Blanco BOSE 635AX Instruction Manual

GUIDE TO INS T ALL A TION
Oven
BOSE 635AX

EN
2
Dear Customer,
Thank you for buying a BLANCO oven.
Before we continue telling youabout this oven, we cordially invite you to
become part of the Blanco family bysubscribingonline. Please visit our website
where youcan easily subscribe and request suchthings as ‘invitations to future
cooking
classes’ and gourmet recipes. Goto www.blanco-australia.com andfill
in the subscriptiondetails.
You will find that the clean lines and modern look of your Blanco oven blends in
perfectly with yourkitchendécor.It is easy to useand performs to a high
standard.
Blanco also makes a range of products that will enhance yourkitchensuchas
cooktops,
rangehoods, dishwashers and microwaves, sinksand taps. There are
models to complement your new Blanco oven.
Of
course, we make every effort to ensure that our products meet all your
requirements, andour Customer Relations department is at your disposal, to
answer all your questions andto listento all your suggestions.
Please complete the warranty card and keep yourreceipt asproof of purchase.
Retain all documents relating to the purchase of this product.
Blanco is committed to providing increasingly efficientproductsthat are easy to
use.
BLANCO

3
EN
1
/ SAFETY INSTRUCTIONS 04
• Packaging 07
2
/ INSTALLING YOUR APPLIANCE
• Choice of location 08
• Build-in 09
• Electrical connection 10
3
/ DESCRIPTION OF YOUR APPLIANCE
• Presentation of the oven 12
• Presentation of the programmer 13
• Accessories 14
4 / USING YOUR APPLIANCE
• Using theprogrammer
17
º
Setting the time
17
º
Instant cooking
18
• Programmed cooking
19
• Using the time switch function
21
• Using the Booster function
21
• Display brightness
22
• Locking the display
22
5 / OVEN COOKING MODES
23
6 / CARING FOR AND CLEANING YOUR APPLIANCE
• Cleaning the outer surfaces
26
• Cleaning the door
26
• What is pyrolysis?
28
• In what situations should pyrolysis beused?
28
• Instant pyrolytic cleaning
29
• Delayed pyrolytic cleaning
30
• Replacing the oven lamp
31
7 / TROUBLESHOOTING 32
8 / “AUTO COOK” PRINCIPLE AND ADVANTAGES 33
9 / “AUTO COOK” COOKING MODES 36
TIPS AND HINTS 38
RECIPES 39

4
EN 1 / SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS - READ CAREFULLY AND
RETAIN FOR FUTURE USE.
Important
When you receive the appliance, unpack it or have it
unpacked immediately. Give it an overall inspection. Make
note of any concerns or reservations on the delivery slip and
make sure to keep a copy of this form. Keep this user guide with
your appliance. If the appliance is ever sold or transferred to
another person, ensure that the new owner receives the user
guide. Please become familiar with these recommendations
before installing and using your oven. They were written for your
safetyandthe safetyof others.
WARNING:
— The Appliance is not intended for use by persons (including
Children) with reduced physical,sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given
supervised instruction concerning use of the appliance by a
responsibleperson for their safety.
Cleaning and maintenance
operations mus t not be carried out by children without
supervision.
— Children must be supervised to prevent them from playing with
theappliance.
WARNING:
— The applianceand the accessible parts of it will become hot
during
use. Be careful not to touch the heated elements. Children
must not be allowed to touch the appliance, unless they are
supervised continually.
Use
— Before using your oven for the first time, heat it while empty for
approximately 15 minutes. You should ensure you heat each
element in the oven before use. Make sure that the room is
sufficiently ventilated. You may notice a particular odour, or a small
release of smoke. All of this is normal.
— Your appliance is intended for standard household use. Do not

5
1 / SAFETY INSTRUCTIONS EN
use it for commercial or industrial purposes or for any other purpose
than that for which it was designed.
— This ovenwas designed for use by private individuals in their
homes. It is intended solely for cooking foodstuffs. This oven does
not
contain any asbestos-based components.
— Do not modifyor attempt to modify any of the characteristics of
this
appliance. This would be dangerous to yoursafety.
— Never pullyour appliance bythe door handle.
— When placing dishes inside or removing them from the oven, do
not
place your hands close to the upper heating elements and use
heat-protective kitchen gloves.
— At the end of cooking,do not pick up oven or grill items (grid, r o -
tisserie,...) with your bare hands.
— Never place aluminium foil directly in contact with the floor of the
oven (see the chapter on oven description), as accumulated heat
may cause deterioration of the enamel.
— Do not place heavy weights on the open oven door, and make
sure that children are able neither to climbnor sit onit.
— Donot use your oven as a larder or to store any items afteruse.
— After using your oven, make surethat all the controls are in their
stop position.
— In addition to the accessories supplied with your oven, only use
dishes capable of withstanding high temperatures (follow the ma-
nufacturer’s instructions).
Cleaning bypyrolysis
— Before beginning a pyrolysis cleaning cycle in your oven, remove
all parts of your grids, trays and accessoriesand remove major
spillresidue.
— During cleaning, the surfaces may become warmer than under
normal conditions of use. It is
advisable to keep small children
away fromthe appliance.
Maintenance andcleaning
— Donot use a steam cleaner .
— For any cleaning operation inside the oven cavity, the oven must
be
switched off.
— Before unclipping the glass, allow the appliance to cool.

6
EN 1 / SAFETY INSTRUCTIONS
— Before removing the back, ensure that the appliance is powered
down. After
cleaning, the back should be replaced in accordance
with theinstructions.
— Do not use abrasive cleaning products or hard metal scrapers
for cleaning the oven's glass door, as they could scratch the
surface and cause the glass to shatter.
— To cleanboth the electronic programmer window and the oven
door,
use a window washing product applied to asoft cloth.
— Donot use abrasive creams or scouringsponges.
Warning:
Make sure the appliance is disconnected from the power
before replacing the lamp in order to avoid the risk of electric
shock. Change the lamp only when the appliance has cooled
down. To unscrew the view port and the light, use a rubber
glove,whichwill
make disassembly easier.
Warning :
Installation should only be performed by qualified installers
andtechnicians.
Warning :
The electrical plug must remain accessible after
installation.
It must be possible to disconnect the appliance from the power
supply, either using a plug or by fitting a switch on the fixed
wiring
system in accordance with installation rules.
If the power cable is damaged, it should be replaced by the
manufacturer, its after-sales service department or by a similarly
qualified person in order to avoid danger.

7
1 / SAFETY INSTRUCTIONS EN
•
PACKAGING
other waste.
— This appliance’s packing materials are
recyclable. Recycle them by depositing them in
local authority containersprovided for this
purpose.
— Your appliance also contains many recyclable
materials. It is therefore marked with this logo to
indicate that used appliances must not be mixed with

8
EN 2 / INSTALLING YOUR APPLIANCE
•
CHOICE OF LOCATION
The above diagrams show the dimensions of a cabinet that will be
able to hold youroven.
This appliancemay be installed either under a worktop or in a
cabinet column, as indicated on the installation diagram.If the
cabinet is open, its opening mustbe 70 mmmaximum.
Your oven has optimised air circulation that allows it to achieve
remarkable cooking and cleaning results if the f o llowing
guidelines are followed:
— Centre the oven in the unit so as to ensure a minimum distance
of 10 mm between the appliance and the surrounding unit.
The material of the unit supporting the appliance must be heat-re-
sistant (or covered with a heat-resistant material). For greater sta-
bility, attach the ovento the unit with 2 screws through the holes
provided on theside panels (fig.1).

9
2 / INSTALLING YOUR APPLIANCE EN
•
BUILD-IN
1) Drill a hole Ø 2 mm in the cabinet panel to avoid splitting the
wood.
2) Attachthe oven withthe2screws.
Tip
To be certain that you have properly installed your
appliance, do not hesitate to call on a household
appliance specialist.

1

10
EN 2 / INSTALLING YOUR APPLIANCE
PYROLYSIS OVENS:
220-240V
~ Single
phase line
Sing le phase 20A Meter
220-240V~ 50Hz
16A fuse or differential
circuit breaker
Minimum cord size: 3G 1.5mm2
P ower
supply cable
length 1.50 m approx.
•
ELECTRICAL CONNECTION
The appliance must be fitted correctly to
guarantee electrical
safety.
The electrical connections are made before the appliance is
installed in its housing.
Ensure that:
- the electrical installation has sufficient voltage,
- the electrical wires are ingood condition,
- t he diameter of the wires com plies with the installation
requirements.
During
maint e nance operations, the appliance mus t be
unplugged from the electrical grid. Fuses must be switched off or
removed.

11
2 / INSTALLING YOUR APPLIANCE EN
Warning :
If the electrical installation in your residence requires any
changes in order to hook up your appliance, contact a
professionalelectrician.
If the oven malfunctions in any way, unplug the appliance or
remove the fuse corresponding to the sector where the oven is
hookedup.

12
EN 3
/ DESCRIPTION OF YOUR APPLIANCE
• PRESENTATION OF THE OVEN
B C E F G
A D
O H
N I
M
L
K
J
A
Cooking mode button
B
“AUTO COOK” button
C
Temperature button
D
Pyro and Pyro ECO button
E
Programmer
F
“ + ” adjustment button
G
Confirm button
H
STOP button
I
“ - ” adjustment button
J
Level indicator
K
Oven light
L
“Time set” button
M
“Time switch”button
N “Endof cooking” button
O “Cookingtime” button
Tip
This installation and user manual applies to several different models. There may be
slight differences between your model and the one described as regards details and
accessories.

13
3 / DESCRIPTION OF YOUR APPLIANCE EN
• PRESENTATION OF THE PROGRAMMER
M
N
A
B C
D E
F
L
K J
I
H
G
A
B
C
D
E
F
G
Time and cooking timedisplay
Timer indicator
Cooking mode indicator
Shelf support indicator
AUTO COOK indicator
AUTO COOK plates indicator
Temperature riseindicator
H
I
J
K
L
M
N
Lockeddoorindicator
Temperature display
ECO indicator (cooking and pyrolysis)
Pyrolysis indicator
BOOSTER indicator
End of cooking display
Cooking timedisplay

14
EN
3 DESCRIPTION OF YOUR
Warning
Before starting a pyrolysis cleaning cycle, makesure that
any accessories that are not pyrolysis safe
have been removed
from the oven (sliding rails, baking trays, chrome-plated grills,
and so on) as well as any cookware. The side grills are
pyrolysis safeand
may be left inside the oven during pyrolysis.
•
Anti-tipping safetygrid (fig.1)
The grid can be used to hold all
dishes and moulds containing
foodstuffs to be cooked or
browned.
Front
Rear
fig.1
•
Bakingsheet (fig.2)
This lissium baking sheet
features a food-grade non-stick
sur face and is designed
especially f o r y o ur pas t ry
creations, par ticularly light
pas t ries. Y o u can set y o ur
choux and puf f pas t ries,
meringues, madeleines and
other
delights directly on it.
Front
Rear
fig.2
N.B.: The bakingsheetshould
never be used to hold baking
dishes or cake moulds.
The lissium baking sheet can-
not be
used with the telescopic
runners.

15
3 DESCRIPTION OF YOUR
EN
• 45mm multi-purpose tray wi-
th special grid for grilling.
Fully accessible telescopic
runners system (fig.3)
The telescopic runners system
with support (fully
accessible)
makes food more practical and
easier to handle as the trays
can be
ef fortlessly pulled f o r
simpler handling. The trays can
be completely removed, provi-
ding full
access. Their stability
ensures that food can be hand-
led safely, reducing the risk of
burns. This means that you can
take food out of the oven far
more easily. Please note: 45mm
enameled baking tray must only
be used in conjunction with the
telescopic runners. Take care
to locate the tray correctly on
the telescopic runner before
using theoven.
FRONT
REAR
fig.3

16
EN
3 DESCRIPTION OF YOUR
•Turnspit (fig.4)
REAR
Pass the spit through the joint
to be
roasted, thread on the se-
cond fork, centre the joint and
screwthe forks tight.
Place the spit in its cradle: the
cradle should be placed in the
deep enamel dish.
Slide the cradle on to shelf sup-
port 3, push gently to engage
the end of the spit into the
square drive at the back of the
oven (fig.5).
Unscrew and remove the hand-
le, so that the door can close.
At the end of cooking, screw
the
handle back on to the spit,
so that y o u can remove the
joint without burning yourself
(fig. 6).
FRONT
fig.4
fig.5
fig.6
N.B.: should you wish to roast a large piece of meat(up to 2kg), you
can place the dish on the bottom shelf support and insert the crad-
lein shelf support 3, to prevent the meat from touching the back of
thedish
and stopping thespit from turning.

17
EN
4 USING OF YOUR
•
Setting the time
- When the appliance is startedup :
12:00 will flash on the display (fig.1).
fig.1
Adjust the time by pressing the + or – adjustment buttons (if you hold them down, the time will
count up quickly).
Example : 12:30h
fig.2
Confirm by pressing the START button (fig.2).
The display willstop flashing.
- Toset the clock to the correct time:
Press the ‘Time set’ button. This button will remain lit up duringadjustment.
The timewill flash on the display to show thatthe timecannowbeset.
Set thetimeby pressing the + or – adjustment buttons to set the time forward or backward (fig.1).
fig.1
Confirm by pressing the START button (fig.2).
fig.2
Important
If you do not confirm the selected time by pressing the START button, it will be registered
automaticallyafter a fewseconds
have elapsed.

18
EN
4 USING OF YOUR
• Instant cooking
— Theprogrammer should only show the time, which should not beflashing.
Select the cooking mode by pressing the ‘COOKING’ button and thenthe + or - button.
Example : “White meat” setting (fig.1). The button will remain lit up duringthe settingprocess.
Confirm by pressing the “START” button.
fig.1
The selected cooking mode will then appear on the display, and the elements set to function will
light up (bottom
element, grill, rotary heat, etc.)together with the set temperature -> the oven will
start up
and the temperature indicatorwill appear on thedisplay.
Place yourdishinthe oven according to the setting shown on the display.
Example : “White meat” setting
-> level 2is recommended.
The oven will suggest the temperature most commonly used for this typeof cooking.
However, you may adjust the temperature if you wish by pressing the “TEMPERATURE” button
and then the + or – buttons to obtain the desired temperature. The “TEMPERATURE” button
remains lit up duringthe settingprocess.
Example : “White meat” setting, set to 190º (fig.2).
fig.2
After this
has been done, the oven willstart to heat up :
These rising thermometers shown thatthe temperature inside the oven is increasing.
A series of beeps willsound when the oven reaches the selected temperature.
Depending on the model,the adjusted temperature setting and the temperature insidethe oven
may appear.
Important
After a cooking cycle,the cooling turbine continuesto function for a while.
Important
The door must always be closed for cooking.
Important
Donot hang any cloths or teatowels on the door handle.

19
4 USING OF YOUR
EN
•
PROGRAMMED COOKING
- Cooking with instant start and programmed cooking time
- Select the desired cooking mode and adjustthe temperature (fig.1).
Example : “White meat” setting.
Temperature 200ºC
fig.1
- Press the “Cookingtime” button (fig.2).
A
duration of 0:00h will flash on the display to indicate that adjustment cannowbemade.
- Press the + or - button to setthe desired time.
Example : 30 minutes cooking.
The “Cookingtime”button will remain lit up duringthe setting process.
fig.2
The cooking time will be registered
automatically after a few seconds, or you can press the
“Start” button to confirm. Thedisplay willstop flashing.
Thecountdown starts immediately afteradjustment.
The endof cooking time(starttime + cooking duration) appears automatically on the display.
Inthis
case : endof cooking timeat 13:00.
After these 3 adjustments, the oven willstart heating up :
The temperature on thermometer willstart to rise.
A series of beeps willsound when the oven reaches the selected temperature.
At theendof cooking
(end of timeprogrammed),
- the oven switches off,
- 0:00 flashes on the display (fig.4).
- a series of beeps sound for several minutes.Thesebeeps can be stopped by pressing the
“STOP” button.
