Blaupunkt COBURG DJ A User manual

Coburg RCM 127
Casablanca RCM 127
Cannes RCM 127
Woodstock DJ I
Woodstock DJ A
Radio / Cassette / Changer
Operating instructions
Coburg ..RCM127 d 13.02.2001, 10:15 Uhr1

2
1
3
2
11
9
45
12
15
8
7
6
13
10
16
17
18 14
Coburg
Woodstock
Casablanca
Cannes
Woodstock
RCM 127
RCM 127
DJ A
RCM 127
DJ I
3
2
4
11
Fernbedienung RC 06 (Option)
Remote control RC 06 (optional)
Télécommande RC 06 (en option)
Telecomando RC 06 (optional)
Afstandsbediening RC 06 (Optie)
Fjärrkontroll RC 06 (Tillval)
Mando a distancia RC 06 (opcional)
Telecomando RC 06 (opção)
Coburg ..RCM127 d 13.02.2001, 10:15 Uhr2

27
ENGLISH DEUTSCH
FRANÇAIS
ITALIANO
NEDERLANDS
SVENSKA
ESPAÑOL
PORTUGUÊS
Contents
Quick reference ............................ 28
Important notes ............................ 33
Precautions........................................... 33
Traffic safety ......................................... 33
Installation............................................. 33
Sound source mute .............................. 33
Accessories .......................................... 33
KeyCard theft protection system 34
Putting the unit into operation .............. 34
Removing the KeyCard ........................ 34
“Training” a second KeyCard/
Replacing a KeyCard............................ 34
Displaying the radio pass data ............. 34
Short Additional Memory (S.A.M.)........ 35
Turn On Message (T.O.M.) .................. 35
Optical indication of anti-theft
protection .............................................. 35
Care of your KeyCard........................... 35
Switching the audio source ........ 35
Radio operation with RDS ........... 36
AF - Alternative frequency.................... 36
REG - regional programme .................. 36
Selecting a waveband
(only Casablanca RCM 127,
Cannes RCM 127, Woodstock DJ A)...
36
Station tuning........................................ 37
Automatic tuning / ....................... 37
Manual tuning with << >>.................. 37
Scrolling through the broadcasting
networks................................................ 37
Changing the memory bank ................. 37
Storing stations ..................................... 37
Automatically storing the strongest
stations with Travelstore....................... 38
Recalling stored stations ...................... 38
Scanning stored stations with
Preset Scan .......................................... 38
Scanning stations with Radio-Scan...... 38
Selecting the seek tuning sensitivity .... 39
Switching from stereo to mono............. 39
Loudness .............................................. 39
PTY –Programme-Type....................... 39
Switching PTY on/off......................... 39
Programme type ................................... 39
Checking the programme type of the
station ................................................ 40
Displaying the selected programme
type.................................................... 40
Selecting a programme type ............. 40
Storing programme types.................. 41
Scanning stations with PTY-SCAN... 41
PTY priority........................................ 41
Receiving traffic programme
stations with RDS-EON................ 42
Traffic announcement priority on/off .... 42
Beep tone ............................................. 42
Switching off the beep tone............... 42
Automatic seek tuning start .................. 42
Adjusting the volume for traffic
announcements and the beep tone...... 43
Tape operation ............................. 43
Inserting a tape..................................... 43
Removing a tape................................... 43
Fast Forward/Rewind ........................... 43
Selecting titles with CPS ...................... 43
Switching the tape side (autoreverse).. 44
Tape equalisation ................................. 44
Scanning cassette titles with SCAN ..... 44
Listening to the radio during
fast tape winding with RM .................... 44
Care notes ............................................ 44
CD changer operation.................. 45
Switching to the CD changer mode...... 45
Selecting CDs and titles ....................... 45
MIX playback ........................................ 45
Selecting the display mode .................. 46
SCAN .................................................... 46
DSC programming ....................... 47
Overview of DSC factory settings ........ 49
Appendix....................................... 49
Specifications........................................ 49
Blaupunkt telephone hotline ................. 49
Coburg ..RCM127 gb 13.02.2001, 10:19 Uhr27

28
3For instantly muting the volume.
By pressing the button the volume
can be muted immediately. “MUTE”
will appear in the display.
The function is cancelled by pressing
button or VOL+.
When pressing VOL-, the (mute)
volume will be adopted.
To programme the mute volume level,
proceed as follows:
•Adjust the desired volume.
•Press for 1 second until you
hear a beep.
Now this volume level is stored as your
mute volume.
Switching on/off via the ignition:
When connected correspondingly, the
set can also be turned on and off with
the vehicle ignition.
After the ignition has been switched
off, a double beep tone will remind you
that you should remove the KeyCard
before leaving your vehicle.
Switching on with the ignition being
switched off:
To keep on operating the set when the
ignition is switched off (KeyCard is in-
serted), proceed as follows:
Press ON. The unit will be turned on.
To avoid that the battery goes flat, the
system will be turned off automatically
after one hour of playback.
2VOL+ / VOL-
To alter the volume.
Each time the set is switched on, it will
play with the pre-adjusted volume
(VOL FIX).
You may also change the VOL FIX set-
ting (see chapter “DSC programming”).
Quick reference
1Switching on/off with the ON button:
Press ON.
When switching the set on with the ON
button, the KeyCard has to be insert-
ed. The unit will play with the pre-ad-
justed volume.
Switching on/off with the KeyCard:
The set has to be turned on with the
ON button.
Note:
Read the information in chapter
“KeyCard theft protection system”.
Coburg ..RCM127 gb 13.02.2001, 10:19 Uhr28

29
ENGLISH DEUTSCH
FRANÇAIS
ITALIANO
NEDERLANDS
SVENSKA
ESPAÑOL
PORTUGUÊS
4Rocker switch
Radio operation
/ Station search
Up
Down
<</>> Up/Down in short intervals
(on FM only if AF is off)
On FM only:
<</>> To scroll through the station net-
works when AF is on, e.g.NDR 1, 2,
3, 4, N-JOY, FFN, ANTENNE ...
Tape operation
/ Title selection (S-CPS)
Up
Down
Fast forward
Fast rewind
Stop function by pressing the opposite key.
Changer operation
Optional:
Coburg RCM 127, Casablanca
RCM 127, Cannes RCM 127
Included in scope of delivery:
Woodstock DJ I, Woodstock DJ A
CD selection
Up
Down
Title selection
Upwards: Press briefly.
CUE - fast advance (audible):
Keep depressed.
Downwards: Press as many times
as required.
To re-start a title: Press briefly.
REVIEW - fast reverse (audible):
Keep depressed.
Extra rocker switch functions:
Further setting functions with
AUD B
DSC Mode A
PTY @
Condition: The corresponding function
is activated.
5Display
k
e fgih j
a
l
d
b
c
a) NDR1 NDS - Station name
b) TR 1 - Track (side) 1 of the cas-
sette
c) 1 : 52 - Playback TIME or disc
NUMBER during CD
changer operation
d) FM - Waveband
e) 5 - Preset button (1-6)
f) I, II, T - Memory bank I, II or
Travelstore
g) lo - Seek tuning sensitivity
h) AF - Alternative frequency for
RDS operation
i) TP - A traffic station is being
received
j) TA - Priority for traffic stations
k) LD - Loudness
l) PTY - Programme type function
Coburg ..RCM127 gb 13.02.2001, 10:19 Uhr29

30
6KeyCard theft protection system
To operate the set it is necessary that
the KeyCard is inserted.
KeyCard
Inserting the KeyCard
With the KeyCard tongue sticking out
of the unit, introduce the KeyCard into
the slot with the contact area show-
ing up.
To remove the card, press first to un-
lock.
Read also the information in chapter
“KeyCard theft protection system”.
Flashing KeyCard tongue
When the radio is turned off and the
KeyCard removed, the KeyCard
tongue can be programmed to flash
for optical theft protection.
For more information see chapter
“DSC programming”.
This flashlight can be switched off by
pushing in the tongue and lock.
“WRONG KC”will briefly appear
on the display and the set will switch
off automatically.
7FMT
(Coburg RCM 127,
Woodstock DJ I)
BND (Casablanca RCM 127,
Cannes RCM 127, Woodstock DJ A)
For selection of the FM memory banks
I, II and T (Travelstore).
To switch over:
Press button repeatedly.
The selected memory bank will appear
in the display.
Travelstore
To store and recall the six most power-
ful stations with Travelstore.
To store: Press button for approxi-
mately 1 sec. until you hear a beep
and “T-STORE”appears in the display.
To recall: Select the memory bank “T”
and press the corresponding preset
button (1-6) briefly.
Casablanca RCM 127,
Cannes RCM 127, Woodstock DJ A:
Additional selection of medium- and
long-wave stations, provided that “AM
ON”has been adjusted in the DSC
menu.
8AF
Alternative frequency during RDS op-
eration:
When “AF”lights up in the display, the
system will automatically seek a fre-
quency offering better reception of the
same RDS programme.
AF on/off: Press AF briefly.
Regional function on/off:
Press the AF button for approximately
1 sec. until you hear a beep. “REG-
ON”or “REG-OFF”will appear in the
display (see chapter REG - regional
programme).
9TA (priority for traffic announcements)
When “TA”lights up in the display, the
system will play traffic stations only.
Priority on/off: Press TA.
:1, 2, 3, 4, 5, 6 - preset buttons
You can store six stations for each of
the memory banks I, II and T.
To store a station: Press a preset
button during radio operation and hold
down until the set resumes play after
the muting and you hear a beep.
To recall a station: Select the desired
memory bank and press the relevant
preset button briefly.
Coburg ..RCM127 gb 13.02.2001, 10:19 Uhr30

31
ENGLISH DEUTSCH
FRANÇAIS
ITALIANO
NEDERLANDS
SVENSKA
ESPAÑOL
PORTUGUÊS
?SC
Radio operation
Scan
Press SC briefly.
The scanned frequency or the station
name will start flashing in the display.
During the actual scanning process
“FM-SCAN”or “AM-SCAN”will be dis-
played. The unit will scan all FM sta-
tions which can be received.
Preset Scan
Press SC for approximately 1 sec. until
you hear a beep.
“SCAN”and the name or frequency of
the scanned station will alternately ap-
pear in the display.
The unit will scan all stations stored on
the preset buttons.
To stop Scan / Preset Scan:
Press SC once again.
Extra function of lo button:
To switch between mono and stereo
reception:
Press button for approximately 1 sec.
(beep).
The selected condition will be briefly
displayed.
=/
To switch the tape side: Press briefly.
To eject the tape: Press for approxi-
mately 1 sec.
Extra function /
Frequency display during radio opera-
tion:
Press button briefly.
The frequency will be briefly displayed.
>Cassette loading slot
Insert the tape with side A or 1 facing
up, the open side showing to the right.
Extra function of preset buttons
To store and recall a PTY programme
type.
When PTY is active (“PTY”lights up in
the display), you can store and recall
one programme type on/from each
preset button on FM.
;SRC (Source)
You can switch between the radio,
tape and CD changer operating
modes, provided that a cassette/CD is
inserted.
<lo
To switch the seek tuning sensitivity
level:
Press button briefly.
If “lo”is displayed, the radio will only
pick up strong, local stations (normal
sensitivity).
If “lo”does not light up, the radio will
also pick up weaker, distant stations
(high sensitivity).
Coburg ..RCM127 gb 13.02.2001, 10:19 Uhr31

32
Tape operation
Cassetten-Scan
Press SC.
“CC-SCAN”will appear in the display.
All cassette titles will be scanned brief-
ly.
To stop cassette scan:
Press SC once again.
Changer operation
CD-Scan
Press SC briefly.
“CDC-SCAN”will appear in the dis-
play.
All CD titles will be scanned briefly.
To stop CD-Scan:
Press SC once again.
@PTY (Programme Type)
In the PTY mode, the preset buttons
become programme type buttons. With
every preset you can select one pro-
gramme type, such as for example
NEWS, SPORT, POP MUSIC, EDU-
CATE, etc.
ADSC (Direct Software Control)
Use the DSC function to customise
certain programmable, basic settings
to suit your personal needs and prefer-
ences. See chapter “DSC program-
ming”for more information.
BAUD
To adjust the treble, bass, balance and
fader.
If the display shows “TRE”or “BAS”,
you can adjust the reproduction of the
treble and bass frequencies with the
rocker switch. If “BAL”or “FAD”is dis-
played, you can set the balance (left/
right) and fader (front/rear).
Press AUD as many times as required
and make the setting using the rocker
switch.
Treble + / Fader front
Treble –/ Fader rear
Bass –/ Balance left
Bass + / Balance right
The last setting will be stored automat-
ically.
To switch off AUD: Press button once
again.
If the setting remains unchanged with-
in 8 seconds, the display will switch
back to the previous condition.
Extra function AUD
Loudness - When listening at a low
level, the Loudness function creates a
more natural sound by boosting
the low frequency range.
Loudness on/off: Press AUD for ap-
proximately 1 sec.
“LD”lights up in the display if the
Loudness function is switched on.
Please refer to chapter “DSC program-
ming”for more information on how to
program the Loudness boost.
Coburg ..RCM127 gb 13.02.2001, 10:19 Uhr32

33
ENGLISH DEUTSCH
FRANÇAIS
ITALIANO
NEDERLANDS
SVENSKA
ESPAÑOL
PORTUGUÊS
Important notes
Precautions
Before starting to use your new car radio,
please read the following information care-
fully.
Traffic safety
Traffic safety always has the highest priori-
ty.
As the driver of a motor vehicle, it is your
responsibility to pay attention to the traffic
situation at all times. Never use your car
radio in a way that could distract you.
Please keep in mind that you travel a dis-
tance of 14 m per second at a speed of only
50 km/h.
Should the traffic situation become particu-
larly demanding, we advise you not to use
the radio.
Always make sure that you are still able to
hear any warning signals coming from out-
side of the vehicle, such as police or fire
engine sirens, so that you can react accord-
ingly.
Therefore, you should always select a mod-
eratevolume forplaying your car radio while
you are driving.
Installation
If you would like to install your new car ster-
eo yourself or add other audio components
to existing ones, then please read carefully
the enclosed instructions on installation and
connection.
Inorder to ensurethat the set operatesprop-
erly it is necessary that the positive power
supply line is connected to the ignition and
the permanent +12 V lead.
Do not ground the loudspeaker outputs!
Telephone mute
Ifthereis a mobile telephoneinstalledin your
vehicle, the radio, tape player or CD player
canbe mutedautomatically when the phone
is being used.
“PHONE”will then appear in the display.
When TA is active, traffic messages will al-
ways have priority. The announcement will
be aborted by pressing the TA button.
Accessories
Use accessories and spare parts approved
by Blaupunkt only.
You can use the following Blaupunkt prod-
ucts with this car radio:
Amplifier
All Blaupunkt amplifiers, the preamp-out
cable 7 607 893 093 is required.
Changer
CDC A 05/F 05
(adapter cable 7 607 889 093 is required),
CDC A 06
(Woodstock DJ I, Woodstock DJ A):
CDC A 06 included in the delivery.
Remote control
With the infrared remote control RC 06 you
can control all of the important functions of
your car radio system from the steering
wheel.
Coburg ..RCM127 gb 13.02.2001, 10:19 Uhr33

34
Thesystem will switchoff after approximate-
ly 10 seconds.
When inserting another card type (e.g.
phone or credit card), the display will show
“WRONG KC”for approximately 2 seconds.
The set will switch off automatically.
Remove the wrong card and introduce the
correct KeyCard.
•Press ON to turn on the set.
Removing the KeyCard
Never pull out the KeyCard directly!
•First, slightly push in the KeyCard.
Thisreleasesthe card andputsit in theprop-
er position for being removed.
•Now you can pull it out.
“Training”a second KeyCard/
Replacing a KeyCard
While operating the unit with the first
KeyCard, you can “train”a second one to
be also used with the set:
•Insert the first KeyCard and turn on the
set.
•Press the DSC button and select
“LEARN KC”with / .
•Press << or >>.
The display will switch to “CHANGE”.
•Push in the KeyCard. The card is re-
leased and put in the proper position
for being removed.
•Remove the first KeyCard and insert
the new one.
After the display indication “READY”or
“LEARN KC”,
•press DSC.
Now you can also use the new KeyCard for
operating your unit.
A maximum of two cards can be used for
the set.
When trying to “train”a third one, the ac-
cess authorisation for the KeyCard not used
for the “training”process will be deleted au-
tomatically.
Displaying the radio pass data
Using the KeyCard supplied with your set
you can have the radio pass data such as
the model name, product number (7 6..) and
serial number indicated on the display pan-
el.
Please refer to chapter “DSC programming
- READ KC”.
KeyCard theft protection system
This car radio is supplied with one KeyCard
as standard, though it can also be operated
with a second card.
If you have lost your KeyCard or if it was
damaged, you can buy a new one from your
specialised dealer.
When using a second KeyCard, the settings
storedon the first card willbe adopted. How-
ever, you can individually store the follow-
ing functions:
Bass, treble, balance and fader settings,
Loudness, TA (traffic announcement vol-
ume), beep volume.
In addition, the settings activated before
switching the radio off, such as the station
tuned in, TA priority, AF, AM ON/OFF and
RM ON/OFF will also remained stored.
This ensures that you will find your basic
settings re-adjusted automatically as soon
as you have inserted your KeyCard.
Putting the unit into operation
•Turn on the set.
With the KeyCard tongue sticking out,
introduce the KeyCard into the slot
with the contact area showing up.
The car radio is now ready for operation.
If a wrong KeyCard is inserted, then “CARD
ERR”followed by “WAIT”will appear in the
display. In this case please do not make any
further adjustments.
Coburg ..RCM127 gb 13.02.2001, 10:19 Uhr34

35
ENGLISH DEUTSCH
FRANÇAIS
ITALIANO
NEDERLANDS
SVENSKA
ESPAÑOL
PORTUGUÊS
Switching the audio source
Using the SRC button you can switch be-
tween the following audio sources:
radio,
tape,
changer (optional for Coburg RCM
127, Casablanca RCM 127 and
Cannes RCM 127)
.
Tape/changer operation is only available if
a cassette/disc is inserted.
To switch to another source,
•press SRC briefly.
Short Additional Memory
(S.A.M.)
Using the second KeyCard to be purchased
at any specialised dealership, you can pro-
grama short textby selecting the DSCmenu
item READ KC. This text will be moved
through the display and might be the tele-
phone number of a car repair service or the
emergency call number of your auto club.
Any specialised dealer with the proper
equipmentcan program thedesired text with
up to a maximum of 162 characters onto the
KeyCard.
Turn On Message (T.O.M.)
Using the second KeyCard to be purchased
at any specialised dealership, you can pro-
gram the unit to display a selected “Turn On
Message”after the set is switched on.
Any specialised dealer with the proper
equipmentcan program thedesired text with
up to a maximum of 48 characters onto the
KeyCard.
Each time you switch on your car radio us-
ing the second KeyCard, this text will ap-
pear in the display.
Optical indication of anti-theft
protection
Flashing KeyCard tongue
When the vehicle is stationary and the
KeyCard removed, the KeyCard tongue can
be switched to flash for extra anti-theft se-
curity.
Forthis itis necessarythat the positive pow-
ersupply lineand thepermanent +12V lead
are connected such as described in the in-
stallation instructions.
Be sure that “LED ON”is adjusted in the
DSC mode.
If required, please refer to chapter “DSC
programming - LED”.
Switching off the flashlight
The flashlight can be switched off by push-
ing in the KeyCard and lock.
If you would like to deactivate the flashing
tongue with general effect, adjust the rele-
vant item in the DSC menu to “LED OFF”.
Care of your KeyCard
In order to ensure that the KeyCard always
functions correctly, it is important for the
contacts to be free from any foreign parti-
cles. Avoid direct skin contact.
If necessary, clean the KeyCard contacts
using a cotton swab dipped in alcohol.
Coburg ..RCM127 gb 13.02.2001, 10:19 Uhr35

36
switching on the radio or recalling one of the
stored frequencies, the unit is automatically
searching for an alternative frequency.
“SEARCH”will disappear from the display
when the alternative frequency has been
found or after the frequency band has been
run through completely.
If the reception quality of the selected pro-
gramme becomes too bad:
•Tune into another station.
REG - regional programme
Certain radio programmes are split up at
times into regional programmes offering lo-
cal information. The 1st programme broad-
cast by NDR, for example, offers pro-
grammeswith different contents inthe north-
ern states of Germany Schleswig-Holstein,
Hamburgand Lower Saxonyat certain times
of the day.
If you are listening to one regional pro-
gramme and move to an area where anoth-
er linked regional programme becomes
stronger, the unit will switch to that pro-
gramme.
If you wish to continue listening to the first
programme,
•press the AF button for approximately
1 sec.
“REG ON”appears in the display.
If you leave the service area of the regional
programme tuned into, or if you would like
to take advantage of the full RDS service,
switch to “REG OFF”.
•Press the AF button for approximately
1 sec. until “REG OFF”appears.
If the REG function is active, “REG ON”will
be briefly displayed each time the radio is
switched on.
Selecting a waveband
(only Casablanca RCM 127,
Cannes RCM 127, Woodstock DJ A)
You can select between the following wave-
bands:
FM 87.5 - 108 MHz
MW 531 - 1602 kHz
LW 153 - 279 kHz
•Press the BND button until the desired
waveband shows on the display panel.
Note:
In the DSC menu you can deactivate the
station selection on either MW or LW or for
both wavebands at the same time.
This has the advantage that only the re-
quired bands will allow to be activated, so
that you must press the BND button less
often. For more information, please refer to
chapter “DSC programming - AM ON/OFF”.
Radio operation with RDS (Radio Data System)
The Radio Data System offers you more
conveniencewhen listeningto FMradio sta-
tions.
More and more radio stations have begun
to broadcast RDS information alongside
their programmes.
As soon as a programme has been identi-
fied, the station name including a regional
identifier,if applicable,will appearin thedis-
play,for example, NDR1 NDS (regional pro-
gramme in Lower Saxony, Germany).
When RDS is activated, the preset buttons
becomeprogramme buttons. You now know
exactly which programme you have tuned
into, making it easy to find the desired sta-
tion quickly.
But RDS offers you further advantages:
AF - Alternative frequency
The AF (Alternative Frequency) function
makes sure that the strongest frequency of
the currently selected programme is always
tuned in automatically.
Thisfunction is activatedwhen “AF”appears
in the display.
In order to switch this function on or off,
•press the AF button briefly.
While searching for the strongest reception
signal, the radio may switch to mute briefly.
If “SEARCH”appears in the display when
Coburg ..RCM127 gb 13.02.2001, 10:19 Uhr36

37
ENGLISH DEUTSCH
FRANÇAIS
ITALIANO
NEDERLANDS
SVENSKA
ESPAÑOL
PORTUGUÊS
Manual tuning:
•Press << >>; the frequency will change
in short intervals in downwards or up-
wards direction.
Whenholdingthe right orleftpart of therock-
er switch depressed, the frequency scan is
speeded up.
Scrolling through the broadcast-
ing networks
You can use the << >> buttons to tune in
stations of your reception area.
If several programmes of the broadcasting
networks can be received, you can scroll
through them in forwards direction pressing
>>, or backwards using the << button, e.g.
NDR 1, 2, 3, 4, N-JOY, FFN, ANTENNE ...
Forthis it is necessary that the stationshave
been tuned in at least once and that “AF”is
active (lights up in the display).
For this purpose, you may start Travelstore
seek operation:
•Press FMT or BND for 1 sec.; the
system starts to run through the fre-
quency band. The display shows
“T-STORE”.
If “AF”does not light up,
•press AF.
This fulfils the requirements for selecting
stations with << >>.
Station tuning
Automatic tuning /
•Press /; the car radio will automati-
cally search for the next station.
When keeping the upper or lower part /
of the rocker switch depressed, seek tuning
will speed up in upwards or downwards di-
rection.
Seek tuning
Up
Down
Down in short intervals
(“AF”must be switched off)
Up in short intervals
(“AF”must be switched off)
Manual tuning with << >>
You can also tune in a station manually.
Condition:
AF and PTY must be switched off (i.e. the
symbols do not light up in the display).
If necessary, deactivate these functions:
•Press AF or PTY briefly.
Changing the memory bank
You can shift between the memory banks I,
II and T in order to store stations and recall
them later.
The currently selected memory bank is in-
dicated in the display.
•Press the FMT or BND button as many
times until the desired memory bank
lights up in the display.
Storing stations
On FM, you can store six stations on the
preset buttons 1-6 for each of the memory
banks I, II and T.
On MW/LW, you can also store six stations
each. (only with Casablanca RCM 127,
Cannes RCM 127, Woodstock DJ A)
•Select the desired memory bank.
•Tune in a station with the rocker switch
(either automatically or manually).
•Press and hold down the desired pre-
set button until the radio resumes play
after the muting (takes approximately 1
sec., confirmed by beep).
Now the station has been stored.
The activated preset button is indicated in
the display.
Coburg ..RCM127 gb 13.02.2001, 10:19 Uhr37

38
Recalling stored stations
Youcanrecall any stored stationat the touch
of a button.
•Select the memory bank with FMT or
BND.
•Press the corresponding preset button
briefly to recall the station.
Scanning stored stations with
Preset Scan
Youcan have allof the stored stationsbriefly
scanned on all wavebands.
To start Preset Scan:
•Press SC for approximately 1 sec.
All of the stored stations to be received will
be scanned one after the other.
To select a scanned station and switch
off Preset Scan:
•Press SC briefly.
Note:
If “TA”shows on the display panel, the sys-
tem will scan the stored traffic stations only.
Scanning stations with Radio-
Scan
You can also scan all stations which can
currently be received.
To start the Scan function:
•Press SC briefly.
The scanned frequency or the station name
will start flashing in the display. During the
actual scanning process “FM-SCAN”or
“AM-SCAN”will be displayed.
To select a scanned station and switch
off Radio-Scan:
•Press SC briefly.
If no station is selected, the scan function
will be automatically switched off after the
frequency band has been run through com-
pletely. The unit will tune in the station lis-
tened to before starting the scan.
Notice:
Should you tune in a station which has al-
ready been stored before, then the corre-
sponding preset position and memory bank
will briefly flash in the display.
Automatically storing the
strongest stations with
Travelstore
You can automatically store the six most
powerful FM stations of your current recep-
tion area sorted according to their signal
strength.Thisfunction is particularlyconven-
ient on longer trips.
•Press the FMT or BND button for
1 sec.
“T-STORE”will appear in the display.
The six strongest FM stations will be auto-
matically stored on the memory bank “T”
(Travelstore). When this process has been
completed, the radio will play the first sta-
tion stored on preset 1.
If desired, stations can also be stored man-
ually on the Travelstore bank (see “Storing
stations”).
Coburg ..RCM127 gb 13.02.2001, 10:19 Uhr38

39
ENGLISH DEUTSCH
FRANÇAIS
ITALIANO
NEDERLANDS
SVENSKA
ESPAÑOL
PORTUGUÊS
Selecting the seek tuning sensi-
tivity
You can alter the automatic seek tuning
sensitivity.
If “lo”is displayed, the radio will only pick up
strong, local stations.
If “lo”does not light up, the radio will also
pick up weaker, distant stations.
To switch the seek tuning sensitivity:
•Press lo briefly.
The sensitivity level can be altered sepa-
rately in both modes. Please refer to chap-
ter “DSC programming - S-LO, S-DX”).
Switching from stereo to mono
Every time the radio is switched on, stereo
playback is activated automatically.
The unit will gradually switch to mono if re-
ception is poor.
Youcanalso switch betweenmonoand ster-
eo reception manually:
•Press the lo button for approximately
1 sec.
The selected condition will briefly appear in
the display.
Loudness
Adjusts the low bass frequencies for a more
natural sound.
Switching Loudness on/off:
•Press the AUD button for approximate-
ly 1 sec.
When the Loudness function is active, “LD”
will light up in the display.
See chapter “DSC programming”for more
information.
PTY –Programme-Type
PTY is an RDS service offered by more and
moreradio broadcasters. This featureallows
you to select FM stations according to their
programme type. After you have chosen the
PTY of your preference, the corresponding
stations can be selected either by seek tun-
ing or using the scan function.
Switching PTY on/off
•Press PTY.
When the function is active, the programme
type selected last will briefly appear in the
display. “PTY”will be permanently indicat-
ed in the lower right corner of the display
panel.
Programme type
Use << >> to have the last selected pro-
grammetype displayed and tochoose a new
one.
You can select any one of the stored types
with the preset buttons 1-6.
Condition: PTY must be active.
Using DSC you can choose between Ger-
man and English (see “DSC programming -
PTY LANG”).
All of the programme types listed below are
available.
The letters printed in bold are identical to
the actual short-time indication in the dis-
play.
NEWS
CURRENT AFFAIRS
INFORMATION
SPORT
EDUCATE
DRAMA
CULTURE
SCIENCE
VARIED
POP MUSIC
ROCK MUSIC
M.O.R. M (middle of the road music)
LIGHT M (light classical)
CLASSICS (serious classical)
Coburg ..RCM127 gb 13.02.2001, 10:19 Uhr39

40
OTHER M (other music)
WEATHER
FINANCE
CHILDREN’S PROGRAMMES
SOCIAL AFFAIRS
RELIGION
PHONE IN
TRAVEL
HOBBIES
JAZZ MUSIC
COUNTRY MUSIC
NATIONAL MUSIC
OLDIES MUSIC
FOLK MUSIC
DOCUMENTARY
ALARM TEST
Checking the programme type of the
station
•Press PTY for approximately 1 sec.
After the beep tone the display will show the
programme type offered by the tuned in sta-
tion.
If “NONE”appears in the display, the cur-
rent station has no PTY code.
Displaying the selected programme
type
•Press << or >>.
The programme type selected last will be
displayed briefly.
Selecting a programme type
a) Using the preset buttons
When PTY is switched on, you can use
the preset buttons 1-6 to select the
programme types stored at the factory.
•Press one of the presets 1-6.
The selected programme type will be
displayed for 2 seconds.
If you wish to listen to a station with
this PTY,
•press /to start seek tuning.
If the system is unable to find a station of-
feringthe selectedprogramme type, the dis-
play will show “NO PTY”and a beep tone
will be released. The station received be-
fore starting seek tuning will be tuned in.
You can assign different programme types
toeach preset position. Pleaserefer to chap-
ter “Storing programme types”.
b) Using the << >> buttons of the rocker
switch
When PTY is switched on, you can se-
lect a programme type using buttons
<< >>.
•Press << or >>; the programme
type selected last will be displayed
for 3 seconds.
•During this period press >> (for-
wards) or << (backwards) to select
the desired type.
•Press << or >> as many times as
required.
If you wish to listen to a station offering
the selected PTY,
•press /to start seek tuning.
If the system is unable to find a station of-
feringthe selectedprogramme type, the dis-
play will show “NO PTY”and a beep tone
will be released. The station received be-
fore starting seek tuning will be tuned in.
Coburg ..RCM127 gb 13.02.2001, 10:19 Uhr40

41
ENGLISH DEUTSCH
FRANÇAIS
ITALIANO
NEDERLANDS
SVENSKA
ESPAÑOL
PORTUGUÊS
PTY priority
Situation:
PTY is switched on and lights up in the dis-
play.
No station offering the selected programme
type can be currently received (neither with
seek tuning nor with scan).
The set will switch back to the previous sta-
tion.
Assoon as a programme with such PTY can
bereceived within the broadcastingnetwork,
the unit will switch over to the correspond-
ing station for the duration of the pro-
gramme.
Example: German broadcasting network
NDR:
- Station tuned in: NDR3.
-“PTY”lights up in the display.
- Programme type “POP”selected.
- Seek tuning is started.
- No station with “PTY-POP”can be
found.
- The display shows “NO PTY”and
- automatically switches back to NDR3.
- NDR2 airs a “PTY-POP”programme.
- The system will switch to the linked
NDR2 station for the duration of the
“POP”programme.
Storing programme types
At the factory, one programme type was
assigned to each of the preset buttons 1-6.
If desired, you can also store other availa-
ble programme types.
To do so, make sure that “PTY”lights up in
the display.
•If necessary, press the PTY button to
switch on the function.
•Select a programme type using but-
tons << >> and
•hold down the desired preset button
(1-6) until you hear a beep.
Now the selected programme type can be
recalledby pressingthis preset. For this, the
PTY function must be active.
Scanning stations with PTY-SCAN
Condition:“PTY”must appear in the display.
•Press the SC button.
All of the received stations offering the se-
lected programme type will be scanned.
To switch off PTY-SCAN:
•Press SC once again.
During tape operation, the set will also au-
tomatically switch to the programme offer-
ing the selected PTY within the broadcast-
ing network.
After the PTY programme the system will
remain in the radio mode.
Notice:
As mentioned earlier, these functions are
currentlyonly supported bya limited number
of RDS stations.
Coburg ..RCM127 gb 13.02.2001, 10:19 Uhr41

42
Receiving traffic programme stations with RDS-EON
Traffic announcement priority
on/off
If the priority for traffic announcement pro-
grammes is activated, “TA”will light up in
the display.
To switch the priority on or off:
•Press the TA button.
When pressing TA while a message is be-
ing broadcast, this message will be inter-
rupted. The unit will then switch back to the
previous condition. The priority for all other
traffic messages remains active.
Please note that several buttons have no
function while a traffic announcement is
broadcast.
Beep tone
If you leave the reception area of the traffic
programme station currently tuned into, you
will hear a beep tone approximately every
30 seconds.
This tone will also be released when press-
ing a preset button which has no traffic pro-
gramme allocated to it.
Switching off the beep tone
a) Tune into another station offering traf-
fic information:
•Press the rocker switch or
•press a preset button which has a
traffic programme station allocated
to it.
Alternatively:
b) Switch off the priority for traffic an-
nouncements:
•Press TA.
“TA”will disappear from the display.
Automatic seek tuning start
(tape and CD changer operation)
Whenleavingthe reception area ofthetuned
in traffic programme station while listening
to a tape or CD, the system will automati-
cally start searching for a new TA pro-
gramme.
If no such station is found within approxi-
mately 30 seconds, you will hear a warning
beep every 30 seconds. To switch off the
beep tone proceed as described above.
The abbreviation “EON”stands for En-
hanced Other Networks, meaning the ex-
changeofinformation within aradionetwork.
Many FM broadcasters offer traffic messag-
es for their service area at regular intervals.
All traffic programme stations transmit a
special carrier signal alongside their pro-
grammes, which is decoded by your car ra-
dio. If this signal is identified, “TP”will ap-
pear in the display (Traffic Programme).
In addition to these, there are also stations
which do not actually transmit traffic pro-
grammes themselves, but by using RDS-
EON they offer the possibility to receive the
traffic messages broadcast by another traf-
fic programme station in the same radio
network.
If you wish to have the priority for traffic an-
nouncements activated while listening to
oneof these stations(e.g. NDR3), “TA”must
appear on the display panel.
If a traffic announcement is broadcast, the
radio will automatically switch to the linked
traffic programme station (in this case,
NDR2) for the duration of the message and
return to the original programme (NDR3)
afterwards.
Coburg ..RCM127 gb 13.02.2001, 10:19 Uhr42

43
ENGLISH DEUTSCH
FRANÇAIS
ITALIANO
NEDERLANDS
SVENSKA
ESPAÑOL
PORTUGUÊS
Adjusting the volume for traffic
announcements and the beep
tone
This volume was preset at the factory,
though you can alter the value using the
DSC function (see “DSC programming, TA
VOL”).
If the volume level is altered while a mes-
sage is being played, this will only affect the
current announcement.
Fast Forward/Rewind
Fast forward
Fast rewind
/ Title selection (S-CPS)
Up
Down
Stop function by pressing .
Selecting titles with CPS
(Cassette Programme Search)
Use this function to skip ( ) and repeat ( )
recorded titles.
To start CPS:
•Press / .
In order for CPS to function properly, there
has to be an unrecorded tape portion of at
least 3 seconds between the individual ti-
tles.
Tape operation
The car stereo has to be switched on.
The unit will automatically switch to tape
operation when inserting a cassette.
Inserting a tape
•Turn on the set.
•Insert a tape.
Thecassette willbe automaticallytransport-
edtothe playback position.SideA or 1starts
to play.
During tape operation, “TR 1”or “TR 2”
(track) will be indicated on the display pan-
el.
Insert the tape with side A or 1 facing up, the open side
showing to the right.
Removing a tape
•Press for 1 sec.
The cassette will eject.
Coburg ..RCM127 gb 13.02.2001, 10:19 Uhr43

44
Switching the tape side
(autoreverse)
Tochange the tapedirection during cassette
playback:
•Press briefly.
At the end of a tape side the mechanism
changes directions automatically to play the
other side (autoreverse). The display shows
“TR 1”for track (side) 1 or “TR 2”for track 2.
Notice:
If there is too much tension on the tape dur-
ing playback, the set may switch over by it-
self before having reached the end of the
tape side. In this case check the condition
of the cassette tape. Sometimes it helps to
rewind it completely.
Tape equalisation
When a metal or CrO2tape is inserted, the
tape mechanism automatically adjusts to
metal/CrO2tape equalisation.
Scanning cassette titles with
SCAN
Youcan have the cassettetitles played brief-
ly by using the scan function. If you like a
title, stop the scan to continue listening to
that track.
To start/stop the scan function:
•Press the SC button briefly.
Scan condition: There has to be an unre-
corded tape portion of at least 3 seconds
between the individual titles.
Listening to the radio during
fast tape winding with RM
(Radio Monitor)
When the tape is fast forwarded or rewound
(also with CPS), the radio will normally be
muted. In order to listen to the radio during
fast winding, you can activate the Radio
Monitor function.
For more information please refer to chap-
ter “DSC programming - RM ON/OFF”.
Care notes
Toavoid possible problems, we recommend
you to use C-60/C-90 type cassette tapes
only. Store your tapes in a cool place away
from dirt, dust and temperatures exceeding
50 °Celsius. Allow very cold tapes to warm
up before playing them in order to avoid
uneven tape transport. After approximately
100 hours of use, dust particles collected
on the playback head or roller may lead to
tape run problems and sound distortions.
Use a head cleaning tape to remove nor-
mal dirt build-up. For tougher cases, use a
cotton swab (Q-Tip) dipped in alcohol. Do
not attempt to clean by inserting a hard ob-
ject into the player!
Coburg ..RCM127 gb 13.02.2001, 10:19 Uhr44
