Blaupunkt 5DA17150AU User manual

EN
COOKER HOOD
([WUDFWRUKRRG '$17150$8

EN
USER MANUAL .....................................................................................................................3

3
1. SAFETY
INFORMATION
For your safety and
correct operation of the
appliance, read this manual
carefully before installation
and use. Always keep these
instructions with the
appliance even if you move
or sell it. Users must fully
know the operation and
safety features of the
appliance.
The wire connection has
to be done by specialized
technician.
• The manufacturer will not be
held liable for any damages
resulting from incorrect or
improper installation.
• The minimum safety
distance between the cooker
top and the extractor hood
is 650 mm (some models
can be installed at a lower
height, please refer to the
paragraphs on working
dimensions and installation).
• If the instructions for
installation for the gas hob
specify a greater distance,
this must be respected.
• Check that the mains voltage
corresponds to that indicated
on the rating plate xed to
the inside of the hood.
• Means for disconnection
must be incorporated in the
xed wiring in accordance
with the wiring rules.
• For Class I appliances,
check that the domestic
power supply guarantees
adequate earthing.
• Connect the extractor to
the exhaust ue through a
pipe of minimum diameter
120 mm. The route of the
ue must be as short as
possible.
• Regulations concerning the
discharge of air have to be
fullled.
• Do not connect the extractor
hood to exhaust ducts
carrying combustion fumes
(boilers, replaces, etc.).
• If the extractor is used
in conjunction with non-
electrical appliances (e.g.
gas burning appliances), a
sufcient degree of aeration
must be guaranteed in the
room in order to prevent the
backow of exhaust gas.
When the cooker hood is
used in conjunction with
appliances supplied with
energy other than electric,
the negative pressure in the
room must not exceed 0,04
mbar to prevent fumes being
drawn back into the room by
the cooker hood.
• The air must not be
discharged into a ue that is
used for exhausting fumes
from appliances burning gas
or other fuels.
EN

4
• If the supply cord is
damaged, it must be
replaced from the
manufacturer or its service
agent.
• Connect the plug to a socket
complying with current
regulations, located in an
accessible place.
• With regards to the technical
and safety measures
to be adopted for fume
discharging it is important to
closely follow the regulations
provided by the local
authorities.
WARNING: Before
installing the Hood,
remove the protective
lms.
• Use only screws and small
parts in support of the hood.
WARNING: Failure to
install the screws or xing
device in accordance with
these instructions may
result in electrical
hazards.
• Do not look directly at the
light through optical devices
(binoculars, magnifying
glasses…).
• Do not ambè under the
range hood; risk of re.
• This appliance can be
used by children aged
from 8 years and above
and persons with reduced
physical, sensory or
mental capabilities or
lack of experience and
knowledge if they have
been given supervision or
instruction concerning use
of the appliance in a safe
way and understand the
hazards involved. Children
shall not play with the
appliance. Cleaning and
user maintenance shall not
be made by children without
supervision.
• Children should be
supervised to ensure that
they do not play with the
appliance.
• The appliance is not to be
used by persons (including
children) with reduced
physical, sensory or mental
capabilities, or lack of
experience and knowledge,
unless they have been given
supervision or instruction.
Accessible parts may
become hot when used
with cooking appliances.
• Clean and/or replace the
Filters after the specied
time period (Fire hazard).
See paragraph Care and
Cleaning.
• There shall be adequate
ventilation of the room when
the range hood is used at
the same time as appliances
burning gas or other fuels
(not applicable to appliances
that only discharge the air

5
back into the room).
• The symbol on the
product or on its packaging
indicates that this product
may not be treated as
household waste. Instead
it shall be handed over to
the applicable collection
point for the recycling of
electrical and electronic
equipment. By ensuring
this product is disposed
of correctly, you will
help prevent potential
negative consequences
for the environment and
human health, which
could otherwise be
caused by inappropriate
waste handling of this
product. For more detailed
information about recycling
of this product, please
contact your local city
ofce, your household
waste disposal service
or the shop where you
purchased the product.
2. USE
• The extractor hood has been
designed exclusively for domestic
use to eliminate kitchen smells.
• Never use the hood for purposes
other than for which it has been
designed.
• Never leave high naked ames
under the hood when it is in
operation.
• Adjust the ame intensity to direct
it onto the bottom of the pan only,
making sure that it does not engulf
the sides.
• Deep fat fryers must be
continuously monitored during use:
overheated oil can burst into ames.
3. CARE AND CLEANING
- The Activated charcoal lter is
not washable and cannot be
regenerated, and must be replaced
approximately every 4 months of
operation, or more frequently for
particularly heavy usage (W).
W
- The Grease lters must be cleaned
every 2 months of operation, or
more frequently for particularly
heavy usage, and can be washed
in a dishwasher (Z).
=
• Clean the hood using a damp cloth
and a neutral liquid detergent.

6
4. CONTROLS
LLight Switches the lighting system on
and off.
MMotor Switches the extractor motor on
and off.
VSpeed Sets the operating speed of the
extractor:
1. Low speed, used for a
continuous and silent air change
in the presence of light cooking
vapour.
2. Medium speed, suitable for most
operating conditions given the
optimum treated air ow/noise
level ratio.
3. Maximum speed, used for
eliminating the highest cooking
vapour emission, including long
periods.
5. LIGHTING
Lamp Power (W) Socket Voltage (V) Dimension (mm) ILCOS Code
4 E14 220 – 240 107 x 37 DRBB/F-4-220-240-E14-35/100

EN
INSTALLATION MANUAL

8
EN
Warning! Before proceeding with installation,
read the safety information in the User
Manual.

9
L = 8x (A= 520mm)
L = 10x (A= 700mm)

10
1x
ø 120 mm
ø 150 mm
ø 120 mm
ø 150 mm
1x
W
G
650
mm
500
mm
G1
2x
450
mm
650
mm

11
1
Min. 450mm Min. 650mm

12
2
3
Galassi, Raffaele
10-Oct-2018
Released

13
4
A520 700
L1 497 677
5
L
1
2

14
6

15
7
W
G
G1
2x
G
G1
2x
W

16
8
Z
10
9

Service
www.blaupunkt-einbaugeraete.com
1800 252 878 658
Australia
[email protected]
