Blaupunkt Chicago 600 User manual

Radio Navigation
Chicago 600
www.blaupunkt.com
Operating instructions
Chicago600_gb.indd 1Chicago600_gb.indd 1 27.02.12 11:2227.02.12 11:22

2
Controls
1 MENU button
Call up main menu
In the main menu: Call up menu of active source
2 MAP button
Call up navigation
In navigation mode: Call up menu of active source
3 Microphone
4 Rotary/pushbutton
Short press: Switch on device
In operation: Mute audio source
Long press: Switch o device
Turn: Adjust volume
5 Infrared receiver
6 Reset button
Restoring the original factory settings of the device.
Caution! All personal settings will be lost!
7 Cover
8 SD card reader
Access only with open cover
9 Front AV-IN socket (source AV-IN 1)
Access only with open cover
: Front USB socket (source USB 1)
Access only with open cover
; Display button
Turns o the display
< Touchscreen user interface
= MicroSD card reader for navigation data
Access only with open cover
1
2
4
7
5
3
6
13
12
11
8
9
10
Chicago600_gb.indd 2Chicago600_gb.indd 2 27.02.12 11:2227.02.12 11:22

3
Contents
Safety notes ................................................................ 4
Symbols used ...........................................................................4
Road safety................................................................................4
General safety notes ..............................................................4
Declaration of conformity....................................................4
Cleaning notes............................................................ 4
Disposal notes............................................................. 4
Scope of delivery ........................................................ 5
Placing the device in operation................................. 5
Switching on/o......................................................................5
Volume........................................................................................5
Main menu ................................................................................5
Radio mode ................................................................. 5
Start radio mode .....................................................................5
Select memory bank..............................................................5
Tuning into a station..............................................................5
Storing stations manually....................................................6
Storing stations automatically (Travelstore) .................6
Switching RDS on/o ...........................................................6
Trac information ..................................................................6
Navigation................................................................... 7
Loading navigation data......................................................7
Download of map data.........................................................7
Starting the navigation.........................................................7
Initial startup ............................................................................7
Entering a destination...........................................................7
Address ......................................................................................7
Points of Interest ....................................................................8
Setting route options ............................................................9
Map Settings.......................................................................... 10
USB/SDHC/iPod media playback ............................ 11
Basic information ................................................................. 11
USB data carrier .................................................................... 11
SDHC cards............................................................................. 11
iPod/iPhone via USB ........................................................... 11
Audio playback of USB, SDHC or iPod/iPhone .......... 12
Video playback from USB or SDHC (AVI format) ....... 12
Image playback from USB or SDHC............................... 13
Bluetooth mode........................................................ 14
Starting Bluetooth mode .................................................. 14
Registering Bluetooth devices ........................................ 14
Telephone mode - Bluetooth........................................... 14
Bluetooth settings ............................................................... 15
Rear Seat Entertainment (RSE) ................................ 15
External audio/video sources.................................. 16
Sound settings.......................................................... 16
Volume distribution (fader/balance) ............................ 16
Equalizer.................................................................................. 16
Basic settings ............................................................ 17
General .................................................................................... 17
Time .......................................................................................... 17
Sound....................................................................................... 17
Language................................................................................ 18
Bluetooth ................................................................................ 18
Video......................................................................................... 18
Volume..................................................................................... 18
Useful information ................................................... 19
Warranty.................................................................................. 19
Service...................................................................................... 19
Connection diagram ................................................ 20
Appendix................................................................... 21
Chicago600_gb.indd 3Chicago600_gb.indd 3 27.02.12 11:2227.02.12 11:22

4
Safety notes | Cleaning notes | Disposal notes
Safety notes
The car sound system was manufactured according to
the state of the art and established safety guidelines.
Even so, dangers may occur if you do not observe the
safety notes in these instructions.
These instructions are intended to familiarise you with
the most important functions. Detailed information can
be found on the Internet under www.blaupunkt.com.
• Read these instructions carefully and completely
before using the car sound system.
• Keep the instructions at a location so that they
are always accessible to all users.
• Always pass on the car sound system to third parties
together with these instructions.
In addition, observe the instructions of the devices used
in conjunction with this car sound system.
Symbols used
These instructions employ the following symbols:
DANGER!
Warns about injuries
DANGER!
Warns about high volume
The CE mark conrms the compliance with EU
directives.
쏅Identies a sequencing step
• Identies a listing
Road safety
Observe the following notes about road safety:
• Use your device in such a way that you can always
safely control your vehicle. In case of doubt, stop
at a suitable location and operate your device while
the vehicle is standing. As the driver, you may not use
the applications that will distract you from trac (de-
pending on the scope of functions of the device, e.g.
viewing videos, entering a destination).
• Follow the driving recommendations during the
route guidance only if you are not violating any
trac regulations! Trac signs and trac regula-
tions have always priority over driving recommenda-
tions.
• Always listen at a moderate volume to protect
your hearing and to be able to hear acoustic warn-
ing signals (e.g. police sirens). During mute phases
(e.g. when changing the audio source), changing the
volume is not audible. Do not increase the volume
during this mute phase.
General safety notes
Use as directed
This car sound system is intended for installation and
operation in a vehicle with 12 V vehicle system voltage
and must be installed in a DIN slot. Observe the output
limits of the device. Repairs and installation, if necessary,
should be performed by a specialist.
Installation instructions
You may only install the car sound system yourself if you
are experienced in installing car sound systems and are
very familiar with the electrical system of the vehicle. For
this purpose, observe the connection diagram at the end
of these instructions.
Declaration of conformity
We, Blaupunkt AudioVision GmbH & Co. KG, arm that
the device Chicago 600 fulls the fundamental require-
ments and other relevant regulations of the EU Directive
1999/5/EC.
The declaration of conformity can be found on the Inter-
net under www.blaupunkt.com.
Cleaning notes
Solvents, cleaning and scouring agents as well as dash-
board spray and plastics care product may contain in-
gredients that will damage the surface of the car sound
system.
Use only a dry or slightly moistened cloth for cleaning the
car sound system.
Disposal notes
Do not dispose of your old unit in the household
trash!
Use the return and collection systems available to
dispose of the old device.
Chicago600_gb.indd 4Chicago600_gb.indd 4 27.02.12 11:2227.02.12 11:22

5
Scope of delivery
The scope of delivery includes:
• Chicago 600
• TMC Tuner (for 1 011 103 600 only)
• MicroSD card with navigation data in the MicroSD
card slot (only for devices with navigation)
• GPS antenna
• External Bluetooth microphone
• Getting started
• Support frame
• Small parts set
• Installation material
• Connecting cable
Placing the device in operation
Switching on/o
Switching on/o with the rotary/pushbutton
쏅For switch-on, press the rotary/pushbutton
4 .
쏅For switch-o, hold the rotary/pushbutton
4
pressed for more than 2 seconds.
Switching on/o via vehicle ignition
If the car sound system is connected with the vehicle
ignition and it was switched o with the rotary/pushbut-
ton
4 , it is switched on or o with the ignition.
Volume
Adjusting the volume
You can adjust the volume in steps from 0 (o) to 50
(maximum).
쏅Turn the rotary/pushbutton
4 to change the vol-
ume.
Muting the car sound system (Mute)
쏅Briey press the rotary/pushbutton 4 to mute the
device or to reactivate the previous volume.
Main menu
In the main menu, you press the buttons on the touch-
screen to call up the dierent sources and operating
modes.
쏅Press the MENU button
1 .
The main menu is displayed.
As long as you do not select a new audio source, the
last active audio source is played back.
Note:
The gures used in these instructions are intended
to facilitate the explanations and details may deviate
from your device.
Radio mode
Start radio mode
쏅In the main menu, press the Radio button.
The radio menu is displayed.
Select memory bank
Dierent memory banks and wavebands are available.
Up to 6 stations can be stored in each memory bank.
쏅Press the button repeatedly until the desired
memory bank is displayed.
Tuning into a station
Tuning into stations manually
쏅Briey press the or button once or sev-
eral times to change the frequency in increments.
Scope of delivery | Startup | Radio mode
Chicago600_gb.indd 5Chicago600_gb.indd 5 27.02.12 11:2227.02.12 11:22

6
Enter broadcast frequency directly
If the frequency of the desired stations is known, it can
be entered directly via the touchscreen.
쏅In radio mode, press the button.
A numeric keypad is displayed for the frequency
input.
쏅Enter the frequency of the desired station with the
numeric keypad.
쏅Press the button.
The radio menu is displayed, the station of the
frequency entered is played back.
Starting station seek tuning
쏅Press the or button for approx. 2 seconds
to start station seek tuning.
The radio tunes into the next receivable station.
Note:
For the reception area Europe: In the FM waveband,
only trac information stations are tuned into if the
priority for trac information is switched on.
Storing stations manually
쏅Select the desired memory bank with the but-
ton.
쏅Set the desired station.
쏅Press the button.
The menu for storing stations is displayed. 6 memory
locations are available that are displayed as buttons.
쏅Press the button under which you want to store the
current station.
The station is stored, the radio menu is displayed
again.
Storing stations automatically
(Travelstore)
With Travelstore, you can automatically search for and
store the 6 FM stations oering the strongest reception
in the region in the memory bank FM1, FM2 or FM3.
쏅Select an FM memory bank.
쏅In the radio menu, press the button.
쏅In the options menu, press the Travelstore button.
The tuner starts the automatic station seek tuning.
After the storing is completed, the radio plays the
station at memory location 1 of the previously se-
lected memory bank.
Note:
With switched-on priority for trac information, only
trac information stations are stored.
Switching RDS on/o
Many FM stations broadcast an RDS (Radio Data System)
signal in addition to their programme in the reception
area Europe that allows additional functions, such as the
display of the station name.
쏅In the radio menu, press the button.
쏅The options menu is displayed, the current setting is
shown after RDS.
쏅In the options menu, press the RDS button to change
the setting.
쏅Press the button.
The radio menu is displayed again.
Trac information
In the reception region Europe, an FM station can iden-
tify trac announcements via an RDS signal. If priority for
trac reports is switched on, a trac report is automati-
cally switched through, even if the car sound system is
currently not in radio mode.
Note:
The volume is increased for the duration of the
switched-through trac announcement.You can ad-
just the minimum volume for trac announcements.
Switching priority for trac announcements on/o
쏅In the radio menu, press the TA button to switch the
priority for trac announcements on or o.
The TA button is lit if the priority for trac announce-
ments is switched on.
Setting the minimum volume for trac
announcements
쏅In the radio menu, press the button.
쏅In the options menu, press the TA VOL button.
쏅Adjust the desired volume with the  or but-
ton.
쏅Press the button.
The radio menu is displayed again, the set volume
is stored.
Radio mode
Chicago600_gb.indd 6Chicago600_gb.indd 6 27.02.12 11:2227.02.12 11:22

7
Navigation
Loading navigation data
The navigation software and map data are located on a
MicroSD card. For devices with navigation, the device is
delivered with the MicroSD card in the MicroSD card slot.
To be able to use the navigation, the MicroSD card must
be inserted in the card slot.
쏅Open the cover of the card slot
= .
쏅Insert the MicroSD card with the printed side up into
the slot until it engages.
쏅Close the cover of the slot.
Download of map data
To ensure that you have the latest version of the map
data when you purchase the Chicago 600, you have
30days from the rst GPS positioning to download the
latest version of the map data once and free of charge
to the standard MicroSD card from the Internet at
www.naviextras.com.
You can always purchase map material from this site at
a later time.
Important note:
If the MicroSD card is lost or damaged, the naviga-
tion map license associated with the card will be lost.
In this case, the license must be purchased anew with
a new MicroSD card.
Starting the navigation
쏅In the main menu, press Navigation to start the navi-
gation mode.
The navigation menu is displayed. If you start the
navigation for the rst time, the setup wizard is dis-
played.
Initial startup
If you start the navigation for the rst time, a setup wizard
appears which performs the basic settings for the naviga-
tion.
쏅Adjust the language for the navigation. This can be
a dierent language from the other functions of the
Chicago 600.
쏅Conrm the selection with .
The end-user license agreement is displayed.
쏅Read the end-user license agreement. If you agree
with the terms and conditions, press .
The conguration wizard starts.
쏅Press to continue.
쏅Select a voice for the voice output of the navigation.
Various voices are available for the languages.
쏅Conrm the selection with .
쏅Specify the time format and the units for the naviga-
tion. Next, press .
On the next screen, you can perform your preferred
route settings.
쏅If necessary, change the entries by pressing the dis-
played menu entries.
쏅Press ,after you adjusted the settings.
쏅Touch , to nish the conguration.
The navigation menu is displayed.
Entering a destination
Destinations can be entered in dierent ways: Via the ad-
dress or as point of interest from the database of points
of interest. Points of interest can be sights, museums, sta-
diums, petrol stations.
Address
쏅Open the navigation menu.
쏅Press on Find.
The menu for the destination entry is displayed.
쏅Press Find Address.
Navigation
Chicago600_gb.indd 7Chicago600_gb.indd 7 27.02.12 11:2227.02.12 11:22

8
The menu for the address entry is displayed.
쏅Enter the country, city and street in succession as
well as the intersection or house number. To do so,
press the corresponding entry in the address entry
menu.
A menu for text entry is displayed.
쏅Enter the desired destination via the keyboard.
With every character entered, the entry in the input
line is automatically completed.
쏅If the name of the desired destination is displayed in
the address line, press the button.
The selected destination is displayed on the map.
쏅Press Next to start the route guidance.
The calculation of the route starts. Depending on the
distance between start and destination, the route
calculation may take some time.
After the route calculation is complete, the param-
eters of the route, such as distance and time, are
displayed. In addition, the entire route is displayed
on the map.
쏅Press Go! to start the route guidance.
Points of Interest
쏅Open the navigation menu.
쏅Press on Find.
The menu for the destination entry is displayed.
쏅Press Find Places.
The point of interest menu is displayed.
쏅You can select a point of interest from one of the
four predened categories Petrol Station, Parking,
Restaurant and Accommodation or start a separate
search.
쏅For example, press on Petrol Station to quickly nd
a petrol stations.
Navigation
Chicago600_gb.indd 8Chicago600_gb.indd 8 27.02.12 11:2227.02.12 11:22

9
A list of petrol stations in the vicinity of the vehicle is
displayed. The petrol stations are sorted by distance
to vehicle.
쏅Select a petrol station from the list by pressing on the
list entry.
The petrol stations is displayed on the map.
쏅Press Next.
The route course and the route data are displayed.
쏅Press Go! to start the route guidance.
Setting route options
In the route options, the vehicle type, type of route
(quick, short, dynamic) and additional parameters are
dened which are required by the device to calculate the
route according to your requirements.
You dene the route options during the initial congura-
tion of the navigation, but you can change them for any
route guidance.
Adjusting route options before the route guidance
쏅Call up the navigation menu.
쏅Press More….
쏅Press Settings.
The settings menu for the navigation is displayed.
쏅Press on the button to display the second page.
쏅Press Route Settings.
The route settings are displayed.
쏅Change the settings, if necessary.
쏅Press Back repeatedly until the navigation menu is
displayed again.
Navigation
Chicago600_gb.indd 9Chicago600_gb.indd 9 27.02.12 11:2227.02.12 11:22

10
Changing route options during route guidance
쏅During a route guidance, press the More button.
쏅Press Route Settings.
The route settings are displayed.
쏅Change the settings, if necessary.
쏅Press Back.
The route guidance is displayed again.
Map Settings
With the map settings, you can adjust the view mode
(2D or 3D), the viewing angle of the map, the colours and
the display of buildings and points of orientation on the
map. In addition, you can specify for categories of points
of interest whether they should be displayed on the map,
e.g. car dealerships, cafés, restaurants.
쏅Call up the navigation menu.
쏅Press More….
쏅Press Settings.
The settings menu for the navigation is displayed.
쏅Press on the button to display the second page.
쏅Press Map Settings.
The map settings are displayed.
쏅Change the settings, if necessary.
쏅Press Back repeatedly until the navigation menu is
displayed again.
Note:
You can also change the map settings during the
route guidance:
쏅During a route guidance, press the More button.
쏅Press Map Settings.
The map settings are displayed.
쏅Change the settings, if necessary.
쏅Press Back.
The route guidance is displayed again.
Navigation
Chicago600_gb.indd 10Chicago600_gb.indd 10 27.02.12 11:2227.02.12 11:22
