Blaupunkt CASABLANCA MP56 User manual

1
Radio CD SD USB MP3 WMA
http://www.blaupunkt.com
Casablanca MP56 7 646 580 310
Bedienungsanleitung
Operating instructions
Notice d’emploi
Istruzioni d’uso
Gebruiksaanwijzing
00_Titels_Casablanca_1.indd Inhalt100_Titels_Casablanca_1.indd Inhalt1 01.06.2006 12:05:25 Uhr01.06.2006 12:05:25 Uhr

Index
67
ENGLISH DEUTSCHFRANÇAISITALIANO
NEDERLANDS
03_BA_Casablanca_1_ENG.indd Inhalt6703_BA_Casablanca_1_ENG.indd Inhalt67 31.05.2006 11:15:31 Uhr31.05.2006 11:15:31 Uhr

Index
68
03_BA_Casablanca_1_ENG.indd Inhalt6803_BA_Casablanca_1_ENG.indd Inhalt68 31.05.2006 11:15:32 Uhr31.05.2006 11:15:32 Uhr

Index
69
ENGLISH DEUTSCHFRANÇAISITALIANO
NEDERLANDS
Index
About these instructions ................72
For your safety................................72
Scope of delivery ............................73
Warranty .........................................73
Device overview..............................74
Controls...........................................74
Placing the device in operation......75
Detaching/attaching the control
panel................................................75
Switching the device on/off.............76
General functions ...........................76
Inserting a CD..................................76
Inserting an MMC/SD card ..............77
Connecting the USB medium...........77
Adjusting the volume .......................78
Muting the device ............................78
Operation with telephone................78
Selecting an audio source ...............79
The tuner display..........................80
The audio CD display ...................80
The CD changer display ...............81
The MP3 display ⁸) .......................81
Overview of the operation..............82
Overview of the buttons ..................82
Overview of the functions MIX,
RPT, and TRAFFIC............................83
Switching random track play
on/off (MIX) .................................83
Switching Repeat title on/off
(REPEAT) ......................................84
Scanning titles (SCAN).................84
Buttons for menu operation ............84
Example of a menu operation ..........85
Calling up a menu ........................85
Selecting a menu item in the
settings menu...............................85
Changing and saving a setting......86
Exiting a menu item......................86
Operating the tuner ........................87
Searching for stations......................87
Manually searching for stations....87
Automatically searching for
stations ........................................88
Storing stations ...............................89
Listening to stored stations .............89
Scanning all receivable stations
(SCAN).............................................89
Set the device to the region
Europe, USA or Thailand ..............90
Changing the tuner settings
("TUNER" MENU) .............................91
Permanently switching the
priority of traffic announcements
on/off (TRAFFIC)..........................91
Switching the display of radio
text on/off (R-TEXT) .....................92
Allowing alternative frequencies
(RDS) ...........................................92
Searching FM stations
automatically and storing them in
the FMT memory bank (T-STORE)..92
Changing the seek tuning
sensitivity (SENS) ........................92
Allowing/preventing automatic
changing to other regional
programmes (REGIONAL) ............93
Activating/deactivating improved
reception (HIGH CUT) ..................93
03_BA_Casablanca_1_ENG.indd Inhalt6903_BA_Casablanca_1_ENG.indd Inhalt69 31.05.2006 11:15:33 Uhr31.05.2006 11:15:33 Uhr

Index
70
Restricting station seek tuning to
certain programme contents
(PROG TYP) .................................94
Toggle between mono and
stereo operation (MONO) ............94
Traffic announcements (TA) ...........95
Receiving traffic announcements .....95
Skipping a traffic announcement.....95
Permanently switching the priority
of traffic announcements on/off......95
Operating the integrated
CD player.........................................97
What features do MP3 or
WMA CDs have to have?...............97
Functions of the integrated CD
player if an audio CD is inserted ..98
Switching the CD text display
on/off (TEXT) ...............................99
Switching the scrolling text
for CD text on/off (SCROLL)........99
Operating the MP3/WMA player..100
Showing all the information of
the current title (SHOW ALL).......101
Switching scrolling text on/off
(SCROLL)...................................101
Selecting the title information
to be displayed (INFO)...............101
Selecting a title from a list
(Browser mode/playlist) ............102
Operating the optional
CD changer....................................104
Selecting a CD from the CD
magazine (CD overview) ............105
Changing the name of a CD in
the magazine of the CD changer
(CD NAME).................................105
Changing basic settings in the
settings menu ...............................106
Adjusting sound and balance
(AUDIO) .........................................107
Changing treble or bass
(TREBLE/BASS) .........................107
Changing the volume distribution
(BALANCE/FADER) .....................107
Changing the equalizer
setting (DEQ) .............................108
Creating/changing a user-defined
equalizer setting (ADJUST) ........109
Which equalizer setting is
the correct one?.........................111
Selecting a sound presetting
(PRESET)....................................112
Setting the speed-dependent
volume increase (AUTO SND).....112
Setting the bass increase
(XBASS) .....................................112
Configuring the preamplifier
output for the subwoofer
(SUBOUT) ..................................112
Switching the equalizer off
(OFF)..........................................113
Changing display settings
(DISPLAY) ......................................114
Changing the colour of the
display (COLOR) ........................114
Changing the user-defined
colour (USER) ............................115
Adjusting the display viewing
angle (ANGLE)............................115
Inverting the display (INVERT) ...116
Switching the spectrum
analyser on/off (SPECTRUM) .....116
Activating/deactivating the
screen saver (SCREEN S)...........116
Changing volume presettings
(VOLUME)......................................117
03_BA_Casablanca_1_ENG.indd Inhalt7003_BA_Casablanca_1_ENG.indd Inhalt70 31.05.2006 11:15:33 Uhr31.05.2006 11:15:33 Uhr

Index
71
ENGLISH DEUTSCHFRANÇAISITALIANO
NEDERLANDS
Changing the volume presetting
of traffic announcements
(TRAFFIC)...................................117
Changing the volume presetting
of the telephone (PHONE) .........118
Changing the volume presetting
of the signal tone (BEEP) ...........118
Changing the presetting of the
power-on volume (ON VOL) .......118
Restoring the volume at
switch-on (LAST VOL) ................118
Changing clock settings (CLOCK)..119
Setting the time (TIME)..............120
Switching the time display on/
off with switched-off device
(OFFCLOCK) ..............................120
Switching the RDS
synchronisation of the clock
on/off (AUTOSYNC)....................120
Switching the 24-hour time
display on/off (24H MODE)........120
Configuring audio inputs (AUX) .....121
Activating/deactivating audio
inputs (AUX1/2) .........................121
Renaming audio inputs (EDIT) ...121
Changing special settings
(VARIOUS) .....................................123
Changing the welcome text
(ON MSG) ..................................123
Switching the internal amplifier
on/off (AMP ON) ........................124
Resetting the device to factory
settings (NORMSET) ..................124
Changing the scan time
(SCANTIME) ...............................124
Displaying the serial number
(SER NUM) .................................125
Error table.....................................125
Technical data ...............................126
Glossary ........................................127
Index .............................................130
Installation instructions................332
Blaupunkt stands for technical know-how in mobile radio reception,
for precise navigation systems and first-class sound. The blue dot
made its debut in 1923 as a seal of quality that was assigned after
rigourous functional – and it still applies today. At that time as well
as today, the blue dot identifies products of extraordinary quality.
03_BA_Casablanca_1_ENG.indd Inhalt7103_BA_Casablanca_1_ENG.indd Inhalt71 31.05.2006 11:15:34 Uhr31.05.2006 11:15:34 Uhr

For your safety
72
About these
instructions
Please read these instructions
and, in particular, the following
chapter, "For your safety", before
using the device!
Please also ob-
serve the following instructions:
CD Changer, if available
Remote Control, if available
For your safety
The device was manufactured
according to the state of the art
and established safety guidelines.
Even so, dangers may occur if you
do not observe these safety infor-
mation:
Read these instructions care-
fully and completely before us-
ing the device.
Keep the instructions at a loca-
tion so that they are always ac-
cessible to all users.
Always pass on the device
to third parties together with
these instructions.
Use as directed
The device is designed for opera-
tion in a vehicle with 12 V vehicle
system voltage and must be in-
stalled in a DIN slot.
•
•
➔
➔
➔
If you are installing device
yourself
You may only install the device
yourself if you are experienced in
installing car sound systems and
are very familiar with the electri-
cal system of the vehicle.
Observe the following!
Danger of injuries!
Do not open or modify the
device! The device con-
tains a Class 1 laser that emits in-
visible laser radiation which can
cause injuries to your eyes. The
warranty is void if the device has
been opened.
Danger of accidents!
Operate the device only if
traffic situation permits it!
Danger of hearing
damage!
Always listen at moder-
ate volume so that you can always
hear acoustic warning signals!
This will also help to protect your
hearing. The device briefly switch-
es to mute, e.g. while the CD
changer changes the CD or if you
are switching the audio source.
Do not increase the volume dur-
ing this mute phase
03_BA_Casablanca_1_ENG.indd Sicher7203_BA_Casablanca_1_ENG.indd Sicher72 31.05.2006 11:15:34 Uhr31.05.2006 11:15:34 Uhr

73
ENGLISH DEUTSCHFRANÇAISITALIANO
NEDERLANDS
Danger to the device!
Do not insert any mini
CDs (8 cm diameter) and
shape CDs since they destroy the
drive!
Theft protection
Carry the control panel with you
in the supplied case whenever
you leave the vehicle.
Cleaning
Clean the device with a dry or
slightly moistened cloth. Do not
use any solvents, cleaning agents
or cleansers and no cockpit spray
and care product for plastic ma-
terials.
Disposal
Do not dispose of your old
device in the household
trash. Please use the available re-
turn and collection systems for
the disposal.
Scope of delivery
1 Casablanca MP56
1 Case for the control panel
1 Operating instructions
1 Support frame
2 Disassembly bar
1 Guide pin
1 USB connecting cable
Note:
Remote controls are available
as optional equipment. You can
find out from your Blaupunkt
dealer or on the Internet at
www.blaupunkt.com which re-
mote controls can be used with
this device.
Warranty
We provide a manufacturer's war-
ranty for products bought within
the European Union. For devices
purchased outside the European
Union, the warranty terms issued
by our respective responsible do-
mestic agency are valid.
The warranty terms can be called
up under www.blaupunkt.com or
requested directly from:
Blaupunkt GmbH
Hotline
Robert-Bosch-Str. 200
D-31139 Hildesheim
Scope of delivery
03_BA_Casablanca_1_ENG.indd Liefer7303_BA_Casablanca_1_ENG.indd Liefer73 31.05.2006 11:15:35 Uhr31.05.2006 11:15:35 Uhr

Device overview
74
Device overview
Controls
672 14359:;<=
>
8
?
@AB
1button
for detaching the control panel
2TUNER button
Selecting the tuner as audio
source
Opening the "TUNER" menu
3Rocker switch
Tuner: Start the station seek
tuning
Settings menu: Change settings
4On/Off button
Press short: Switch on/mute
Press long: Switch off
5Volume control
6NEXT button
Tuner: Select memory bank (FM1,
FM2, FM3, FMT)
Settings menu: Go to the next
menu page
MP3/WMA: Switch between
"PLAY", "BROWSER" and
"PLAYLIST"
7to <Softkeys
to select the function shown on
the display next to the respective
button
= button
to eject/insert a CD
>Display (see page 80 and 81)
03_BA_Casablanca_1_ENG.indd Elemente7403_BA_Casablanca_1_ENG.indd Elemente74 31.05.2006 11:15:35 Uhr31.05.2006 11:15:35 Uhr

Placing the device in operation
75
ENGLISH DEUTSCHFRANÇAISITALIANO
NEDERLANDS
?MENU button
to call up the settings menu
@ESC button
Settings menu: Confirm menu
item and change to the display of
the audio source
Scan/Travelstore: Cancel
AOK button
Press short: Confirm menu item
and change to the next higher
menu level
Press long: Start scan/station
seek tuning
BSRC button
Consecutively switching between
the available audio sources
CCD drive
C
DMMC/SD card slot
D
Placing the device in
operation
Detaching/attaching the
control panel
You can detach the control panel
to protect against theft.
CAUTION!
Danger of theft!
The device is worthless to a thief
without the control panel.
Never keep the control pan-
el in the vehicle, not even in a
hidden place; instead, carry it
with you in its case when you
leave the vehicle!
CAUTION!
Damage to the control
panel!
The control panel can be damaged
or malfunction if the following is
not observed:
Never drop the control panel.
Do not expose the control pan-
el to direct sunlight or another
heat source.
Transport it exclusively in the
supplied case.
➔
➔
➔
➔
03_BA_Casablanca_1_ENG.indd Betrieb7503_BA_Casablanca_1_ENG.indd Betrieb75 31.05.2006 11:15:36 Uhr31.05.2006 11:15:36 Uhr

General functions
76
Do not touch the contacts on
the rear side with your fingers.
Clean the contacts of the con-
trol panel regularly using a soft
cloth moistened with cleaning
alcohol.
To detach the control panel:
Press the button 1.
The control panel opens to the
front on the left. The device
switches off automatically.
Detach the control panel.
To attach the control panel:
Place the control panel in the
slot with the right side first.
Next, carefully push the left
side to the back until the con-
trol panel engages.
Switching the device
on/off
To switch on the device:
Press the On/Off button 4.
The device plays the audio
source you previously listened
to.
Note:
If you switch on the device
without first switching on the
vehicle ignition, the device au-
tomatically switches off after
one hour to save the vehicle
battery.
➔
➔
➔
➔
➔
➔
➔
To switch off the device:
Press and hold the On/Off but-
ton 4for approx. two seconds.
In addition, the device is automat-
ically switched off as soon as you
switch of the vehicle ignition. If
you switch on the ignition again,
it also automatically switches on
the device again.
General functions
Inserting a CD
CAUTION!
Damage to CD drive from
unsuitable CDs!
Mini CDs (8 cm diameter) or
shape CDs damage the drive!
Insert only circular CDs with
a 12-cm diameter into the CD
drive.
To insert an MP3, WMA or audio
CD, the device must be switched
on.
Press the button =.
The control panel opens. If a
CD is in the drive, it is ejected.
If you do not remove this CD, it
is automatically pulled in again
after approx. 10 seconds.
➔
➔
➔
03_BA_Casablanca_1_ENG.indd AllgFkt7603_BA_Casablanca_1_ENG.indd AllgFkt76 31.05.2006 11:15:37 Uhr31.05.2006 11:15:37 Uhr

General functions
77
ENGLISH DEUTSCHFRANÇAISITALIANO
NEDERLANDS
Insert the CD with its print-
ed side uppermost into the CD
drive Cuntil you feel some re-
sistance.
The CD is automatically drawn
in and the control panel closes.
This CD can now be selected as
audio source.
Note:
As long as the CD is in the
drive, the device stores track
and playing time of the CD
played last, and after calling up
the audio source, the playback
starts at the position where it
was interrupted.
Inserting an MMC/SD card
Note:
Blaupunkt cannot guarantee
the correct functioning of all
MMC/SD card available on the
market and, for this reason,
recommends the use of MMC/
SD cards manufactured by
"SanDisk" or "Panasonic". The
cards must be formatted using
the FAT16 or FAT32 file system
and contain MP3 or WMA files.
Remove the control panel as
described on page 9.
Insert the MMC/SD card in the
card slot Duntil it engages.
The contacts of the card must
point down and to the rear.
➔
➔
➔
Attach the control panel as
described on page 9.
This MMC/SD card can now be
selected as audio source.
To remove the MMC/SD card:
Remove the control panel as
described on page 9.
Push on the MMC/SD card
until it disengages.
Pull the MMC/SD card out of
the card slot D.
Connecting the USB
medium
To be able to connect a USB stick
or a USB hard disk, the supplied
USB cable must be connected
to the rear side of the device be-
fore the installation as described
in the installation instructions.
This cable can be routed, for ex-
ample, to the glove compartment
or a suitable place of the center
console.
Note:
Always switch off the device
before connecting or discon-
necting your USB medium!
Connect the USB medium to
the USB cable that is routed
from the rear side of the de-
vice.
The USB medium can now be
selected as audio source.
➔
➔
➔
➔
➔
03_BA_Casablanca_1_ENG.indd AllgFkt7703_BA_Casablanca_1_ENG.indd AllgFkt77 31.05.2006 11:15:37 Uhr31.05.2006 11:15:37 Uhr

General functions
78
For the device to recognise the
USB medium, it must be specified
as mass storage device and for-
matted using the FAT16 or FAT32
file system and contain MP3 or
WMA files. Blaupunkt cannot
guarantee the proper function-
ing of all USB media available on
the market. If extensive files are
stored on your USB medium, the
file search (see page 102) can be
slow.
Adjusting the volume
WARNING!
Danger from excessive
volume!
Excessive volume can damage
your hearing and you may fail to
hear acoustic warning signals!
Do not increase the volume
while the device changes the
CD in the CD changer or the
audio source.
Always set the device to a
moderate volume.
Turn the volume control 5.
The current volume is shown
in the central area Bof the
display and used for all audio
sources.
➔
➔
➔
Note:
To preset the volume of traffic
announcements (TRAFFIC), a
connected telephone (PHONE)
and the signal tone (BEEP), see
pages 117 and 118.
Muting the device
The device can be muted as fol-
lows:
Briefly press the On/Off but-
ton 4.
The display shows "MUTE".
To cancel the mute function:
Briefly press the On/Off but-
ton 4again or turn the volume
control 5.
Operation with telephone
If a hands-free system is installed
in your vehicle or your cell phone
is connected to the device via a
Bluetooth adapter, the device re-
sponds as follows to incoming or
outgoing telephone calls:
The voice of the person calling
you is played back via the loud-
speakers of the vehicle.
The display shows "PHONE
CALL".
The currently playing audio
source is muted.
➔
➔
•
•
•
02_BA_Casablanca_1_GB.indd 7802_BA_Casablanca_1_GB.indd 78 11.09.2007 14:55:38 Uhr11.09.2007 14:55:38 Uhr

General functions
79
ENGLISH DEUTSCHFRANÇAISITALIANO
NEDERLANDS
During the telephone call, you
change the volume of the tele-
phone call by means of the vol-
ume control 5.
Traffic announcements (TA) are
not automatically shown.
Selecting an audio source
The device features the following
audio sources:
Tuner
Integrated CD player (can play
audio CDs as well as CDs with
MP3 or WMA files)
MMC/SD card with MP3 or
WMA files
In addition, the following external
audio sources can be connected:
Either an optional CD changer
or AUX1
AUX2 (e.g. MiniDisc or external
MP3 player)
USB stick with MP3 or WMA
files
To be able to select an external
audio source, it must be connect-
ed and contain audio data.
Press the SRC button Bre-
peatedly until the display brief-
ly shows the desired audio
source.
•
•
•
•
•
•
•
•
➔
02_BA_Casablanca_1_GB.indd 7902_BA_Casablanca_1_GB.indd 79 11.09.2007 14:55:39 Uhr11.09.2007 14:55:39 Uhr

General functions
80
The tuner display
12:34FM1
AUDIO
94.60
96.20
97.70
TUN>
RADIO KISS
RADIO KISS
RADIO SUN
93.40
TP XBS TMC RDS PTY
B
DE
A
91.50 MHZ
C
C
AMain line
Left: Arrow
Middle: Station name or frequency
BCentral area
Audio source
CMemory location for radio sta-
tions which can be selected
using the six softkeys 7to <
DInfo line 1
Left: memory bank
In between: TP ¹), XBS ²), TMC ³),
RDS ⁴), PTY ⁵)
Right: Clock
EInfo line 2
Frequency
The audio CD display
MIX
REPEAT
TRAFFIC
SHOW ALL
SCROLL
INFO
TRACK 01
CD
TEXT: EUROPE - FINAL CO01:15
12:34CD TP XBS TMC RDS PTY
DEC
BCA
AMain line
Left: Arrow
Middle: Track number
BCentral area
Audio source
CFunctions which can be select-
ed using the softkeys 7to <
DInfo line 1
Left: Audio source
In between: TP ¹), XBS ²), TMC ³),
RDS ⁴), PTY ⁵), RPT ⁶), MIX ⁷)
Right: Clock
EInfo line 2
Left: Playing time,
Middle: CD text
¹) TP: appears if a traffic information station is set (see page 95).
²) XBS: appears if XBass is switched on (see page 112).
³) TMC: appears only if you connect an external navigation system and it starts
searching for TMC stations.
⁴) RDS: appears if changing to alternative frequencies is permitted (see page
92).
⁵) PTY: appears if the station seek tuning was restricted to a specific pro-
gramme type (see page 94).
03_BA_Casablanca_1_ENG.indd AllgFkt8003_BA_Casablanca_1_ENG.indd AllgFkt80 31.05.2006 11:15:38 Uhr31.05.2006 11:15:38 Uhr

General functions
81
ENGLISH DEUTSCHFRANÇAISITALIANO
NEDERLANDS
The CD changer display
DISC 2: BOB MARL01:15
12:34CDC
CD NAME
TRACK 05
CDC>
CDC>
MIX
REPEAT
TRAFFIC
B
DE
AC
C
TP XBS TMC RDS PTY
AMain line
Left: Arrow
Middle: Track number
BCentral area
Audio source
CFunctions which can be select-
ed using the softkeys 7to <
DInfo line 1
Left: audio source
In between: TP ¹), XBS ²), TMC ³),
RDS ⁴), PTY ⁵), RPT ⁶), MIX ⁷)
Right: Clock
EInfo line 2
Left: Playing time,
Middle: CD text or CD name
The MP3 display ⁸)
12:34MP3
DISC 4
DISC 5
NEXT
TRACK 05
CDC>
CDC>
ALICIA K
MADONNA
BOB MARL
MIX
REPEAT
TRAFFIC
SHOW ALL
SCROLL
INFO
Europe - Final Co
MP3
SONG: EUROPE - FINAL CO01:15
B
DE
AC
C
TP XBS TMC RDS PTY
AMain line
Left: Arrow
Middle: Track number
BCentral area
Audio source
CFunctions which can be select-
ed using the softkeys 7to <
DInfo line 1
Left: audio source
In between: TP ¹), XBS ²), TMC ³),
RDS ⁴), PTY ⁵), RPT ⁶), MIX ⁷)
Right: Clock
EInfo line 2
Left: Playing time,
Middle: Title information (e.g. ID3
or file name)
⁶) RPT: appears if a repeat function is switched on (see page 84).
⁷) MIX: appears if the random playback is switched on (see page 83).
⁸) The MP3 display appears if a CD, SD/MMC card or USB stick with MP3 or
WMA files is inserted and selected as audio source. The corresponding
MP3 medium is displayed left on info line 1 E.
03_BA_Casablanca_1_ENG.indd AllgFkt8103_BA_Casablanca_1_ENG.indd AllgFkt81 31.05.2006 11:15:39 Uhr31.05.2006 11:15:39 Uhr

Overview of the operation
82
Overview of the operation
This chapter first presents the buttons on the device.
It is followed by a description of the audio functions MIX, REPEAT,
TRAFFIC and SCAN since their operation is identical for all audio
sources.
The operation of the device menus is described starting on page 84.
Overview of the buttons
Many basic functions during the playback of music, such as forwarding
and reversing music, are performed using the rocker switch 3(using
the four functions , , , and ), the OK button Aor the six softkeys
7to <.
Note:
These functions are not shown on the display!
The following table shows the functions that can be performed by
these buttons.
What do you want to do?
Selectable audio sources
Tuner CD MP3/
WMA CDC AUX
Forward – Hold pressed
No operation possible of Casablanca
Reverse – Hold pressed
Title forward –Press short
Title reverse –Press short
Previous CD/folder ––
Press short
Next CD/folder ––
Press short
Scan track/station
(see also page 84) Press OK for 2 seconds
Play radio station Press short –– –
Store radio station Press for 2 s –– –
03_BA_Casablanca_1_ENG.indd Bedienen8203_BA_Casablanca_1_ENG.indd Bedienen82 31.05.2006 11:15:39 Uhr31.05.2006 11:15:39 Uhr

Overview of the operation
83
ENGLISH DEUTSCHFRANÇAISITALIANO
NEDERLANDS
Overview of the functions MIX, RPT, and TRAFFIC
The display of the active audio source can show up to six functions F
at the left and right edge of the display which you always operate us-
ing the same six softkeys 7to <independent of the audio source.
The different settings of a function are selected by repeatedly pressing
the same softkey.
The following table shows which settings are available for the func-
tions MIX, REPEAT, and TRAFFIC.
Softkey next to the
audio function
Selectable audio sources
Tuner CD MP3 CD USB/SD/
MMC CDC AUX
MIX (random track play)
(see also page 83) –
OFF
CD CD OFF
DIR
FOLDER
OFF
ALL
CD
ALL
OFF
No operation possible
of Casablanca
RPT (repeat mode)
(see also page 84) –
TRACK
OFF
TRAC
K
DIR
OFF
TRAC
K
DIR
OFF
TRAC
K
CD
OFF
TRAFFIC (traffic an-
nouncement, see page 96) ON
OFF
Switching random track play on/
off (MIX)
Press the softkey 7(next to
"MIX").
The random track play mode is
displayed on the main line A.
"MIX CD": All tracks on the
current audio CD are played
in random order.
"MIX ALL": All tracks on all
CDs in the magazine of the
CD changer are played in
random order.
➔
•
•
"MIX FOLDER"/"MIX DIR": Up
to 99 MP3 or WMA titles in
the current folder are played
in random order.
"MIX MEDIUM": All MP3 or
WMA titles on the current
data carrier (CD, MMC/SD
card or USB stick) are played
in random order.
"MIX OFF": The random track
play is switched off. All titles
are played in the order in
which they are found on the
data carrier.
•
•
•
03_BA_Casablanca_1_ENG.indd Bedienen8303_BA_Casablanca_1_ENG.indd Bedienen83 31.05.2006 11:15:40 Uhr31.05.2006 11:15:40 Uhr

Overview of the operation
84
If you switched on random track
play, the selected random track
play mode is displayed on info
line 1 Dand indicated by "MIX"
at the side of the display.
Switching Repeat title on/off
(REPEAT)
Press the softkey 8(next to
"REPEAT").
The repeat mode is displayed
on the main line A.
"REPEAT TRACK": The cur-
rent track is repeated until
you quit repeat.
"REPEAT DIR"/"REPEAT
FOLDER": All titles in the cur-
rent folder are repeated until
you quit repeat.
"REPEAT CD": All tracks on
the CD are repeated until you
quit repeat.
"REPEAT OFF": The repeat
mode is switched off. How-
ever, the playback does not
stop with the last track. After
the last title in the last fold-
er, the playback is continued
with the first title in the first
folder.
The selected repeat mode is dis-
played on info line 1 Dand indi-
cated by "REPEAT" at the side of
the display.
➔
•
•
•
•
Scanning titles (SCAN)
You can scan all the titles of a
data carrier. The scan time is
selected in the settings menu
("SCANTIME" menu item, see
pages 123 and 124).
Press and hold the OK button
Afor approx. two seconds.
All tracks are scanned. The
main line of the display alter-
nately shows "SCAN" and the
track number or the file name.
To cancel the scan:
Press the OK button A.
The playback of the current
title is continued.
Buttons for menu operation
The device features menus which
allow you to change the preset-
tings or make a selection. The dis-
play shows up to six menu items.
Each menu item is assigned to
one of the six softkeys 7to <.
The following buttons are re-
quired to operate the menus:
The MENU button ?is used
to call up the settings menu
("USER MENU") at any time.
If a menu consists of several
pages, you can consecutively
scroll them using the NEXT
button 6.
➔
➔
•
•
03_BA_Casablanca_1_ENG.indd Bedienen8403_BA_Casablanca_1_ENG.indd Bedienen84 31.05.2006 11:15:41 Uhr31.05.2006 11:15:41 Uhr

Overview of the operation
85
ENGLISH DEUTSCHFRANÇAISITALIANO
NEDERLANDS
If "TUNER" is selected as the
audio source, the TUNER but-
ton 2calls up the "TUNER"
menu.
If the current menu features
several pages, the left side of
the main line Ashows an ar-
row ( ). This means, you can
use the NEXT button 6to con-
secutively scroll the different
pages.
The softkeys 7to <are used
to select the menu items that
are shown on the display next
to the corresponding button.
In some menus, the rocker
switch 3is used to change the
setting of a menu item.
This setting is immediately
effective and automatically
stored.
You confirm the setting with
the OK button Aand go back
one higher menu level.
If you are navigating in a menu,
the right side of the main line
A shows the ESC symbol ( ).
This means that you can exit
the menu using the ESC button
@. You also confirm the dis-
played setting with the ESC
button @, but you are leaving
the menu and return to the dis-
play of the active audio source.
•
•
•
•
•
•
If you do not press any button,
the display of the active audio
source automatically appears
after approx. 16 seconds.
Example of a menu
operation
The following example from the
settings menu (Changing the dis-
play brightness) shows how to
operate the menus in general.
Calling up a menu
Press the MENU button ?.
The settings menu ("USER
MENU") is displayed.
USER MENU
MENU
AUDIO
DISPLAY
VOLUME
CLOCK
AUX
VARIOUS
Selecting a menu item in the
settings menu
Press the softkey 8(next to
"DISPLAY").
DISPLAY MENU
DISPLAY
COLOR
ANGLE
BRIGHT
SPECTRUM
INVERT
DISPLAYDISPLAY
The "DISPLAY" menu appears.
Press the softkey <(next to
"BRIGHT").
•
➔
➔
➔
03_BA_Casablanca_1_ENG.indd Bedienen8503_BA_Casablanca_1_ENG.indd Bedienen85 31.05.2006 11:15:42 Uhr31.05.2006 11:15:42 Uhr
