Blaupunkt TS120 User manual

INSTRUCTION MANUAL
Bluetooth | USB | AUX-IN | HDMI-ARC

TECHNICAL SPECIFICATIONS
6.5"*2+3"*2+2”*2Speaker Size
20Hz~20KHzFrequency Response
≥60dBS/N Rao
≥45dBSeparaon
≤500mV rms@1 KHzSensivity
88MHz to 108 MHzFM Frequency Range
AC 110V~290/50HzPower Supply
1. Twin Tower Speaker 2.2 Channel with HDMI
ARC/BT/FM/Optical/AUX/USB
2. Class D amplifier with wide AC working voltage range.
3. AUX 3.5 Jack & RCA Input compatible with DVD/PC/TV
4. HDMI ARC & Optical Input for compatible with Smart
TV/Media Player
5. Digital FM Playability with wired Antenna
6. Big White LED Display
7
8
9
10
11
12
FEATURES

MAIN UNIT TOP TOUCH CONTROL
1. Power ON/Mode Key: Touch short to Start Unit, Then again short touch to switching in all mode, Long touch to stand by again.
2. Previous/Vol- Key: Short Touch to Previous Track, Long touch to Volume Decrease.
3. Play/Pause/Scan:- Short touch to play pause playback & in FM mode for scan channel
4. Next/Vol+ Key: Press Short to Next Track, Press Long to Volume Increase.
5. EQ: Short Press for tone control, Long Press for Equaliser effect change.
1 2 3 4 5

REMOTE DESCRIPTION
1. POWER: Press to Stand-By Mode On/Off
2. MUTE: Press once to playback mute & press again to release the
Mute.
3. TRE+: To increase high frequency sound effect level
4. TRE-: To decrease high frequency sound effect level
5. Mode Key: Short Press for switching in all mode/ Long Press to
On-Off MIC Priority
6. EQ Key: Short Press for select sound effect equaliser , Long Press for
Control MIC Volume, Echo Effect, Gain Level.
7. U/SD SCN Key: Press for Switching USB Mode
8. RPT Key: Press key for Repeat One, All, Folder & Random in USB
Mode.
9. BASS+: To increase low frequency sound effect level
10. BASS-: To decrease low frequency sound effect level
11. Vol+ : Press to Increase Volume Level in All Modes.
12. Previous : Press Short to Previous Track, Press Long to Fast
Backward track while playing USB.
13. Next : Press Short to Next Track, Press Long to Fast Forward.
14. Vol- : Press to Decrease Volume Level in All Modes.
15. Play/Pause: Play/Pause the playback
16. 0-9 Numeric Key: Press for Select Directly Song select in USB Mode,
In FM mode press for direct tune specific Frequency.
17. Loudness: Boost Audio.

BACK CONTROL CONNECTION
1. HDMI ARC: To connect with TV/Media player via HDMI ARC
2. AUX1: AUX 3.5 MM Jack Input via TV/DVD/PC
3. FM Ant. : FM Antenna Connection
4. AUX2: AUX RCA Input via TV/DVD/PC
5. Optical: To connect with TV/Media player via Optical
6. Wired MIC: Wired MIC connection
7. USB Port: USB Drive Port
8. Mid, TW: Slave Unit Mid & Tweeter Audio connection
9. Woofer: Slave Unit Woofer Audio connection
10. On/Off Switch
11. AC Input Socket

Subwoofer should always
be facing inwards

ADVANCE SETUP

i s n 't

If you have issue with our product please contact our service center Service Centre.
Authorized Service Center Blaupunkt Speakers
Address: Envent World Wide Pvt Ltd.
Khasra. No- 15/15(4-16), Village Samalkha, Tehsil Vasant
Vihar, New Delhi- 110037
E-Mail: [email protected]
Whatsapp only: 8860 022 600
Please prepare & submit the following information during the telephone or e-mail
notification to facilitate the process:
▪Serial Number
▪Date of purchase
▪A copy of proof of purchase in case of warranty
Note- Important Information
Please use the original packaging or other suitable
packaging to protect the unit in transit.
WARRANTY INFORMATION 1 YEAR*
