Blanco BOSE6APX Instruction Manual

GUIDE TO INS T ALL A TION
Oven
BOSE6APX

EN
2
Dear Customer,
Thank youfor buying a BLANCO oven.
Before we continue telling you about this oven, we cordially invite you to
become part of the Blanco family by subscribing online. Please visit our
website where youcan easily subscribe and request such things as
‘invitations to future cooking classes’ and gourmet recipes. Goto
www.blanco-australia.com andfill in the subscriptiondetails.
You will find that the clean lines and modern look of yourBlanco oven
blends in perfectly with yourkitchendécor.It is easy to useand performs to
a high standard.
Blanco also makes a range of products that will enhance yourkitchensuch
ascooktops, rangehoods, dishwashers and microwaves, sinksandtaps.
There are models to complement your new Blanco oven.
Of
course, we make every effort to ensure that our products meet all your
requirements, andour Customer Relations department is at your disposal, to
answer all your questions andto listento all your suggestions.
Please complete the warranty card and keep yourreceipt asproof of
purchase. Retain all documents relating to the purchase of this product.
Blanco is committed to providing increasingly efficientproducts that areeasy
to use.
BLANCO

3
EN
1 / SAFETY INSTRUCTIONS
• Packaging 04
• Child safety 07
2
/ INSTALLING YOUR APPLIANCE
• Choice of location 08
• Build-in 09
• Electrical connection 10
3
/ DESCRIPTION OF YOUR APPLIANCE
• Presentation of the oven 12
• Presentation of the programmer 13
• Accessories 14
4 / USING OF YOUR APPLIANCE
• Using the programmer
16
º
Setting the time
16
º
Instant cooking
17
• Programmed cooking
18
• Using the time switch function
20
• Using the “GRILL PLUS” function
21
• Economic cooking
22
• Adjusting the display brightness
22
5 / OVEN COOKING MODES
23
6
/ CARING FOR AND CLEANING YOUR APPLIANCE
• Cleaning the outer surfaces
25
• Cleaning the door
25
• What is pyrolysis?
27
• In what situations should pyrolysis beused?
27
• Instant pyrolytic cleaning
28
• Delayed pyrolytic cleaning
29
• Replacing the oven lamp
30
7 / TROUBLESHOOTING
31
8 / “AUTO COOK” PRINCIPLE AND ADVANTAGES
32
9 / “AUTO COOK” COOKING MODES
34
TIPS AND HINTS
35
RECIPES
36

4
EN
1 SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS - READ CAREFULLY AND
RETAIN FOR FUTURE USE.
Important
When you receive the appliance, unpack it or have it
unpacked immediately. Give it an overall inspection. Make note
of any concerns or reservations on the delivery slip and make
sure to keep a copy of this form. Keep this user guide with your
appliance. If the appliance is ever sold or transferred to another
person, ensure that the new owner receives the user guide.
Please become familiar with these recommendations before
installing and using your oven. They were written for your safety
andthe safetyof others.
WARNING:
— The Appliance is not intended for use by persons (including
Children) with reduced physical,sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given
supervised instruction concerning use of the appliance by a
responsibleperson for their safety. Cleaning and maintenance
operations mus t not be carried out by children without
supervision.
— Children must be supervised to prevent them from playing with
theappliance.
WARNING:
— The applianceand the accessible parts of it will become hot
during use. Be careful not to touch the heated elements. Children
must not be allowed to touch the appliance, unless they are
supervised continually.
Use
— Before using your oven for the first time, heat it while empty f o r
approximately 15 minutes. You should ensure you heat each
element in the oven before use. Make sure thatthe roomis
sufficiently ventilated. You may noticea particular odour, or a
small release of smoke. All of this is normal.
— Your appliance is intended for standard household use. Do not
use it for commercial or industrial purposes or for any other
purpose than that for whichit was designed.

5
1 SAFETY INSTRUCTIONS
EN
— This oven was designed for use by private individuals in their
homes. It is intended solely for cooking foodstuffs. This oven does
not contain any asbestos-based components.
— Do not modify or attempt to modify any of the characteristics of
this appliance. This would be dangerous to yoursafety.
— Never pullyour appliance bythe door handle.
— When placing dishes inside or removing them from the oven, do
not place your hands close to the upper heating elements and use
heat-protective kitchen gloves.
— At the end of cooking, do not pick up oven or grill items (grid, r o -
tisserie,...) with your bare hands.
— Never place aluminium foil directly in contact with the floor of the
oven (see the chapter on oven description), as accumulated heat
may cause deterioration of the enamel.
— Do not place heavy weights on the open oven door, and make
sure that children are able neither to climbnor sit on it.
— Donot use your oven as a larder or to store any items afteruse.
— After usingyour oven, make surethat all the controls are in their
stop position.
— In addition to the accessories supplied with your oven, only use
dishes capable of withstanding high temperatures (follow the ma-
nufacturer’s instructions).
Cleaning bypyrolysis
— Before beginning a pyrolysis cleaning cycle in your oven, remove
all parts of your grids, trays and accessories and remove major
spillresidue.
— During cleaning, the surfaces may become warmer than under
normal conditions of use. It is advisable to keep small children
away fromthe appliance.
Maintenance andcleaning
— Donot use a steam cleaner .
— For any cleaning operation inside the oven cavity, the oven must
be switched off.
— Before unclipping the glass, allow the appliance to cool.
— Before removing the back, ensure that the appliance is powered
down. After cleaning, the back should be replaced in accordance
with the instructions.

6
EN 1 / SAFETY INSTRUCTIONS
— Do not use abrasive cleaning products or hard metal scrapers
for cleaning the oven's glass door, as they could scratch the
surface and cause the glass to shatter.
— To clean both the electronic programmer window and theoven
door, use asoft cloth.
— Donot use cleaning products, abrasive creams or scouring
sponges.
Warning:
Make sure the appliance is disconnected from the power
before replacing the lamp in order to avoid the risk of electric
shock. Change the lamp only when the appliance has cooled
down. To unscrew the view port and the light, use a rubber
glove,whichwill make disassembly easier.
Warning :
Installation should only be performed by qualified installers
andtechnicians.
Warning :
The electrical plug must remain accessible after installation.
It must be possible to disconnect the appliance from the power
supply, either using a plug or by fitting a switch on the fixed
wiring system in accordance with installation rules.
If the power cable is damaged, it should be replaced by the
manufacturer, its after-sales service department or by a similarly
qualified person in order to avoid danger.

7
1 / SAFETY INSTRUCTIONS EN
•
PACKAGING
— This appliance’s packing materials are
recyclable. Recycle them by depositing them in
local authority containersprovided for this
purpose.
— Your appliance also contains man y
recy clable mat e rials. It is theref o re mark ed
with this logo to indicate that used appliances
must not be mixed with other waste.
•
CHILD SAFETY (depending on model)
•
SAFETY ACTIVATION
- Open the door.
- Locate the small lug/switch and gently press
downward.
- Close the oven door and door willbelocked.
•
OPEN WITH SAFETY ENGAGED
Press the lever (gently)1 position to the right
to releasethe door. This means that next time
you close the door it will lock again. This is
provided the lug/switch is stillin the downward
position(fig.2).
•
SAFETY DEACTIVATION
- Open the door and move the lug/switch to
the right until it clicks and the lug releases
(fig.3).
fig.1
fig.2
fig.3

8
EN 2 / INSTALLING YOUR APPLIANCE
•
CHOICE OF LOCATION
The above diagrams show the dimensions of a cabinet that will be
able to hold youroven.
This appliancemay be installed either under a worktop or in a
cabinet column, as indicated on the installation diagram.If the
cabinet is open, its opening mustbe 70 mmmaximum.
Your oven has optimised air circulation that allows it to achieve
remarkable cooking and cleaning results if the f o llowing
guidelines are followed:
— Centre the oven in the unit so as to ensure a minimum distance
of 10 mm between the appliance and the surrounding unit.
The material of the unit supporting the appliance must be heat-re-
sistant (or covered with a heat-resistant material). For greater sta-
bility, attach the ovento the unit with 2 screws through the holes
provided on theside panels (fig.1).

9
2 / INSTALLING YOUR APPLIANCE
EN
•
BUILD-IN
1) Drill a hole Ø 2 mm in the cabinet panel to avoid splitting the
wood.
2) Attachthe oven withthe2screws.
Tip
To be certain that you have properly installed your
appliance, do not hesitate to call on a household
appliance specialist.

1
0

10
EN 2 / INSTALLING YOUR APPLIANCE
PYROLYSIS OVENS:
220-240V
~ Single
phase line
Sing le phase 20A Meter
220-240V~ 50Hz
16A fuse or differential
circuit breaker
Minimum cord size: 3G 1.5mm2
P ower
supply cable
length 1.50 m approx.
•
ELECTRICAL CONNECTION
The appliance must be fitted correctly to
guarantee electrical
safety.
The electrical connections are made before the appliance is
installed in its housing.
Ensure that:
- the electrical installation has sufficient voltage,
- the electrical wires are ingood condition,
- t he diameter of the wires com plies with the installation
requirements.
During
maint e nance operations, the appliance mus t be
unplugged from the electrical grid. Fuses must be switched off or
removed.

11
2 / INSTALLING YOUR APPLIANCE EN
Warning :
If the electrical installation in your residence requires any
changes in order to hook up your appliance, contact a
professional electrician.
If the oven malfunctions in any way, unplug the appliance or
remove the fuse corresponding to the sector where the oven is
hookedup.

12
EN 3
/ DESCRIPTION OF YOUR APPLIANCE
•
PRESENTATION OF THE OVEN
A
B
C
D
E
A Programmer
B
Temperature selector
C
Function selector
D Lamp
E
Shelf support indicator
Tip
This installation and user manual applies to several different models. There may be
slight differences between your model and the one described as regards details and
accessories.

13
3 / DESCRIPTION OF YOUR APPLIANCE EN
• PRESENTATION OF THE PROGRAMMER
A B C D
P
ON
M
L K J I H G F E
A
Temperature display
B
ECOindicator (cooking and self-cleaning)
C
Time and duration display
D
Shelf number indicator
E
EASY COOK function button
F
Grill and Button
G
EASY COOK menu
H
EASY COOK indicator
I
Touch controls for setting time
J
Timer touch control
K
Cooking endtimetouch control
L
Cooking time touch control
M
Cooking end time indicator
N Doorlockedindicator
O Cooking timeindicator
P
Self-cleaning indicator

14
EN
3 DESCRIPTION OF YOUR
•
Anti-tippingsafetygrid (fig.1)
Thegrid can be used to hold all dishes and
moulds containing foodstuffs to be cooked or
browned.
It can be usedfor barbecues (to be placed di-
rectlyon the grid).
Front
Rear
fig.1
•
Baking Tray "Deep" (fig.2)
Never place this dish directly on the baseof
theoven.
•
Bakingsheet(fig.)
It serves as a cake dish and has a sloped edge.
It is used for cooking pastries such as cream
puffs, meringues, madeleines, puff pastry, etc.
Rear
fig.2
•
Hollow dish fitted with a special
barbecuesupport grid (fig.4)
It is used to collect juices and greasefrom
cooking with the highgrill or the pulsed grill.
It can be used as a cooking dish when
suitable for the size of the item to be cooked
(e.g. whole poultry surrounded with
vegetables, at moderate temperature).
Never place this dish directly on the base,
except in GRILL position.
Front fig.3
fig.4
•
Handle for deepdishes(fig.5)
fig.5
N.B.: The baking sheet should never be used to hold baking dishes or cake moulds.
Thelissium baking sheet cannot be used with the telescopic runners.

15
3 DESCRIPTION OF YOUR
EN
•Turnspit (fig.6)
Pass the spit through the joint to be roasted,
thread on the second fork, centre the joint
and screwthe forks tight.
Place the spit in its cradle: the cradle should
be placed in the deep enamel dish.
Slide the cradle on to shelf support 3, push
gently to engage the end of the spit into the
square drive atthe back of the oven (fig.7).
FRONT
REAR
fig.6
fig.7
Unscrew and remove the handle, so that the
door can close. At the end of cooking, screw
the handle back on to the spit, so that you
can remove thejoint without burning yourself
(fig. 8).
fig.8
N.B.: should you wish to roast a large piece of meat(up to 2kg), you can place the dish on the bot-
tom shelf support and insert the cradle in shelf support 3, to prevent the meat from touching the
backof thedish and stopping thespit from turning.

16
EN
4 USING OF YOUR
•
USING THE PROGRAMMER
•
Setting the time.
- When the poweris on
The display flashes 12:00. (fig.1)
Set the time by pressing the
+ or - buttons
(continued pressure on the button runs
throughthe numbers quickly) (fig.2).
Example: 12: 30
The adjusted time is
automatically recorded
aftera fewseconds.
The display stops flashing.
•
How to change the time.
- Toset the clock to the correct time.
The function selector must be in position 0
(fig. 1).
Press buttons “ ”and at the same
time for a few seconds (fig.2), then release
them when the time of day begins to flash.
The sound of beeping shows that you can
set it now.
Adjust the time setting using the
+ or -
buttons (fig.3).
The adjusted time is
automatically recorded
aftera fewseconds.
fig.1
fig.2
fig.1
fig.2
fig.3
Important
If you do not confirm the selected time , it will be registered automatically after a few
seconds haveelapsed.

17
4 USING OF YOUR
EN
•Instant cooking
— The programmer should only show the time
wich should not be flashing.(fig 1).
fig.1
Select the cooking mode by turning the func-
tion selector to the positionof yourchoice.
Example: position (fig.2).
The oven will suggest the temperature most
commonly used for this typeof cooking.
You can also adjust the temperature by mov-
ing the temperature selection knob to + or -
(fig.3)
Example: temperature reference 210°C (fig.4).
After this
has been done, the oven will starts to
heat up:
These rising thermometers shown that the
temperature inside the oven is increasing.
A series of beeps will sound when the oven
reaches the selected temperature.
fig.2
fig.3
fig.4
Important
After a cooking cycle, the cooling turbine continues to function for a while.
Important
The door must always be closed for cooking.
Important
Donot hang any cloths or teatowels on the door handle.

18
EN
4 USING OF YOUR
• PROGRAMMED COOKING
- Select the cooking mode desiredand adjust
the temperature (fig.1).
- Press the“” butto n
“ untilthe cookingtime
indicatorstarts to flash.
fig.1
The display flashes 0:00 to tell you that you can
nowset it (fig.2).
- Press the + or - buttonto setthe desired time.
Example: 30 mincooking ( f i g . 3 ).
The cooking time will be registeredautomati-
cally afterafewseconds.
The countdown starts immediately after ad-
justement.
The end of cooking time (start time + cooking
duration) appears automatically on thedisplay.
The temperature on the thermometer will start
to rise.
A series of beeps will sound whenthe oven
reaches the selected temperature.
At the end of cooking (end of time
programmed ),
- the oven switches off,
- 0:00 flashes on the display ( fig. 4 ).
- A series of beeps is emitted for a few
minutes. Press any button to stop the
beeping.
fig.2
fig.3
fig.4
The display goes back to showing the time of
dayby moving the function selector back to 0
(fig.5).
fig.5

19
EN
4 USING OF YOUR
•
PROGRAMMED COOKING
- Cooking with delayed start and selected
endof cooking time
- After adjusting the cooking time,press the
«delayedstart» button; Theend of cooking time
display will flash to indicate thatadjustement
can now be made .
-Press the + or - buttonsto set the desired end
of cooking time.
Example: End of cooking at 13h (fig.1)
The «end of cooking» button will remain it up
during the setting process.
Theend of cooking time will automatically be
registered after a few seconds.
At the end of cooking (end of time
programmed),
- the oven switches off,
- 0:00 flashes on the display (fig.3).
- A series of beeps sound for several
minutes. These beeps can be stopped by
pressing any button.
The display goesbackto showing the time of
day by moving the function selector back to
0(fig.4).
fig.1
fig.2
fig.3
fig.4
