Page 1Rev. 060518 DiscountRamps.com •1-888-651-3431
Deluxe Steel Motorcycle Carrier
Instructions for Part # SMC-600R
General Guidelines
• It is the user’s responsibility to read and follow all instructions.
• Keep these instructions with the product at all times and review before each use.
• It is the responsibility of this product’s owner to furnish the instructions to any person that borrows
or purchases the product.
• Inspect the product before use to ensure it is assembled properly and all parts are in safe working
order and free of defects.
• Never modify this product in any way.
• All circumstances cannot be addressed in these instructions. Please use common sense and
practice general safety measures when using this product.
• Parts and/or instructions are subject to change without notice.
Safety
• NOT recommended for tow-behind trailers including 5th wheel trailers and camping trailers
• Carrier Carrying Capacity: The SMC-600R carrier is designed to safely carry 600 lbs
• Never exceed the maximum tongue weight rating of your trailer hitch (check the weight sticker on
the trailer hitch)
• Total hauling weight is calculated by adding the total weight of the motorcycle + 99 lbs (SMC-600R
weight)
• Hitch Weight Limit: Most Class III hitches are rated for 500 lbs - Most Class IV hitches are rated for
1,000 lbs
• Some vehicles may require air shocks or heavier springs to sti󰀨en up the suspension to prevent
sagging
• Please check with the dealer or manufacturer to determine the carrying/hauling capacity of your
vehicle
• Will not work with 1-1/4" Class II or smaller receivers
• NOT recommended for use with hitch adapters/extensions
Page 2Rev. 060518 DiscountRamps.com •1-888-651-3431
Parts
Part Description Quantity
A 3-1/2" Pinch Bolt & 5/8" Sleeve 1
B 3" Bolt 4
C 3/4" Bolt 8
D 2" Bolt 4
E Lock Nuts for Bolts (C) & (D) 12
F Lock Nuts for Loop Bolts (J) 4
G Lock Nuts for Bolts (H) & (B) 10
H 1" Bolt 6
I 5/8" Sleeve 4
J Tie Down Loop Bolts 4
K Wing Nuts 2
Part Description Quantity
L 5/8" Hitch Pin 1
MFront Tire Stop 1
N Rear Cradle 1
O Carrier Frame 1
PTie Down Tubes 2
Q Loading Ramp 1
RMain Tube 1
SReverse Anti-Tilt 1
TCarrier Track 1
U Support Bracket 2
A B C
D
E
F
G
H
I
J
K
L M N
O P
Q R
S T U
Page 3Rev. 060518 DiscountRamps.com •1-888-651-3431
Assembly
Step 2. Slide the carrier frame (O) between
the support brackets (U) and secure using
the 2" bolts (D) and the small lock nuts (E).
Tighten ALL bolts including bolts from Step
1. Be careful not to overtighten.
Step 1. Place the main hitch tube (R) on a piece
of cardboard to protect the paint, then connect the
support brackets (U) to the hitch tube using eight
3/4" bolts (C) and lock nuts (E), keeping bolts loose.
Step 3. Slide the tie down tubes (P) into the carrier
frame (O). Then secure the carrier track (T) to the car-
rier frame using 3" bolts (B), sleeves (I), and lock nuts
(G) on each end. Note: Sleeves (I) are used to eliminate
extra play between the carrier frame and tie down tubes.
(1)
(2)
(3a)
(3b)
Note: Smaller holes face up;
larger holes face down
G
G
I
I
O
P
Tbottom view
B B
Page 4Rev. 060518 DiscountRamps.com •1-888-651-3431
Step 6. From here there are two methods for stabilizing the carrier. Both methods may be used, but
at least one is recommended.
1st Method - Using hitch pin (L) and reverse anti-tilt (S).
Slide the reverse anti-tilt (S) onto the main tube
(R) with the single bolt pointing toward the car-
rier track. Slide the carrier main tube (R) into
the trailer hitch, lining up the larger 5/8" hole in
the main tube with the hitch pin hole. Insert the
hitch pin (L) and install the hitch pin clip. Slide
the reverse anti-tilt bracket (S) forward toward
the vehicle hitch until it is ush against the hitch.
Tighten the four bolts on the anti-tilt bracket.
2nd Method - Using pinch bolt (A) and reverse anti-tilt bracket (S)
Slide the reverse anti-tilt (S) onto the
main tube (R) with the single bolt pointing
toward the carrier track. Slide the carrier
main tube (R) into the trailer hitch, lining
up the larger 1/2" hole in the main tube
with the hitch pin hole. Slide the 3-1/2"
pinch bolt (A) (with sleeve on bolt side of
bolt) through the trailer hitch hole. Install
the lock nut on the bolt and tighten. See
diagram.
Step 4. Next connect the front tire stop and
the rear cradle using six 1" bolts (H) and the
larger lock nuts (G) to secure it to the carrier
track.
Step 5. Connect the loading ramp (Q) to the tie
down tubes (P) by lining up the holes with the
welded bolts, then connect using the wing nuts
(K). Connect the loop bolts (J) to the end of
each tie down tube (P) using the lock nuts (F).
Slide the anti-tilt (S) onto the main tube (R).
(4)
(5)
(6a) (6b)
(6c)
Page 5Rev. 060518 DiscountRamps.com •1-888-651-3431
Product Warranty and Liability
GENERAL PRODUCT WARRANTY: Products purchased from the Authorized Dealer (original place
of purchase) or Merchant (“Dealer”) will be free of defects in material and workmanship at the time of
receipt, and will meet the specications stated at the place of purchase transaction or online at the
Dealer’s website, under normal use and service when correctly installed, operated and maintained.
This product warranty is e󰀨ective for the period of time stated below, unless otherwise stated in the
product instructions or depicted in the product advertisement. All Authorized Dealer warranties are
NON-TRANSFERABLE and cover only the original end purchaser. This limited warranty does not
cover products purchased through non-authorized dealers. Non-authorized dealer receipts are not
accepted for warranty verication.
***Warranty claims must be made directly to the original place of purchase.***
WARRANTY PERIOD: This warranty remains in force for one year from the date of the product’s
accepted delivery. The Authorized Dealer o󰀨ers a one year manufacturer’s warranty for most products
unless otherwise specied on the product advertisement.
WARRANTY SERVICE: The Authorized Dealer will replace any defective or malfunctioning part at
no charge, including payment of the shipping costs of parts or replacement product to and from the
manufacturer. The purchaser is responsible for labor charges. If the product does not meet specica-
tions as depicted in the advertisement, the Authorized Dealer will refund the full purchase price of the
product.
Questions regarding the warranty on a specic product and warranty claims should be directed to the
Authorized Dealer with whom the purchase transaction was made.
WARRANTY LIMITATIONS: The above warranty does not apply to products that are repaired, modi-
ed or altered by any party other than the Authorized Dealer; are subjected to unusual physical stress
or conditions (such as overloaded ramps or corrosion), natural disaster, governmental actions, wars,
strikes, labor disputes, riots, theft, vandalism, terrorism or any reason beyond reasonable control; are
damaged due to improper installation, misuse, abuse, accident or negligence in use, storage, trans-
portation or handling, or tampering; or to products that are considered consumable items or items
requiring repair or replacement due to normal wear and tear.
Product should be inspected prior to signing for delivery. Product damage incurred during shipping,
unless noted on the Bill of Lading at the time of delivery, renders this warranty void.
LIMITED LIABILITY: In no event shall THE AUTHORIZED DEALER be liable to the purchaser or any
third party for any indirect, incidental, consequential, special, exemplary or punitive damages arising
out of the use of the product, including, without limitation, property damage, loss of value of the prod-
uct or any third party products that are used in or with the product, or loss of use of the product or any
third party products that are used in or with the product.
