BlissLights Firefly MOTION PN-RG130-M1 User manual

User’s Guide
Please ONLY use
manufacturer provided
power supply
Firey MOTION™
Manufactured by: BlissLights
Phone: [phone]
Model #: PN-RG130-M1
www.blisslights.com
[email protected]
MADE IN CHINA

TABLE OF CONTENTS
Notice ..............................................................................................................................1
Introduction ..................................................................................................................2
Before You Begin..........................................................................................................2
Parts List..........................................................................................................................2
Setting up the BlissLights Firey Motion ............................................................3
Operating the BlissLights Firey Motion.............................................................3
Operating the Timer...................................................................................................3
Caution............................................................................................................................4
Cleaning Instructions.................................................................................................4
Disposal...........................................................................................................................4
Using the Remote Control........................................................................................5
Increasing and Decreasing the Light Animation Speed ...............................5
Precautionary Tips for Remote Control ...............................................................5
Installation Tips ............................................................................................................6
Product Specications...............................................................................................6
Troubleshooting ..........................................................................................................7
Limited Warranty .........................................................................................................8

NOTICE
CAUTION—Use of controls or adjustments or performance of procedures other than those
specied herein may result in hazardous radiation exposure.
This device (Model PN-RG130-M1) complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation. Note:
This equipment has been tested and found to comply with for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur
in a particular installation. If the equipment does cause harmful interference to radio or television
reception, which can be determined by turning the unit o and on, the user is encouraged to try to
correct the interference by one or more of the following measures: Reorient or relocate the receiving
antenna. Increase the separation between the equipment and the receiver. Connect the equipment to
an outlet on a circuit dierent from that to which the receiver is connected. Consult the dealer or an
experienced radio/TV technician for help.
This laser product is certied as a CLASS 3R laser product, and adheres to the requirements of the
US Federal Laser Product Performance Standard (FLPPS) contained in the regulations in 21 CFR
Subchapter J.
Avoid direct eye contact of CLASS 3R laser energy as it can be hazardous. For reference, the FLPPS
requirements for demonstration laser products, like laser pointers, are limited to CLASS 3R levels of
laser energy. This product uses diractive optics to scatter the beam energy. This scattering eect
causes the energy concentration to drop below the exposure limits for momentary or accidental
viewing at a relatively short distance from the laser aperture. As with all bright light-sources, when you
operate this device in unsupervised general public areas, it is recommended that up-close access to
the light be restricted or prevented.
This laser display device incorporates a CLASS 3B laser system which, by itself, may be hazardous.
However, this laser display device incorporates a protective housing and diractive holographic optics
in the machine design so that there is no exposure or human access to laser radiation during operation
or maintenance above the CLASS 3R limits. Each individual laser beamlet’s power is under 5 mW, which
is less than a standard laser pointer.
UNDER NO CIRCUMSTANCES shall attempts be made to open the protective housing or operate the
device if the aperture window is damaged.
Warning: Changes or modications to this unit not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
All service to this laser display device requiring the protective housing to be opened and/ or removed
shall be performed by service personnel or their authorized agents. Opening the protective housing
voids the warranty.
NO LASERS SHOULD BE POINTED INTO THE SKY WITHIN 10 NAUTICAL MILES(18.5
km) OF AN AIRPORT. IF YOU ARE LOCATED WITHIN THIS SPECIFIC PERIMETER, WE
RECOMMEND THE LASERS BE POINTED DOWN AT THE GROUND SO NO STRAY BEAMS
ARE PROJECTED INTO THE AIR. CHECK WITH YOUR LOCAL AIRPORT OR PROVINCIAL
GUIDELINES FOR FURTHER INFORMATION.
1

INTRODUCTION
Thank you for purchasing the BlissLights Firey Motion. The BlissLights Firey Motion is a
unique dual-color indoor/outdoor light xture that uses laser and holographic technology
to project thousands of moving pin-points of light. See the“reies” dance in your garden
without the need for wind, create a fun and mesmerizing ambience indoors, or add some
extra allure to your holiday display. We hope you enjoy this incredibly unique lighting
experience.
Each unit provides up to 2,500 square feet (50ft x 50ft) of coverage. It has maximum
electrical usage of 2 to 9 W, which is more energy ecient than many LED landscape
lights. The xture housing is weather resistant ABS resin for year-round indoor or outdoor
operation.
BEFORE YOU BEGIN
Immediately upon receiving the xture, carefully unpack and check the carton contents
to ensure that all parts are present and in good condition. Notify the shipper immediately
and retain packing material for inspection if any parts appear damaged from shipping or
the carton itself shows signs of mishandling. Save the carton and all packing materials. In
the event that the xture must be returned to the factory, it is important that the xture be
returned in the original factory box. Please see parts list below for box contents.
PARTS LIST:
1) 1 x BlissLights Firey Motion Laser Fixture
2) 1 x Remote Control with 1pcs 3V lithium battery CR2025
3) 1 x Swivel
4) 1 x Power Supply
5) 1 x Ground Stake
6) 1 x Floor Stand
7) 1 x Thumbscrew
1
3
6
7
5
4
2
2

3
Before operating your Firefly Motion, please read the “Before you Begin” and “Notice”sections
of this user guide.
SETTING UP THE BLISSLIGHTS FIREFLY MOTION
1. Connect the light xture to the provided power supply.
2. Attach the swivel by inserting the thumbscrew through the swivel and into the hole in
the xture base. Turn screw clockwise until tight.
3. Attach the stake to the xture head by inserting the xture with gentle pressure.
4. Attach the light xture to provided stake or base. Twist base clockwise until tight and
set on at surface; or stake the light into the desired location by holding the top of the
stake and gently pushing the stake into the ground.
5. Adjust the angle of the projected light by turning the thumbscrew attached to the side
of the xture.
6. Connect the power supply into an available standard electrical outlet.
7. Use the included remote control to adjust the speed of the light movement.
8. To turn o the light, use the provided remote or remove the power plug from the
electrical outlet.
OPERATING THE BLISSLIGHTS FIREFLY MOTION
The Blisslights Firey Motion operates in temperatures of 19°F to 95°F. There may be a slight
delay in projection intensity if operating in temperatures below 55°F. Please allow up to 10
minutes for the light to warm up and reach its full projection intensity.
OPERATING THE TIMER
When you rst plug in your light, it will automatically turn on and will operate at its slowest
rotation speed. It will continue on for 6 hours, or until it is shut o using the remote control.
Using the remote control to shut o the unit also disables the timer, and every time it is
turned on, it will reset the timer.
The Blisslights Firey Motion has a built-in timer that is designed to automatically shut o
after 6 hours of operation, though it can be set to stay on for 4, 6, or 8 hours. It will go into
sleep mode for 18 hours on default mode (20 when set to 4 hours on, or 16 hours when set
to 8-hours on) and resume its operation thereafter. The rotation speed will remain at the
same setting for every timer cycle, unless you unplug the unit, which will return it to the
slowest rotation speed.

4
CAUTION
This is not a toy. Young children must be supervised while using this device at all times.
CLEANING INSTRUCTIONS
Surface clean only with a soft, dry cloth. Unplug unit before cleaning.
DISPOSAL
At the end of its serviceable life, this product should not be treated as household or general waste. It
should be handed over to the applicable collection point for the recycling of electrical and electronic
equipment.

5
USING THE REMOTE CONTROL
INCREASING AND DECREASING THE LIGHT ANIMATION SPEED
Press the SPEED button on your remote to choose slow, medium, or fast light animation
speed. Press the Play/Pause button to stop the movement or start it again.
FCC Compliance:
This device complies with Part 15 of FCC Rules. Operation is subject to the following two
conditions: 1. this device may not cause harmful interference, and 2. this device must accept
any interference received, including interference that may cause undesired operation.
For detailed information, see NOTICE on page 1.
PRECAUTIONARY TIPS FOR THE REMOTE CONTROL
• The remote control should be kept dry and away from heat sources. Avoid humidity. If
the device responds erratically to the remote control, or doesn’t respond at all, check
the batteries.
• Do not subject the remote control to undue physical stress, such as striking or
dropping it.
• Do not attempt to clean the remote control with a volatile solvent. Wipe it with a clean,
damp, soft cloth when cleaning.
Power
Press to turn ON or OFF
Color
Press to cycle through red/
green, green only, and red only
Blink
Press to cycle through
ash eect speed settings
Speed
Press to cycle through
motion speed settings
Timer reset
Press to reset timer
Play/Pause
Press to stop or start motion
Timer increments
Press to set timer ON
increment to 4, 6, or 8 hours
BATTERY DISPOSAL
At the end of its serviceable life, this remote should not be treated as household or general waste. It
should be handed over to the applicable collection point for the recycling of electrical and electronic
equipment.

6
PRODUCT SPECIFICATIONS
INSTALLATION TIPS
• Do not connect the light to a dimmer pack, as a dimmer accessory may damage
the laser component.
• Use only the manufacturer-provided power supply.
• Limit the use of extension cords. If you need an extension cord, use only UL, CUL, or
CSA approved 3rd party extension cords. When using outdoors, ONLY use extension
cords that are weather resistant, such as waterproof cords.
• The darker the display area, the brighter your projection will appear. Try to avoid
display areas with strong ambient light sources, such as commercial street lights or
bright security ood lights.
• If you choose to mount the BlissLights Firey Motion for down lighting (e.g. from
balcony railing, fence line, roof line, etc.), it is recommended that, for safety purposes,
your lights are properly mounted using a suitable hanging clamp and safety cable.
Dimensions
Housing
Laser Classication
Laser Wavelength
Maintenance
Power Consumption
Power Supply Input
Light Input
Operating Temperature
Operation
Projection Coverage
Remote Control Functions
Timer
Warranty
110.2 x 103 x 331 mm
4.3 x 4 x 13”
ABS
Class 3R
Red—660 nm, Green—515 nm
Maintenance free
2-9 W, continuous operation 24/7
120 V AC, 60Hz (with provided UL/CUL power supply)
12 VDC
19°F to 95°F (-7°C to 35°C)
Indoor/outdoor
Up to 50 x 50’ (15.2 x 15.2 m)
Power, increase speed, decrease speed
4/6/8 timer (on for 4/6/8 hours/o for 20/18/16 hours)
One-year warranty

How to plug-in your laser projector:
1. Locate the two-copper socket at the bottom of the power supply provided.
7
TROUBLESHOOTING
TWO-COPPER SOCKET
TWO-PRONG
4. Secure the water seal and plug it in into any standard AC outlet to turn on the laser
projector.
2. Locate the two-prong side of the cord that comes with the xture.
3. Align to the two-copper socket and insert directly.

8
How to avoid a rotation problem:
If the rotation of your Firey Motion starts and stops randomly, there is a wireless signal
interference (i.e. radio control toys, remote controls for TV or entertainment systems,
automatic vacuums, etc.). To verify if this is the case, please try covering the receiver
between the dual laser lenses with your nger to block stray infrared signals from entering
the Firey Motion. If this corrects the problem, please check the other electronic products
running in the room to determine where the stray signals are coming from.
1-YEAR LIMITED WARRANTY
This product carries a one (1) year warranty against defects in workmanship and materials. BlissLights,
LLC agrees to replace the defective product free of charge within the stated warranty period, when
returned by the original purchaser with proof of purchase. This product is not guaranteed against
wear or breakage due to misuse and/or abuse. For more detailed warranty information, please visit
www.blisslights.com/warranty/
Made in China
Designed in the USA
By BlissLights, LLC
San Marcos, CA 92069

www.blisslights.com
