Blizzard Lighting Redstone 240Z Wash User manual

Blizzard Lighting, LLC
http://www.blizzardpro.com
Waukesha, WI USA
Copyright (c) 2019
240Z WASH

Page 2
Redstone™ 240Z Wash Manual - Rev. A (c) 2019 Blizzard Lighting, LLC
TABLE OF CONTENTS
Redstone™ 240Z Wash LED Moving Head 1
1. Getting Started 3
What’s In The Box? 3
Getting It Out Of The Box 3
Powering Up! 3
Getting A Hold Of Us 3
Safety Instructions (Don’t Stick Your Hand In The Toaster!) 4
2. Meet Redstone™ 240Z Wash 5
Main Features 5
DMX Quick Reference 5
The Redstone™ 240Z Wash Pin-up Picture 6
3. Setup 7
Connecting A Bunch Of Redstone™ 240Z Wash Fixtures 7
Data/DMX Cables 7
Using The Built-in W-DMX™ 7
Cable Connectors 8
3-Pin??? 5-Pin??? Huh? 8
Take It To The Next Level: Setting up DMX Control 8
Fixture Linking (Master/Slave Mode) 9
Clamp Mounting 9
Securing the Fixture 9
4. Operating Adjustments 10
The Control Panel 10
Control Panel Menu Structure 11
DMX Mode 12
Set the Starting DMX Address 12
Select the DMX Channel Mode 12
Signal Selection 12
Auto Mode 12
Sound Active Mode 12
Pan/Tilt Inverse 12
PT Feedback 12
White Balance 12
Dimmer Curves 13
Display Inverse 13
Backlight Switch 13
Backlight Intensity 13
Language 13
Test Modes 13
Calibration 13
DMX Values In-Depth 14
5. Appendix 16
A Quick DMX Lesson 16
Keeping Your Redstone™ 240Z Wash As Good As New 17
Returns (Gasp!) 17
Shipping Issues 17
Tech Specs 18
Troubleshooting 18
Dimensional Drawings 19
Photometric Data 18

Page 3
Redstone™ 240Z Wash Manual - Rev. A (c) 2019 Blizzard Lighting, LLC
1. GETTING STARTED
What’s In The Box?
• 1 x Redstone™ 240Z Wash
• 1 x Ever-So-Handy Power Cord
• 1 x DMX Signal Cable
• 2 x Mounting Bracket
• 1 x Safety Cable
• This Lovely User Manual
Getting It Out Of The Box
Congratulations on your purchase of the Redstone™ 240Z Wash xture, you're a go for
launch! So now that you’ve got your 240Z (or hopefully 240Zs) , you should carefully
unpack the box and check the contents to ensure that all parts are present and in good
condition. If anything looks as if it has been damaged in transit, notify the shipper imme-
diately and keep the packing material for inspection. Again, please save the carton and
all packing materials. If a xture must be returned to the factory, it is important that the
xture be returned in the original factory box and packing.
Powering Up!
All xtures must be powered directly o a switched circuit and cannot be run o a
rheostat (variable resistor) or dimmer circuit, even if the rheostat or dimmer
channel is used solely for a 0% to 100% switch.
AC Voltage Switch - Not all xtures have a voltage select switch, so please verify that the
xture you receive is suitable for your local power supply. See the label on the xture or
refer to the xture’s specications chart for more information. A xture’s listed current
rating is its average current draw under normal conditions. Check the xture or device
carefully to make sure that if a voltage selection switch exists that it is set to the correct
line voltage you will use.
Warning! Verify that the voltage select switch on your unit matches the line
voltage applied. Damage to your xture may result if the line voltage applied does
not match the voltage indicated on the voltage selector switch. All xtures must
be connected to circuits with a suitable Ground (Earthing).
Getting A Hold Of Us
If something is wrong, please just visit our website at www.blizzardpro.com/
support and open a support ticket. We’ll be happy to help, honest.
Disclaimer: The information and specications contained in this document are subject
to change without notice. Blizzard Lighting™ assumes no responsibility or liability for any
errors or omissions that may appear in this user manual. Blizzard Lighting™ reserves the
right to update the existing document or to create a new document to correct any errors
or omissions at any time. You can download the latest version of this document from www.
blizzardpro.com.
Author: Date: Last Edited: Date:
J. Thomas 4/4/2019 J. Thomas 4/4/2019

Page 4
Redstone™ 240Z Wash Manual - Rev. A (c) 2019 Blizzard Lighting, LLC
Please read these instructions carefully. They include
important information about the installation, usage and
maintenance of this product.
SAFETY INSTRUCTIONS
• Please keep this User Guide for future use. If you sell the unit to someone
else, be sure that they also receive this User Guide.
• ALWAYS make sure that you are connecting to the proper voltage, and that
the line voltage you are connecting to is not higher than that stated on the de-
cal or rear panel of the xture.
• This product is intended for indoor use only.
• To prevent risk of re or shock, do not expose xture to rain or moisture.
• Make sure there are no ammable materials close to the unit while operating.
• The unit must be installed in a location with adequate ventilation, at least
20in (50cm) from adjacent surfaces. Be sure that no ventilation slots are
blocked.
• ALWAYS disconnect from the power source before servicing or replacing fuse
and be sure to replace with same fuse size and type.
• ALWAYS secure xture using a safety chain. NEVER carry the xture by its
head. Use its carrying handles.
• DO NOT operate at ambient temperatures higher than 104°F (40°C).
• In the event of a serious operating problem, stop using the unit immediately.
NEVER try to repair the unit by yourself. Repairs carried out by unskilled people
can lead to damage or malfunction. Please contact the nearest authorized tech-
nical assistance center. Always use the same type spare parts.
• NEVER connect the device to a dimmer pack.
• Make sure the power cord is never crimped or damaged.
• Never disconnect the power cord by pulling or tugging on the cord.
• Avoid direct eye exposure to the light source while it is on.
Caution! There are no user serviceable parts inside the unit. Do not
open the housing or attempt any repairs yourself. In the unlikely event
your unit may require service, please open a support ticket at www.
blizzardpro.com/support.

Page 5
Redstone™ 240Z Wash Manual - Rev. A (c) 2019 Blizzard Lighting, LLC
2. MEET REDSTONE™ 240Z WASH
MAIN FEATURES
• 1x 240W OSRAM 4-IN-1 RGBW LED
• 5°-70° smooth and quiet linear motorized zoom
• Highly ecient Fresnel lens, integrated w/light pipe technology
• Built-in Wireless Solutions™ W-DMX receiver
• Even, soft edge and pure color mixing coverage
• Flicker free operation for broadcast TV and lm
• 540°/270° PAN and TILT + invert and calibration
• 4x user selectable dimming curves
• 1-25Hz fps strobe + random/pulse eects
• Multiple pre-programmed macro eects with variable speed
• Rotating prism beam shaping eects
• Ecient low noise self-adjusting fan cooling system
• 3-pin DMX In/Out + RJ45 etherCON In/Out (Art-NET)
• PowerCON® compatible AC power In/Out
• 2.4-inch TFT LCD display menu with 4 button control panel
• 18/21/28 DMX channel modes
• DMX512, Art-Net, RDM, M/S, sound active & auto mode
DMX Quick Reference (21/18/28-Channel Modes)
Ch. 21-Channel Ch. 18-Channel Ch. 28-Channel
1Pan 1Pan 1Pan
2 Fine Pan (16-bit) 2 Tilt 2 Fine Pan (16-bit)
3 Tilt 3 Pan/Tilt Speed 3 Tilt
4 Fine Tilt (16-bit) 4 Red Intensity 4 Fine Tilt (16-bit)
5 Pan/Tilt Speed 5 Green Intensity 5 Pan/Tilt Speed
6 Red Intensity 6 Blue Intensity 6 Red Intensity
7 Green Intensity 7 White Intensity 7 Red Intensity Fine
8 Blue Intensity 8 Strobe 8 Green Intensity
9 White Intensity 9 Dimmer 9 Green Intensity Fine
10 Strobe 10 CTO 10 Blue Intensity
11 Dimmer 11 Color Macros 11 Blue Intensity Fine
12 Dimmer Fine 12 Color Presets 12 White Intensity
13 CTO 13 Color Preset Dimmer 13 White Intensity Fine
14 Color Macros 14 Focus 14 Strobe
15 Color Presets 15 Beam Shaper (Prism) 15 Dimmer
16 Color Preset Dimmer 16 Beam Shaper Rotation 16 Dimmer Fine
17 Focus 17 Zoom 17 CTO
18 Beam Shaper (Prism) 18 Special Function 18 Color Macros
19 Beam Shaper Rotation -- -- 19 Color Presets
20 Zoom -- -- 20 Color Preset Dimmer
21 Special Function -- -- 21 Focus
-- -- -- -- 22 Focus Fine
-- -- -- -- 23 Beam Shaper (Prism)
-- -- -- -- 24 Beam Shaper Rotation
-- -- -- -- 25 Indexing Fine
-- -- -- -- 26 Zoom
-- -- -- -- 27 Zoom Fine
-- -- -- -- 28 Special Function

Page 6
Redstone™ 240Z Wash Manual - Rev. A (c) 2019 Blizzard Lighting, LLC
Figure 1: Redstone™ 240Z Wash Pin-Up Picture
Figure 2: The Rear Connections
Figure 1: Redstone™ 240Z Wash Pin-Up Picture
240W OSRAM
RGBW LED
Light Source
Carry
Handle
4-Button
Control Panel
with 2.4" TFT
Color Display
Head/Arms
Art-Net
Antenna
DMX In
DMX Out Power In
Power Out
Fuse
Power Switch

Page 7
Redstone™ 240Z Wash Manual - Rev. A (c) 2019 Blizzard Lighting, LLC
3. SETUP3. SETUP
Connecting A Bunch of Redstone™ 240Z Wash Fixtures
You will need a serial data link to run light shows using a DMX-512 controller or to run
shows on two or more xtures set to sync in master/slave operating mode. The combined
number of channels required by all the xtures on a serial data link determines the number
of xtures the data link can support.
Fixtures on a serial data link must be daisy chained in one single line. Also, connecting
more than 32 xtures on one serial data link without the use of a DMX optically-isolated
splitter may result in deterioration of the digital DMX signal. The maximum recommended
cable-run distance is 500 meters (1640 ft). The maximum recommended number of
xtures on a serial data link is 32 xtures.
Data/DMX Cabling
To link xtures together you’ll need data cables. You should use data-grade cables that can
carry a high quality signal and are less prone to electromagnetic interference. The cables
should have the following characteristics:
• 2-conductor twisted pair plus a shield
• Maximum capacitance between conductors – 30 pF/ft.
• Maximum capacitance between conductor & shield – 55 pF/ft.
• Maximum resistance of 20 ohms / 1000 ft.
• Nominal impedance 100 – 140 ohms
Using The Built-in W-DMX™
To use the built-in W-DMX™ receiver, you will rst need a W-DMX™ transmitter to
broadcast the signal, such as our own LightCaster™ W-DMX™ transceiver. Paired up with a
LightCaster™ W-DMX™ transceiver, you can expect an outstanding wireless range of up to
500 meters (line-of-sight).
If you’re using an external wireless W-DMX transmitter like our LightCaster™ W-DMX™
transceiver, power it up and plug it into the “DMX OUT” connector of the controller.
* Please refer to your W-DMX™ transmitter user manual for more product specic instructions.
1. One transceiver with multiple receivers:
a.) Power on all units, and verify that your transmitter is transmitting a signal.
b.) On the receiving W-DMX xtures, use the control panel menu to navigate to DMX
> Connect to, then highlight Wireless Only (wireless will also work as a secondary
connection method under the XLR Priority menu selection if an XLR signal is lost.)
c.) Press and hold down the <ENTER> button to sync the xtures.
2. Multiple transceivers, multiple receivers; e.g. 3 groups consisting of a transceiver &
receiver(s) named A, B, and C:
1.) Turn power o of all units.
2.) Group “A” gets powered on, then follow step 1 above.
3.) Group “B” gets powered on, then follow step 1 above.
4.) Group “C” gets powered on, then follow step 1 above.

Page 8
Redstone™ 240Z Wash Manual - Rev. A (c) 2019 Blizzard Lighting, LLC
Cable Connectors
Cables must have a male XLR connector on one end and a female XLR connector on the
other end. (Duh!)
CAUTION: Do not allow contact between the common and the xture’s chassis
ground. Grounding the common can cause a ground loop, and your xture may
perform erratically. Test cables with an ohm meter to verify correct polarity and
to make sure the pins are not grounded or shorted to the shield or each other.
3-Pin??? 5-Pin??? Huh?!?
If you use a controller with a 5 pin DMX output connector, you will need to use a 5 pin to 3 pin adapter.
They are widely available over the internet and from specialty retailers If you’d like to build your own, the
chart below details a proper cable conversion:
Conductor 3-Pin Female (Output) 5-Pin Male (Input)
Ground/Shield Pin 1 Pin 1
Data 1- (Primary Data Link) Pin 2 Pin 2
Data 1+ (Primary Data Link) Pin 3 Pin 3
Data 2- (Optional Secondary Data Link) Pin 4 Pin 4
Data 2+ (Optional Secondary Data Link) Pin 5 Pin 5
Take It To The Next Level: Setting Up DMX Control
Step 1: Connect the male connector of the DMX cable to the female connector (output) on
the controller.
Step 2: Connect the female connector of the
DMX cable to the rst xture’s male connector
(input). Note: It doesn’t matter which
xture address is the rst one connected. We
recommend connecting the xtures in terms
of their proximity to the controller, rather than
connecting the lowest xture number rst, and
so on.
Step 3: Connect other xtures in the chain
from output to input as above. Place a DMX
terminator on the output of the nal xture to
ensure best communication.

Page 9
Redstone™ 240Z Wash Manual - Rev. A (c) 2019 Blizzard Lighting, LLC
1/ 4 Tur n 1/4 Turn
Fixture Linking (Master/Slave Mode)
1. Connect the (male) 3-pin connector side of the DMX cable to the output (female)
3-pin connector of the rst xture.
2. Connect the end of the cable coming from the rst xture which will have a (female)
3-pin connector to the input connector of the next xture consisting of a (male) 3-pin
connector. Then, proceed to connect from the output as stated above to the input of
the following xture and so on.
Clamp Mounting
This xture provides a mounting bracket assembly that secures the bottom of the base, the
“Omega Brackets,” and the safety cable rigging point together. When mounting this xture
to truss, be sure to secure an appropriately rated clamp to the omega bracket using an
M10 screw tted through the center hole of the “omega bracket”.
2
3
1
1.) Clamp
2.) Omega Bracket
3.) Safety Cable
4.) ¼ Turn Quick Locks
Securing the Fixture
Regardless of the rigging option you choose for your xtures always be sure to secure
your xture with a safety cable. Be sure to only use the designated rigging point found on
the underside of the base assembly for the safety cable. Never secure a safety cable to a
carrying handle.
4

Page 10
Redstone™ 240Z Wash Manual - Rev. A (c) 2019 Blizzard Lighting, LLC
4. OPERATING ADJUSTMENTS
The Control Panel
All the goodies and dierent modes possible with the Redstone 240Z
Wash are accessed by using the control panel on the front of the x-
ture. There are 4 control buttons to the right of the LCD display which
allow you to navigate through the various control panel menus.
<MENU>
Is used to navigate to the previous higher-level menu item.
<ENTER>
Is used to select and conrm/store the current selection.
<UP>
Scrolls through menu items and numbers in ascending order.
<DOWN>
Scrolls through menu items and numbers in descending order.
The control panel display shows the menu items you select from the
menu map on page #11. When a menu function is selected, the dis-
play will show immediately the rst available option for the selected
menu function. To select a menu item, press <ENTER>.
Use the <UP> and <DOWN> buttons to navigate the menu options.
Press the <ENTER> button to select the menu function currently dis-
played, or to enable a menu option. To return to the previous option or
menu without changing the value, press the <MENU> button.
DMX Address Led 29°C
MasterSlave Mode 21Ch.
