Black Horce Model HAWKER TYPHOON MK1B User manual

SPECIFICATION


Wingspan : 2,000 mm 78.74 in.


Length : 1,600 mm 62.99 in


Weight : 07 kg 15.40 Lbs.
Partslistingrequired(notincluded).


Radio : 08 channels.


Servo : 09 standar high torque servos.


Engine : O.S GT 22-33 CC Gas.
Instruction Manual book
MadeinVietnam.
ITEM CODE:BH132.

HAWKER TYPHOON MK1B - Item code: BH132 . Instruction Manual
2
This instruction manual is designed to help you build a great flying aeroplane. Please read this
manual thoroughly before starting assembly of your HAWKER TYPHOON MK1B. Use the parts
listing below to identify all parts.
WARNING.
Please be aware that this aeroplane is not a toy and if assembled or used incorrectly it is
capable of causing injury to people or property. WHEN YOU FLY THIS AEROPLANE YOU
ASSUME ALL RISK & RESPONSIBILITY.
IfyouareinexperiencedwithbasicR/CflightwestronglyrecommendyoucontactyourR/Csupplier
and join your local R/C Model Flying Club. R/C Model Flying Clubs offer a variety of training
proceduresdesignedtohelpthenewpilotonhiswaytosuccessfulR/Cflight.Theywillalsobeable
to advise on any insurance and safety regulations that may apply.
TOOLS & SUPPLIES NEEDED.
Thick cyanoacrylate glue.
30 minute epoxy.
5 minute epoxy.
Hand or electric drill.
Assorted drill bits.
Modellingknife.
Straight edge ruler.
2mm ball driver.
Phillips head screwdriver.
220 grit sandpaper.
90° square or builder’s triangle.
Wire cutters.
Masking tape & T-pins.
Thread-lock.
Paper towels.
Some more parts.
HARDWAREPACK
COWLING.
Landinggear.....
Toavoid scratching your new airplane, donot
unwrap the pieces until they are needed for
assembly. Cover your workbench with an old
towel or brown paper, both to protect the air-
craftand to protect the table. Keep a coupleof
jars or bowls handy to hold the small parts af-
ter you open the bag.
Pleasetrialfitalltheparts.Makesureyouhave
the correct parts and that they fit and are
alignedproperly beforegluing!This willassure
proper assembly.HAWKER TYPHOON MK1B
ARF is hand made from natural materials,
every plane is unique and minor adjustments
may have to be made. However, you should
find the fit superior and assembly simple.
The painted and plastic parts used in this kit
are fuel proof. However, they are not tolerant
of many harsh chemicals including the follow-
ing:paintthinner,C/Aglue accelerator,C/Aglue
debonderandacetone. Donot letthese chemi-
cals come in contact with the colors on the
covering and the plastic parts.
PARTS LISTING.
FUSELAGE ASSEMBLY
(1) Fuselage.
WING ASSEMBLY
(1) Right wing half with pre-installed
aileron.
(1) Left wing half with pre-installed
aileron.
Tail section assembly
(1) Vertical stabilizer with pre-
installedrudder.
(1) Horizontal stabilizer with pre-
installedelevator halves.
SUGGESTION.
NOTE.

3
HAWKER TYPHOON MK1B - Item code: BH132 . Instruction Manual
Caution: this model is not a toy!
If you are a beginner to this type of powered
model, please ask an experienced model flyer
for help and support. If you attempt to operate
the model without knowing what you are doing
you could easily injure yourself or somebody
else. Please keep your safety and well-being
in mind at all times.
Important: before you start construction
Even if you have already built a large number
of RC models please read right through these
instructions and check all the kit components
against the parts list. We have taken great
trouble to keep construction as simple as
possible, without making any compromises in
the area of safety.
Note regarding the film covering
Minor creases or bubbles may develop in the
film covering due to major fluctuations in
weather conditions (temperature, humidity
etc.); in rare cases you may even find a slight
warp in a component. These minor faults are
in the nature of film-covered built-up wooden
structures, and can easily be corrected using
a heat gun, as commonly used for modelling.
Creases: Blow warm air over the area
and rub down with a soft
cloth.
When self-tapping screws have to be
screwed into wood, apply a little white
glue to prevent them shaking loose: just
squirt white glue into the hole and fit the
screw.
+ This is not a toy
+ Be sure that no other flyers are using your
radio frequency.
+ Do not smoke near fuel
+ Store fuel in a cool, dry place, away from
children and pets.
+ Wear safety glasses.
+Theglow plugclip mustbe securelyattached
to the glow plug.
+ Do not flip the propeller with your fingers.
+ Keep loose clothing and wires away from
the propeller.
+ Do not start the engine if people are near.
Do not stand in line with the side of the propel-
ler.
+ Make engine adjustments from behind the
propeller only. Do not reach around the spin-
ning propeller.
SAFETY PRECAUTION.
Caution! do not heat the film more than is
absolutely necessary. If the air or the iron is
too hot, the film may melt and holes may be
formed.
This model is highly pre-fabricated and can be
built in a very short time. However, the work
which you have to carry out is important and
must be done carefully. The model will only be
strong and fly well if you complete your tasks
competently - so please work slowly and
accurately.
REPLACEMENT LARGE PARTS
Wing warp: Holdthe panel twisted gently
in the opposite direction to
thewarp, and apply warm air
to remove the creases from
the covering.
B2. B1.
D1.
C.
D2.
A.
E.
F1.
F2.
A.Cowling.
B. Wing panel.
C. Fuselage.
D. Horizontal stabilizer.
E. Rudder
F1.Aluminium tube wing
dihedral brace.
F2.Aluminium tube
horizontal stabilizer.
K.
K. Pilot

HAWKER TYPHOON MK1B - Item code: BH132 . Instruction Manual
4
REPLACEMENT SMALL PARTS
 1. Install the rubber grommets and brass
eyelets onto the aileron servo.
INSTALLING THE AILERON SERVO.
I. SERVO
3. Wheels.
4. Tail gear set.
9.Spinner.
1.Air retract main gear.
11. Valve control.
15.Gun sets
2.Door mounting wheel.
6.AirTank.
14. Fuel Tank.
13.Air line set
7.PlywoodAir tank.
Bottom side.
Top side.
5A. Rockets (Right).
10.Valve one way.
8. 3 way connector.
12.Plastic parts of elevator and rudder
pushrod.
5B. Rockets (Left.)
A.
B.
15.
1.
2. 2.
4.
5.
9.
12.
3. 3
8.
11. 13.
14.
6.
7.
10. A. B.

5
HAWKER TYPHOON MK1B - Item code: BH132 . Instruction Manual
Secure.
Remove
covering.
2)Using a modeling knife, removethecov-
ering at possition show below.
3) Using the thread as a guide and using
masking tape, tape the servo lead to the end
of the thread: carefully pull the thread out.
When you have pulled the servo lead out, re-
move the masking tape and the servo lead
from the thread.
4)Drill 1,6mm pilot holes through the block
of wood for each of the four mounting screws
provided with the servo.
5. Instal servo tray with aileron servo into
the wing as same as picture below.
2x10mm.
Tray servo
Electric wire.

HAWKER TYPHOON MK1B - Item code: BH132 . Instruction Manual
6
Repeat the procedure for the other wing
half.
Secure.
Repeat the procedure for the other wing
half.
Aileroncontrolhorn
Aileron
control horn.
Installing the aileron linkages as pictures
below.
INSTALLING THE AILERON
LINKAGES.
secure.
Aileron
Installaileron control horn as same
aspicturebelow.
A+B Epoxy
PLUS glue
INSTALLINGTHEAILERON CONTROLHORN.
60mm
3x15mm

7
HAWKER TYPHOON MK1B - Item code: BH132 . Instruction Manual
II. FLAP
1.INSTALLING THE FLAP SERVO
Electric wire.
thread
2x10mm.
2.INSTALLING THE FLAP
CONTROL HORN.
ControlhornFlap.
secure.
A+B Epoxy
PLUS glue
Installflapcontrolhornassameas
picturebelow.
Flap
Servotray.

HAWKER TYPHOON MK1B - Item code: BH132 . Instruction Manual
8
Control horn
of the flap.
Repeat the procedure for the other wing
half.
4x12mm.
Installing the flap linkages as pictures
below.
Secure.
3.INSTALLING THE FLAP
LINKAGES.
60mm
3x15mm
Bottom side.
Secure.

9
HAWKER TYPHOON MK1B - Item code: BH132 . Instruction Manual
PARTSREQUIRED
INSTALLING AIR RETRACTABLE
LANDING GEAR.
3x15mm
3x15mm
5x40mm
hole 6mm
Drill a hole 6mm
diameter Secure.
3x 15 mm

HAWKER TYPHOON MK1B - Item code: BH132 . Instruction Manual
10
5x 40 mm
Secure.
Drill a hole
3mm

11
HAWKER TYPHOON MK1B - Item code: BH132 . Instruction Manual
Repeat the procedure for the other gear
half.
Bottom side.
INSTALLING THE AIR TANK
See pictures below:
Airtank
Secure.
Secure.
3x4mm
3x6mm
Secure.
Airtank

HAWKER TYPHOON MK1B - Item code: BH132 . Instruction Manual
12
Drill a hole
5mm diameter
Airtank
INSTALLING THE ENGINE MOUNT.
See pictures below:
C/Aglue
7.
5x70mm

13
HAWKER TYPHOON MK1B - Item code: BH132 . Instruction Manual
1. Install one adjustable metal connector
through the third hole out from the center of
one servo arm, enlarge the hole in the servo
arm using a 2mm drill bit to accommodate the
servo connector. Remove the excess mate-
rial from the arm.
After installing the adjustable metal con-
nector apply a small drop of thin C/A to
the bottom nut. This will prevent the con-
nector from loosening during flight.
INSTALLING THE THROTTLE - CABLE.
Secure.
Front view.
Throttle servo
Throttle servo.
Throttle cable.

HAWKER TYPHOON MK1B - Item code: BH132 . Instruction Manual
14
5) Test fit the stopper assembly into the
tank. It may be necessary to remove some of
the flashing around the tank opening using
amodeling knife. If flashing is present, make
sure none of it falls into the tank.
6) When satisfied with the alignment of
thestopperassemblytightenthe 3mmx 20mm
machine screw until the rubber stopper ex-
pandsand sealsthetank opening.Donot over
tighten the assembly as this could cause the
tank to split.
7) Using a modeling knife, cut 3 lengths of
fuel line 150mm long. Connect 2 lines to the 2
vent tubes and 1 line to the fuel pickup tube in
the stopper.
When the stopper assembly is installed in the
tank, the top of the vent tube should rest just
belowthe top surface of the tank. It should not
touch the top of the tank.
Throttle cable.
INSTALLING THE STOPPER ASSEMBLY
1) The stopper has been pre-assembled
at the factory.
2) Using a modeling knife, cut one length
ofsilicon fuel line (the length of silicon fuel line
iscalculatedbyhow theweighted clunkshould
restabout 8mm away from the rear of thetank
andmove freely inside the tank).Connectone
end of the line to the weighted clunk and the
otherend to the nylon pick up tube in the stop-
per.
3) Carefully bend the second nylon tube
up at a 45 degree angle (using a cigarette
lighter). This tube will be the vent tube to the
muffler.
4) Carefullybend thethird nylontubedown
ata 45degreeangle (usinga cigarette lighter).
This tubewill be venttubeto the fueling valve.
FUEL TANK.
Cut off the
excess cable.
Tygon gas tubing not included.
Vent tube Fuel pick- up tube
Fuelfill tube

15
HAWKER TYPHOON MK1B - Item code: BH132 . Instruction Manual
Secure.
9) To secure the fuel tank in place, apply a
bead of silicon sealer to the forward area of
thetank, where itexitsthe fuselage behindthe
enginemountingbox andto therear ofthetank
at the forward bulkhead.
Do not secure the tank into place perma-
nently until after balancing the airplane. You
may need to remove the tank to mount the
battery in the fuel tank compartment
8) Feed three lines through the fuel tank
compartment and through the pre-drilled hole
in the firewall. Pull the lines out from behind
the engine, while guiding the fuel tank into
place. Push the fuel tank as far forward as
possible,the frontofthe tank shouldjust about
touch the back of the firewall.
Blow through one of the lines to ensure the
fuel lines have not become kinked inside the
fueltank compartment.Airshouldflow through
easily.
Fueltank
Pushrod Choke.

HAWKER TYPHOON MK1B - Item code: BH132 . Instruction Manual
16
1. Slide the fiberglass cowl over the en-
gineand line uptheback edge ofthecowl with
the marks you made on the fuselage.
COWLING.
2. While keeping the back edge of the
cowl flush with the marks, align the front of
thecowlwiththe crankshaftof theengine. The
front of the cowl should be positioned so the
crankshaft is in nearly the middle of the cowl
opening. Hold the cowl firmly in place using
pieces of masking tape.
Bottom side
Top side
Left side. 3. Slide the cowl back over the engine
andsecure it in place using four woodscrews.
Right side
Pushrod
Choke.
Pushrod choke.

17
HAWKER TYPHOON MK1B - Item code: BH132 . Instruction Manual
Secure.
Drill a hole 2.5mm.
3x 12mm
4. Installthemufflerandmufflerextension
onto the engine and make the cutout in the
cowl for muffler clearance. Connect the fuel
and pressure lines to the carburetor, muffler
andfuel filler valve.
Lefft side.
Left side.
Front view
Rightside.
Machine screw.

HAWKER TYPHOON MK1B - Item code: BH132 . Instruction Manual
18
5x 50mm.Length 34mm.
secure.
INSTALLING THE SPINNER.
Installthe spinnerbackplate,propeller and
spinner cone. The spinner cone is held in
placeusing two 3mm x 8mmmachinescrews.
Aluminium 10mm
5x50mm.
Secure.

19
HAWKER TYPHOON MK1B - Item code: BH132 . Instruction Manual
HORIZONTAL STABILIZER.
Horizontal stabilizer installation
See picture below.
INSTALLING THE ELEVATOR
SERVOS.
1. Install the rubber grommets and brass
collets into the elevator servo. Test fit the
servo into the servo tray.
2. Mount the servo to the tray using the
mounting screws provided with your radio
system.
Elevator
servo
Elevator servo
9mm
295 mm
Aluminium
Push.
Bottom side.

HAWKER TYPHOON MK1B - Item code: BH132 . Instruction Manual
20
Elevator control horn install as same as the
way of aileron control horn. Please see pic-
tures below.
ELEVATOR CONTROL HORN
INSTALLATION.
A+B Epoxy
PLus glue
Left elevator
Right elevator
Secure.
Bottom side.
Secure
