Blaupunkt WS30WH User manual

Owner's Manual
Instrukcja obsługi
Návod k použití
Navodila za uporabo
Használati útmutató
Upute za upotrebu
Instrucțiune de deservire
Инструкция за употреба
Οδηγίες χρήσης
Kasutusjuhend
Naudojimo instrukcijos
Užívateľská príručka
Multi-functional Weather station
WS30WH/WS30BK
Lietošanas instrukcija

Important Notes
Ÿsafety and operating instruction should be retained for future reference.
ŸThe apparatus should not be exposed to dripping or splashing or placed in a humid
atmosphere such as a bathroom.
ŸDo not install the product in the following areas:
ŸPlaces exposed to direct sunlight or close to radiators.
ŸOn top of other stereo equipment that radiate too much heat.
ŸBlocking ventilation or in a dusty area.
ŸAreas where there is constant vibration.
ŸHumid or moist places.
ŸDo not place near candles or other naked flames.
ŸOperate the product only as instructed in this manual.
ŸBefore turning on the power for the first time, make sure the power adaptor is properly
connected.
For safety reasons, do not remove any covers or attempt to gain access to the inside of the
product. Refer any servicing to qualified personnel.
Do not attempt to remove any screws, or open the casing of the unit; there are no user
serviceable parts inside. Refer all servicing to qualified service personnel.
SAFETY INSTRUCTIONS
1.Read Instructions - All the safety and operating instructions must be read before the product
is operated.
2. Retain Instructions - The safety and operating instructions should be kept with the product
for future reference.
3. Heed warnings - All warnings on the product and in the operating instructions should be
adhered to.
4. Follow instructions - All operating and users' instructions should be followed.
5. Installation - Install in accordance with the manufacturer's instructions.
6. Power sources - This product should be operated only from the type of power source
indicated by the marking adjacent to the power cord entry. If you are not sure of the type of
power supply to your home, consult your product dealer or local power company.
7. Water and moisture - To reduce the risk of fire or electric shock, do not expose the product to
train, dripping, splashing or excessive moisture such as in a sauna or bathroom. Do not use this
product near water, for example, near a bathtub, washbowl, kitchen sink, laundry tub, in a wet
basement or near a swimming pool (or similar).
8. Object and Liquid Entry - Never push objects of any kind into this product through openings,
as they may touch dangerous voltage points or short-circuit parts that could result in a fire or
electric shock. Never spill liquid of any kind on the product. Do not place any object containing
liquid on top of the product.
9. Servicing - Do not attempt to service this product yourself, as opening or removing covers
may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service
personnel.
10. Replacement parts - When replacement parts are required, ensure that the service
technician has used replacement parts specified by the manufacturer or have the same
characteristics as the original part. Unauthorized substitutions may result in fire, electric shock
or other hazards.
11. The highest environmental temperature suitable for this product is 35°C.
12. ESD hints - If the product maybe reset or not reset to operation of control due to
electrostatic discharge, just switch off and reconnect again, or move the product to another
location.
13. Battery
1

a. The batteries must not be exposed to excessive heat such as sunshine, fire or the like.
b. The batteries should be drawn to the environmental aspects of battery disposal.
c. Battery usage CAUTION-to prevent battery leakage which may result in body injuries,
property damage, or damage to the apparatus:
. Install all batteries correctly, + and – as marked on the apparatus.
. Do not mix batteries (old and new or carbon and alkaline, etc.)
. Remove batteries when the unit is not used for a long time.
ERP2 (Energy Related Products) note
This product with ecodesign complies with the stage 2 requirements of Commission
Regulation (EC) NO. 1275/2008 implementing Directive 2009/125/EC regard to standby and off
mode electric power consumption of electronic household and office equipment.
WARNING
This appliance is not intended for use by persons (including children) with reduced physical
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible for
their safety. Children should be supervised to ensure that they do not play with the appliance.
1. Never use the device unsupervised! Switch off the device whenever you are not using it,
even if this only for a short while.
2. The appliance is not intended to be operated by means of an external timer or separate
remote control system.
3. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or
similarly qualified persons in order to avoid a hazard.
4. Before operating this system, check the voltage of this system to see if it is identical to the
voltage of your local power supply.
5. To prevent fire or shock hazard, do not expose this equipment to hot places, rain, moisture or
dust.
6. Do not place this unit close to a strong magnetic field.
7. Do not place the unit on a amplifier or receiver.
8. Do not place this unit in a damp area as the moisture will affect the life of electric
components.
9. If the system is brought directly from a cold to a warm location, or is placed in a very damp
room, moisture may condense on the lens inside the player. If this occurs, the system will not
operate properly. Please leave the system turned on for about an hour until the moisture
evaporates.
10. Do not attempt to clean the unit with chemical solvents as this might damage the finish.
Wipe with a clean, dry or slightly damp cloth.
NOTICE
Conformity
Hereby, Blaupunkt Competence Center 2N-Everpol Sp. z o.o., declares that this equipment is in
compliance with the essential requirement and other relevant provisions of Directive
2014/53/EU. Declaration of conformity can be obtained from the product page at
www.blaupunkt.com.
Responsible party: 2N-Everpol Sp. z o.o, Puławska 403A, 02-801 Warsaw, Poland, Phone: +48 22
688 08 00, E-mail: [e-mail]
2

3
Your products is designed a manufactured with high quality materials and components, which
can be recycled and reused.
When this crossed-out wheeled bin symbol is attached to a product it means that the product
is covered by the European Directive 2012/19/EU. Please inform yourself about the local
separate collection system for electrical and electronic products. Please cat according to your
local rules and do not dispose of your old products with your normal household waste. Correct
disposal of your old product helps to prevent potential negative consequences for the
environment and human health.
Your product contains batteries covered by the European Directive 2006/66/EC, which cannot
be dispose with normal household waste. Please inform yourself about the local rules on
separate collection of batteries because correct disposal helps to prevent negative
consequences for the environmental and human health.
Environmental information
All unnecessary packaging has been omitted. We have tried to make the packaging easy to
separate into three materials: cardboard (box),polystyrene foam(buffer) and poly ethylene
(bags, protective foam sheet). Your system consists of material which can be recycled and
reused if disassembled by a specialized company. Please observe the local regulations
regarding the disposal of packaging materials, exhausted batteries and old equipment.
Recording and playback of material might require consent. See Copyright Act 1956 and The
Performer's Protection Acts 1958 to 1972.

4
Many thanks purchase our model, this weather station product includes below features.
Please read and reference this manual carefully before operate the unit. Please keep the
manual for future operation reference.
Features
ŸWeather forecast: Sunny, Partly cloudy, Cloudy, Rainy, Snowy.
ŸIndoor/outdoor temperature.
ŸIndoor & outdoor humidity.
ŸIn/outdoor maximum & minimum temp. & humidity history memory.
Ÿ12/24 hours clock time, calendar.
ŸAlarm with snooze function.
ŸMaximum support and work with 3 outdoor wireless transmitters in different channel
(only one transmitter included).
ŸIn/outdoor low and high temperature alert.
ŸBarometer
ŸFreezing point indicator.
ŸCircumstance comfortable level indicator.
Display & controls

5
1. Indoor temperature/trend 2. 2. Indoor humidity/trend
3. Outdoor temperature/trend 4. Outdoor humidity/trend
5. Animated weather forecast 6. Clock time
7. Wireless transmitter channel 8. Barometric pressure data
9. Frost icon 10. high-low temperature warning
11. low battery power icon 12. Channel selector
13. Rope and hook hole 14. Sensor
15. alarm icon
16-17-18-19-20-21: set/up&channel/down/alarm/alert/memory button
22. Backlight/snooze button 23. backup cell battery compartment
24. foldable stand (unfold for table placement) 25. Attached DC IN power jack
26. calendar 27. Weekday
Power setting
Plug in the supplied AC/DC power adaptor to an AC household outlet in order to get power
source, and plug the DC connector of power adaptor to the attached DC in power jack on the
back panel of main unit. Then the unit is ready work for you.
Open the battery compartment cover of outdoor wireless transmitter, insert 2 x AA batteries
to the compartment according to the correct polarity showed in the compartment. (Batteries
are included) We recommend use high quality alkaline or lithium batteries for the best
product performance. Heavy duty or rechargeable batteries are not recommended.
Extend the foldable stand, take off the insulation sheet from the cell battery(CR2032,
included) compartment. The backup battery can keep all settings(include time clock) in the
event of power interruption. Push out the bracket and reinstall with fresh battery base on
below in case of power exhausted.
Receive signal from outdoor wireless transmitter
The main unit can detect and receive the outdoor temperature and humidity wireless signal
from transmitter automatically after power setting ready. There will take 3 minutes maximum
for signal searching. The wireless symbol(nearby channel on display) will flash on
display during searching, and becomes stable after get the signal. If there is no available
signal be received, the wireless symbol will be disappeared after 3 minutes, and outdoor
temperature and humidity data will show “ - - “ on display. In case you need reconnect the
wireless signal, please press and hold the up button 3 seconds.
Placement and important notes:
1. The main unit are able to work and connect with 3 outdoor wireless transmitters maximum.
Open up the battery door of outdoor wireless transmitter can see and adjust the
channel(include 3 channels). it requires to set up at same channel with main unit for signal
receiving. For example, you select channel 1 at wireless transmitter, then the channel display
of main unit should show CH1 for connection. Press the up button on side panel of main unit

6
can adjust the channel number and check the outdoor data between CH1-3 on display. You can
take the same mothed to connect other wireless transmitter, but please set it in different
channels. Only one wireless transmitter include in the package.
2. please use and put main unit or transmitter device 1.5~2 meters away from interference
source like computer monitors or TV sets. Please also place the main unit stand up far away with
metal window frames.
3. Please do not use other electronic products such as headphones or speakers operating at the
same signal frequency (433.92MHz), which may cause interference. Your neighbors use
electronic devices operating on the same signal frequency (433.92MHz) can also cause
interference.
4. To ensure accurate temperature measurement, place the device in a dry area, free of dirt and
dust. Place out of direct sunlight and away from heat sources or vents.
5. You can install the wireless transmitter outdoor. For better accuracy of using, please place the
sensor lengthwise/ standing up 1.5~2 meters at least away from the ground with enough air
flowing and protection without rainy. Please do not expose the sensor to direct sunlight for a
long time.
6. The maximum working distance of wireless transmitter is 80 meters away from main unit.
7. The wireless signal from transmitter will refresh in every 114(channel
1)/134(channel2)/158(channel3) seconds in recycle.
Settings
Press and hold set button 3 seconds and get the weekday language text flash on display, press
up or down button to choose the weekday language(GER (German), ENG (English), FRE (French),
ITA (Italian), SPA (Spanish), DUT (Dutch), DAN (Danish), press set button to confirm and skip to
keep tone on/off setting, which is same operation as language 's setting; repeat and finish rest
setting for barometric unit /temperature unit/year/month&day format/month/date/ 12&24
hours format/hour/minute/weather ( Press and hold up or down button can accelerate the
adjustment; there will auto save and exit current setting if there is no further operation last for
over 20 seconds)
Alarm and snooze
Short press alarm button repeatedly can switch the alarm mode between alarm1 wake up by
working day/alarm1 wake up by weekend/alarm2 wake up by working day/alarm2 wake up by
weekend. Choose the alarm mode, Press and hold alarm button can activate alarm setting
mode, press up or down button to adjust the hour digits, press alarm button to confirm and skip
to minute and alarm on/off setting which is same operation as hour's setup. Short press alarm
button to finish the alarm setting. Using the same method can set up the rest alarm. In case you
set up alarm successful, the relevant alarm icon will show on display. Press top backlight and
snooze can save and exist the current setting.
When the alarm is ring up due to the setting time is being, press any button (except top
backlight/snooze button) to cancel the alarming voice, and it will wake up again at same time in
coming of next day. Short press top backlight/snooze button to activate snooze function, which
will wake up again after 5 minutes. The snooze can repeat in each 5 minutes. Press any other
button (except snooze) can cancel the snooze.
The buzz alarm voice will last for 2 minute if there is no further operation.
Temperature and humidity
1. Indoor temperature range: -10 ~+50 ℃ / 14 ~122 ℉.
2. Outdoor temperature range: -40°C~60°C(-40°F~140°F) .
Remarks: LL.L℃ or HH.H℃ will show on display when out of the above range

7
3. Indoor and outdoor humidity range: 1%-99%
LL% or HH% will display when out of range
4. Temperature accuracy: ±1,0℃ between 0℃~ +50℃/ 32℉~104℉.
±1,5℃ outside this measuring range
5. Humidity accuracy: (40-70%) ± 5%, others ±8%
6. Press memory to check maximum and minimum history data, press and hold memory
button to manually clear the record. (Remarks: Historical record will be cleared automatically
at 00:00 every day).
Temperature trend
The temperature trend arrow (nearby temperature data) in different directions depending
on whether the latest temperature reading is higher or lower than previous readings.
Arrow angled upwards=Temperature rose up 1℃ in the past 1 hour.
Arrow in straight =Temperature changed less than 1℃ in the past 1 hour.
Arrow angled downwards=Temperature fell off 1℃ in the past 1 hour.
Humidity trend
The humidity trend arrow in different directions depending on whether the latest humidity
reading is higher or lower than previous readings.
Arrow angled upwards=Temperature rose up 5% in the past 1 hour.
Arrow in straight =Temperature changed less than 5% in the past 1 hour.
Arrow angled downwards=Temperature fell off 5% in the past 1 hour.
Weather forecast
The weather forecast is based on collected hourly barometric pressure value data from the
main unit. The forecast station predicts weather conditions for the next 12 hours with 70-
75% accuracy. The default weather icon is partly cloudy, the base station will calibrate the
weather report in the first 1-2 week after power on ,based on the barometric pressure data.
Weather forecast will appear in one of the following combinations (reference only):
SUNNY PARTLY CLOUD CLOUDY RAINY SNOWY
Please note that the device forecasts the weather based on limited parameters and may
differ from official weather forecasts which are calculated on the basis of advanced
algorithms.
Backlight and auto dim
Press top backlight/snooze button to turn on the backlight. The backlight will last 20
seconds and auto off.
Frost indicator
After the outside temperature has fallen below 3°C / 34°F, the symbol is displayed
as an indication and warning signal.
Barometric pressure
Barometer display in mmHg, inHg or hPa mb with max/min record.

8
Barometer range: 850-1050hPa/mb (637-787mmHg,25.1-31 inHg ).
Please note that this weather station reads absolute air pressure, which may differ from
that in the official weather forecasts. The reason for this difference is that the relative
pressure reported in the official weather forecasts is reduced to sea level. The absolute
pressure indicated in this model is the pressure at a given location at the appropriate
altitude.
Comfort level indicator
Temperature alert
The model includes alert function which is able to get voice warning in case of the
temperature is over the setup limit. Short press the alerts button repeatedly to check the
alert temperature mode sequence of outdoor high temperature/ outdoor low
temperature/indoor high temperature/ indoor low temperature. When you chose a
temperature alert, short press up or down button to turn on/off the alert function; long
press the alerts button, press up or down button can adjust the alert temperature. Short
press top backlight/snooze button can save and exist current setting. The temperature
alert symbol will show on display in case of you turn on relevant alert. When the measured
temperature exceeds the setup alert limit, the warning voice will come out from unit in
every 60 seconds. Short press alerts button can stop and cancel the voice, but the alert
icon keep flare on display until the measured data out of alert range.
Notes:
When the main unit is searching for signals from outdoor wireless transmitter, if you press
the alert button to check or set the alerts, that will stop the signal searching.
Calibration
Weather stations had calibrated precisely at our manufacturing facility, but if you want the
data of this product to be consistent with the reading of the equipment you are more
trusted or more used to, you can manually calibrate the indoor temperature, humidity and
barometer values.
1.When the display is normal mode, press and hold “ALERTS” and “MEM” button at the same
time to enter calibration mode.
2.Press and release the “SET” button to confirm and move to the next setting:
3.Indoor Temperature ------Indoor Humidity------- Barometer ------Exit.
4. Press “ / CH ” or “ ” button to adjust the value.
5. Calibration range: +/- 5 degree for temperature; +/-10% for humidity; +/-9 for
barometric pressure. The final data on display will plus or minus the calibrated values if
you set up.
Display
Humidity
Too wet
84-99%
Wet
76-83%
Comfort
40%-75%
Dry
26-39%
Too dry
1-25%
