Blizzard Lighting Stiletto Glo 19 User manual

Blizzard Lighting, LLC
www.blizzardlighting.com
Waukesha, WI USA
Copyright (c) 2016

Page 2
Stiletto™ Glo User Manual Rev. C (c) 2016 Blizzard Lighting, LLC
TABLE OF CONTENTS
Stiletto™ Glo Moving Head Fixture 1
1. Getting Started 3
What’s In The Box? 3
Getting It Out Of The Box 3
Powering Up! 3
Getting A Hold Of Us 3
Safety Instructions (Don’t Stick Your Hand In The Toaster!) 4
2. Meet The Stiletto™ Glo 5
Main Features 5
Control 5
DMX Quick Reference 5
The Stiletto™ Glo Pin-up Picture 6
3. Setup 7
Fuse Replacement 7
Connecting A Bunch Of Stiletto™ Glo Fixtures 7
Data/DMX Cables 7
Cable Connectors 8
3-Pin??? 5-Pin??? Huh? 8
Take It To The Next Level: Setting up DMX Control 8
Fixture Linking (Master/Slave Mode) 9
Mounting/Rigging 9
4. Operating Adjustments 10
The Control Panel 10
Control Panel Menu Structure 11
Operation and Effects 12
Pattern (Beam) and Glo (Wash) 12
Dimming 12
Zoom 12
Macros 12
RGBW and RGB Control 12
Classic Mode 12
Individual LED Control 12
DMX Channel Values In-Depth 13
LEE Colors and RGB Equivalents 18
5. Appendix 19
A Quick DMX Lesson 19
Keeping Your Stiletto™ Glo As Good As New 20
Returns (Gasp!) 20
Shipping Issues 20
Troubleshooting 20
Tech Specs 21
Dimensional Drawings 22

Page 3
Stiletto™ Glo User Manual Rev. C (c) 2016 Blizzard Lighting, LLC
1. GETTING STARTED
What’s In The Box?
• 1 x Stiletto™ Glo Moving Head Fixture
• 1 x Set of Mounting Brackets
• An Ever-So-Handy Power Cord
• This Lovely User Manual
Getting It Out Of The Box
Congratulations on your purchase of the Stiletto™ Glo, the powerful beam and wash
luminaire that is built to impress with its sharp beams and glowing personality! So now
that you’re the proud owner of a Stiletto™ Glo (or hopefully, Stilettos!), you should
carefully unpack the box and check the contents to ensure that all parts are present and
in good condition. If anything looks as if it has been damaged in transit, notify the shipper
immediately and keep the packing material for inspection. Again, please save the carton
and all packing materials. If a xture must be returned to the factory, it is important that
the xture be returned in the original factory box and packing.
Powering Up!
All xtures must be powered directly off a switched circuit and cannot be run off a
rheostat (variable resistor) or dimmer circuit, even if the rheostat or dimmer
channel is used solely for a 0% to 100% switch.
AC Voltage Switch - Not all xtures have a voltage select switch, so please verify that the
xture you receive is suitable for your local power supply. See the label on the xture or
refer to the xture’s specications chart for more information. A xture’s listed current
rating is its average current draw under normal conditions. Check the xture or device
carefully to make sure that if a voltage selection switch exists that it is set to the correct
line voltage you will use.
Warning! Verify that the voltage select switch on your unit matches the line
voltage applied. Damage to your xture may result if the line voltage applied does
not match the voltage indicated on the voltage selector switch. All xtures must
be connected to circuits with a suitable Ground (Earthing).
Getting A Hold Of Us
If something happens goes wrong, please visit www.blizzardlighting.com/
support and open a support ticket. We’ll be happy to help, honest.
Disclaimer: The information and specications contained in this document are subject
to change without notice. Blizzard Lighting™ assumes no responsibility or liability for any
errors or omissions that may appear in this user manual. Blizzard Lighting™ reserves the
right to update the existing document or to create a new document to correct any errors
or omissions at any time. You can download the latest version of this document from www.
blizzardlighting.com.
Author: Date: Last Edited: Date:
J. Thomas 2/27/2016 J. Thomas 11/20/2018

Page 4
Stiletto™ Glo User Manual Rev. C (c) 2016 Blizzard Lighting, LLC
SAFETY INSTRUCTIONS
• Please keep this User Guide for future use. If you sell the unit to someone
else, be sure that they also receive this User Guide.
• ALWAYS make sure that you are connecting to the proper voltage, and that
the line voltage you are connecting to is not higher than that stated on the
decal or rear panel of the xture.
• This product is intended for indoor use only.
• To prevent risk of re or shock, do not expose xture to rain or moisture.
• Make sure there are no ammable materials close to the unit while operating.
• The unit must be installed in a location with adequate ventilation, at least
20in (50cm) from adjacent surfaces. Be sure that no ventilation slots are
blocked.
• ALWAYS disconnect from the power source before servicing or replacing fuse
and be sure to replace with same fuse size and type.
• ALWAYS secure xture using a safety chain. NEVER carry the xture by its
cord. Use its carrying handles.
• DO NOT operate at ambient temperatures higher than 104°F (40°C).
• In the event of a serious operating problem, stop using the unit immediately.
NEVER try to repair the unit by yourself. Repairs carried out by unskilled people
can lead to damage or malfunction. Please contact the nearest authorized
technical assistance center. Always use the same type spare parts.
• NEVER connect the device to a dimmer pack.
• Make sure the power cord is never crimped or damaged.
• Never disconnect the power cord by pulling or tugging on the cord.
• Avoid direct eye exposure to the light source while it is on.
Caution! There are no user serviceable parts inside the unit. Do not
open the housing or attempt any repairs yourself. In the unlikely event
your unit may require service, please contact Blizzard Lighting at www.
blizzardlighting.com/support.

Page 5
Stiletto™ Glo User Manual Rev. C (c) 2016 Blizzard Lighting, LLC
2. MEET THE STILETTO™ GLO MOVING HEAD™
MAIN FEATURES:
• 19*15W OSRAM™ 4-in-1 RGBW LEDs (patterns)
• RGB color mixing Glo™ control (secondary background LED array)
• 11°-58° zoomable beam angle
• Linear smooth dimming 0-100%
• 1000-2500K CTC (Color Temperature Control)
• 540° pan & 270° tilt (16-bit)
• Internal fan cooling system
• Color macro effects
• USITT DMX-512 (14/17/28/74/85 and 93-channel)
• 3/5-pin XLR input and output
• 5-button menu with LCD display
DMX Quick Reference (Standard, Shape, Extended, Extended RGBW, & Full Modes)
STD. SHAPE EXT. RGBW FULL What is does
1 1 1 1 1 Red Intensity (0% <--> 100%)
2 2 2 2 2 Green Intensity (0% <--> 100%)
3 3 3 3 3 Blue Intensity (0% <--> 100%)
4 4 4 4 4 White Intensity (0% <--> 100%)
5 5 5 5 5 Linear CTO
6 6 6 6 6 Color Macros
7 7 7 7 7 Beam Strobe
8 8 8 8 8 Master Dimmer
99999Pan
10 10 10 10 10 Fine Pan
11 11 11 11 11 Tilt
12 12 12 12 12 Fine Tilt
13 13 13 13 13 Reset
14 14 14 14 14 Zoom
15 15 15 15 15 Glo Red
16 16 16 16 16 Glo Green
17 17 17 17 17 Glo Blue
-- 18 -- -- 18 Pattern Selection
-- 19 -- -- 19 Pattern Speed
-- 20 -- -- 20 Pattern Red
-- 21 -- -- 21 Pattern Green
-- 22 -- -- 22 Pattern Blue
-- 23 -- -- 23 Pattern White
-- 24 -- -- 24 Pattern Dimmer
-- 25 -- -- 25 Beam Dimmer
-- 26 -- -- 26 Pattern Strobe
-- 27 -- -- 27 Beam Strobe
-- 28 -- -- 28 Background Selection
-- -- 18 18 29 LED 1 Red (0% <--> 100%)
-- -- 19 19 30 LED 1 Green (0% <--> 100%)
-- -- 20 20 31 LED 1 Blue (0% <--> 100%)
-- -- -- 21 -- LED 1 White (0% <--> 100%)
-- -- -- -- -- --
-- -- 72 90 83 LED 19 Red (0% <--> 100%)
-- -- 73 91 84 LED 19 Green (0% <--> 100%)
-- -- 74 92 85 LED 19 Blue (0% <--> 100%)
-- -- -- 93 -- LED 19 White (0% <--> 100%)
DMX Quick Reference (Classic Mode)
Channel What is does Channel What is does
1 Beam Shutter 8 Reset
2 Beam Dimmer 9 Beam Color Effects
3 Zoom 10 Beam Red
4Pan 11 Beam Green
5 Pan Fine 12 Beam Blue
6 Tilt 13 Beam White
7 Fine Tilt 14 Beam CTC

Page 6
Stiletto™ Glo User Manual Rev. C (c) 2016 Blizzard Lighting, LLC
Figure 1: The Stiletto™ Glo Pin-Up Picture
19* 15W OSRAM™
RGBW LEDs + Glo™
RGB Color Mixing
5-Button
Control Panel
with Backlit
LCD Graphic
Display
Figure 2: The Rear Connections
3/5-Pin DMX Outputs
Head/Arms
Fuse Holder
Power Input3/5-Pin DMX Inputs

Page 7
Stiletto™ Glo User Manual Rev. C (c) 2016 Blizzard Lighting, LLC
3. SETUP
Fuse Replacement
With a phillips head screwdriver, unscrew the fuse holder out of its hous-
ing. Remove the damaged fuse from its holder and replace with exact
same type fuse. Reattach the fuse holder, and then reconnect power.
Connecting A Bunch of Stiletto™ Glo Fixtures
You will need a serial data link to run light shows using a DMX-512
controller or to run shows on two or more xtures set to sync in master/
slave operating mode. The combined number of channels required by all
the xtures on a serial data link determines the number of xtures the
data link can support.
Fixtures on a serial data link must be daisy chained in one single line. Also,
connecting more than 32 xtures on one serial data link without the use
of a DMX optically-isolated splitter may result in deterioration of the digital
DMX signal.
The maximum recommended cable-run distance is 500 meters (1640 ft).
The maximum recommended number of xtures on a serial data link is 32
xtures.
Data/DMX Cabling
To link xtures together you’ll need data cables. You should use data-
grade cables that can carry a high quality signal and are less prone to
electromagnetic interference.
For instance, Belden© 9841 meets the specications for EIA RS-485
applications. Standard microphone cables will “probably” be OK, but note
that they cannot transmit DMX data as reliably over long distances. In any
event, the cable should have the following characteristics:
2-conductor twisted pair plus a shield
Maximum capacitance between conductors – 30 pF/ft.
Maximum capacitance between conductor & shield – 55 pF/ft.
Maximum resistance of 20 ohms / 1000 ft.
Nominal impedance 100 – 140 ohms

Page 8
Stiletto™ Glo User Manual Rev. C (c) 2016 Blizzard Lighting, LLC
Cable Connectors
Cables must have a male XLR connector on one end and a female XLR
connector on the other end. (Duh!)
CAUTION: Do not allow contact between the common and the
xture’s chassis ground. Grounding the common can cause a ground
loop, and your xture may perform erratically. Test cables with an
ohm meter to verify correct polarity and to make sure the pins are not
grounded or shorted to the shield or each other.
3-Pin??? 5-Pin??? Huh?!?
If you use a controller with a 5 pin DMX output connector, you will need to use a 5 pin to 3 pin adapter.
They are widely available over the internet and from specialty retailers. If you’d like to build your own,
the chart below details a proper cable conversion:
Conductor 3-Pin Female
(Output)
5-Pin Male
(Input)
Ground/Shield Pin 1 Pin 1
DMX Data (-) Pin 2 Pin 2
DMX Data (+) Pin 3 Pin 3
Not Used. No Connection. No Connection.
Not Used. No Connection. No Connection.
Take It To The Next Level: Setting Up DMX Control
Step 1: Connect the male connector of the
DMX cable to the female connector (output)
on the controller.
Step 2: Connect the female connector of
the DMX cable to the rst xture’s male
connector (input). Note: It doesn’t matter
which xture address is the rst one
connected. We recommend connecting the
xtures in terms of their proximity to the
controller, rather than connecting the lowest
xture number rst, and so on.
Step 3: Connect other xtures in the chain
from output to input as above. Place a DMX
terminator on the output of the nal xture
to ensure best communication.

Page 9
Stiletto™ Glo User Manual Rev. C (c) 2016 Blizzard Lighting, LLC
Fixture Linking (Master/Slave Mode)
1. Connect the (male) 3/5-pin connector side of the
DMX cable to the output (female) 3/5-pin connector
of the rst xture.
2. Connect the end of the cable coming from the
rst xture which will have a (female) 3/5-pin con-
nector to the input connector of the next xture
consisting of a (male) 3/5-pin connector. Then, pro-
ceed to connect from the output as stated above to
the input of the following xture and so on.
A quick note: Often,
the setup for Master-
Slave and Standalone
operation requires that
the rst xture in the
chain be initialized for
this purpose via either
settings in the control
panel or DIP-switches.
Secondarily, the xtures
that follow may also re-
quire a slave setting.
Check the “Operating Adjustments” section in this manual for com-
plete instructions for this type of setup and conguration.
Mounting & Rigging
This xture may be mounted in any SAFE position provided there is
enough room for ventilation.
It is important never to obstruct the fan or vents pathway. Mount the
xture using a suitable “C” or “O” type clamp. The clamp should be
rated to hold at least 10x the xture’s weight to ensure structural sta-
bility. Do not mount to surfaces with unknown strength, and ensure
properly “rated” rigging is used when mounting xtures overhead.
Adjust the angle of the xture by loosening both knobs and tilting the
xture. After nding the desired position, retighten both knobs.
• When selecting installation location, take into consideration access
for routine maintenance.
• Safety cables MUST ALWAYS be used.
• Never mount in places where the xture will be exposed to rain,
high humidity, extreme temperature changes or restricted ventilation.

Page 10
Stiletto™ Glo User Manual Rev. C (c) 2016 Blizzard Lighting, LLC
4. OPERATING ADJUSTMENTS
The Control Panel
All the goodies and different modes possible with the Stiletto Glo™ are
accessed by using the control panel on the front of the xture. There
are 5 control buttons next to the LCD display which allow you to navi-
gate through the various control panel menus.
<ENTER>
Is used to navigate to a higher-level menu item.
<UP>
Scrolls through menu items and numbers
in ascending order.
<DOWN>
Scrolls through menu items and numbers
in descending order.
<OK>
Is used to save any changes made to a
menu setting.
<MENU>
To return to the previous option or menu without changing the value.
Access control panel functions using the ve panel buttons located
directly to the right of the LCD display.
The control panel LCD display shows the menu items you select from
the menu map on page #11. When a menu function is selected, the
display will show immediately the rst available option for the selected
menu function. To select a menu item, press <ENTER>.
Use the <UP>, <DOWN>, and <ENTER> buttons to navigate the
menu map and menu options. Press the <OK> button to enable a
menu option. To return to the previous option or menu without chang-
ing the value, press the <MENU> button.
OK
ENTERMENU
