Blaupunkt BT02 User manual

BT02
Owner's Manual
Instrukcja obsługi
Návod k obsluze
Návod na použitie
Felhasználói kézikönyv
Bluetooth speaker
Głośnik Bluetooth
Bluetooth reproduktor
Bluetooth reproduktor
Bluetooth hangszóró

BT02
IMPORTANT NOTES
To achieve the utmost in enjoyment and performance, and in
order to become familiar with its features, please read this
manual carefully before attempting to operate this product.
This will assure you years of trouble free performance and
listening pleasure.
For safety reasons, do not remove any covers or attempt to gain
access to the inside of the product. Refer any servicing to
qualified personnel.
Do not attempt to remove any screws, or open the casing of the
unit; there are no user serviceable parts inside. Refer all
servicing to qualified service personnel.
SAFETY INSTRUCTIONS
This safety and operating instruction should be retained
for future reference.
The apparatus should not be exposed to dripping or s
plashing or placed in a humid atmosphere such as a
bathroom.
Do not install the product in the following areas:
Places exposed to direct sunlight or close to radiators.
On top of other stereo equipment that radiate too
much heat.
Blocking ventilation or in a dusty area.
Areas where there is constant vibration.
Humid or moist places.
Do not place near candles or other naked flames.
Operate the product only as instructed in this manual.
•
•
•
•
•
•
•
•
•
•
Read Instructions - All the safety and operating
instructions must be read before the product is operated.
Retain Instructions - The safety and operating
1.
2.
1

BT02
instructions should be kept with the product for future
reference.
Heed warnings - All warnings on the product and in the
operating instructions should be adhered to.
Follow instructions - All operating and users’ instructions
should be followed.
Water and moisture - To reduce the risk of fire or electric
shock, do not expose the product to train, dripping,
splashing or excessive moisture such as in a sauna or
bathroom. Do not use this product near water, for
example, near a bathtub, washbowl, kitchen sink, laundry
tub, in a wet basement or near a swimming pool (or
similar).
Object and Liquid Entry - Never push objects of any kind
into this product through openings, as they may touch
dangerous voltage points or short-circuit parts that could
result in a fire or electric shock. Never spill liquid of any
kind on the product. Do not place any object containing
liquid on top of the product.
Servicing - Do not attempt to service this product
yourself, as opening or removing covers may expose you
to dangerous voltage or other hazards. Refer all servicing
to qualified service personnel.
Replacement parts - When replacement parts are
required, ensure that the service technician has used
replacement parts specified by the manufacturer or have
the same characteristics as the original part. Unauthorized
substitutions may result in fire, electric shock or other
hazards.
Place your clock radio on a stable surface, away from
sources of direct sunlight or excessive heat or moisture.
Protect your furniture when placing your units on a
3.
4.
5.
6.
7.
8.
9.
10.
2

BT02
natural wood and lacquered finish by using a cloth or
protective material between it and the furniture.
Clean your unit with a soft cloth moistened only with mild
soap and water. Stronger agents such as Benzine, thinner
or similar materials can damage the surface of the unit.
Make sure the unit is unplugged before cleaning.
Battery
1). The batteries must not be exposed to excessive heat
such as sunshine, fire or the like.
2). The batteries should be drawn to the environmental
aspects of battery disposal.
11.
12.
WARNING
This appliance is not intended for use by persons (including
children) with reduced physical sensory or mental capabilities,
or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the
appliance by a person responsible for their safety. Children
should be supervised to ensure that they do not play with the
appliance.
The apparatus must not be exposed to dripping or
splashing and that objects filled with liquids, such as
vases, must not be placed on the apparatus.
To prevent fire or shock hazard, do not expose this
equipment to hot places, rain, moisture or dust.
Do not locate this unit near any water sources e.g. taps,
bathtubs, washing machines or swimming pools. Ensure
that you place the unit on a dry, stable surface.
Do not place this unit close to a strong magnetic field.
Do not place the unit on a amplifier or receiver.
Do not place this unit in a damp area as the moisture will
1.
2.
3.
4.
5.
6.
3

BT02
affect the life of electric components.
If the clock is brought directly from a cold to a warm
location, or is placed in a very damp room, moisture may
condense on the lens inside the player. If this occurs, the
system will not operate properly. Please leave the system
turned on for about an hour until the moisture evaporates.
Do not attempt to clean the unit with chemical solvents as
this might damage the finish. Wipe with a clean, dry or
slightly damp cloth.
7.
8.
NOTICE
This product complies with the radio interference
requirements of the European community.
Your products is designed an manufactured with high quality
materials and components, which can be recycled and reused.
When this crossed-out wheeled bin symbol is attached to a
product it means that the product is covered by the European
Directive 2002/96/EC. Please inform yourself about the local
separate collection system for electrical and electronic
4

BT02
products. Please cat according to your local rules and do not
dispose of your old products with your normal household
waste. Correct disposal of your old product helps to prevent
potential negative consequences for the environment and
human health.
Your product contains batteries covered by the European
Directive 2006/66/EC, which cannot be dispose with normal
household waste. Please inform yourself about the local rules
on separate collection of batteries because correct disposal
helps to prevent negative consequences for the environmental
and human health.
Environmental information
All unnecessary packaging has been omitted. We have tried to
make the packaging easy to separate into three materials:
cardboard(box), polystyrene foam(buffer) and poly ethylene
(bags, protective foam sheet). Your system consists of material
which can be recycled and reused if disassembled by a
specialized company. Please observe the local regulations
regarding the disposal of packaging materials, exhausted
batteries and old equipment.
Recording and playback of material might require consent. See
Copyright Act 1956 and The Performer's Protection Acts 1958
to 1972.
5

BT02
INSTRUCTION
This product is a portable Bluetooth sound system supporting
stereo music, equipped with digital signal processing
technology. It is applied to the different circumstances like
office and house etc., and it may be connected to most other
equipment and mobile phones supporting Bluetooth feature
by means of wireless for hi-quality and play the stereo music
from other equipment and mobile phones.
FEATURES
LOCATION OF CONTROLS
Built in Bluetooth® Handsfree (HFP) and audio streaming
(A2DP & AVRCP).
Built in high-fidelity magnetically-shielded speakers.
Max to support 32GB microSD card, can play the music in
microSD card directly.
Support MP3/WMA audio files.
Can work with computer as an external speaker.
FM radio function.
Audio output and AUX IN function.
Built-in rechargeable 800mAh lithium battery.
•
•
•
•
•
•
•
6

BT02
: Skip Forward/ Volume Down Button.
In Bluetooth mode and during playback, press the button
to skip the previous music, press and hold the button to
decrease volume.
In FM radio, press the button to skip previous channel.
: Play/ Pause Button
In Bluetooth mode and during music playback, press the
button to play/pause the music. When a call is incoming
during playback, press the button to hook off the music to
answer the phone, when finished, press the button again
to resume to music playback.
In FM radio, press it to search the channel automatically,
press it again to stop the search.
During playback, press the button to play/pause the
music.
Press and hold the button to change the mode: Bluetooth
mode/ microSD card mode/ FM radio/ AUX mode.
Attention: The AUX IN and mircoSD card playback mode is
available only when you plug on the external AUX IN audio
cable and microSD card inside of unit.
: Skip Backward / Volume UP Button
In Bluetooth mode and during playback, press the button
to skip the next music, press and hold the button to
increase volume.
In FM radio, press the button to skip next channel.
Indicators and Microphone.
:microSD card slot.
It max to support 32GB MicroSD card.
ON/OFF: Power ON/OFF switch.
Slide the button to ON is turn on the speaker, slide the
button to OFF is turn off the speaker.
DC 5V(For charging)
1.
2.
3.
4.
5.
6.
7.
7

BT02
Inset the small plug from the supplied USB cable to the
mini USB port on the unit, insert the other plug to the USB
Port on the Personal Computer or any USB Charger having
DC 5V, 500mA (or more than 300mA) output. During
charging, the red indicator will turn on, when finished ,it
will turn off.
AUX IN
For external audio source input, using supplied 3.5mm
audio cable for connection. Please adjust the volume from
your external player directly.
AUX OUT/ Headphone
For external audio player output, using supplied 3.5mm
audio cable for connection. Or you can plug the
headphone/earphone to listen the music from speaker.
8.
9.
BATTERY CHARGING
Before play the speaker, please follow up below step to mount
the battery and charging in order to give power. The unit has
built-in re-chargeable battery inside.
1. Open the battery cover at the bottom of unit and mount
the supplied 3.7V, 800mAh lithium-ion rechargeable
battery directly with correct voltage polarity, then close
the battery cover as shown on following photo.
2. Connect the speaker with the computer or any USB
8

BT02
charger by the supplied USB cable as: Inset the small plug
from the supplied USB cable to the Mini USB Port on the
unit, insert the other plug to the USB Port on the Personal
Computer or any USB Charger having DC 5V, 500mA (or
more than 500mA) output.
3. During charging, the red indicator will turn on. When
finished, it will turn off.
Notes:
The battery lifetime will last longer if you follow up below
simple guidelines for charging and storing.
a. For charging first time, charge it at least 10 hours. And the
battery will provide the best performance after fully
charge and discharge 3 times. It is better to charge the unit
after discharge completely, otherwise there may impact
the battery's lifetime.
b. Recharge and store the unit within the temperature range
of 5°C~35°C (40°F~95°F).
c. Do not charge the battery for a period longer than 24
hours. Excessive charging may shorten the battery's life.
d. During charging, you can play the music at the same time.
e. Please don't use it under the high humidity and
temperature environment for long time.
f. Please turn off the speaker if long time not to use.
Important:
We do not recommend taking out the battery and playing
music base on USB power connection directly. Because that
will pop up some unexpected noise.
Due to prolong charging and discharging, the unit battery life
will be affected and playback will also be shorten. We cannot
guarantee the same playback consistently throughout and this
is not include in our warranty and service.
9

BT02
OPERATING INSTRUCTION
Bluetooth mode
1. Slide the Power ON/OFF switch to ON position to turn on
the speaker, Blue indicator will light on and blinking.
2. In first time use or re-pairing to new BLUETOOTH device,
pairing the unit to external BLUETOOTH device as below:
a. Power on the external BLUETOOTH device and enter to
searching mode, when the external BLUETOOTH device
searched the unit, the model number “BLAUPUNKT
BT02” will appear on the display of external BLUETOOTH
device, Pairing code “0000” may need to enter.
b. Start pairing as the on screen instructions on the
external BLUETOOTH device. After paired, blue indicator
stop blinking.
Attention:
· Please make sure your Bluetooth device is stereo before
connection it.
· Not all the Bluetooth device is the same, so read your
Bluetooth device (such as iPhone, iPad, laptop, etc. )
instruction carefully before connection.
· If the Bluetooth is not in the match state, please reboot
speaker and the password is 0000 if necessary.
3. Play the music in the paired BLUETOOTH device as usual,
the Blue indicator will blinking slowly.
4. During music playback:
a. Press the “-” button to skip the previous music, press and
hold the“-” button to decrease volume.
b. Press the button to pause and the Blue indicator stop
blinking, press again to resume normal playback and the
Blue indicator will blinking slowly.
c. Press the “+” button to skip the next music, press and
hold the button to increase volume.
10

BT02
5. If the unit is paired to cell phones, when a call is incoming
during music playback, press the button to hook off
the music to answer the phone, when finished, press the
button again to resume to music playback.
Note:
On phone pick up mode, it is better to let your spoken less than
30 cm far away from micro phone of speaker for better sound
quality reception.
6. When you play the music, you can connect the 3.5mm jack
on the supplied audio cable to AUX OUT jack on the
speaker, connect the another 3.5mm jack to the AUX IN
jack on any external audio player, it will be as a player for
external audio player.
7. In Bluetooth mode, you can press and hold the button
to exit and change to other modes.
8. When finished listening, slide the Power ON/ OFF Switch
to OFF position to shut off the speaker.
·The Bluetooth word mark and logos are registered
trademarks owned by Bluetooth SIG, Inc. and any use of
such marks by 2N-Everpol Sp. z o.o. is under license.
Other trademarks and trade names are those of their
respective owners.
TF-CARD MODE
1. Plug the microSD card into the microSD card slot.
2. Slide the Power ON/OFF Switch to ON position to turn on
the speaker, then press and hold the button to choose
microSD card mode, the Blue indicator will blinking slowly
and it will play the music in microSD card automatically.
3. Press the “-” button to skip the previous music, press and
hold the“-” button to decrease volume.
4. Press the button to pause the music and the Blue
11

BT02
indicator stop blinking, press again to resume normal
playback and the Blue indicator will blinking slowly.
5. Press the “+” button to skip the next music, press and hold
the button to increase volume.
6. When you play the music, you can connect the 3.5mm jack
on the supplied audio cable to AUX OUT jack on the
speaker, connect the another 3.5mm jack to the AUX IN
jack on any external audio player, it will be as a player for
external audio player.
7. In microSD card mode, you can press and hold the
button to exit and change to other modes.
8. When finished listening, slid the Power ON/ OFF Switch to
OFF position to shut off the speaker.
FM RADIO MODE
1. Before play and tune the FM radio, insert the mini USB
plug from the supplied USB cable to the mini USB port on
the speaker, or plug in the supplied 3.5mm stereo audio
cable as a FM antenna for better reception.
2. Slide the Power ON/OFF Switch to ON position to turn on
the speaker, then press and hold the button to choose
FM radio mode, the Blue indicator will light and stop
blinking.
3. Press the button to search the channel automatically
and the Blue indicator is blinking, press it again to stop the
search and the Blue indicator stop blinking.
4. Press the “-” button to skip the previous channel, press and
hold the“-” button to decrease volume.
5. Press the “+” button to skip the next music, press and hold
the button to increase volume.
6. When you play the music, you can connect the 3.5mm jack
on the supplied audio cable to AUX OUT jack on the
12

BT02
speaker, connect the another 3.5mm jack to the AUX IN
jack on any external audio player, it will be as a player for
external audio player.
7. In FM mode, you can press and hold the button to exit
and change to other modes.
8. When finished listening, slide the Power ON/ OFF Switch
to OFF position to shut off the speaker.
AUX IN MODE
1. Connected the 3.5mm jack on the supplied audio cable to
the AUX OUT/Line OUT/Phones jack on any external audio
player, connect the another 3.5mm jack to AUX IN jack on
the speaker.
2. Slide the Power ON/OFF Switch to ON position to turn on
the speaker, the Blue indicator is light and enter AUX
mode. Plays the music in the connected Player as usual.
3. During playback, press the button to play/pause the
music.
4. In AUX mode, you can plug out the audio cable or press
and hold the button to exit.
5. When finished listening, slide the Power ON/ OFF Switch
to OFF position to shut off the speaker.
Important:
In the Bluetooth or mircoSD card playback mode, if you plug in
the 3.5mm stereo audio cable, the speaker will switch to AUX
IN play mode automatically.
SPECIFICATION:
· Bluetooth version: 2.1+EDR
· Support L2CAP/A2DP (AVCTP / AVDTP / AVCRP to receive
stereo audio signal and control the Prev/Next operation of
13

BT02
the audio transmitter by agreement.
· Support HFP (Handsfree profile), equipped with a
speakerphone for voice communications.
· Frequency range: 2.401-2 .480 GHz (2.4GHz ISM Segment)
· Frequency Response: 20Hz~20kHz
· Transmit power: Class2, less than 4dbm, low radiation.
· Scope: <10 meters of wireless communication (consistent
with the Bluetooth protocol specifications CLASS 2)
· The receiver sensitivity: <-90dBm, BER <0.1%
· Coincide with IEEE 802.11
· FM Frequency: 87.5~108.00MHz
· Speaker: 4ohm, 3W
· Rated power: 2W
· SNR: 90dB
· Distortion: <1%
· Power supply: Built-in 800mAh rechargeable lithium
battery
· Charging time from empty battery: approximately 7 hours
· Work voltage: 3.6-4.2V
· Work current: <30mA (Bluetooth module)
· Work current: <400mA (power amplifier, Bluetooth )
· Standby current: <3mA
· Product dimensions: 62 x 62 x 60mm
· Product weight: 166g
· Accessory: 1 pc x USB charging cable, 1 pc x Audio cable
14

BT02
WAŻNE INFORMACJE
Prosimy o przeczytanie tej instrukcji przed przystąpieniem do
obsługi urządzenia, aby zapoznać się z jego funkcjami i
wykorzystać je zgodnie z przeznaczeniem. Zapewni to
długotrwałą, bezawaryjną obsługę urządzenia i przyjemność z
użytkowania.
• Należy zachować instrukcję obsługi oraz informacje
dotyczące bezpieczeństwa w celu wykorzystania ich w
przyszłości.
• Nie należy dopuszczać do tego, aby na urządzenie kapała
lub wylewała się ciecz. Nie wolno też używać go w
wilgotnych miejscach, jak np. łazienka.
• Nie wolno instalować tego urządzenia w następujących
miejscach:
• Wystawionych na bezpośrednie działanie promieni
słonecznych lub w pobliżu grzejników.
• Kłaść go na wierzchu innego sprzętu stereofonicznego
który wydziela ciepło.
• Blokując wentylację lub w zapylonym miejscu.
• W miejscach narażonych na ciągłe drgania.
• W miejscach o wysokiej wilgotności.
• Nie wolno stawiać urządzenia w pobliżu świec lub
otwartego ognia.
• Urządzenia można używać wyłącznie w sposób opisany w
niniejszej instrukcji.
• Przed pierwszym włączeniem zasilania należy upewnić się,
że zasilacz został prawidłowo podłączony.
Ze względów bezpieczeństwa nie należy demontować
obudów ani uzyskiwać dostępu do wnętrza urządzenia.
Urządzenie powinno być naprawiane przez wykwalifikowany
personel serwisu.
15

BT02
Nie wolno rozkręcać urządzenia ani otwierać jego obudowy,
gdyż wewnątrz nie ma żadnych części, które mogłyby być
naprawiane przez użytkownika. Konserwacją i naprawą
sprzętu zajmują się wyłącznie wykwalifikowani pracownicy
serwisu.
INSTRUKCJE DOTYCZĄCE BEZPIECZEŃSTWA
1. Przeczytać instrukcje — przed korzystaniem z urządzenia
należy przeczytać całość instrukcji obsługi oraz informacje
o bezpieczeństwie.
2. Zachować instrukcje — należy zachować instrukcje
użytkowania i obsługi w celu wykorzystania ich w
przyszłości.
3. Przestrzegać ostrzeżeń — należy postępować zgodnie z
wszystkimi ostrzeżeniami zamieszczonymi na urządzeniu
oraz zgodnie z instrukcją obsługi.
4. Przestrzegać instrukcji — należy postępować zgodnie z
instrukcją obsługi oraz wskazówkami dla użytkownika.
5. Woda i wilgoć — aby zmniejszyć zagrożenie pożarem lub
porażeniem elektrycznym, nie wolno narażać urządzenia
na bezpośrednie działanie deszczu, wody i wilgoci, jak np.
w saunie czy w łazience. Nie używać niniejszego
urządzenia w pobliżu wody, na przykład obok wanny,
umywalki, zlewu kuchennego lub balii, w wilgotnej
piwnicy lub w pobliżu basenu (lub w podobnych
miejscach).
6. Przedmioty i ciecze w urządzeniu — nie należy wciskać
jakichkolwiek przedmiotów przez otwory urządzenia,
ponieważ mogą one zetknąć się z punktami
niebezpiecznego napięcia i podzespołami, co może
wywołać pożar lub porażenie prądem. Pod żadnym
pozorem nie należy rozlewać jakichkolwiek cieczy na
16
