Blaupunkt BT5BK User manual

BT5BK
Owner's Manual
Instrukcja obsługi
Návod k obsluze
Príručka vlastníka
Használati útmutató
Bluetooth hangszóró powerbank funkcióval és USB-lejátszással
Bluetooth speaker with power bank and USB playback
Głośnik Bluetooth z odtwarzaniem/zasilaniem przez USB
Bluetooth reproduktor s nabíjačkou a prehrávaním obsahu zariadenia USB
Reproduktor s podporou technologie Bluetooth s funkcí
externího akumulátoru a přehráváním ze zařízení USB

1
BT5BK
IMPORTANT SAFETY INSTRUCTIONS
RISK OF ELECTRIC SHOCK.
DO NOT OPEN
Caution:
To reduce the risk of electric shock, do not dismantle the product and do not expose the apparatus to rain or
moisture. No user-serviceable parts inside. Refer servicing to qualified personnel only.
Explanation Of Graphical Symbols:
The lightning flash within an equilateral triangle is intended to alert you to the presence of uninsulated
dangerous voltage within the product’s enclosure that may be of sufficient magnitude to constitute an
electric shock to a person or persons.
CAUTION
ENGLISH
To achieve the utmost in enjoyment and performance, and in order to become familiar with its features, please read
this manual carefully before attempting to operate this product. This will assure you years of trouble free
performance and listening pleasure.
Important Notes
Do not install the product in the following areas:
bathroom.
The apparatus should not be exposed to dripping or splashing or placed in a humid atmosphere such as a
This safety and operating instruction should be retained for future reference.
•
•
The exclamation point within an equilateral triangle is intended to alert you to the presence of
important operating and maintenance (servicing) instructions in the literature accompanying the
product.

2
BT5BK
On top of other stereo equipment that radiate too much heat.
Places exposed to direct sunlight or close to radiators.
Blocking ventilation or in a dusty area.
Areas where there is constant vibration.
Humid or moist places.
Do not place near candles or other naked flames.
Operate the product only as instructed in this manual.
Before turning on the power for the first time, make sure the power adaptor is properly connected.
•
•
SAFETY INSTRUCTIONS
1. Read Instructions- All the safety and operationg instructions must be read before the product is operated.
2. Retain Instructions- The safety and operating instructions should be kept with the product for future reference.
3. Heed warnings- All warnings on the product and in the operating instructions should be adhered to.
4. Follow instructions- All operating and users’instructions should be followed.
•
For safety reasons, do not remove any covers or attempt to gain access to t h e i nside of the product. Refer any
servicing to qualified personnel. Do not attempt to remove any screws, or open the casing of the unit; there a r e n o
user serviceable parts inside. Refer all servicing to qualified service personnel.
5. Installation- Install in accordance with the manufacture’s instructions.
6. Power sources- This product should be operated only from the type of power source indicated by the marking
adjacent to the power cord entry. If you are not sure of the type of power supply to you home, consult your
product dealer or local power company.
7. Grounding or polarization- the product is not required to be grounded. Ensure that the plug is fully inserted
into the wall outlet or extension cord receptacle to prevent blade or pin exposure. Some versions of the product
are equipped with a power cord fitted with a polarized alternating line plug(a plug having one blade wider than
the other). This plug will fit onto the power outlet only one way. This is a safety feature. If you are unable to
insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your

3
BT5BK
electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug. When using
an extension power-supply cord or a power-supply cord other than that supplied with the appliance, it should
be fitted with the appropriate molded plugs and carry safety approval appropriate to the country of use.
8. Power cord protection- Power-supply cords should be routed so that they are not likely to be walked on,
kinked or pinched by items placed on or against them, paying particular attention to cords from plugs,
receptacles and the point where they exit from the product.
9. Overloading- Do not overload wall outlets, extension cords, or multiple sockets, as this can result in a risk of fire
or electric shock.
10. Ventilation- The product must be properly ventilated. Do not place the product on a bed, sofa, or other similar
surface. Do not cover the product with any items such as tablecloths, newspapers, etc.
11. Heat- The product should be situated away from heat sources such as radiators, heat registers, stoves, or other
products, including amplifiers that produce heat. No naked flame sources, such as lighted candles, should be
placed on the apparatus.
12. Water and moisture- To reduce the risk of fire or electric shock, do not expose the product to train, dripping,
splashing or excessive moisture such as in a sauna or bathroom. Do not use this product near water, for
example, near a bathtub, washbowl, kitchen sink, laundry tub, in a wet basement or near a swimming pool(or
similar).
13. Object and Liquid Entry- Never push objects of any kind into this product through openings, as they may
touch dangerous voltage points or short-circuit parts that could result in a fire or electric shock. Never spill
liquid of any kind on the product. Do not place any object containing liquid on top of the product.
14. Cleaning- Unplug the product from the wall outlet before cleaning. Dust in the woofer may be cleaned with a
dry cloth. If you wish to use an aerosol cleaning spray, do not spray directly on the cabinet; spray onto the cloth.
Be careful not to damage the drive units.
15. Attachments- Do not use attachments not recommended by the product manufacturer, as they may cause
hazards.
ENGLISH

4
BT5BK
16. Accessories- Do not place this product on an unstable cart, stand, tripod, bracket or table. The product may fall.
causing serious injury to a child or adult, and serious damage to the product. Use only with a cart, stand, tripod,
bracket or table recommended by the manufacturer or sold with the product. Any mounting of the product
should follow the manufacturer’s instructions and should use a mounting accessory recommended by the
manufacturer.
17. Moving the product- A product and cart combination should be moved with care. Quick stops, excessive force
and uneven surfaces may cause the product and cart combination to overturn.
18. Unused periods- The power cord of the appliance should be unplugged from the outlet during lightning
storms or when the apparatus is left unused for a long period of time.
19. Servicing-Do not attempt to service this product yourself, as opening or removing covers may expose you to
dangerous voltage or other hazards. Refer all servicing to qualified service personnel.
20. Please remove the power plug form the main power source or wall power source when not in use. When
plugged in to a power source, the system is in sandby mode, so the power is not entirely cut off.
21. Replacement parts- When replacement parts are required, ensure that the service technician has used
replacement parts specified by the manufacturer or have the same characteristics as the original part.
Unauthorized substitutions may result in fire, electric shock or other hazards.
22. Mains fuses- For continued protection against fire hazard, use fuses only of the correct type and rating. The
correct fuse specification for each voltage range is marked on the product.
23. Do not turn up volume while listening to a section with very low level inputs or no audio signals. If you do, the
speaker may be damaged when a peak level section is suddenly played.
24. The only means of completely disconnecting the product from the power supply is by removing the power cord
from the wall outlet or the product. The wall outlet or the power cord entry to the product must remain freely
accessible at all times while the product is in use.
25. Try to install the product near a wall socket or extension cord and shall be easily accessible.
26. The highest environmental temperature suitable for this product is 35°C.

5
27. ESD hints- The normal function of the product may be disturbed by strong Electro-Magnetic Interference. If so,
simply reset the product to resume normal operation by following the instruction manual. In case the function
could not resume, please use the product in other location.
28. Battery
1). The batteries must not be exposed to excessive heat such as sunshine, fire or the like.
2). The batteries should be drawn to the environmental aspects of battery disposal.
3). Battery usage CAUTION-to prevent battery leakage which may result in body injuries, property damage, or
damage, or damage to the apparatus:
- Install all batteries correctly, + and- as marked on the apparatus.
- Do not mix batteries ( old and new or carbon and alkaline, etc.)
- Remove batteries when the unit is not used for a long time.
ERP2- ( Energy Related Produces) note
This product with ecodesign complies with the stage 2 requirements of Commission Regulation( EC) NO.1275/2008
implementing Directive 2009/125/EC regard to standby and off mode electric power consumption of electronic
household and office equipment. Follow up the instruction manual to resume the operation.
The Bluetooth® word mark and logos are registered trademarks owned by B l u e tooth SIG, Inc. and any use of
such marks by us is under license. Other trademarks and trade names are those of their respective owners.
Warning
This appliance is not intended for use by persons (including children) with r e d u c ed physical sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety. C h i l d ren should be supervised to ensure that they do
not play with the appliance.
BT5BK
ENGLISH

6
1.To prevent possible hearing damage, do not listen at high volume levels for l o n g time periods respectively a
sudden high volume level.
2. Never use the device unsupervised! Switch off the device whenever you are n o t u sing it, even if this only for a
short
while.
3. The appliance is not intended to be operated by means of an external timer o r s e parate remote control system.
4. If the supply cord is damaged, it must be replaced by the manufacturer, its s e r v i ce agent or similarly qualified
persons in order to avoid a hazard.
5. Before operating this system, check the voltage of this system to see if it is i d e n t ical to the voltage of your local
power supply.
6. The unit should not be impeded by covering the ventilation opening with items such as new spaper, table-cloths,
curtains etc. Make sure that there are at least 20 cm of space above and at least 5 cm of space on each side of the unit.
7. The apparatus must not be exposed to dripping or splashing and that objects filled with liquids, such as vases,
must not be placed on the apparatus.
8. To prevent fire or shock hazard, do not expose this equipment to hot places, rain, moisture or dust.
9. Do not locate this unit near any water sources e.g.taps, bathtubs, washing machines or swimming pools. Ensure
that you place the unit on a dry, stable surface.
10. Do not place this unit close to a strong magnetic field.
11. Do not place the unit on a amplifier or receiver.
12. Do not place this unit in a damp area as the moisture will affect the life of electric components.
13. If the system is brought directly from a cold to a warm location, or is placed in a very damp room, moisture may
condense on the lens inside the player. If this occurs, the system will not operate properly. Please leave the system
turned on for about an hour until the moisture evaporates.
14. Do not attempt to clean the unit with chemical solvents as this might damage the finish. Wipe with a clean, dry or
slightly damp cloth.
BT5BK

7
15. When removing the power plug from the wall outlet, always pull directly on the plug, never pull on the cord.
16. The mains plug is used as the disconnect device, the disconnect device must remain readily operable.
NOTICE
This product complies with the radio interference requirements of the European community.
Your products is designed an manufactured with high quality materials and components, which can be recycled and
reused.
When this crossed-out wheeled bin symbol is attached to a product it means that the product is covered by the
European Directive 2002/96/EC. Please
inform yourself about the local separate collection system for electrical and
electronic products. Please cat according to your local rules and do not dispose of your old products with your
normal household waste. Correct
disposal of your old product helps to prevent potential negative
consequences for
the environment and human health.
Your product contains batteries covered by the European Directive 2006/66/EC, which cannot be dispose with
normal household waste. Please
inform yourself about the local rules on separate collection of batteries
because correct disposal helps to prevent negative consequences for the environmental and human health.
BT5BK
ENGLISH

8
Environmental information
All unnecessary packaging has been omitted. We have tried to make the packaging easy to separate into three
foam(buffer) and poly ethylene(bags, protective foam sheet). Your system
consists of material which can be recycled and reused if disassembled by a
specialized company. Please observe the
disposal of packaging materials, exhausted batteries and old equipment.
Recording and playback of material might require consent. See Copyright Act 1956 and The Performer’s Protection
materials: cardboard(box), polystyrene
local regulations regarding the
Acts 1958 to 1972.
Thanks for your purchase of our product. connections and operating this
Please read through this manual before making
product. Retain this manual for future reference.
WARNING: The batteries shall not be
exposed to be exposed to excessive heat such as sunshine, fire or the like.
CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalenttype.
BT5BK

9
ENGLISH
BT5BK
Control locations
Front view
Top view
Side View

10
BT5BK
1. Operating mode LED indicator
2. Button
While then unit is in Bluetooth/USB Playback mode, press to play or pause the current track.
In Bluetooth mode, when receiving an incoming call on your cell phone, press this button once to
answer the phone, press this button again to end the call.
3. - Button
In Bluetooth & USB mode :
- Press and hold this button to adjust volume level down.
- Short press this button once to return to the beginning of current track or previous track.
4. + Button
In Bluetooth & USB mode :
-Press and hold this button to adjust volume level up.
-Short press this button once to advance to the next track.
5. Power On/Off Button
- Press and hold this button to turn on/off the unit.
- In power on mode, short press this button to change the operating mode if there is USB stick or AUX
cable plugged into the unit.
6. Microphone hole
7. Battery power indicator
- The LEDs will flare when you charge the unit.
- The LED will ligh on when you power on the unit.
- The number of lighted on LED is indicate the battery power status. For example, there have 3 LEDs light
on, means the battery have 60% power remained.

11
BT5BK
ENGLISH
5. Micro USB jack
6. Aux-In
7. USB port
Battery charging specification
This unit built-in a rechargeable Li-ion battery with micro USB charging jack, which is allow you to charge
the unit by a supplied USB cable connect with the USB port on your PC or a USB adaptor (not included) .The
requirement of charging power source is DC 5V/500mA or up. We high recommend to connect the unit for
charging by DC 5V/1A rating power.
Note: The Micro USB jack located on this unit is only designed for charging the battery.
Charging operation
1. Connect the power adaptor (not included) to the Micro USB charging jack, and plug the power adaptor
into a convenient wall mains outlet ; Or connect the unit with USB port on your PC by the supplied USB cable
for charging.
2. The battery power indicator on the left side of unit will turn on and flash during charging, and it will stop
to flash when the unit is fully charged.
3. Disconnect the charging power once the unit is fully charged.
Notes:
a. After prolonged use, the internal battery will become weak and the operation may become intermittent.
When the battery is low, only the bottom LED light of the Battery Level Indicator is on, and when the
battery is very low, it will rapidly flash to alert you to recharge the internal battery as soon as possible.
b. The charging time are varies depend on the charging current.
c. We recommend you switch off the speaker power during the charging process.

12
BT5BK
Important:
The battery life will last longer if you follow up below simple guideline for charging and storage.
a. The battery should be fully charged on first time using.
b. Once the battery is fully discharged, immediately recharge (regardless of whether you plan to use this
unit or not) in order to maximize battery life.
c. If you plan not to use the battery for an extended period of time (one week or longer), we recommend
that you fully charge the battery. For longer periods of storge, please recharge the battery at least every
two months to maintain the battery in optimum condition.
d. Due to prolong charging and discharging, the unit battery life will be affected , and playback time will
also be shorten. We cannot guarantee same playback time and battery capacity consistently throughout
and this is not include our warranty and sevice.
Battery Note and Care
Do not burn or bury batteries.
Do not puncture or crush.
Do not disassemble.
Li-ion batteries must be recycled. Do not dispose of in the trash.
Be sure the charger's voltage and current settings are correct for the battery pack being charged.
Charge batteries on a fireproof surface and away from flammable items or liquids.
Batteries should NEVER be left unattended while charging.
Only adults should charge the batteries.
Unplug the charger when the battery is charged or not in use.

13
Power on/off
1. Press and hold the Power ON/OFF button on the top of the speaker to turn the unit on, the battery level
indicator will turn on. Meanwhile, the operating mode indicator will flash in blue. Press and hold the
Power ON/OFF button again will turn the unit off.
2. ECO design: When the unit is idle or there is no any audio input or output (charging other device) for
about 90 minutes, it will power off automatically.
Note : In Bluetooth pairing mode, if the unit is idle(no device paired) for about 7 minutes, the operating
mode indicator (flashing blue) will be turned off automatically. However, it can be activated again by
pressing any button on the speaker.
Bluetooth operation
Bluetooth involves a technology for wireless radio connection of devices over a short distance. Devices with
Bluetooth standard are transmitting between 2.402 and 2.480 GHz in the ISM band (Industrial, Scientific and
Medical). Interference can be caused, for example by WLAN-networks, DAB radios, cordless phones, or
microwave ovens which work on the same frequency band.
Due to the different device manufacturers, models, and software versions, a full functionality cannot be
guaranteed.
Pairing : If the speaker has never been paired with the Bluetooth device . You need follow up below pairing
instructions to connect the speaker with your Bluetooth device .
1. When the speaker is power on, and the operating mode LED is flashing in blue color, that means the
speaker is ready to pair with your other Bluetooth device .
2. Activate Bluetooth function on your Bluetooth device, and searching Bluetooth device( Please reference
the operation from the manual of your device) .
BT5BK
ENGLISH

14
BT5BK
3. Check the available Bluetooth device on the menu list of your device, and select “BP BT5BK” from the
list. Then pairing between two units will be started.
4. If a POP poassword is asked on your Bluetooth device during paring, please enter digits “0000”(four
zero) and press OK.
5. If pairing has been carried out successfully, a beep sound will come out from speaker. Meanwhile, the
blue color LED will stop flare.
6. Select the music, and play it on your device; then the playback sound will output from the speaker.
7. Press the button to pause or resume playback ; Press and hold the + / - button on the speaker to
adjust to the desired volume level ; Short press the + / - button to skip to next track or previous track.
Phone call hands free : When receiving an incoming call on your cell phone during Bluetooth playback
mode, press button on the speaker to pick up the phone call. And the phone call voice will output
from the speaker. Put the unit close to your mouth, and answer the phone aim to the microphone hole(
on the top of unit). Press the button again will end the phone call, and resume to playback the music.
Please adjust the volume on your cell phone to obtain the desired sound level if need.
Notes :
a. Only one Bluetooth device can be connected to the speaker at one time. If the speaker is already
connected to another playback unit, the speaker will not appear in the Bluetooth selection menu list.
b. If the speaker paired the Bluetooth device before. The speaker can auto search and pair with the device
automatically if the device is in the working distance.
c. The best Bluetooth playback working distance is within 10 meters between the speaker and other
Bluetooth device.
d. Please do not put your cell phone very close the speaker unit during phone call hands free mode,
because that will interference the signal and impact the output sound quality.

15
BT5BK
USB playback
This device includes USB playback function, which can decode and playback the MP3 music from your USB
stick. Before start the playing, please copy the MP3 format music to you USB device.
1. Power on the unit, then insert the USB stick to the USB port ; the LED indicator will turns to cyan colour
automatically which means enter into the USB mode already.
2. The unit will decode the MP3 file automatically and start the sound output after a few seconds.
3. In USB playback mode, press and hold + / - button on the speaker to adjust to the desired volume level ;
Short press + / - button can skip to next track or previous track.
Notes :
a. In USB mode, if you pull out the USB stick from the unit, the speaker will switch to Bluetooth mode
automatically.
b. The USB playback only available when the USB stick is plug on.
c. An extension cable for USB connection and playing is not recommended, which may cause intermittent
sound output due to signal loss during the data transportation.
d. The unit only can support till 32GB max storage device
e. Due to different design and brand in the market, compatible all USB devices and MP3 audio file is not
guaranteed.
Power bank (charging other device)
The USB port is also designed for charging other devices, such as smart phones, tablets and other USB
power devices.
1. Plug the USB power cable of your device into the USB port of speaker, and then power on the unit .
2. Plug the other end of the USB cable into your device, Then the charging will be started automatically.
ENGLISH

16
BT5BK
Notes:
a. You can continue to listen the speaker while charging.
b. USB rated output is 5V/1A. Please check the required charging power on your device before the
connection.
c. Please check charged status on your device side.
d. Due to different design and brand in the market, not all USB devices are guaranteed for charging
operation.
AUX IN( MP3 Link)
If you are using an iPod, MP3/MP4 player or other mobile phone which can not connect this unit via
bluetooth directly, you can still play it with speaker through by an supplied audio cable connection in
between.
1. Plug one end of the 3.5mm audio cable (included) into the headphone or line out jack on your player,
plug the other end of cable into the unit AUX-IN jack of the speaker.
2. Turn on the external audio player and play it.
3. Press and hold the power ON/OFF button to turn on the unit, the operating mode indicator will light up
in green color.
4. The volume level can be controlled through the unit. Please operate all other functions on your external
player as usual.
Notes:
a. You may only need adjust the volume control on the speaker side if the speaker connect with the Line
out jack of your external player ; But you need adjust the volume both on the speaker and your external
player if a headphone jack was connected.

17
Specification
Battery capacity: 4,000 mAh
Battery charging voltage: DC 5V, 500mA and up(recommend 5V/1A).
Battery charging time: 5-7 Hours (varies by charging current)
Max Playback Time: 12 Hours (varies by volume level and audio content)
USB output: DC 5V, 1A
Music Format supports: MP3, WMA
USB Format supports: 2.0 (up to 32GB)
Bluetooth version: V4.0
Bluetooth transmitter frequency range: 2.402GHz-2.480GHz
Bluetooth transmission range: approx. 10 metres
Dimensions (W x D xH): 148 x 80 x 25mm
Weight: 285g
Working Temperature: 0°C – 35°C
Working Humidity: 20%~80%
( the above spec may update without prior notice)
b. The unit will switch to AUX IN mode automatically when the audio cable is plug on ; and switch back to
Bluetooth mode when you remove the audio cable.
c. Press and hold the Power ON/OFF button to turn off the unit when you finish the listening. And don't
forget to switch off the power on your external player.
BT5BK
ENGLISH

18
Troubleshooting Guide
Issue: Cannot power on the unit.
a. Please charge the unit and try again due to low power.
b. Please contact the sevice center if the problem remians.
Issue: Cannot charge the unit.
a. Please check if the connection is correct and in position between the unit, power adaptor or other
power source.
b. Please contact the sevice center if the problem remians.
Issue : Cannot charge other device.
a. Please check if the connectin between the devices is properly.
b. Please power on the unit in order to start the charging.
c. Please charge the unit first and try again due to no or low power.
d. Please contact the sevice center if the problem remians.
Issue : No sound output or intermittent sound in Bluetooth mode.
a. Please check if the pairing is still connected sucessfully.
b. Please turn off the unit and repair the unit again.
c. Please try to adjust the volume on your Bluetooth device and speaker.
d. Please move your Bluetooth device more close to the speaker.
e. Please contact the sevice center if the problem remians.
BT5BK
