Racelogic Performance Box Touch V1 User manual

Performance Box Touch V1 – Speed Display Mode
https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/Performance_Box_Touch/
Performance_Box_Touch_V1/User_Guide_%E2%80%93_Performance_Box_Touch_V1/
04_Display_Modes_%E2%80%93_Performance_Box_Touch_V1/
Performance_Box_Touch_V1_%E2%80%93_Speed_Display_Mode
In Speed Display Mode, you can view live speed data,. You have 3 screens options available; Speed,
VMAX and Average Speed. You can access this mode by pressing the Mode Button at the bottom of the screen and
selecting Speed.
The unit will display the last used Speed Display Mode after each power cycle.
1

Speed Display Mode Overview
There are 3 different Speed Display screens and you can access them by using the Forward and Back arrows at the
bottom right of the screen or by swiping left or right on the screen.
Speed Display - Speed Screen
This is the default speed screen and it displays Live Speed data. If you have set a Target Speed in the Speed Settings,
this will be displayed in grey underneath the Live Speed.
If the vehicle is traveling less than 0.5 km/h or if the unit has lost its satellite lock (less than 4 sats), the value will display
as 000.0.
2

Speed Display - VMAX Screen
This screen displays the Absolute Top Speed reached until the Reset Button is pressed at the bottom of the screen.
If a Target Speed is selected within the Speed Settings, it will be displayed in grey underneath the VMAX.
Speed Display - Average Speed Screen
Formatted in two halves, the Average Speed screen displays both the Average Speed (since last boot up or power
cycle) and Distance Travelled (since last boot up or power cycle) on the same screen any time that movement is
detected. The average speed is displayed using either continuous or moving calculations.
The screen can be reset at any time by pressing the Reset Button at the bottom of the screen.
If you have selected a Target Speed in the Speed Settings, it will be displayed in grey underneath the Average Speed.
Speed Display Settings
You can access the Speed Display settings screen by selecting the Settings Button on the bottom left of the screen.
Here you can chose between speed display options.
3

To return to the main screen, select the Exit Button on the bottom left.
Decimal Places
You can adjust the number of decimal places displayed for speed values across all Speed displays, between 0,1
(default) and 2decimal places. Tap the button to cycle through the options.
Speed Display Smoothing
If required, live speed values displayed can be smoothed. Available options include 0.0 s,0.25 s (default),0.5 s and 1.0
sand refer to the amount of time that the displayed data is averaged by. Tap the buttons to change the smoothing
levels.
IMPORTANT
This option will smooth live speed displays within all relevant screen modes.
Notes:
•Smoothing only applies to the screen displays, not recorded data.
•It introduces a slight delay to the displayed value.
4

V Avg Mode
You can change whether the average speed on the Average Speed Screen is calculated as Continuous or Moving.
•Continuous: Average speed will start to calculate as soon as an SD card is inserted and initialised.
•Moving: Average speed will start to calculate as soon as a speed over 0.8 km/h is detected. calculations will stop
when the speed is less than 0.8 km/h.
Set a Target Speed
A Target Speed can be defined which will be displayed underneath the Speed value on the Speed
Screen, VMAX and Average Speed Screen.
You can choose whether to enable or disable an audible alert (continuous beep for 2 seconds) along with a visual alert
(all 4 LEDs will flash green) when the value is reached. Alerts will only show once unless the vehicle has been stationary
since the last alert.
Enabling one, or both of the alerts will set the target speed and also allow you to access the sub-menu where you
can define the target speed condition by pressing the value box and then using the keypad presented.
5

Target Speed Keypad Example
To save the value inputted, press the Confirm button at the bottom right of the screen, or press the Cancel
button at the bottom left of the screen to return to the Settings screen without saving. The value will be remembered
after each power cycle.
Note: You can enter speed with up to 1 decimal place.
Reset
Selecting the Reset Button on the bottom right of the screen will reset all results shown on the current screen. When
pressed, the LEDs will briefly flash green twice.
6
