Blaupunkt RCM 104 User manual

1
Paris RCM 104
DEUTSCH
ENGLISH
ITALIANO
PORTUGUES NEDERLAND
ESPAGÑOL SVENSKA FRANÇAIS
Operating instructions
RCM 104

3
Paris RCM 104
ENGLISH
ITALIANO
PORTUGUES NEDERLAND
ESPAGÑOL SVENSKA FRANÇAIS
1
32
1625
45
24
12
111096
23
22
21
20
19 18 17 15 14 13
87

Paris RCM 104
20
Contents
Short description.......................... 21
Important notes ............................ 25
What you must know!............................ 25
Traffic safety ......................................... 25
Installation/connection ....................... 25
Optical indication of theft protection ...... 25
KeyCard ................................................ 25
Replacing a KeyCard......................... 26
Radio operation with RDS
(Radio Data System) ...................... 26
AF - alternative frequency..................... 26
REG - Regional ..................................... 26
Selecting the waveband........................ 27
Automatic seek tuning /.................. 27
Manual seek tuning << >> ................... 27
Adjusting the seek tuning sensitivity ..... 27
Stereo - mono switch (FM).................... 27
Changing the memory bank (FM) ......... 27
Storing stations ..................................... 27
Storing the strongest stations auto-
matically with Travelstore...................... 28
Recalling stored stations....................... 28
Sampling stored stations briefly with
Preset Scan .......................................... 28
Sampling stations briefly with
Radio Scan ........................................... 28
Reception of traffic announcements
with RDS-EON............................... 29
Priority of traffic announcements
ON/OFF ................................................ 29
Warning beep........................................ 29
Switching the warning beep off.......... 29
Automatic seek tuning start................... 29
Adjusting the traffic message volume ... 29
Tape operation.............................. 30
Inserting a tape ..................................... 30
Ejecting a tape ...................................... 30
Fast winding .......................................... 30
Autoreverse........................................... 30
Tape equalisation switch for MTL ......... 30
Dolby B-NR*.......................................... 31
Skipping/repeating titles
with CPS ............................................... 31
Listening to the radio during fast winding
with RM (Radio Monitor) ....................... 31
Changing the audio source
with SRC ............................................... 31
Care of your audio equipment............... 31
DSC programming........................ 32
CD changer control (option)....... 34
Switching the CD mode on using SRC
of the car radio ...................................... 34
Selecting a CD/track using the rocker
switch .................................................... 34
SCAN .................................................... 34
MIX........................................................ 34
Enter/display CD names ....................... 35
Deleting CD names............................... 35
Survey of DSC default settings ............. 35
Appendix ....................................... 36
Technical data....................................... 36

21
Paris RCM 104
DEUTSCH
ENGLISH
ITALIANO
PORTUGUES NEDERLAND
ESPAGÑOL SVENSKA FRANÇAIS
4M•L
To change between medium wave
(MW) and long wave (LW) frequencies.
5-dB - for instantly changing the volume
Press the -dB button to instantly mute
the audio source. The display will then
show MUTE. Return to normal volume
by pressing either the -dB button once
again or the VOL+ button.
When pressing VOL-, the normal volu-
me will be identical to the -dB (muted)
volume.
To program the mute volume, proceed
as follows:
•Adjust the desired volume.
• Press -dB for approximately 2 se-
conds (beep tone is released).
Diese Lautstärke ist als Mute-Lautstär-
ke gespeichert.
This volume will then be stored as the
mute volume.
Extra function:
Press this button to store the values set
in the DSC menu.
Short description
1Switching on:
Press ON (the KeyCard has to be in-
serted), the set plays with the pre-adju-
sted volume.
Switching off:
Press ON for approximately 1 second.
If the set was turned on by pressing
ON, the KeyCard can be used for swit-
ching the system on and off (KeyCard =
passive anti-theft protection).
The set may also be turned off via the
vehicle’s ignition (provided that it was
connected correspondingly). After the
ignition was switched off, a double
beep tone reminds you that you should
remove the KeyCard before leaving
your vehicle.
To operate the set when the ignition is
switched off (KeyCard is inserted), pro-
ceed as follows:
Press ON approximately 8 seconds
after the ignition was switched off. The
set will be turned on.
To protect the battery, the system will
automatically shut off after a playing
time of one hour.
2To change the volume:
Press VOL+/VOL-.
Each time the set is switched on, it will
play with the pre-adjusted volume (VOL
FIX). You may also change the VOL
FIX setting (see chapter “DSC pro-
gramming”).
3FMT
Press this button to change the wave-
band or memory bank in the following
order:
•Change from MW/LW to FM. If FM is
already activated, this function will be
skipped.
•Switch between the memory banks I
and II.
•Activate the Travelstore memory
bank
Extra function:
Store the six most powerful stations
automatically with Travelstore:
Press FMTuntil the search starts on
the display.

Paris RCM 104
22
9AF button (alternative frequency) du-
ring RDS operation
When “AF” lights up in the display, the
system will automatically seek a fre-
quency offering better reception of the
same RDS program.
“AF” on/off: press the AF button briefly.
When pressing the AF button for about
2 seconds, the display will show “REG-
ON” or “REG-OFF” (see REG - regio-
nal).
:PS/SCA
Radio functions:
PS (preset scan)
Press button shortly - the system will
briefly play all stations stored on the
preset buttons.
Scan
Press button for more than 2 seconds -
the system will briefly play all receiva-
ble FM stations.
CD functions (option):
SCA (scan)
To sample the CD tracks.
To start or stop the scan function:
Press PS/SCA briefly.
6Rocker switch
Station search
up
down in short
intervals
(when AF is off)
down
up in short
intervals
(when AF is off)
Extra functions:
Track /CD operation
Press briefly:
to select the title.
Hold down:
CUE/REVIEW
CD << >> To select the disc.
In the DSC
mode Select function and
program parameter.
In the AF
mode Use the << >> button
to scroll through the
programs of a radio
network, e.g. from
NDR1 to NDR4 (North
German broadcaster).
7Display
Station name (NDR 3)
Waveband
Memory bank (FM I)
Radio mode
Cassette mode
TR1 (track 1)
Dolby B
CD-mode
(option)
Disc number,
title number
8KeyCard
In order to operate the set, the corre-
sponding KeyCard has to be inserted.
For this purpose, introduce the Key-
Card (contact area showing up) into the
corresponding slot above the flashing
KeyCard tongue.
Read also the information given in the
“KeyCard” chapter.
(AF in the
display)

23
Paris RCM 104
DEUTSCH
ENGLISH
ITALIANO
PORTUGUES NEDERLAND
ESPAGÑOL SVENSKA FRANÇAIS
;TA (Traffic Announcement)
If “TA” lights up in the display, the sy-
stem will only play traffic stations.
To activate/deactivate the priority for
traffic announcements:
Press TA.
<1, 2, 3, 4, 5, 6 - preset buttons
You can store 6 stations on each FM
memory bank (I, II, and “T”) and
another 6 stations on W and LW each.
To store a station: Press button during
radio operation and hold down until the
radio resumes play.
To recall a station: Select the wave-
band. With FM, select the desired me-
mory bank and press the corresponding
preset button.
=RM (Radio Monitor)
Press this button to listen to the radio
while fastforwarding or rewinding the
tape.
During tape operation:
To switch RM on/off: Press button.
When this function is activated, the
display shows “RM”.
>B - Dolby NR*
This set allows you to play cassettes
recorded with Dolby-B noise reduction.
To switch Dolby-NR on/off:
Press the button.
When Dolby is activated, the display
shows “B”.
*Noise reduction system manufactured under li-
cense from Dolby Laboratories. “DOLBY” and the
double-DsymbolaretrademarksofDolbyLabora-
tories.
?Fast winding/Autoreverse
Switch-over to the other track
Press simultaneously
TR1-PLAY or TR2-PLAY on the display
Fast
forward;
To stop:
press FR
Fast
rewind;
To stop:
press FF
@Cassette slot
Insert tape (side A or 1 facing up, the
open side showing to the right).
AEject tape
Press .
BCPS
To repeat or skip cassette titles.
To switch CPS on/off during cassette
operation:
Press button.
CDSC (Direct Software Control)
Use the DSC function to adapt a num-
ber of programmable basic settings
according to your preference. For more
information, read through chapter “DSC
programming”.
DMIX
See chapter CD changer control.

Paris RCM 104
24
EAUD
To adjust the treble and bass frequen-
cies using the rocker button.
Treble
+
Bass Bass
Treble
+
The last setting will be automatically
stored.
If the setting remains unchanged within
8 seconds, the display will show the
previous status.
Flo
To change the seek tuning sensitivity
lo lit up in the display indicates normal
seek tuning sensitivity (the system will
pick up all powerful, nearby stations).
dx lit up in the display indicates high
seek tuning sensitivity (the system will
also pick up weaker stations).
To change the seek tuning sensitivity:
press lo.
GGEO
To adjust the BALANCE (left/right) and
FADER (front/rear).
Balance
left
Fader rear
Fader front
Balance
right
The last setting will be stored automati-
cally.
If the setting remains unchanged within
8 seconds, the display will show the
previous status.
HLD (loudness)
Use this function to boost the low fre-
quencies for more bass, especially at
low volume levels.
To switch LD on/off: Press the button.
For more information, see chapter
“DSC programming”
ISRC (source)
To select between the connected audio
sources, e.g. cassette, radio, or CD
changer (option).

25
Paris RCM 104
DEUTSCH
ENGLISH
ITALIANO
PORTUGUES NEDERLAND
ESPAGÑOL SVENSKA FRANÇAIS
Optical indication of theft protection
When the car is stationary, you can let the
KeyCard tongue flash in order to show that
the set is theft-protected. DSC allows you to
adjusttwodifferent settings: LEDONor LED
OFF.
For more information, please read through
chapter“DSCprogramming-LEDON/OFF”.
KeyCard
Thiscarradio cannot beoperatedunless the
corresponding KeyCard is inserted. The
KeyCard code is stored in the set.
Turn on the set and introduce the KeyCard
completely. The car radio is now ready for
operation.Wheninsertingawrong KeyCard,
the display will show “----”.
After approximately 10 seconds the display
shows CARD ERR.
In this case do not go on operating the set
until you have the corresponding KeyCard
available.
NevertrytopullouttheKeyCardby force.
First,slightlypushinthe card,whichwillthen
bereleased(thedisplayshowsLEARNING),
and then remove it.
Should you have lost your KeyCard, or if it
hasbecomedamaged,pleasecontactoneof
our authorised service partners to get a new
card.
Important notes
What you must know!
Beforestartingtouseyournewcarradio,you
should carefully read through the following
information.
Traffic safety
As the driver of a motor vehicle, it is your
responsibility to pay attention to the traffic
situationatalltimes.Neveruseyourcarradio
in a way that could distract you.
Please keep in mind that you travel a di-
stanceof 14m persecond ata speedof only
50 km/h.
Should the traffic situation become particu-
larly demanding, we would advise you not to
use the radio.
When adjusting the volume, make sure that
you are still able to hear all sounds coming
from outside of the vehicle, so that you are
always able to react to warning signals, for
example from the police or the fire brigade.
Installation/connection
If you like to install your new car radio by
yourself or add other audio components to
the existing ones, then please read carefully
the enclosed instructions on installation and
connection.
Blaupunktalso offers designerKeyCards for
an additional fee.
You can find the service providers listed in
the car radio service register ( ). In case of
doubt, please contact the central service
centre in your country for more information
on the next KeyCard service facility in your
vicinity.
The following functions can be individually
stored with the KeyCard (1 and 2): bass,
treble, balance and fader settings, preset
stations, loudness, TA (volume of traffic an-
nouncements), SPEECH (tone control for
speech programs), BEEP volume, SCANTI-
ME, VOLFIX.
Moreover,theparametersadjustedlastsuch
as the waveband, station, TA priority, loud-
ness, AF, CPS, Dolby B, RM, REG ON/OFF
or seek tuning sensitivity remain stored.
With this, you will always find your basic
settingsadjusted again after you have inser-
ted your KeyCard.

Paris RCM 104
26
cally searching for an alternative frequency.
“SEARCH” goes out as soon as the system
has found an alternative frequency or after
the frequency band has been scanned com-
pletely.
Should the reception quality of the selected
program become too bad,
•tune into another program.
REG - Regional
At some times of the day, larger radio stati-
ons split up their main program into regional
program versions offering local information.
If you want the radio to lock onto a regional
program,
• hold down the AF button for about 2
seconds.
The display will show “REG ON”.
If you leave the service area of the regional
station tuned in, or if you wish to use the
normal RDS service again, switch to “REG
OFF”.
•Hold down the AF button for about 2
seconds until “REG OFF” is displayed.
The display will show “REG ON” or “REG
OFF” each time the radio is switched on.
Replacing a KeyCard
Any KeyCard can only be replaced by a new
one with the same identification number
(1 or 2).
For example, to replace KeyCard 2,
•insert KeyCard 1 into the set and turn it
on.
•Slightly push in the card so that it is
released; the display will show
LEARNING.
•Take out KeyCard 1 and insert the new
KeyCard 2 while the display is still
showing LEARNING.
You can use the new KeyCard 2 to operate
the set.
To turn it on, you can only employ one Key-
Card 1 or 2.
Radio operation with RDS (Radio Data System)
The Radio Data System offers you more
convenience for listening to FM.
An ever increasing number of FM radio sta-
tionsbroadcastadditionalinformationinpar-
allel with their normal program.
Assoonasaradioprogramcanbeidentified,
thestationnameandpossiblyalsoaregional
identifier will appear in the display, e.g.
“NDR1 NDS” (local radio program in Lower
Saxony, Germany).
With RDS, the preset buttons turn into pro-
gram buttons. Now you know exactly to
whichprogram your set is tunedin, making it
absolutely easy to find the desired station
quickly.
But RDS even offers you more advantages:
AF - alternative frequency
The AF function makes sure that the stron-
gest frequency of the selected program is
always tuned in automatically.
This function is activated if “AF” lights up in
the display.
To switch AF on/off:
• Press AF briefly.
Duringseektuningforthe frequency offering
the best reception of the selected program,
the radio is muted for a moment.
If “SEARCH” appears in the display when
turning on the set or when calling up one of
the stored frequencies, the set is automati-

27
Paris RCM 104
DEUTSCH
ENGLISH
ITALIANO
PORTUGUES NEDERLAND
ESPAGÑOL SVENSKA FRANÇAIS
Manual seek tuning << >>
(prerequisite: AF is switched off!)
•Press << or >> to change the frequen-
cy in small steps in upwards/down-
wards direction.
Hold down the right or left part of the rocker
switch to speed up this procedure.
Adjusting the seek tuning sensi-
tivity
Thesetallowsyoutomodify the seektuning
sensitivity.
If “lo” is indicated, the radio will only pick up
strong stations (low sensitivity).
If “lo” is deactivated, the radio will also pick
uplesspowerfulstations(highersensitivity).
The degree of sensitivity can be separately
adjusted for both levels (see chapter “DSC
programming”).
Stereo - mono switch (FM)
You can switch to mono when the reception
quality becomes poor:
• Press lo for approximately 2 seconds.
Duringmonoreceptionthestereosymbol
in the display will go out.
Each time the car radio is switched on, the
radio will be automatically set to stereo re-
ception.
Selecting the waveband
With your car radio you can select between
the following wavebands:
FM 87.5 – 108 MHz
MW 531 – 1602 kHz, and
LW 153 – 279 kHz
•Select the desired waveband by pres-
sing the FMTor M•L button.
To switch between MW and LW:
• press M•L.
Automatic seek tuning /
• Press / . The radio will automatically
tune into the following station.
If you keep the upper or lower part of the
rocker switch / depressed, seek tuning
speeds up in upwards or downwards direc-
tion.
down in short
intervals up in short
intervals
down
up
It will automatically switch to mono when the
reception quality becomes poor.
Changing the memory bank (FM)
YoucanshiftbetweenthememorybanksI,II,
and T to store and recall preset stations.
Theselectedmemorybankisindicatedinthe
display.
• Press FMTuntil the desired memory
bank lights up in the display (press re-
peatedly if necessary).
Storing stations
Using the preset buttons 1, 2, 3, 4, 5, 6 you
can store six stations on each FM memory
bank (I, II, T).
In the MW/LW range you can store six stati-
ons each.
• Press the FMTor M•L button to select
the waveband.
•Use the rocker switch to tune to a stati-
on (either automatically /or manu-
ally << >>).
•Press the desired preset button and
hold it down. The radio will be muted
and will resume play after approximate-
ly 2 seconds.

Paris RCM 104
28
Recalling stored stations
Youcanrecallanystoredstationbypressing
the corresponding preset button.
• Press FMTor M•L to select the wave-
band. For FM, also choose the corre-
sponding memory bank by pressing
FMTuntil the desired bank is indicated
in the display.
•Briefly press the corresponding preset
button.
Sampling stored stations briefly
with Preset Scan
With this function you can briefly sample all
preset stations of a waveband. Choose the
desired SCANTIME in the DSC menu.
•Briefly press PS/SCA.
The radio will briefly play all the stored
stations of the tuned in waveband one
after another.
OnFM,thesystemwillsamplethestationsof
one of the memory banks I, II, or T, depen-
ding on which bank was selected before.
Free preset buttons will be skipped.
To switch off Preset Scan:
• Press PS/SCA once again.
The radio will continue to play the cur-
rently sampled station.
Now the station is stored. The activated pre-
set button is indicated in the display.
Note:
Should you tune into a station which has
already been stored, the corresponding pre-
set button and the memory bank will start
flashingin the displayfor a shortwhile, if you
have selected another memory bank.
Storing the strongest stations
automatically with Travelstore
YoucanusetheTravelstorememorybankto
automatically store the six strongest FM sta-
tions sorted on the preset buttons according
to their signal strength. This feature is espe-
cially useful when travelling, because it will
alwaysgiveyouthemostpowerfulstationsat
a fingertip as you pass through the various
reception areas.
• Press FMTfor at least 2 seconds.
The radio will seek the six most powerful FM
stations and store them on the “T” memory
bank(Travelstore). Assoon as this procedu-
rehasfinished,thefirststationwillbeplayed.
FM stations can also be stored manually on
the Travelstore memory bank (see “Storing
stations”).
Sampling stations briefly with
Radio Scan
Startingwiththecurrentlyplayedstation,you
mayletthesystemsamplethefollowingones
one after another. Choose the desired
SCANTIME in the DSC menu.
To activate Scan:
• Press PS/SCA for about 2 seconds.
The sampled frequency or the station
name starts flashing in the display. Du-
ring the actual search process, “SCAN”
is flashing.
To continue listening to a sampled stati-
on/switch Scan off:
•Briefly press PS/SCA.
If no station is selected during the search
operation, the scan function will be automa-
tically switched off after the entire frequency
band has been passed through. The radio
will then return to the initial station that was
being played when the scan function was
activated.
For more information, please also refer to
chapter “DSC programming - SCANTIME”.

29
Paris RCM 104
DEUTSCH
ENGLISH
ITALIANO
PORTUGUES NEDERLAND
ESPAGÑOL SVENSKA FRANÇAIS
Automatic seek tuning start
Prerequisite:
Priority for traffic announcements is activa-
ted.
If you leave the reception area of your traffic
program while listening to a tape or disc or
when having turned down the volume com-
pletely, the car radio will automatically tune
into another traffic program station.
If no such traffic program station is found
within approximately 30 seconds, tape or
disc reproduction will be interrupted and the
system will send out a warning beep. To
switch off the warning beep, proceed as
described above.
Adjusting the traffic message
volume
The volume of the warning beep and of the
currently played traffic message has been
pre-adjusted at the factory. However, you
can change this default setting using the
DSC function (see “DSC programing - TA
LEVEL”).
Reception of traffic announcements with RDS-EON (Enhanced Other Networks)
Warning beep
Whenever you leave the reception area of
the traffic program station you have tuned
into,youwillhearawarningbeepafterappro-
ximately 30 seconds.
Thiswarningbeepwillalsobereleasedwhen
pressing a preset without a traffic program.
Switching the warning beep off
a) Tune to another traffic program station:
•Press the rocker switch, or
•press a preset button with a station
offering traffic information.
Alternative:
b) Switch off the priority for traffic an-
nouncements:
• Press TA.
In the display, the “TA” indication
goes out.
You can reduce the beep tone volume to
the pre-selected mute volume.
• For this purpose, press -dB.
Many FM broadcasters provide their service
area with traffic messages at regular inter-
vals.
All traffic program stations transmit a special
telegram signal in addition to the radio pro-
gram, which is recognised and decoded by
the car radio. As soon as such a signal is
received, the display shows “TP” (Traffic
Program).
Other radio stations do not air traffic an-
nouncements by themselves, but offer the
possibility to receive the traffic announce-
ments of another station within the same
radio network. In this case, “TP” will light up
inthedisplayassoonasthepriorityfortraffic
announcements is activated. The display
must then show “TA”.
If a traffic announcement comes in, your
radio will automatically switch to the traffic
programforthe durationofthe message and
return to the previous station after the end of
the message.
Priority of traffic announcements
ON/OFF
If the priority of traffic announcements is
activated, “TA” lights up in the display. To
switch the function on/off:
•Press the TA.

Paris RCM 104
30
Autoreverse
If, while a tape is playing, you wish to switch
to the other track of that tape:
• press FR and FF simultaneously.
At the end of the tape, the set will automati-
callyswitchtotheothertrack.Thedisplaywill
show TR1-PLAY for track 1 or A and TR2-
PLAY for track 2 or B.
Note:
Ifthereistoomuchtensiononthetapeduring
playback, the set may switch to the other
trackbyitself.Inthiscasecheckthecondition
of the tape. Sometimes it helps to rewind the
cassette tape completely.
Tape equalisation switch for
MTL
The equalisation is done automatically.
Tape operation
Inserting a tape
•Turn on the set.
•Insert a tape.
Insert cassette with side A or 1
facing up, the open side facing
to the right
Eject
cassette
The tape will be played in the direction used
last.
If TR1-PLAY is displayed, this means that
track 1 or A of the tape is played.
Ejecting a tape
• Press .
The cassette will be ejected.
Fast winding
Fast forward
• Press FF (fast forward).
At the end of the tape, the set will
switch to the other track and start play-
ing it.
To stop fast forward:
• press FR.
Fast rewind
• Press FR (fast rewind).
When the tape has been completely
rewound, the set will start playing the
same track again.
To stop fast rewind:
• press FF.
Switch-over to the other track
Press simultaneously
TR1-PLAY or TR2-PLAY on the display
Fast
forward;
To stop:
press FR
Fast
rewind;
To stop:
press FF

31
Paris RCM 104
DEUTSCH
ENGLISH
ITALIANO
PORTUGUES NEDERLAND
ESPAGÑOL SVENSKA FRANÇAIS
Dolby B-NR*
Withthissetyoucanplaycassettesrecorded
with or without Dolby-B noise reduction.
Cassettes recorded with Dolby NR* distin-
guishbytheirreducedbackgroundnoiseand
the improved dynamic characteristics.
To switch Dolby on/off:
• press B. When Dolby is on, “B” is indi-
cated on the display.
*Noise reduction system manufactured under license
from Dolby Laboratories. “Dolby” and the double-D
symbol are trademarks of Dolby Laboratories.
Skipping/repeating titles
with CPS
CPS stands for Cassette Program Search.
Thisfunctionallowsyoutoskipatitleorlisten
to it once again.
To switch the function on/off:
• press CPS.
When the function is activated, “CPS” lights
up in the display.
Fully depress button -
the tape is rewound to the beginning of the
currently played title, provided that this title has
already been played for more than 8 seconds. If
not, the tape will be rewound to the beginning of
the previous title.
Fully depress button -
the tape is fast forwarded to the next title
Listening to the radio during fast
winding
with RM (Radio Monitor)
When the tape is fastforwarded or rewound,
the radio is normally muted. To listen to the
radio during fast winding (also with CPS):
• press RM. “RM” lights up on the dis-
play.
Changing the audio source
with SRC
Usethisbuttontoselectbetweenradio,tape,
or CD (option) reproduction.
To switch over,
•press the SRC button.
Care of your audio equipment
WerecommendthatyouuseonlyC-60/C-90
cassettetapesinyourcarradio.Protectyour
cassettes from dirt, dust and temperatures
exceeding50 °C.During cold weather,allow
cold cassettes to warm up somewhat before
playing them in order to avoid uneven tape
transport. Operating problems and sound
distortions may occur after approximately
100 hours of playing time and are caused by
dust particles which adhere to the rubber
roller and the audio head.
Useacleanercassettetoremovenormaldirt
build-up. For tougher cases, use a cotton
swab (Q-tip) soaked with alcohol. Never use
any hard tools to clean your unit!

Paris RCM 104
32
DSC programming
This car radio offers direct software control
(DSC), which allows you to adapt a number
of default settings to your preference and to
store these values.
Inthefollowingyouwillfindanoverviewofall
the default settings adjusted at the factory.
To change a programmed parameter,
• press DSC.
Then use the rocker switch and the -dB
button to select and change the functions
described below. The display shows the ad-
justed status.
Select function
Select function
Change-
setting Change-
setting
CD NAME Use this function to name
your discs (see also CD
changer control, “Entering/
displaying CD names”)
ANGLE Use one of the values -1, 0,
or +1 to adapt the individual
viewing angle.
Adjust the ANGLE so as to
provide the best view.
BEEP Acknowledgement tone for
all functions where the re-
spective button has to be
held down for more than 2
seconds to activate the
function.
Adjust volume between 0
and 9 (0 = OFF).
BRIGHT The display brightness can
be adjusted between 1 and
16. You may set one day
and one night adjust-
ment.Brightness of night
illumination:
Switch on the vehicle’s li-
ghting system and program
the brightness value. For
this, the lighting connector
has to be connected to the
electric system of the car.
COLOUR
(Variocolour) To gradually match the co-
lours of the car radio and
dashboard lighting to each
other.
green .............bright orange ............... red
CD DISP During CD operation, use <<
>> to select between the
following displays:
NAME –
the name specified with CD
NAME.
TIME –
the playback time of the title.
NUMBER –
disc and track number.
LED ON You can select between LED
ON and LED OFF. When
setting LED ON, the Key-
Card tongue will flash for
optical theft protection when
the set is switched off and
the KeyCard removed.
(only, if
changer is
connected)
(only, if
changer is
connected)

33
Paris RCM 104
DEUTSCH
ENGLISH
ITALIANO
PORTUGUES NEDERLAND
ESPAGÑOL SVENSKA FRANÇAIS
LOUDNESS When listening at a low level,
the loudness function will
create a more natural sound
by emphasizing the low fre-
quency range.
LOUD 1 - low boost
LOUD 6 - strong boost
SCANTIME Use this function to specify
the scan time in the radio
mode). Choose a value bet-
ween 5 and 30 seconds.
S-DX 1 Use this function to adjust
the seek tuning sensitivity for
distant reception.
DX. 1 - high sensitivity
DX. 3 - low sensitivity
S-LO 1 Use this function to adjust
the seek tuning sensitivity for
local reception.
LO1 - high sensitivity
LO3 - low sensitivity
The seek tuning sensitivity
values can be separately
adjusted for AM and FM.
SPEECH In the future, the RDS broad-
casters will make a di-
stinction between music and
speech programs. Use the
“SPEECH” function to adjust
the sound settings for
speech programs separately.
TA LEVEL Use this function to adjust
the volume of the traffic an-
nouncements and the
warning beep between 1 and
9. It is also possible to adjust
the fader, balance, treble,
and bass settings. The last
adjustment will be stored.
The announcement will be
played in accordance with
the specified values.
CD UPD Use this function to delete
named discs in order to get
new memory capacities for
new CD names (see also
“CD changer control, Dele-
ting CD names”)
VOL FIX Use this function to adjust
the initial volume when the
set is switched on.
Use << >> to adjust the desi-
red initial volume.
To quit the DSC mode and store the
setting:
• Press DSC
(only, if
changer is
connected)

Paris RCM 104
34
CD changer control (option)
Selecting a CD/track using the
rocker switch
Selecting
CDs
(downwards)
Repeating a track: press briefly
Selecting a track (downwards): briefly press
two or more times
REVIEW - fast reverse (audible):
press and hold down
Selecting
CDs
(upwards)
Selecting a track (upwards): press briefly
CUE - fast advance (audible):
press and hold down
The display shows which mode has been
selected.
SCAN
For briefly sampling the CD tracks.
Start SCAN:
• Press PS/SCA on the car radio for 1
sec. The tracks are briefly played in
ascending sequence.
Stop SCAN:
• Press PS/SCA briefly. The radio will
keep on playing the track scanned last.
MIX
For playing the CD tracks in random se-
quence.
MIX CD –The tracks of the selected CD
areplayedrandomly.Thefollo-
wing CDs are selected in nu-
meric order, their tracks are
played randomly.
MIX MAG –All tracks of the CD magazine
are played randomly.
MIX OFF –MIX is switched off. The tracks
are played in numeric order.
Selecting the MIX function
• Press MIX until the desired function is
briefly shown in the display.
If MIX is on, “MIX” is shown in the lower right
part of the display.
This car radio makes it possible to remote
control a Blaupunkt CD changer: CDC-A03,
-F03, -A05.
Switching the CD mode on using
SRC of the car radio
BesurethataCDmagazineisinsertedinthe
changer. Use the SRC button to change the
audio source (radio - changer - cassette)
Press SRC until the changer functions ap-
pearin the display. First, “CDON” isdisplay-
ed briefly, then e.g.
CD1 -T1
CD = Disc, T= TRACK
CD no. Track no.

35
Paris RCM 104
DEUTSCH
ENGLISH
ITALIANO
PORTUGUES NEDERLAND
ESPAGÑOL SVENSKA FRANÇAIS
Enter/display CD names
You can allocate names for up to 99 CDs.
WhenplayingaCD,the displaywillthengive
you entered name, e.g. VIVALDI.
Precondition:NAME mustbeset underDSC
- CD DISP.
Entering a name:
Besurethatatleast1CDisinsertedintheCD
magazine.
• Press SRC to change to CDC
• Press DSC
• Press the rocker switch / until CD
NAME is displayed.
• Press -dB
The first character position flashes.
•Select a character using the rocker
switch / .
The display will give you one after the other
the capital letters (A-Z), the special charac-
ters and the numbers 0-9.
• Use the rocker switch << >> to change
to the next character position and sel-
ect a character.
Each name may have up to seven charac-
ters.
To complete the entry:
• Press -dB. The entry is stored and you
can now select another DSC function
using the rocker switch / .
Alternatively:
• Press DSC. The entry is stored and you
quit the DSC menu.
Storing the entry/selecting the next CD:
• Press -dB and select the next CD using
<< >>.
• Press -dB and enter a name.
Storing a new name deletes the previous
name (overwrite).
Deleting CD names
If you try to store more than 99 CD names,
“FULL” will be shown in the display. In the
DSC mode, you can delete the name of one
or more CDs to free memory space.
The function CDC-UPDATE can be used to
confirm all CDs, which names you wish to
maintain.Alltheothernameswillbedeleted.
• Press DSC.
•Insert a magazine with the CDs, which
names you wish to maintain.
• Press /until “CDC UPD” is display-
ed.
•Press << >> and “LOAD CD” is display-
ed.
After having confirmed all CDs of this maga-
zine, “NEXT MAG” appears in the display.
• Press EJECT on the CD changer and
insert the next magazine.
RepeatthesestepsforallCDs,whichnames
you wish to maintain.
•To finalize your selection, press -dB for
about 2 sec. until “UP DATING” ap-
pears in the display. The updating pro-
cess is completed, when the display
shows “READY”.
The names of all CDs you have inserted
remainstoredinthememory.Foralltheother
CDs, the names are deleted.
You can interrupt this process by pressing
DSC.
Survey of DSC default settings
ANGLE 0
BEEP 4
BRIGHT 16
COLOUR Medium position (yellow)
CD DISP NAME
LED ON
LOUDNESS 3
SCANTIME 10s
S - DX 2
S - LO 2
SPEECH 0
TA LEVEL 5
VOL FIX 20

Paris RCM 104
36
Appendix
Technical data
Amplifier:
Output power: 4 x 20 watts RMS acc.
to DIN 45 324
4 x 25 watts music
power acc. to
DIN 45 324
FM sensitivity: 0.9 µV at 26 dB
S/N ratio
Frequency response:
FM 35 - 16,000 Hz (-3 dB)
Cassette (metal) 30 - 16,000 Hz (-3 dB)
Subject to modifications!

Paris RCM 104
20
Blaupunkt-Werke GmbH
Bosch Gruppe
1/95 K7/VKD 3 D94 147 007 PM
