Blaze King CLARITY CL2714.SP User manual

180-CL2714.SP v1.00 July 30, 2020
CLARITY CL2714.SP
DIRECT VENT GAS FIREPLACE INSERT
with 7 Day Shuto Standing Pilot (SP)
For use with natural gas (NG) or propane (LPG)
OPERATION & INSTALLATION MANUAL
Installer: Please complete the details on the back cover and leave this manual with the
homeowner.
Homeowner: Please keep these instructions for future reference.
Pour la version française de nos manuels S.V.P. vous référez à notre site web: www.blazeking.com
Date Installed:
Serial No.:
WARNING: If the information in these instructions are not followed exactly, a re or
explosion may result causing property damage, personal injury or loss of life.
PFS report#:F18-431
A safety screen designed to reduce the risk of burns from
the hot viewing glass is provided with this appliance and
shall be installed for the protection of children and other
at-risk individuals. If the safety screen becomes damaged,
the safety screen shall be replaced with the manufacturer’s
safety screen for this appliance.
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings
exactly could result in serious injury,
death, or property damage.
— Do not store or use gasoline or other
ammable vapors and liquids in the
vicinity of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not
use any phone in your building.
• Leave the premises.
• Immediately call your gas supplier from a
neighbor’s phone. Follow the gas supplier’s
instructions.
• If you cannot reach your gas supplier, call
the re department.
— Installation and service must be
performed by a qualied installer, service agency
or the gas supplier.
This appliance may be installed in an aftermarket,
permanently located, manufactured home (USA only) or
mobile home, where not prohibited by local codes.
This appliance may be installed in an OEM Installation in a
manufactured home (USA only) or mobile home and must be
installed in accordance with the manufacturer’s instructions
and the Manufactured Home Construction and Safety
Standard, Tittle 24 CRF, Part 3280, in the United States, or the
Standard for Installation in Mobile Homes, CAN/CSA Z240 MH
Series, in Canada.
This appliance is only for use with the type of gas indicated
on the rating plate. This appliance is not convertible for use
with other gases, unless a certied kit is used.

180-CL2714.SP v1.00 July 30, 2020
Page 2 Clarity CL2714 SP
SAFETY PRECAUTIONS _________________________________________________________________ 4
GENERAL....................................................................................................................................................................4
YOUR SAFETY..........................................................................................................................................................4
INSTALLATION ..........................................................................................................................................................5
GENERAL INFORMATION ________________________________________________________________ 6
APPLIANCE CERTIFICATION..............................................................................................................................6
INSTALLATION CODES .........................................................................................................................................6
SPECIFICATIONS.....................................................................................................................................................6
HIGH ALTITUDE INSTALLATION .....................................................................................................................6
CERTIFICATION LABEL __________________________________________________________________ 7
MA Code - CO Detector __________________________________________________________________ 8
DIMENSIONS_____________________________________________________________________________ 9
RATING LABEL LOCATION .................................................................................................................................9
SHROUD AND SHELF OPTIONS _________________________________________________________ 10
LIGHTING INSTRUCTIONS _______________________________________________________________ 12
820 NOVA VALVE_________________________________________________________________________ 13
OPERATING INSTRUCTIONS ____________________________________________________________ 14
PILOT LIGHT..............................................................................................................................................................14
LIGHTING THE BURNER ......................................................................................................................................14
OPTIONAL BLOWER...............................................................................................................................................14
MAINTENANCE and SERVICE____________________________________________________________ 15
ROUTINE MAINTENANCE....................................................................................................................................15
CLEANING SURFACES .........................................................................................................................................15
CLEANING THE GLASS.........................................................................................................................................15
SAFETY SCREEN TRIM REMOVAL ..................................................................................................................16
GLASS DOOR REMOVAL .....................................................................................................................................16
GLASS DOOR REPLACEMENT..........................................................................................................................17
BURNER REMOVAL................................................................................................................................................17
SAFETY SCREEN REPLACEMENT ..................................................................................................................18
FUEL CONVERSION...............................................................................................................................................19
INSTALLATION PLANNING_______________________________________________________________ 21
PRECAUTIONS .........................................................................................................................................................21
GAS CONNECTIONS..............................................................................................................................................21
SHUT-OFF VALVE LOCATION.............................................................................................................................21
FACTORY BUILT FIREPLACE OR ZERO CLEARANCE FIREPLACE...................................................22
INSTALLATION CLEARANCES ___________________________________________________________ 23
MINIMUM FIREPLACE DIMENSIONS ..............................................................................................................24
OPTIONAL BLOWER _____________________________________________________________________ 25
S.Z4946.SP BLOWER INSTALLATION .............................................................................................................25
INITIAL SETUP ..........................................................................................................................................................28
VENT TERMINATION LOCATION.......................................................................................................................29
VENTING .....................................................................................................................................................................29
VENT CONNECTOR REMOVAL AND INSTALLATION................................................................................30
VENT RESTRICTOR ...............................................................................................................................................31
AIR SHUTTER ADJUSTMENT .............................................................................................................................32
BURNER FLAME APPEARANCE .......................................................................................................................32
ELECTRICAL REQUIREMENTS .........................................................................................................................33
TABLE OF CONTENTS

180-CL2714.SP v1.00 July 30, 2020
Page 3
Clarity CL2714 SP
Manufactured By
Valley Comfort Systems Inc.
1290 Commercial Way
Penticton, BC V2A 3H5
CANADA
Phone: [phone]
Fax: [phone]
Blaze King Industries
146 A Street
Walla Walla, WA 99362
U.S.A.
Phone: [phone]
Fax: [phone]
TABLE OF CONTENTS
VENTING PARTS LIST ___________________________________________________________________ 34
VALVE REMOVAL & INSTALLATION _____________________________________________________ 37
PARTS LIST ______________________________________________________________________________ 38
TROUBLESHOOTING ____________________________________________________________________ 39
WARRANTY ______________________________________________________________________________ 40
NOTES ___________________________________________________________________________________ 44
CALIFORNIA PROPOSITION 65
WARNING: This product can expose you to chemicals including
benzene, which is known to the State of California to cause cancer and
birth defects or other reproductive harm. For more information:
www.P65Warnings.ca.gov
REQUIRED KIT (choose one)
S.Z4981 CL2714 SHROUD 24.5” x 36.5”
S.Z4982 CL2714 SHROUD 26.5” x 38”
S.Z4983 CL2714 SHROUD 29” x 40”
S.Z4984 CL2714 SHROUD 32” x 44”
S.Z4985 CL2714 SHROUD 32” x 44” TRIMMABLE
OPTIONAL KITS
S.0402 CL2714 FIREBOX GLASS KIT (3PC)
S.0602 CL2714 FIREBOX GLASS KIT (4PC)
S.0519 LOG SET DRIFT CLARITY (5PC)
S.0529 LOG SET DRIFT CL2714 (7PC)
S.Z4990 CL2714 45” SHELF WITH RISERS
S.Z4991 CL2714 MANTLE SHIELD 40”
S.Z4992 CL2714 MANTEL SHIELD 32”
S.Z4993 CL2714 SHELF RISER
S.Z4994 CL2714 ANGLED SHROUD BASE
S.Z4946.SP CL2118 & CL2714 FAN KIT IPI
S.5100 CLARITY CUSTOM FIREBOX ARTWORK
S.5120 CL26 & CL2714 “CITY SCAPE” FIREBOX ARTWORK
S.5142 CL26 & CL2714 “IN THE WOODS” FIREBOX ARTWORK
S.5301 CL2714 “MARINE SCAPE” LARGE FIREBOX ARTWORK
S.5302 CL2714 “MOUNTAIN SCAPE” LARGE FIREBOX ARTWORK

180-CL2714.SP v1.00 July 30, 2020
Page 4 Clarity CL2714 SP
SAFETY PRECAUTIONS
NOTE: Failure to follow these instructions could cause a malfunction of the replace, which could result in
death, serious bodily injury, and/or property damage.
GENERAL
• Installation and repair should be done by a qualied service person. The appliance should be inspected
before the rst use and, at least, annually by a qualied service person. More frequent cleaning may
be required due to excessive lint from carpeting, bedding material, etc. It is imperative the control
compartments, burners and circulating air passageways of the appliance be kept clean.
• If the CLARITY CL2714 is pulled out of its installation, and the vent-air intake pipes is disconnected for
any reason, ensure that the vent-air intake pipes are reconnected and re-sealed in accordance to the
instructions noted in INSTALLATION - VENT CONNECTOR REMOVAL AND INSTALLATION.
• Due to high temperatures, the appliance should be located out of high tra󰀩c areas and away from furniture
and draperies.
Children and adults should be alerted to the hazards of high surface
temperatures and should stay away to avoid burn or clothing ignition.
• Young children should be carefully supervised when in the same room as the appliance. Toddlers, young
children and others may be susceptible to accidental contact burns. A physical barrier (safety screen) is
required if there are at risk individuals in the house. To restrict access to a replace or stove install an
adjustable safety gate to keep toddlers, young children and other at risk individuals out of the room and
away from hot surfaces. Any safety screen, guard, or barrier removed for servicing an appliance must be
replaced prior to operating the appliance.
• Clothing or other ammable materials should not be placed on or near the appliance.
YOUR SAFETY
• Have the venting system inspected annually by a qualied installer for blockage and signs of deterioration.
• To prevent injury, do not allow anyone who is unfamiliar with the stove to operate it.
• To prevent injury, if the pilot or pilot and burners have gone out on their own, open the glass door and wait
5 minutes to air out before attempting to relight the stove.
• Always keep the area around these appliances clear of combustible material, gasoline and other ammable
liquids and vapors.
• These appliances should not be used as a drying rack for clothing or for hanging Christmas stockings/
decorations.
• Due to the paint curing on the stove, a faint odor and slight smoking will likely be noticed when the stove is
rst used. Open a window until the smoking stops.
• Do not use this appliance if any part has been under water. Immediately call a qualied service technician
to inspect the appliance and to replace any part of the control system and any gas control which has been
under water.
• Do not abuse the glass by striking it or slamming the door shut.
DO NOT OPERATE WITH THE GLASS FRONT REMOVED, CRACKED OR BROKEN. REPLACEMENT
OF THE GLASS SHOULD BE DONE BY A LICENSED OR QUALIFIED SERVICE PERSON.

180-CL2714.SP v1.00 July 30, 2020
Page 5
Clarity CL2714 SP SAFETY PRECAUTIONS
INSTALLATION
• Installation and service must be performed by a qualied installer, service agency or gas supplier
• Only doors certied with the appliance shall be used. (see door part numbers in “PARTS LIST”)
• This installation must conform to local codes or, in the absence of local codes, with the National Fuel Gas
Code, ANSI Z223.1 / NFPA 54 in the US, or the Natural Gas and Propane Installation Code, CSA B149.1 in
Canada.
• A manufactured home (USA only) or mobile home OEM installation must conform with the Manufactured
Home Construction and Safety Standard, Title 24 CFR, Part 3280, or, when such a standard is not
applicable, the Standard for Manufactured Home Installations, ANSI / NCSBCS A225.1, or Standard for
Gas Equipped Recreational Vehicles and Mobile Housing, CSA Z240.4.
• Always connect this gas appliance to a vent system and vent to the outside of the building envelope.
Never vent to another room or inside the building. Make sure the specied vent pipe is used, properly
sized and of adequate height to provide su󰀩cient draft.
• The ow of combustion and ventilation air must not be obstructed .
• The appliance and its appliance main gas valve must be disconnected from the gas supply piping system
during any pressure testing of that system at test pressures in excess of 1/2 psi (3.5 kPa).
• This gas appliance must not be connected to a chimney ue serving a separate solid-fuel burning
appliance.
• The appliance, when installed, must be electrically grounded in accordance with local codes or, in the
absence of local codes, with the National Electrical Code, ANSI / NFPA 70, in the US, or the Canadian
Electrical Code, CSA C22.1, in Canada.
• Caution: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper
and dangerous operation. Verify proper operation after servicing.
FAILURE TO POSITION THE PARTS IN ACCORDANCE WITH THE DIAGRAMS IN THIS BOOKLET,
OR FAILURE TO USE ONLY PARTS SPECIFICALLY APPROVED WITH THIS APPLIANCE, MAY
RESULT IN PROPERTY DAMAGE OR PERSONAL INJURY.

180-CL2714.SP v1.00 July 30, 2020
Page 6 Clarity CL2714 SP
SPECIFICATIONS
MODEL
CL2714.SP Natural Gas (NG) Propane (LP)
Manifold Pressure 3.8 in. w.c. (0.95kPa) 11.0 in. w.c. (2.74 kPa)
Min. Supply Pressure for
Purpose of Input Adjustment 7 in. w.c. (1.74 kPa) 13.0 in. w.c. (3.23 kPa)
Orice Size DMS #41 DMS #53
Nominal Input Rating 24,682 BTU/hr, 7.23 kWh 24,956 BTU/hr, 7.31 kWh
Minimum Input Rating 12,893 BTU/hr, 3.78 kWh 12,982 BTU/hr, 3.80 kWh
Altitude 0 - 4,500 ft. (0 - 1372 m) 0 - 4,500 ft. (0 - 1372 m)
Primary Air Opening 1/16” (Minimum) 1/16”
Electrical Rating 120 V.A.C. System 120 V.A.C. System
HIGH ALTITUDE INSTALLATION
When installing this appliance beyond 4500 ft. (1372 m) above sea level, the appliance must be properly de-
rated and installed according to local codes, in the absence of local codes, with the current National Fuel Gas
Code, ANSI Z223.1/ NFPA 54, in the US or Installation Code, CSA-B149.1, in Canada.
GENERAL INFORMATION
INSTALLATION CODES
This appliance must be installed by a qualied gas
appliance installer. This appliance is certied for installation
in a bedroom or a bedsitting room. This appliance is only
for use with the type of gas indicated on the rating plate and
may be installed in an aftermarket, permanently located,
manufactured (mobile) home where not prohibited by
local codes. This appliance is not convertible for use with
other gases, unless a certied kit is used. Only for direct
discharge without duct connection. This appliance must
be direct vented using listed and approved Simpson Dura-
Vent, Selkirk, Security or American Metal Products vent
components.
We recommend
that our gas hearth
products be installed
and serviced by
professionals who are
certied in the U.S. by
the National Fireplace
Institute (NFI) as NFI
Gas Specialists.
APPLIANCE CERTIFICATION
This appliance is tested and certied to the following US and Canadian gas appliance standards:
• ANSI Z21.88-2017 / CSA 2.33-2017 Vented Gas Fireplace Heaters,
• CAN/CGA-2.17-M91 (R2014) Gas-Fired Appliance for Use at High Altitudes
• CSA P.4.1-15 Testing Method for Measuring Annual Fireplace E󰀩ciency
STEADY STATE EFFICIENCY
Natural Gas (NG) Propane (LP)
Steady State E󰀩ciency - High E󰀨ySS,H 66.87% 69.48%
Annual Fireplace E󰀩ciency FE 61.12% 60.91%

180-CL2714.SP v1.00 July 30, 2020
Page 7
Clarity CL2714 SP CERTIFICATION LABEL

180-CL2714.SP v1.00 July 30, 2020
Page 8 Clarity CL2714 SP
MA Code - CO Detector
(for the State of Massachusetts only)
5.08: Modications to NFPA-54, Chapter 10
(2) Revise 10.8.3 by adding the following additional requirements:
(a) For all side wall horizontally vented gas fueled equipment installed in every dwelling, building or structure used in whole or in part for
residential purposes, including those owned or operated by the Commonwealth and where the side wall exhaust vent termination is less than
seven (7) feet above nished grade in the area of the venting, including but not limited to decks and porches, the following requirements shall
be satised:
1. INSTALLATION OF CARBON MONOXIDE DETECTORS. At the time of installation of the side wall horizontal vented gas fueled equipment,
the installing plumber or gastter shall observe that a hard wired carbon monoxide detector with an alarm and battery back-up is installed on
the oor level where the gas equipment is to be installed. In addition, the installing plumber or gastter shall observe that a battery operated
or hard wired carbon monoxide detector with an alarm is installed on each additional level of the dwelling, building or structure served by the
side wall horizontal vented gas fueled equipment. It shall be the responsibility of the property owner to secure the services of qualied licensed
professionals for the installation of hard wired carbon monoxide detectors.
a. In the event that the side wall horizontally vented gas fueled equipment is installed in a crawl space or an attic, the hard wired carbon
monoxide detector with alarm and battery back-up may be installed on the next adjacent oor level.
b. In the event that the requirements of this subdivision can not be met at the time of completion of installation, the owner shall have a period
of thirty (30) days to comply with the above requirements; provided, however, that during said thirty (30) day period, a battery operated carbon
monoxide detector with an alarm shall be installed.
2. APPROVED CARBON MONOXIDE DETECTORS. Each carbon monoxide detector as required in accordance with the above provisions
shall comply with NFPA 720 and be ANSI/UL 2034 listed and IAS certied.
3. SIGNAGE. A metal or plastic identication plate shall be permanently mounted to the exterior of the building at a minimum height of eight (8)
feet above grade directly in line with the exhaust vent terminal for the horizontally vented gas fueled heating appliance or equipment. The sign
shall read, in print size no less than one-half (1/2) inch in size, “GAS VENT DIRECTLY BELOW. KEEP CLEAR OF ALL OBSTRUCTIONS”.
4. INSPECTION. The state or local gas inspector of the side wall horizontally vented gas fueled equipment shall not approve the installation
unless, upon inspection, the inspector observes carbon monoxide detectors and signage installed in accordance with the provisions of 248
CMR 5.08(2)(a)1 through 4.
(b) EXEMPTIONS: The following equipment is exempt from 248 CMR 5.08(2)(a)1 through 4:
1. The equipment listed in Chapter 10 entitled “Equipment Not Required To Be Vented” in the most current edition of NFPA 54 as adopted by
the Board; and
2. Product Approved side wall horizontally vented gas fueled equipment installed in a room or structure separate from the dwelling, building or
structure used in whole or in part for residential purposes.
(c) MANUFACTURER REQUIREMENTS - GAS EQUIPMENT VENTING SYSTEM PROVIDED. When the manufacturer of Product Approved
side wall horizontally vented gas equipment provides a venting system design or venting system components with the equipment, the
instructions provided by the manufacturer for installation of the equipment and the venting system shall include:
1. Detailed instructions for the installation of the venting system design or the venting system components; and
2. A complete parts list for the venting system design or venting system.
(d) MANUFACTURER REQUIREMENTS - GAS EQUIPMENT VENTING SYSTEM NOT PROVIDED. When the manufacturer of a Product
Approved side wall horizontally vented gas fueled equipment does not provide the parts for venting the ue gases, but identies “special venting
systems”, the following requirements shall be satised by the manufacturer:
1. The referenced “special venting system” instructions shall be included with the appliance or equipment installation instructions; and
2. The “special venting systems” shall be Product Approved by the Board, and the instructions for that system shall include a parts list and
detailed installation instructions.
(c) A copy of all installation instructions for all Product Approved side wall horizontally vented gas fueled equipment, all venting instructions, all
parts lists for venting instructions, and/or all venting design instructions shall remain with the appliance or equipment at the completion of the
installation.

180-CL2714.SP v1.00 July 30, 2020
Page 9
Clarity CL2714 SP
35"
22
1
2
"
SECONDARY TRIM
SAFETY SCREEN TRIM
20
5
8
"
41
4
"
GAS INLET
1
3
4
"
15
1
2
"
2
1
2
"
18
1
8
"
41
4
"
GAS INLET
1
3
4
"
22
1
8
"
29
1
8
"
10
1
8
"
12
1
4
"
NOTE: TURNING ON YOUR APPLIANCE WHEN IT HAS BEEN OFF FOR
AWHILE MAY CAUSE TEMPORARY CONDENSATION TO APPEAR ON THE
GLASS. THIS IS A NORMAL OCCURRENCE AS YOUR APPLIANCE HEATS UP.
DIMENSIONS
RATING LABEL LOCATION
The rating label is located below the rebox behind a ip down door. It is a󰀩xed to rectangular metal sheets
that are chained to the appliance.
FLUE
EXHAUST AIR
INTAKE

180-CL2714.SP v1.00 July 30, 2020
Page 10 Clarity CL2714 SP
SHROUD AND SHELF OPTIONS
S.Z4981 CL2714 SHROUD 24.5” x 36.5”
S.Z4982 CL2714 SHROUD 26.5” X 38”
S.Z4983 CL2714 SHROUD 29” x 40”
S.Z4984 CL2714 SHROUD 32” x 44”
32"
44"
40"
29"
38"
261
2
"
24
1
2
"
36
1
2
"

180-CL2714.SP v1.00 July 30, 2020
Page 11
Clarity CL2714 SP SHROUD AND SHELF OPTIONS
S.Z4985 CL2714 SHROUD 32” x 44”
TRIMMABLE
S.Z4990 CL2714 45” SHELF W/ RISERS
REQUIRES CL2714 SHROUD
S.Z4994 CL2714 ANGLED SHROUD BASE
REQUIRES S.Z4981 CL2714 SHROUD 24.5”x36.5”
OR S.Z4982 CL2714 SHROUD 26.5”x38”
44"
32"
15
8
"
39"
17
8
"
45"

180-CL2714.SP v1.00 July 30, 2020
Page 12 Clarity CL2714 SP
WARNING: If you do not follow these instructions exactly, a  re or explosion may result
causing property damage, personal injury or loss of life.
FOR YOUR SAFETY, READ BEFORE LIGHTING
A. This appliance has a pilot which is lit with a push button piezo lighter. When lighting the pilot, follow these
instructions exactly.
B. BEFORE LIGHTING, smell all around the appliance area for gas. Be sure to smell next to the  oor
because some gas is heavier than air and will settle on the  oor.
WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electric switch; do not use any phone in your building.
• Immediately call your gas supplier from a neighbor’s phone. Follow the gas suppliers instructions.
• If you cannot reach your gas supplier, call the  re department.
C. Use only your hand to push in or turn the gas control knob. Never use tools. If the knob will not push in or
turn by hand, don’t try to repair it, call a quali ed service technician. Force or attempted repair may result
in a  re or explosion.
D Do not use this appliance if any part has been under water. Immediately call a quali ed service technician
to inspect the appliance and to replace any part of the control system and any gas control which has been
under water.
LIGHTING INSTRUCTIONS
1. STOP! Read the safety information above.
2. Set the thermostat to the lowest setting.
3. Valve controls are accessed by lowering the hinged panel that is below the  rebox.
4. Set the manual burner switch to the “OFF” position.
5. Push in gas control knob slightly and turn clockwise to “OFF”.
6. Wait  ve (5) minutes to clear out any gas. Then smell for gas, including near the  oor. If you smell gas,
STOP! Follow “B” in the safety information above. If you don’t smell gas, go to the next step.
7. Turn control knob counterclockwise to “PILOT” position.
8. Depress control knob and push in Piezo ignitor button. Once pilot ignites, continue to hold the control
knob in for about one (1) minute after the pilot is lit. Release knob and it will pop back up.
Pilot should remain lit. If it goes out, repeat steps 6 through 8.
• If knob does not pop up when released, stop and immediately call your service technician or gas
supplier.
• If the pilot will not stay lit after several tries, turn the gas control knob to “OFF” and call your service
technician or gas supplier.
9. Turn gas control knob counter clockwise to “ON”. Turn on all electric power to the appliance. Set
thermostat to the desired setting or set the manual burner switch to the “ON” position.
TO TURN OFF GAS TO THE APPLIANCE
1. Set the thermostat to the lowest setting.
2. Turn o󰀨 all electric power to the appliance if service is to be performed.
3. Push in gas control knob slightly and turn clockwise to “OFF”. Do not force.
WARNING
Improper installation, adjustment, alteration,
service or maintenance can cause injury
or property damage. Refer to the owner’s
information manual provided with this appliance.
For assistance or additional information, consult
a quali ed installer, service agency or your gas
supplier.
170-0360 [03 18]
LIGHTING INSTRUCTIONS

180-CL2714.SP v1.00 July 30, 2020
Page 13
Clarity CL2714 SP 820 NOVA VALVE
AE
P
I
L
O
T
TP TH TP TH
1
5
15 67
8
2349
10
11
13
14
12
820 NOVA VALVE
1ON/PILOT/OFF Knob
2Manual HI-LO adjustment or pressure regulator adjustment
3 Pilot adjustment
4Thermocouple connection
5 Mounting for piezo & bracket
6 Inlet pressure test point
7Outlet pressure test point
8Main operator
9Pilot outlet
10 Main gas outlet
11 Flange mounting screw holes
12 Additional valve mounting holes
13 Alternative TC connection point
14 Thermoelectric unit
15 Inlet

180-CL2714.SP v1.00 July 30, 2020
Page 14 Clarity CL2714 SP
OPERATING INSTRUCTIONS
PILOT LIGHT
Refer to the lighting instruction label on how
to light the pilot. Check that the pilot has
fully engulfed the thermocouple assembly
(Fig.1).
LIGHTING THE BURNER
Standing Pilot (SP)
The CLARITY CL2714 SP controls are
located behind the hinged ap beneath the
rebox.(Fig.2) To light the burner follow the
steps below:
1. Make sure the pilot is lit (see “LIGHTING
INSTRUCTIONS Standing Pilot”)
2. Turn the “Valve Control” knob
counterclockwise to ON.
3. Flip the ame ON/OFF switch, located
beside the igniter to ON.(Fig.2)
4. Turn the “Flame Height” knob to the
desired ame height.(Fig.2)
5. Turn on all electrical power to the unit.
6. NOTE: Burn the appliance on high, with
the optional blower OFF, for the rst
two to three hours. This will cure all the
paint, gasket, and seals. It is advised to
open a door or window as the unit will
smoke and give o󰀨 odors as it is curing.
OPTIONAL BLOWER
An optional blower S.Z4946.SP is available.
For installation refer to the installation
instructions provided with the kit.
Turn the blower on by turning the “Blower
Speed” knob clockwise .(Fig.2) The
blower will only come on when the replace
is up to temperature (approximately 10-
15 minutes) because it is equipped with
a thermal switch. Fan speed control
sequence is o󰀨, then maximum to minimum.
The speed of the fan can be decreased by
turning the knob clockwise . The speed
of the fan can be increased by turning the
knob counterclockwise . The blower
will continue to operate after the burner is
turned o󰀨 (approximately 15-20 minutes).
To turn the blower o󰀨 manually, turn the fan
control knob counterclockwise until it
“clicks”.
Fig.2
Fig.1

180-CL2714.SP v1.00 July 30, 2020
Page 15
Clarity CL2714 SP MAINTENANCE and SERVICE
ROUTINE MAINTENANCE
Regularly:
• Clean and remove any lint accumulations or debris from the grills and combustion or convection air
passage ways.
• Keep the appliance area free from combustible materials, such as paper, wood, clothing, gasoline,
ammable solids, liquids and vapors.
• Visually check the height and color of the burner and pilot ames. The pilot ame should be blue with
little or no yellow on the tips.
• Check for unusual noises or odors during operation of the appliance.
• Check the vent terminal for any damage, or obstruction by plants or debris accumulation.
It is recommended to periodically have your appliance serviced by a qualied service technician:
1. Turn o󰀨 the appliance and allow it to cool down completely
2. Remove the safety screen trim and glass door (see “GLASS DOOR REMOVAL” on next page) and
clean the inside of the glass with a soft, non-abrasive cloth and water or a suitable, mild, non-abrasive
cleaner.
3. Remove and clean the glass oor panel and set aside.
4. Check the burner to see if all the ports are clear and clean. Check the pilot assembly to make sure it is
not blocked by anything. Use a vacuum to clear out any debris around the burner and valve.
5. Completely inspect the appliance and the venting system.
6. Check the safety system of the gas valve.
CLEANING SURFACES
Painted, powder coated, or porcelain enameled surfaces should be wiped with a damp cloth periodically.
Ensure the appliance has cooled down completely before any cleaning. Do not use other cleaners as they
may leave a residue which can become permanently etched into the surface.
CLEANING THE GLASS
DO NOT TO CLEAN THE GLASS WHILE IT IS HOT
One of the by-products of combustion and moisture in the rebox is a white lm which can show up on the
glass of the viewing door. Initial curing of the appliance can also leave a slight lm on the glass, which is a
temporary problem.
1. Turn o󰀨 the appliance and allow it to cool down completely.
2. Remove the safety screen trim and glass door from the rebox (see “GLASS DOOR REMOVAL” on
next page)
3. Check the gasket material on the back of the glass. Ensure that it is attached and intact.
4. Clean the glass with a mild glass cleaner and a soft cloth (see below). Abrasive cleaners will damage
the glass
Slight soiling of SCHOTT ROBAX® panels can be removed using conventional glass cleaning products,
provided they are used according to instructions of use, which means cleaning on cold surfaces. The residues
should be removed since chemical attack is possible on exposure to temperature. The coated ROBAX®
Mirror, ROBAX® TrueView, ROBAX® IR Max and ROBAX® Energy Plus can be cleaned with a soft cloth.
NOTE: IT IS NOT RECOMMENDED TO USE SCOURING PADS, ABRASIVE CLEANSERS OR SCOURING
AGENTS, AS MAY CAUSE DAMAGE TO THE GLASS SURFACE. THE SCHOTT-RECOMMENDED DRY
WIPER IS SUITABLE FOR USE ONLY ON UNCOATED FIRE VIEWING PANELS.

180-CL2714.SP v1.00 July 30, 2020
Page 16 Clarity CL2714 SP
MAINTENANCE and SERVICE
Fig.1
Fig.2
Fig.3
SAFETY SCREEN TRIM REMOVAL
1. Turn o󰀨 the appliance and allow it to cool
down completely.
2. The safety screen trim ts into tabs on the
appliance. Lift the safety screen trim up
and out, away from the appliance, and set
it aside. (Fig.1)
GLASS DOOR REMOVAL
For installation, cleaning, and burner removal the
safety screen trim (see “SAFETY SCREEN TRIM
REMOVAL”) and glass door must be removed.
1. There are two door latch mechanisms on
top of the glass door.(Fig.2) Pull
the tabs forward and up o󰀨 the
door tabs.
2. Carefully slide the door glass assembly up
and out of the unit and set it aside.(Fig.3)

180-CL2714.SP v1.00 July 30, 2020
Page 17
Clarity CL2714 SP
GLASS DOOR REPLACEMENT
The glass in this appliance is a 5 mm anti-
reective high temperature ceramic glass
that will easily withstand the heat that is
produced. In the event the glass breaks or
cracks, contact your dealer to arrange for
your glass door to be replaced with a factory
replacement (see “PARTS LIST”). Do not
operate this appliance with the glass front
removed, cracked, or broken. Removal and
replacement of the glass from the door must
be done by a qualied service technician.
The glass door must be purchased from a
Blaze King dealer. No substitute materials
are allowed.
BURNER REMOVAL
1. Turn o󰀨 the appliance and allow it to
cool down completely.
2. Remove the safety screen trim, and
glass door. (see “SAFETY SCREEN
TRIM AND GLASS DOOR REMOVAL”
on previous page)
3. Remove the oor plate and set it aside.
(Fig.4)
4. Remove the screw from the left hand
side of the burner assembly. (Fig.5)
5. Move the burner to the right, up, and
out.
To re-install the burner follow steps 1 to 5
in reverse. Ensure the burner is centered
in the curved burner slot of the glass oor
plate.
Fig.4
FLOOR PLATE
Fig.5
SCREW
BURNER
MAINTENANCE and SERVICE

180-CL2714.SP v1.00 July 30, 2020
Page 18 Clarity CL2714 SP
MAINTENANCE and SERVICE
SAFETY SCREEN REPLACEMENT
The CL2714 is supplied with a safety screen
pre-installed inside the safety screen trim. If
the safety screen becomes damaged it must
be replaced with part #645-16305 for Z4921
Safety Screen Trim.
1. Turn o󰀨 the appliance and allow it to
cool down completely.
2. Remove the safety screen trim by lifting
up and out. (see “SAFETY SCREEN
TRIM REMOVAL”)
3. Slide the safety screen out of the frame,
the tabs may have to be adjusted.
(Fig.6)
4. Slide the new safety screen in between
the frame face and the tabs. Ensure
screen mesh faces out, furthest from
glass. (Fig.7)
5. Hang the safety screen trim back into
position.
SCREEN
MESH TO
THIS
SIDE
Fig.6
Fig.7

180-CL2714.SP v1.00 July 30, 2020
Page 19
Clarity CL2714 SP
FUEL CONVERSION
THIS CONVERSION KIT SHALL BE INSTALLED BY A QUALIFIED SERVICE AGENCY IN
ACCORDANCE WITH THE MANUFACTURER’S INSTRUCTIONS AND ALL APPLICABLE CODES AND
REQUIREMENTS OF THE AUTHORITIES HAVING JURISDICTION. IF THE INFORMATION IN THESE
INSTRUCTIONS IS NOT FOLLOWED EXACTLY, A FIRE, EXPLOSION OR PRODUCTION OF CARBON
MONOXIDE MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF
LIFE. THE QUALIFIED SERVICE AGENCY IS RESPONSIBLE FOR THE PROPER INSTALLATION OF
THE KIT. THE INSTALLATION IS NOT COMPLETE UNTIL THE OPERATION OF THE CONVERTED
APPLIANCE IS CHECKED AS SPECIFIED IN THE INSTRUCTION MANUAL SUPPLIED WITH THE
KIT. BEFORE PERFORMING THIS OR ANY SERVICE PROCEDURE, MAKE SURE THAT THE GAS
SUPPLY TO THE UNIT AND THE ELECTRICAL SUPPLY ARE SHUT OFF.
CONVERSION KIT CONTENTS
The conversion kit contains the following parts:
• S.Z0770 (LP)> #635-OR53 (#53 orice) and LP regulator.
• S.Z0772 (NG)> #635-OR41 (#41 orice) and NG regulator.
• Conversion kit labels.
To convert from NG to LPG or reverse:
1. Turn o󰀨 the appliance and allow it to cool down completely
2. Remove burner (see “BURNER REMOVAL”)
3. Replace main orice
4. Convert pilot fuel (see below)
5. Replace regulator (see next page)
6. Check and properly adjust gas manifold, as well as verity the input rate of the appliance upon completion of
conversion.
How to convert CLARITY CL2714 SP Pilot orice:
1. Use a 7/16” wrench to loosen the pilot hood.
2. Push the little tab in and the little tab with hole should pop out. The hole stamp tab (LP) out is used for
Propane. The stamped tab (NA) out is for Natural Gas.
3. Re-tighten the pilot hood.
4. Fill out the fuel conversion label and a󰀩x it to the top of the appliance bottom near valve.
All valves have been pre-set and certied for installation at elevations from 0 – 4500 feet (1 – 1372m) above
sea level.
HIGH ELEVATIONS
When installing this unit at higher elevations, it is necessary to decrease the input rating by replacing the
existing burner orice with a smaller size for installations over 4500 feet (1370 m). Above 4500 ft, the
appliance input should be reduced 4% for each additional 1000 feet (305m). For the USA, derate the unit
according to the gas installation code.
MAINTENANCE and SERVICE

180-CL2714.SP v1.00 July 30, 2020
Page 20 Clarity CL2714 SP
820 NOVA
installationi
i
n
n
s
s
t
t
r
r
u
u
c
c
t
t
i
i
o
o
n
n
s
s
HI/LO Conversion Kit
WARNING!
The installation of this conversion kit must only be undertaken by a
qualified and certified gas appliance installer.
WARNING!
This HI-LO conversion kit must ONLY be applied as part of a conversion kit
supplied by the APPLIANCE MANUFACTURER for the specific appliance, and
type of gas, being converted.
INSTALLER NOTICE. These instructions must be left with appliance.
1
2
3
4
5
6
7
This installation or replacement instruction refer to HI-LO pressure
regulator kit to be used to convert the 820 Nova Combination Gas Control
with adjustable pressure regulator into manual HI-LO. The same kit can
also be used for the conversion from LP to Natural Gas and vice versa of
the 820 Nova with manual HI-LO.
7.252.021 001
Turn control knob to the OFF position,
and shut off the gas supply to the
valve.
Using a Torx T20, or slotted screwdriver,
remove and discard the three pressure
regulator mounting screws (A), pressure
regulator tower (B), and the spring and
diaphragm assembly (C).
Ensure the rubber gasket (D), which is
prefitted as part of assembly (E), is
properly positioned and install the new
HI/LO pressure regulator assemble
using the supplied screws (F).
Tighten screws securely.
(Reference torque = 25 lb·in).
Install the enclosed identification label
(G) to the valve body where it can be
easily seen.
Apply gas to system and re-light
appliance according to manufacturers
instructions.
With the main burner “ON”, test the
new pressure regulator assembly for
leaks using a soap solution.
Relight the main burner in both the HI,
and LO positions, and verify proper
burner ignition and operation.
T
T
L
L
O
O
I
I
P
P
O
O
T
T
0
0
N
N
L
L
0
0
F
F
P
P
I
I
F
F
C
C
B
B
A
A
HI
HI
LO
LO
P
P
I
I
O
O
L
L
T
T
T
T
O
O
N
N
0
0
P
P
F
F
I
I
F
F
0
0
L
L
A
A
C
C
B
B
G
G
P
P
I
I
L
L
O
O
T
T
0
0
N
N
I
I
L
L
O
O
T
T
0
0
F
F
F
F
P
P
D
D
E
E
F
F
F
F
HI
HI
LO
LO
MAINTENANCE and SERVICE
