Blade BM5000S User manual

Safety Precaution
CAUTION:
The lightning flash with
arrowhead symbol, within an
equilateral triangle, is intended
to alert the user to "dangerous
voltage" and to prevent from a
risk of electric shock.
Warning:
To reduce the risk of electric
shock, don't open the cabinet.
Refer servicing to qualified
personnel only.
The exclamation point within an
equilateral triangle is intended to
alert the user to important
operating and maintenance
(servicing).
WARNING: Do not use this STB where contact with / or immersion in water is a possibility. Do not use
near flower vases, washbowls, kitchen sinks, laundry tubs, swimming pools, etc.
WARNING: Do not put near naked flame; otherwise there is the danger of fire.
WARNING: The unit should be connected to a power supply only of the type described in the operating
instructions or as marked on the unit. If you are not sure of the type of power supply (for example, 120
or 230 V) to your home, consult your local dealer or local power company.
WARNING: This product installs diodes. Do not open the cabinet or touch any parts in the inner
mechanism. Consult your local dealer for technical service if the opening is required.
Note: To ensure proper use of this product, please read this User manual carefully and retain
for further reference.
Unit Cleaning: After the unit power is turned off, you can clean the cabinet, panel and remote control
with a soft cloth lightly moistened with a mild detergent solution.
Attachments: Never add any attachments and/or equipment without the manufacturer consent; as
such additions may result in the risk of fire, electric shock, or other personal injury.
Locating: Slots and openings in the cabinet are provided for ventilation to protect it from overheating.
Do not block these openings or allow them to be blocked by placing the STB on a bed, sofa, or other
similar surface, nor should it be placed over a radiator or heat register.
1

Power-Cord Protection: Place the power-supply cord out of the way, where it will not be walked on.
Please pay special attention to cords at plugs, convenience receptacles, and the point where they exit
from the unit.
Object and Liquid Entry: Never put objects of any kind into this STB through openings, as they may
touch dangerous voltage points or short-out parts that could result in a fire or electric shock. Never spill
any liquid on the STB.
Note: Moisture may be formed on internal items In the following conditions:
¾When the unit is suddenly moved from cold environment or an air-condition room to a warm place.
¾Immediately after a heater has been turned on.
¾In a steamy or very humid room.
If the moisture forms inside the unit, it may not operate properly. To correct this problem, turn on the
power and wait about two hours for the moisture to evaporate.
Parts Replacement: When the unit parts need to be replaced, user should make sure the service
technician use the replacement parts specified by the manufacturer or having the same characteristics
as the original part. Unauthorized replacement may put the unit In the risk of fire, electric shock or other
hazards.
Safety Check: After all the maintenances and repairs are done, user is required to request the service
technician to conduct the overall safety check to ensure the machine is In the proper condition.
Environment protection
ATTENTION !
Your product is marked with this symbol. It means that the used electrical and electronic products should
not be mixed with general household waste. There is a separate collection system for these products.
2

CONTENTS
SAFETY PRECAUTION....................................................................................1
ENVIRONMENT PROTECTION........................................................................2
1. FRONT PANEL.............................................................................................5
2. REAR PANEL................................................................................................5
3. CONNECTING YOUR SYSTEM ...................................................................6
4. REMOTE CONTROLLER .............................................................................7
5. BASIC OPERATIONS...................................................................................9
5.1 TURN ON STB.............................................................................................9
5.2 POWER.......................................................................................................9
5.3 CHANNEL UP/CHANNEL DOWN ....................................................................9
5.4 VOLUME UP/VOLUME DOWN........................................................................9
5.5 NUMBER.....................................................................................................9
5.6 MUTE .........................................................................................................9
5.7 PAUSE........................................................................................................9
5.8 RECALL ......................................................................................................9
5.9 FAVORITE...................................................................................................9
5.10 AUDIO ....................................................................................................10
5.11 INFORMATION .........................................................................................10
5.12 EPG ......................................................................................................10
5.13 TV/RADIO.............................................................................................11
5.14 CHANNEL LIST ........................................................................................11
5.15 PAGE UP/PAGE DOWN............................................................................11
5.16 TELETEXT...............................................................................................11
5.17 SUBTITLE................................................................................................12
5.18 FIND.......................................................................................................12
5.19 PIP (PICTURE IN PICTURE).......................................................................13
5.20 ZOOM.....................................................................................................15
5.21 MENU.....................................................................................................15
5.22 EXIT.......................................................................................................15
5.23 OK.........................................................................................................15
6. CHANNEL ...................................................................................................16
3

7. INSTALLATION...........................................................................................19
8. MULTIMEDIA ..............................................................................................23
9. SETUP.........................................................................................................27
10. OTHERS....................................................................................................34
11. SPECIFICATIONS.....................................................................................38
4
