Blichmann Engineering Glycol Chiller Installation instructions

Glycol Chiller V1© Blichmann Engineering, LLC 2019
For replacement parts, visit: blichmannengineering.com/genuine-replacement-parts 1
Glycol Chiller
Assembly, Operation, & Maintenance
Congratulations on your purchase, and thank you for selecting the Glycol Chiller from
Blichmann Engineering™. We are condent that it will provide you years of service and
many gallons of outstanding beer. This manual will familiarize you with the use,
assembly, and the sanitation procedures for the product.
Sections labeled “Warning” can lead to serious injury or death if not followed. Please thoroughly read these sections
and understand them completely before use. If you do not understand them or have any questions, contact your
retailer or Blichmann Engineering (www.BlichmannEngineering.com) before use.
Sections labeled “Caution” can lead to equipment damage or unsatisfactory performance of the equipment. Please
read these sections thoroughly. If you have any questions, contact your retailer or Blichmann Engineering
(www.BlichmannEngineering.com) before use.
Sections labeled “Important” should specically be followed to ensure satisfactory results with the product.
WARNING:
CAUTION:
IMPORTANT:
IMPORTANT INFORMATION
PLEASE READ AND THOROUGHLY UNDERSTAND THIS MANUAL PRIOR TO USE
FOR IMPORTANT SAFETY INFORMATION!
ALLOW THE UNIT TO SIT UPRIGHT FOR 24 HOURS BEFORE PLUGGING IN.

Glycol Chiller V1© Blichmann Engineering, LLC 2019
For replacement parts, visit: blichmannengineering.com/genuine-replacement-parts 2
TECHNICAL SPECIFICATIONS
Install the casters with the included hardware located inside
the glycol chiller unit.
Install the cable management cover onto the back of the glycol
chiller with the included hardware. (Figure 3)
Warning: Before use, allow the unit to sit for 24 hours.
DO NOT PLUG IN
After the glycol chiller has sat for 24 hours, add a mixture of
35% glycol and 65% distiled water. Plug in the glycol chiller. Set
the controller on the front of the glycol chiller to the desired
temperature. For maintaining fermentation temperatures set
the chiller at least 5 degrees lower than the desired fermenta-
tion temperature. For crashing a lower temperature may be
required.
Assembly
Caster
Figure 1
Figure 3
Figure 2
Cable
Management
Cover
Lid Screws
(on both sides)
Top Screws
(on both sides)
1. Cooling Capacity: 3400 BTUs/hr
2. Compressor: 3/8 HP
3. Temperature controlling range: -5˚C ~ 10˚C, 23˚F ~ 50˚F
4. Power supply: 110VAC±10%, 60Hz
5. Power consumption: < 500W
6. Operable Ambient temperature: 32˚F ~ 140˚F 0˚C ~ 60˚C
7. Storage temperature: -22˚F ~ 167˚F
Lid
Temp Controller for
Glycol Reservoir

Glycol Chiller V1© Blichmann Engineering, LLC 2019
For replacement parts, visit: blichmannengineering.com/genuine-replacement-parts 3
The way to adjust temperature:
2. The way to modify parameter:
3. The way to switch between Celsius or Fahrenheit
To enter temperature setting mode press SET key, to adjust temperature press key or key.
System will save the modified setting temperature and back to normal working status if no key
operation in 5 seconds.
Press SET key for 3 seconds or more to enter programming mode, and“Set” indicator light on, screen
displays the parameters adjusted last time.
Press key or key to toggle or scroll through the menu item.
Press SET key to select the current menu.
Press SET key, and key or key simultaneously to adjust the value of parameters.
System will save the modified temperature setting and exit the menu if no key is pressed in 5 seconds.
Press RST key and hold more than 3 seconds to automatically switch between ˚F and ˚C.
TECHNICAL SPECIFICATIONS
PREPROGRAMMED PARAMETERS
ERROR INFORMATION
Indicator Light Status Function
Cool Always on Compressor works
Cool Flash Compressor output delay
Code Function Set Range Unit Default
˚C Menu
F1 Temperature Control Band 1-15 ˚C 3
F2 Compressor Delay Time 0-15 min 3
F3 Temperature Calibration Offset -10~10 ˚C 0
˚F Menu
F1 Temperature Control Band 2-27 ˚F 5
F2 Compressor Delay Time 0-15 min 3
F3 Temperature Calibration Offset -18~18 ˚F 0
Error Code Error Analysis Response Way
EE Temperature Sensor Error Alarm, and the machine
does not work
HH Temperature Exceeds Setting
Maximum Display Temperature
Alarm, and the machine
does not work
LL Temperature Exceeds Setting
Minimum Display Temperature
Alarm, and the machine
does not work
•
•
•
•
•
•
•
•

Glycol Chiller V1© Blichmann Engineering, LLC 2019
For replacement parts, visit: blichmannengineering.com/genuine-replacement-parts 4
OPERATION
The Blichmann Glycol Chiller pairs perfectly with our cooling kits. This will allow
you to cool up to 6 fermentors. Connect your hose to the submersible pump and
place the submersible pump into the glycol. Run the hose out of the back of the
glycol chiller as shown in Figure 4. Run the excess cable from the submersible
pump out the back of the glycol chiller and place into the cable management cover
(Figure 4). Plug the temperature controller into the outlet on the glycol chiller and
plug the submersible pump into the temperature controller as shown in Figure 5.
Place the temperature probe from the temperature controller into the thermowell
or tape it to the side of your fermentor and cover with insulation. Set the desired
fermentation temperature on your temperature controller.
Blichmann Temperature Controller
cool
SET
heat
62
Extra Cable Slack
Cable
Management
Cover
Glycol hose in
and out
Figure 4
Figure 5

Glycol Chiller V1© Blichmann Engineering, LLC 2019
For replacement parts, visit: blichmannengineering.com/genuine-replacement-parts 5
Blichmann Engineering Product Warranty
A. Limited Warranty
1. Blichmann Engineering warrants to the original purchaser that this product will be free from manufacturing defects in material and workmanship for a period of one (1) year from the date of purchase by the customer. Proof of
purchase is required. Blichmann Engineering’s obligation to repair or replace defective materials or workmanship is the sole obligation of Blichmann Engineering under this limited warranty.
2. This product is for home use only. The limited warranty covers only those defects that arise as a result of normal use of the product and does not cover any other problems, including, but not limited to, those that arise as a
result of:
a. Improper maintenance or modication;
b. Damage due to incorrect voltage or improper wiring by customer;
c. Operation outside of the product’s specications;
d. Carelessness or neglect to operate the product in accordance with instructions provided with the product;
e. Damaging the tamper label on the product;
f. Damage by over-tightening the fasteners;
g. Failure to follow cleaning and / or maintenance procedures; or
h. Exceeding published operational temperatures.
3. Blichmann Engineering reserves the right to request delivery of the defective component for inspection before processing the warranty claim. If Blichmann Engineering receives, during the applicable warranty period, notice
of a defect in any component that is covered by the warranty, Blichmann Engineering shall either repair or replace the defective component with a new or rebuilt component at Blichmann Engineering’s option.
4. Blichmann Engineering must be notied within seven (7) days of the delivery date of any shipping damage. Customer is responsible for shipping damage outside of this time period. Approval for return must be provided by
Blichmann Engineering prior to any return. Customer is responsible for keeping all original packaging material for warranty returns. Blichmann Engineering is not responsible for damage from improperly packaged warranty
returns, and these repair costs will be the sole responsibility of the customer. Shipping costs for warrantee returns are covered only for the contiguous United States.
5. Blichmann Engineering’s limited warranty is valid in any country where the product is distributed.
________________________________________
B. Limitations of Warranty
1. Any implied warranty that is found to arise by way of state or federal law, including any implied warranty of merchantability or any implied warranty of tness, is limited in duration to the terms of this limited warranty and is
limited in scope of coverage to this warranty. Blichmann Engineering disclaims any express or implied warranty, including any implied warranty of tness for a particular purpose or merchantability, on items excluded from
coverage as set forth in this limited warranty.
2. Blichmann Engineering makes no warranty of any nature beyond that contained in this limited warranty. No one has authority to enlarge, amend, or modify this limited warranty, and Blichmann Engineering does not authorize
anyone to create any other obligation for it regarding this product.
3. Blichmann Engineering is not responsible for any representation, promise, or warranty made by any independent dealer or other person beyond what is expressly stated in this limited warranty. Any selling or servicing dealer
is not Blichmann Engineering’s agent, but an independent entity.
________________________________________
C. Limitations of Liability
1. The remedies provided in this warranty are the customer’s sole and exclusive remedies.
2. Except for the obligations specically set forth in this warranty, in no event shall Blichmann Engineering be liable for direct, indirect, special, incidental, or consequential damages, whether based on contract, tort, or any other
legal theory and whether or not advised of the possibility of such damages.
3. This warranty does not cover, and in no event shall Blichmann Engineering be liable for, travel, lodging, or any other expense incurred due to manufacturing defects in material and workmanship, or any other reason.
4. Any performance of repairs after the warranty coverage period has expired or performance of repairs regarding anything excluded from coverage after this limited warranty shall be considered good-will repairs and they will
not alter the terms of this limited warranty, or extend any warranty coverage period.
5. Venue for any legal proceedings relating to or arising out of this warranty shall be in Tippecanoe County, Indiana, United States, which courts will have exclusive jurisdiction.
________________________________________
D. Local Law
1. This warranty gives the customer specic legal rights. The customer may also have other rights that vary from state to state in the United States or other countries.
2. To the extent that this warranty is inconsistent with local law, it shall be deemed modied, only to the extent necessary to be consistent with such local law.
This product uses FDA and/or NSF approved food grade materials anywhere the product touches the beverage.
Warning: This product contains or may contain chemical(s) known to the State of California to cause cancer, birth defects, or other reproductive harm.
