave the probe stuck for shoveling
guidance.
4.8.6 Multiple burials | MARK function
A multiple burial is indicated clearly on the display by the number of small human figures (2G, 2H).
Marking is possible from a distance reading of 5 m and is indicated by the MARK symbol (2E). Press the button
MARK (1D) briefly to “hide” the localized transmitter. A successful flagging is confirmed by a frame around the
human figure (2J). The display then indicates the direction/distance to the next strongest signal inside the
receiving range. If there are no further signals within the receiving range the display indicates “no signal”.
prior to marking
after marking

Manual BLACK DIAMOND GUIDE BT/RECON BT | Firmware v1.0 | 08/2018 17 / 23
De-mark a single signal: press the button MARK
(1D) for 3 seconds.
De-mark all: switch to send mode and then back
to search mode. With the GUIDE BT you can also
use the SCAN function for a full reset.
Continuous wave indication | old-device-indication
Old analog transceivers are transmitting a continuous wave in addition to the pulse signal. To keep an impact at a
minimum, it is recommended to step a few meters away after marking such a transmitter.
Signal without continuous wave
Signal with continuous wave
The BLACK DIAMOND GUIDE BT/RECON BT identifies a continuous
wave and supports visually by flashing human figures.
4.9 GUIDE BT FEATURES
4.9.1 Vibra support
Send-Vibra: see chapter 4.3.
Vibra on initial signal detection: see chapter 4.8.2.
4.9.2 Extended group check & pro-mode
See chapter 4.4.
4.9.3 Mark range settings
In the PIEPS APP device manager the mark range can be changed from 5 m (default) to 20 m or to max. range.

Manual BLACK DIAMOND GUIDE BT/RECON BT | Firmware v1.0 | 08/2018 18 / 23
4.9.4 Inclinometer
You can use the integrated three dimensional inclinometer to quickly check the gradient:
•Put your ski pole in slope line at that point of the slope you want to measure.
•Press the button SCAN (1E) for 3 seconds while in send mode.
•Put your GUIDE BT next to the ski pole and read the indicated value. The display
switches back to send mode indication automatically after 20 seconds.
DANGER
Risk of device loss during slope angle measurement
Although the GUIDE BT keeps transmitting while the inclinometer is active, the function
should only be used for training reasons. Never use the inclinometer function in avalanche
terrain!
4.9.5 SCAN & victim selection
Two SCAN modes are available:
The Regular SCAN provides a rough overview about the burial situation by indicating the number of victims within
certain distance ranges. This is the default setting. The Detailed SCAN shows direction and distance for each
victim and allows selecting a victim. The setting can be changed in the PIEPS APP device manager.
Regular SCAN
Press the button SCAN (1E) while in search mode.
The GUIDE BT scans the entire receiving range
and displays an overview. During the scan, don´t
move and hold the device steady.
reading 1: total number of victims within 5 m
reading 2: total number of victims within 20 m
reading 3: total number of victims within 60 m
The SCAN mode ends automatically but can also
be interrupted by another SCAN button press.
Detailed SCAN & victim selection
Press the button SCAN (1E) while in search mode.
The GUIDE BT scans the entire receiving range
and ends with indicating the direction and
distance to the first victim.
Use MARK (1D) to scroll through the closest 3
victims. The selected one is encircled (2J) –follow
the direction/distance reading to approach it. The
MARK function is not available in this mode.
Press SCAN to exit the Detailed SCAN mode and
to return to regular search mode.

Manual BLACK DIAMOND GUIDE BT/RECON BT | Firmware v1.0 | 08/2018 19 / 23
4.9.6 Analog mode
The analog mode can be used for specific search strategies as well as for demo reasons (coupling positions).
Disabled by default, the feature can be enabled in the PIEPS APP device manager.
Press the button SCAN (1E) for 3 seconds while in
search mode. The analog mode starts with biggest
range.
Use SCAN to reduce range. Use MARK to increase
range.
Press SCAN for 3 seconds to exit the analog mode and
to return to regular search mode.
4.9.7 TX600 mode
The TX600 mode allows detecting the PIEPS TX600 –this is a mini transmitter for
dogs/equipment that works with 456 kHz.
Start TX600 mode: Press the buttons MARK (1D) and SCAN (1E) simultaneously for 3
seconds while in search mode. You see a “TX” indicated on the display (2M). Follow the
search phases as usual but use a reduced search strip width of 20 m. MARK can also be
used as usual, SCAN and analog mode is not available in TX mode.
Exit TX600 mode: Press MARK and SCAN simultaneously again for 3 seconds. Alternatively,
switch to send mode and then back to search mode. The “TX” indication disappears and
the GUIDE BT is receiving 457 kHz signals again.
NOTICE The recommended search strip width in TX600 mode is 20 m.
5. DEVICE MANAGEMENT WITH THE PIEPS APP
Bluetooth and the PIEPS APP allow a straightforward device management (e.g. software update) and additionally
provide a handy training mode.
Get the PIEPS APP (Android Play Store, iOS App Store), connect your BLACK DIAMOND GUIDE BT/RECON BT and
take advantage of all features!
To enable Bluetooth, press the button MARK (1D) while switching on the beacon.
