Bliss Hammocks GXW-457ALR Zero Gravity Chair User manual

MADE IN CHINA
Max Weight Capacity: 360 LBS (163.3 KGS)
32” W - GRAVITY FREE RECLINER INSTRUCTIONS
Moving parts under armrest
while reclining. do not put
your hands under armrest
while in motion.
To unfold recliner, you may need to release the locking system. If you purchased a recliner with a canopy, the canopy should be snapped
to the frame, on the back of the recliner. NOTE: Some models may not have a canopy and/or drink tray. Recliner pictured may differ from
the model you purchased. The illustrations below are for reference only and your recliner may appear different than illustrated.
1234
57
89
To release the locking
system, lift lever on both
sides of the recliner
6
Before closing recliner, make
sure the locks are unlocked.
Remove the drink tray before folding your
recliner. If the recliner is folded without
doing so, the drink tray will break. Unlock
the two locking mechanisms that are
under the armrests before folding your
recliner. If recliner is folded with out doing
so, the locking mechanism will wear.
ATTENTION
Make sure your recliner is completely
unfolded before sitting in. Please be
careful reclining while sitting in it. Body
shape and weight will affect the way this
recliner operates. Be careful and
proceed with caution. To reduce the risk
of injury, DO NOT play on, stand, or jump
on the recliner. The recliner is intended
for sitting and reclining only.
HOW TO ADJUST LOCK
TENSION, IF NEEDED:
LOCK TOOL CONSISTS OF 2 PARTS:
[1] Hexagon Tube
[1] Flat-Head Rod
UNLOCKED LOCKED
TIGHTEN
LOOSEN
Insert the flat-head rod into the side hole of the hexagon
tube. Hold it by the flat-head rod in order to tighten or
loosen the recliner lock nut to the desired tension.Turn to
right to tighten, left to loosen. The locks must not be loose
in order for the recliner/chair to lock properly.
Once the desired tension of the lock nut is reached, pop
the plastic caps back in to cover the nuts. To lock the
recliner, move the lever down. To unlock the recliner/chair,
move the lever up.
PLEASE NOTE: Lock lever should point away from you in the
unlocked position before use.
Remove the plastic caps covering each nut of the
recliner/chair lock using the flat-head rod.
LOCK TOOL INSTRUCTIONS
1
2
3
REVISED FROM LAST ORDER
D1

IF YOU PURCHASED A RECLINER OR CHAIR WITH A DRINK TRAY AND/OR PILLOW, SEE BELOW FOR INSTALLATION INSTRUCTIONS. PLEASE NOTE THAT
THE RECLINER OR CHAIR, DRINK TRAY AND/OR PILLOW PICTURED BELOW MAY DIFFER IN STYLE AND/OR COLOR FROM WHAT YOU HAVE PURCHASED.
PILLOW
PILLOW STRAP
PILLOW STRAP
BUNGEE CORD
EYELET
EYELET
6Adjust pillow to desired height.
Guide the bungee cord
through the other eyelet.
If your recliner/chair, has a
canopy, place pillow straps
above the canopy snap locks.
ATTACHING THE PILLOW
3
Lay pillow flat against front of recliner/chair
as you wrap the pillow strap around the
frame towards the back.
NOTE: Pillow straps should only
overlap the frame.
Canopy
Snap Lock
Place pillow on seat, leaning
against the bottom of the backrest.
Make sure pillow straps are not
being blocked by the armrests.
Put canopy up, which
will be snapped in
place on the back via
Canopy Snap Lock.
Bungee cord through 1 eyelet,
then pull bungee cord taut.
1 2
4
5
ATTACHING THE DRINK TRAY
With recliner opened, place drink tray
on the RIGHT side (when sitting) of
recliner underneath armrest. Tilt the
wide opening of the drink tray up and
over the meeting poles to attach it.
Start to slide drink tray down until it
cannot be pushed down anymore.
Press firmly to ensure cup holder is
securely in place.
TRAY
TRAY
SEAT
FOR REVIEW ONLY
D1
