Blaze BLZ-3-NG User manual

Blaze Outdoor Products Instructional Book
Page | 1
Version 1.6
USE & CARE GUIDE
GAS GRILLS BLZ-3(NG/LP), BLZ-4(NG/LP), BLZ-5(NG/LP)
ATTENTION:
INSTALLER: PLEASE LEAVE THESEINSTRUCTIONS WITH THE CONSUMER.
CONSUMER: PLEASE READ &RETAIN THESEINSTRUCTIONS FORFUTURE REFERENCEAND BEFORE
INSTALLING
OR OPERATING.
- CONTACT INFORMATION -
Blaze Outdoor Products: 6620 Greenwell Springs Rd, Baton Rouge, LA
70805USA
Phone: [phone] email:
[e-mail]
BLAZEGRILLS.COM
DANGER - IF YOU SMELL GAS:
I) Shut off the gas supply to the appliance at its source.
2) Extinguish any open flames.
3) Open grill hood to release any accumulation ofgas
vapor.
4) If a gas odor persists, Keep away fromyour
appliance and contact your gas supplier or fire
department immediately.
WARNING
I) Do not store or use gasoline or other flammable
liquids or vapor in the vicinity of this or any other
appliance
2) A LP cylinder not connected for use shall not be
stored in the vicinity of this or any other appliances.

Blaze Outdoor Products Instructional Book
Page | 2
Version 1.6
Table of Contents
I. BBQ Specifications 4-6
II. General Safety and Installation Warnings 7-9
i. Location of Appliance 10-12
III. Electrical Safety and Installation Warnings 13
IV. Gas Safety and Installation Warnings 14
i. Checking for Gas Leaks 15-17
ii. Unpacking Unit 18
V. Gas Connections 19
i. Natural Gas Requirements 19
ii. Liquid Propane Gas and TankRequirements 19
iii. Transporting and Storing LP Gas 20-21
VI. Installing the Appliance in a BBQIsland 22
i. Outdoor Kitchen Ventilation 23-25
ii. Building BBQSpecifications + Instruction Diagrams 26-27
VII. First Time Operation 28
i. Lighting theAppliance 28
ii. Manually Lighting theAppliance 29-30
iii. Flame Adjustment 31

Blaze Outdoor Products Instructional Book
Page | 3
Version 1.6
VIII. Cleaning your Appliance 31-32
IX. Optional Infrared Sear Burner 33
i. How to Replace Conventional Burner with Infrared Sear Burner 33
ii. Preheating the Infrared Burner 33
iii. Infrared Burner Cleaning 33
X. Fuel Conversion 34
i. Gas Regulator 34-35
ii. Main Burner 36
iii. Rear Burner 36
XI. Warranty Registration 37
XII. Grill Parts 38-39
XIII. Product Serial Number 40
XIV. Blaze Product Registration 41

Blaze Outdoor Products Instructional Book
Page | 4
Version 1.6
THIS MANUAL APPLIES TO THE FOLLOWING BLAZE GRILLS:
Model:BLZ-3LP / BLZ-3NG 3 BURNER
Cutout Dimensions
23 1/4”W x 21 1/4”D x 8 1/2”H
BTU Output
14,000 BTU per Burner x3
Infrared Back Burner
None
Total BTU
42,000
Primary Ignition
Push N’ Turn Flame Thrower
Secondary Ignition
Flash Tube
Cooking Grid
Dimensions 22 3/8" X 18"
Total Cooking Area
558sq.in
(includes warming rack)
Flame Tamer
Flame Stabilizer Grid
Zone Cooking
Removable Heat Zone
Separators
Rotisserie Kit
(Motor & Forks)
Optional (4 burner kit available for use
withthis model)
Burner
Commercial Quality Cast
Stainless Steel
Gas Type
Each grill contains an NG/LP Orifice
Kit
Warranty
*Limited Lifetime – Defects in
manufacturing and workmanship.
Cooking grids, Flame Tamers, Heat
Zone Separators, stainless housing as
w ell as the stainless burners against
rust- through.
*1 Year –Ignition components and all
other components
*Appliances must be registered within
30 days of purchase to validate this
warranty.
*See w arranty sectionfor
details.
Model:BLZ-4LP / BLZ-4NG 4 BURNER
Cutout Dimensions
30 5/8”W x 21 1/4”D x 8 1/2”H
BTU Output
14,000 BTU per Burner x4
Infrared Back Burner
10,000 BTU
Total BTU
68,000
Primary Ignition
Push N’ Turn Flame Thrower
Secondary Ignition
Flash Tube
Cooking Grid
Dimensions
29 1/2" X 17 7/8"
Total Cooking Area
748sq.in
(includes warming rack)
Flame Tamer
Flame Stabilizer Grid
Zone Cooking
Removable Heat Zone
Separators
Rotisserie Kit
(Motor & Forks) Optional
Burner
Commercial Quality Cast
Stainless Steel
Gas Type
Each grill contains an NG/LP
Orifice Kit
Warranty
*Limited Lifetime – Defects in
manufacturing and
workmanship. Cooking grids,
Flame Tamers, Heat Zone
Separators, stainless housing
as w ell as the stainless burners
against rust- through.
*1 Year –Ignition components
and all other components
*Appliances must be
registered within 30 days of
purchase to validate this
warranty.
*See w arranty sectionfor
details.

Blaze Outdoor Products Instructional Book
Page | 5
Version 1.6
Model:BLZ-5LP / BLZ-5NG 5 BURNER
Cutout Dimensions
38 3/8”W x 21 1/4"D x 8 1/2”H
BTU Output
14,000 BTU per Burner x5
Infrared Back Burner
10,000 BTU
Total BTU
82,000
Primary Ignition
Push N’ Turn Flame Throw er
Secondary Ignition
Flash Tube
Cooking
Grid
Di i
37" X 18"
Total Cooking Area
915sq.in
(includes warming rack)
Flame Tamer
Flame Stabilizer Grid
Zone Cooking
Removable Heat
Zone Separators
Rotisserie Kit
(Motor &
)
Optional
Burner
Commercial Quality
Cast Stainless Steel
Gas Type
Each grill contains an
NG/LP Orifice Kit
Warranty
*Limited Lifetime – Defects in
manufacturing and
workmanship. Cooking grids,
Flame Tamers, Heat Zone
Separators, stainless housing
as w ell as the stainless burners
against rust- through.
*1 Year –Ignition components
and all other components
*Appliances must be registered
within 30 days of purchase to
validate this warranty.
*See w arranty sectionfor
details.

Blaze Outdoor Products Instructional Book
Page | 6
Version 1.6
BBQ SPECIFICATIONS
NOTE: ALWAYS have equipment measured by Contractor before beginning
any project.

Blaze Outdoor Products Instructional Book
Page | 7
Version 1.6
IMPORTANTSAFETY INFORMATION
Please read this manual carefullyand before using your BLAZE GRILLtoensure proper operation,
installation, servicing and toreduce the risk of fire, burn hazard and or other injury. This manual
should be retained for your information
NOTE:
Improper installation and service or maintenance may cause propertydamage, injury or death.
Do not operate this appliance without having read this manual
All gas installations and gas conversions must be performed by a qualified technician or authorized service
agent.
NOTE: This appliance is not intended for commercialuse.
FORYOUR SAFETY
Ifyou smell gas:
1. Shut off gasto the appliance.
2. Extinguish any openflame.
3. Ifodor continues, immediately
call your gassupplier oryour fire department.
General Safety and Installation Warnings
Safe operation of the BLAZE GRILL depends upon its proper installation.Only a qualified professional installer
and service technician mustperform adjustments and service ofthe grill. Proper location and proper use is
essential toinsure safe and continued trouble-free operation. Any non-approved alterations made tothe
appliance will void the product’s warranty.
NOTE: The manufacturer cannot be held responsible for damage or injury caused by improper use ofthis
appliance.
When using yourBlaze appliance,please readand follow these basic precautions:

Blaze Outdoor Products Instructional Book
Page | 8
Version 1.6
To reduce the risk offire, electric shock, orinjury, read and follow these basic precautions before
installing/operating your
appliance.
WARNING: Improper installation, adjustment, alteration, service or maintenance can cause injury orproperty
damage. Read the installation, operatingand maintenance instructions thoroughly before installing orservicing
this equipment.
EXPLOSION HAZARD
Do not use the appliance as storage area for flammable materials. Keep area clear and free fromcombustible
materials, gasoline, and other flammable vapors and liquids. Failure to do so can result in death, explosion, orfire.
In Massachusetts: All gas products must be installedusing a “Massachusetts” licensed plumber or gasfitter. A
“T” handle type manual gas valve must be installed inthe gas supply linetothis appliance. This applies to
permanently installed natural gas and propane installations. This does not apply topropane portable
installations using a 20 pound tank.
APPLIANCE INSTALLATION
This gas appliance must be installed in accordance with all local codes.
If installation is planned in an area with no local codes, the gas appliance must be installed in accord with the
National
Fuel Gas Code ANSI Z223.1 and storage and handling of liquefied petroleum gases, ANSI/NFPA 58 or
CSA
B149.1 natural gas and propane installation code.
CALIFORNIA PROPOSITION 65 WARNING
The burning of gas cooking fuel generates some by-products which are on the list of substances which are
known
by the State of California to cause cancer or reproductive harm. California law requires businesses to
warn
customers of potential exposure to such substances. To minimize exposure to these substances, always
operate
the unit according to the use and care manual, ensuring you provide good ventilation when cooking.

Blaze Outdoor Products Instructional Book
Page | 9
Version 1.6
Have an ABCFire Extinguisher accessible at all times. Never attempt to extinguish a grease fire
with water or other liquids.
IMPORTANT: Consult theAHJ (Authority Having Jurisdiction) or local contractor of any uncertainty.
This unit is for outdoor use only!
Do not operate in a building, garage or any other enclosed areas. This couldresult in carbon monoxide buildup
which
could result in injury ordeath.
For proper operation, burners must be aligned with the valve orifice and seated in the bracket slot. This is
accomplished by first placing the burner tube shutter hole securely over the valve orifice and ensuring the male post
on the rear of the burner rests in the opening in the grill chassis. Failure to do so could result in a fire and injury.
BEWAREOFSPIDERS
CAUTION: BURNER TUBES MUSTBE INSPECTEDAND CLEANED BEFORE EACH USE.
S
pidersand smallinsectsoccasionally spinwebsormake nestsintheburner tubes. These webscan leadto a gasflowobstruction,whic
h
c
ouldresultin a fire inandaroundthe burner tubes. Thistypeof fire isknownas“FLASH-BACK”andcancause seriousdamage to your
app
lianceand create an unsafeoperating condition forthe user. Although an obstructedburnertubenot the only cause “FLASH-BACK”
it
is the most commoncause, and frequent inspection andcleaningof the burner tubesisnecessary.

Blaze Outdoor Products Instructional Book
Page | 10
Version 1.6
Do not attempt to heat unopened containers on the grill as pressure may build up and
cause the container to explode.
Never use charcoal or any other solid fuel in the grill.
Never cook without the drip pan in place.
Neveroperate this grill while under the influence of alcohol or drugs.
Location of Appliance
Most importantly,thisisan outdoor appliance.Ensure your appliance ispositionedsafely awayfrom
anything that can catch fire. Under nocircumstance isthisappliance to be used indoors. Thisincludes
garagesor any other enclosedarea. Thisoutdoor cooking gasappliance isnot approvedto be installed in
or on any recreational vehiclesand /or boats. Blaze Grillsare for single family/residential use only.
When determining a suitable location take into account concerns such as exposure towind, proximity to
traffic paths and keeping any gas supply lines as shortas possible.
 Do not store combustiblematerials, gasoline or flammable liquids or vapors around the appliance.
 This BLAZE GRILL must be located outdoorsonly.As with any gas appliance,harmful carbon
monoxide is produced during the combustion process thatshould notbe allowed toaccumulate in a
confined space. Please note since hot air rises above the BLAZE GRILL whileinoperation, covered
FOR YOUR SAFETY
NOTE: Check with City and Fire department for Local Building Codes. A Permit may be
required for outdoor kitchen construction.

Blaze Outdoor Products Instructional Book
Page | 11
Version 1.6
locations should be avoided. Do not locate the BLAZE GRILL where an overhang or awning may cover it.
 DO NOT obstruct the flow of combustion and ventilation air tothis appliance
 Keep any electrical supply cordsand the fuel supply hoses away from any heated surfaces and/or sharp and
aggressive edges.
 Non-Combustible Enclosure: The BLAZE GRILL must be installedina NON-COMBUSTIBLE
ENCLOSURE ONLY.The determination ofwhether a location is combustible or non-combustible
construction is made by the localfire marshal, building inspector or the local safety authority having
jurisdiction.
 Clearance from Combustibles: Ensure your appliance remains at a distance of at least 14” from sides
& 16” from back from any
combustible material such aswood, gyprock, paperand plants. Do not store
combustiblematerials,
gasoline or flammable liquids or vapors around the appliance. The outdoor kitchen
structure itself should be constructed completely out ofnon-combustible materials.This outdoor cooking
gas appliance shall not be located under overhead construction.
 Adequate Ventilation: Ensure there is adequate ventilation for both the appliance, grillcartand/or
island cavity.This is required not only for proper combustion, but also to prevent gas buildup. While
the amount of venting required varies on a case by case basis, consult with your locallicensed
professional and local code for adequate venting requirements. Keep the ventilation openings ofthe
enclosure free and clear from any debris.
 Firm Level Surface: Use your applianceonly on a firm level surface. This appliance is not designedfor
recreational vehicles, and should not be installed on a boat or marine craft.
 Protection from Weather: Keep the appliance protected from adverse weather, including rain and winds.
Wind, particularly coming into the rear of the grill, can affectthe exhaust from escaping fromthe
grill. Thiscan back upthe heat behind the control panelpotentially creatinga gasleak, damage to
the product, and injury.
 Maintenance Access: When your appliance is installed, you should be able to accessthe gassupply
line including the gas piping or hose, gas regulator, gas cylinder and any shut offvalves. Allow clear
access to the entire gas supply hose andregulator.
 Partial Enclosures: Many backyards have areas that are partially closed off, such asbalconies and
pergolas. In some cases, it is hard to decide whether these partially enclosed areas should beclassified as
indoorareas, particularly in terms of permanent (non-closable) ventilation. Consult the AHJ(Authority
Having Jurisdiction) or local contractor of any uncertainty. This outdoor cooking gas appliance shall not be
located under overhead construction.
Please readall instructionsbefore installing or operatingyour gasappliance to prevent injuryand
appliance
damage.
 All gas appliances will gethot during use. Use extreme caution when operating the appliance.
 Do not touch hot surfaces. Always use thehandle to open or close theappliance.

Blaze Outdoor Products Instructional Book
Page | 12
Version 1.6
 Close supervision is necessary when this orany appliance is used near children. Keep childrenaway
from the appliance during operation and until the appliance has cooled off.
 Do not store any LP cylinder or tank not connected for use with the appliance,in the area ofthis
appliance or any other appliance. Never store an LP cylinder or tank indoors, or within the reachof
children.
 Never test the appliance for gas leaks usinga lighted match or any other open flame; see leak test
procedures using soap/water solutions – see section on Leak Testing.
 The use of accessories, regulators, or components not recommended by the appliancemanufacturer
may cause injuries and will void warranty.
 Never light the appliance with the hood closed and be certain that the burners are positioned andseated
over the gas valves and on the burner support.
 Never lean over the cooking surface when lighting or operating the appliance.
 Use cooking utensils with wood handles and insulated oven mitts when operating the appliance.
 Do not store anything in the appliance. Make sure food is not forgotten in the appliance; forgottenitems
could melt or catch fire when the appliance is turned on.
 To prevent injuries, do not use accessories thatare not recommended by the manufacturer.
 Before cleaning the appliance, disconnectthe rotisserie and "trip"the circuitbreaker.
 Never use the appliance in windy conditions. If located in a consistently windy area (oceanfront,
mountaintop, etc.) a wind break will be required. Winds blowing into or across the back hood gap, can
cause poor performance and / or cause the control panel and knobs to get dangerously hot.
 Always open the appliance hood carefully,using only the handle - the hood may behot.
 Children should not be left alone or unattended in an area where any appliance is in use. They should
never be allowed to touch, sit or stand on any part ofthe appliance.
 Do not store items of interest to children in cabinets above the appliance or in the appliance. Children
climbing on the appliance to reach these items could be seriously injured.
 Wear proper clothing when operating this appliance.Loose-fitting or hanging garmentsshould never be
worn while using the appliance.
 Do not leave the appliance unattended while in use.
 Do not use water on grease fires! A violent steam explosion may result. Instead, smother the fire with a
multipurpose ABCextinguisher.

Blaze Outdoor Products Instructional Book
Page | 13
Version 1.6
Electrical Safety and Installation Warnings
Extension cords may be used ifcare is exercised in theiruse.
If
an extension cord is used:
 The marked electricalrating ofthe cord set or extensioncord should be at least as great as theelectrical
rating of the appliance
 The cord should be arranged so that it will not touch hot surfaces,sharp edges ordrape overthe
countertop or tabletop (where it can be pulled or tripped over unintentionally).
Outdoor extension cords should be used with products suited for outdoor use. They are surface marked with
suffix letters "W" or "W-A"and with a tag stating "Suitable for Use with OutdoorAppliances".
To protect against electrical shock, the power cord and plug should be kept dry and offoftheground.
Do
not clean this product with water spray;do not spray cleanersinto the lamp socket area.
Gasoline, lighter fluid or other flammable liquids and vapors should never be stored in the area ofthis appliance
or any otherappliance.
Before installation or service, disconnect the power supply to the work area by removing the fuse, "tripping"the
circuit breaker, or unplugging theunit.
Keep any electrical supply cord and fuel supply hose away from any heated surfaces, sharp edges and
dripping
grease.
Be certain your appliance is properly installed and grounded by a qualified technician in accordancewith
applicable codes. To guarantee the electrical safety ofthis appliance, continuity mustexist betweenthe
appliance and an effective grounding system. It is imperative that thisbasicsafety requirement be met.The
manufacturer cannot be held responsible for damagescaused by the lack orinadequacy ofaneffective
grounding system.
Do not operate any appliance with a damaged power cord or power plug, and do not operate any appliance
after
the appliance malfunctionsor has been damaged in any manner. If this should occur, return the appliance
to the
nearest authorized service facility for examination, repair or adjustment.
Be certain your appliance is properly installed and grounded by a qualified technician in accordance with
applicable codes. To guarantee the electrical safety of this appliance, continuity must exist between the
appliance and an effective grounding system. It is imperative that this basic safety requirement be met.
The
manufacturer cannot be held responsible for damages caused by the lack or inadequacy of an effective
grounding system.
This appliance conforms to all uniform electrical safety codes and electrical grounding regulations. Install
unit
according to I.A.W. local codes or with National Electrical Code ANSI/NFPA 70 or CSA C22.1 in their
absence.

Blaze Outdoor Products Instructional Book
Page | 14
Version 1.6
Gas Safety and Installation Warnings
• All gas connections should be made by a Professionalqualified technician and inaccordance with local
codes and ordinances. The installation must conform with local codes or, inthe absence of
local codes, with either the national FuelGas Code, ANSI Z223.1/NFPA54, or CAN/CGA-B149.1,
Natural Gas Installation Code or CAN/CGA-B149.2, Propane Installation Code.
• Always check the Rating Plate tomake sure the gas supply you are hooking up to is the gas type
the
appliance is manufactured for.
• Check the rating label on the left hand outside ofthe unit.
• Do not twist the gas supplyhose.
• Before each use, visually inspect the gas supply hose for cracks, cuts or excessive wear. Replace
the
hose if necessary.Check for gas leaks before each use.
• Gas Specifications: Be sure that the gas supplied to the appliance conforms to the modelyou
purchased.ANatural Gas appliance requires natural gastooperate; an LP appliance requires liquid
propane gas tooperate.
• Never connect the appliance to an unregulated gas supply line. Appliancesoperated withoutaregulator are
unsafe and will not be serviced until installed properly and safely.Unsafe operation withoutagas
regulator
will void the warranty ofthe appliance.
• Appliances operated with NG (natural gas) gas must be installed with the NG regulator supplied withthe
unit and set to 4.0" water column pressure.
• Appliances operated with LP (liquid propane) gas must be installed with an LP regulator set to 11"water
column pressure.
• Please contact your dealer and use a licensed contractor or installer to convert your appliance tothe
different gas type.
• CHECK TO ENSURE THAT THE GAS SUPPLYHOSE DOES NOTCOME IN CONTACTWITH ANY
HOT SURFACE, SHARP OR ROUGH EDGES OF THE GRILL OR OUTDOOR KITCHEN
CONSTRUCTION. DO NOT KINK THE GAS LINE WHEN INSTALLING.
RATING PLATE LOCATION

Blaze Outdoor Products Instructional Book
Page | 15
Version 1.6
The self-contained LP system appliance isdesigncertified to be used with a standard 20 lb.,12 1/4" diameter;
18"
high cylinder with right handed connection threads and thisis the maximumsize LP tank to be used.The
cylinder
must be marked in accordance with thelatest U.S. Department ofTransportation specifications forLP
gas cylinders.
(DOT. CFR49 or National Standards ofCanada CAN/CSA-B359 Cylinders, Spheres andTubes for
the
Transportation ofDangerous Goods) a Propane Tank with an ODP) Overfill Prevention Device) must beused
at all
times.
IMPORTANT: Never connect the appliance to an unregulated gassupply.
The installation of this appliance must conform with local codes or in the absence oflocal codes, to the national fuel
gas code, ANSIZ223.1a-1998. Installation in Canada must be in accordance with the standard CAN/CGA-
B149.2,
Propane Installation Code.
A licensed contractor or local gas company representative must perform all natural gas connections.
Ensure that the service supplying the appliance is fitted with a shut off valve conveniently positioned near the
appliance and giving ease of access.
The appliance and its individual shutoff valve must be disconnected from the gas supply piping systemduring
any
pressure testing of that system.
GAS LEAKWARNINGS
Finding and/or fixing a gas leak is NOTa “DO-IT-YOURSELF”procedure – ONLY USE A
PROFESSIONAL.
NEVERUSE THE GRILL WITHOUTFIRST LEAK TESTING THE GAS CONNECTIONS INCLUDING
ALLOFTHE VALVES,FITTINGS, LINES ETC. (ANY GAS CONNECTIONSHOULDBE CHECKED)
WARNING: DO NOTUSE OPENFLAME TO CHECK FOR LEAKS. USE OF ANOPEN FLAME
COULD RESULTIN A FIRE, EXPLOSIONAND BODILY HARM.
DO NOT SMOKE WHILE PERFORMING THE LEAKTEST. Any Open Flame will Ignite the gas.

Blaze Outdoor Products Instructional Book
Page | 16
Version 1.6
To prevent fire or explosion hazard, Perform leak test outdoors only.
Check toensure that flexiblehoses do not have any cuts and wear that may affect the safety before
each use. Only the factory supplied hose and regulator must be used.Use only replacement regulator
and hose assemblies specified by BLAZE OUTDOOR PRODUCTS.
Checking for Gas Leaks
Perform a leak test before each use. In addition, whenever the gas cylinder is connected to the regulator or
whenever any part of the gas system is
disconnected or replaced, perform a leak test.
As a safety precaution, remember to always leak test your appliance outdoors in a well-ventilated area. Never
smokeor permit sources of ignition in the area while doing a leak test. Do not use a flame, suchas a lighted
match to test for leaks. Use a solution of soapy water.
 Prepare a leak testing solution of soapy water by mixing in a spray bottle one part liquid soapto one
part
water.
 Make sure all the control knobs are in the OFFposition .
 Turn on the gas
o On Natural Gas systems, turn themain feed valve to theappliance.
o On LP systems,turn the cylinder valve knob counter clockwise one turn toopen.
 Apply the leak-testing solution by sprayingit on joints ofthe gas delivery system. Thisincludesall
valves, pipe connections, joints, linesandevery point from the gassource to the burners.
 Blowing bubbles in the soap solution and/or there is a faint gas smell(Typically Gas has an Egg Smell)
indicates that a leak is present. Do not attempt to ignite the grill.
 Turn all control knobs back to the full OFF position.
 Stop a leak by tightening the loose joint and/or resealing with thread sealant or Teflon tape, removing
sealant or
tape in the event of a flared connection or by replacing the faulty part with a replacement part
recommended by the manufacturer. Do not attempt to repair the cylinder valve if it is damaged. The
cylinder must be discarded to a proper LP tank location and then replaced.
 If you are unable to stop a leak turn all control knobs back to the full OFF position,shutoffthegas
supply to the appliance and release pressure in the hose and manifold by pushing in and turning any
of
the control valves one quarter turn counter-clockwise.
 On LP systems, remove the cylinder from the appliance.
 Call an authorized gas appliance service technician or an LP gas dealer.
 Do not use the appliance until the leak is corrected.

Blaze Outdoor Products Instructional Book
Page | 17
Version 1.6
 The below diagram is intended to show what a leaking connection would look like.These two locations
are not the only points to check northe only potential areas for a gas leak to be present.
Leak Testing
 All gas piping and connections must be tested for leaks after installation or service along with beforeeach
use. Thisincludesall valves, pipe connections, joints, linesand every point fromthe gas
source to the burners.
All leaks mustbe corrected
immediately. Remember-before exchanging an empty bottle for a new one; make
sure all control valves are in
the “off” position. This can create a low flow of gas through the grill. This would
require the tank to be disconnected from the regulator, and then reconnected to reset the regulator.
Open the valve (shut-off or ‘ON’LP tank). Test for leaks by applying liquidsoap solution toall joints.Bubbles forming
indicate gas leak.
 The following diagram is for informational purposes only. These locations are not the onlypoints to
check nor the only potential areas for a gas leak to be present. Ensure the leak test includesall
valves, pipe connections, joints, linesandevery point from the gassource to the burners.
NEVER USE AN OPEN FLAME TO CHECK FOR LEAKS.

Blaze Outdoor Products Instructional Book
Page | 18
Version 1.6
UNPACKINGUNIT:
Product Inspection:A final inspection ofyour product occursat the factory to ensure a quality product is
packaged. Please re-check for possible shipping damage immediately after unpacking your grill. If the appliance is
found to have some damage, contact yourdealer immediately as often the shipping carrier will have a timeframe to
report damage. Please also save the packaging material the product came with asthat is at times inspectedby the
shipping carrier.
Caution: Do notleave the unit under the sun with the protective filmon for a long period of time asitwillmake
the film difficult to remove and/or leave markingson the materialswhich are not covered by the warranty.
Your Blaze Series Appliance comes pre-assembled and requires very little setup.Wedo however; recommend
the use ofprofessional help during the installation ofyour unit as improper installation may affect your warranty.
Remove the unit from the box along with all accessories and check that no damage has occurred to the unitor
anyparts. Remove all packaging materials, labels and protective plastic filmbefore you start cooking.
Burners: Check the burner tubes and remove any obstructions that may be in the ports or holes. Usingcold
water
and a brush will be sufficient. Make sure all foreign particles are removed from the burner beforeuse.
Make sure
the air shutter on the burners is slightlyopened (to about 1/8" for NG and 1/4" forLP). When finished ensure that
the burners are aligned with the valve orifice and seated in the bracket slot. This is accomplished by first
placing the burner tube shutter hole securely over the valve orifice andensuringthe malepost onthegrill chassis
rests in the corresponding slot in the rear of the burner. Failure to do so could result in a fire and injury.

Blaze Outdoor Products Instructional Book
Page | 19
Version 1.6
Gas Connections
Natural Gas Requirements
 Connect a suitable natural gas flex connector to the grill regulator located on the rear right corner ofthe
appliance. It is recommended to use a flex connector with a minimum of a ½” diameter orlarger.
 Sealing all non-flared fittings with thread sealant orTeflontape.
 Ensure the flex connector is protected from sharp edges,heat,aggressive surfaces, and kinking.
 Check the appliance controls to ensure all control valves are in the full OFF position.
 Turn on the main gas supply and checkall connections for leaks using soapy water as described inthe leak
testing procedure section.
 The regulator used must be set for 4” water column and is for use with Natural gas only. Note: Most low
pressure regulators have a directional arrow indicating the direction in which the gas musttravel. Ensure
the arrow is pointing in the direction ofthe grill.
 Aninstaller supplied gasshutoffvalve must be installed inan accessible place.
Liquid Propane (LP) Gas and TankRequirement
 If your BLAZE Grill is for a Liquid Propane application, a L.Pregulator set for 11” WCmust be used and is for
use with L.P. gas only.
 The regulator and hose supplied must be used with a 20 lb. L.P. cylinder.
 A collar to protect the cylinder threadson the customer suppliedtank.
 An arrangement for gas vapor withdrawal.
 A safety reliefdevice having direct communication with the vapor space of thecylinder.
 A method ofmounting.
 The gas supply mustbe turned off at the LP Gas supply cylinder and the LP Gas supplycylinder mustbe
disconnected from the regulator when this outdoor cookinggas appliance is notin use.
 Always sit the cylinder in an upright position sothat the cylinder valve is at the top. This will ensure proper
vapor withdrawal.
 The cylinder should not be stored in a building, garage, or any other enclosed area. It should be stored
outdoors ina protected, cool,and dry location out ofreach ofchildren.
 Never store any spare or extra gas cylinder(s) around or in the outdoor kitchen containing the BLAZE GRILL
or any other open flame, heat-producing appliance(s) or heat source.

Blaze Outdoor Products Instructional Book
Page | 20
Version 1.6
 Turn control knobs and cylinder valve to the OFF position.Unscrew valve.
 Remove cylinder and have it filled at your local qualified propane dealer.
 Once filled, carefully connect the valve and make sure it is secure and not leaking.
 With the control knobs in the OFFposition,turn on the cylinder valve.
If you smell gas or hear a hiss ofgas escaping from the tank, get awayfrom the tank and do not attemptto
correct
the problem yourself. Call the Fire Departmentimmediately.
If your appliance has no leak at the cylinder, then re-checkfor loose connections and retest for leaksusing the
method detailed in the following pages with soapysolution.
Do not subject your LP gas cylinder to excessive heat, and always store the cylinder in an upright position.
Never
store your LP cylindersindoors.
Make sure that when attaching components,all connections are secured and fully tightened to prevent leakage.
Always check for leaks before every use.
If one is not alreadyavailable, it is required that an ON-OFF shutoff valve be installed at the gas supply
source, and
that the gas supply be turned off when either Natural Gas or LP Gas appliances are not in use.
Transporting and Storing LPGas
Transport only one cylinder at a time. Ensure the cylinder is secured in an upright position with the controlvalve
turned off and the dust cap in place. Store cylinders outdoors and out of the reach ofchildren. Do notstore cylinders
in a building, garage, or any other enclosedarea.
Procedure for LPGasCylinder Connection(20 lbs)
1. Turn the “Hand Wheel” on cylinder clockwise until it stopstoensure the Cylinder Valve is fully
closed.
2. Turn all of the burner knobs tothe OFF position.
3. Connect the 3/8” Flare end of the hose tothe 3/8” Flare end ofthe brass coupling on the unit using
a 3/4” open wrench. Do not apply pipe sealant. (These are flared fittings). Note:remember the
rubber line on the hose and regulator must be protected from sharp edges, hot surfaces, aggressive
Filling and Refilling LP Gas Cylinders:
