Blizzard HYPE 150 User manual

Blizzard Lighting, LLC
http://www.blizzardpro.com
Waukesha, WI USA
Copyright (c) 2022

Page 2
Hype™ 150 User Manual Rev. A © 2022 Blizzard Lighting, LLC
TABLE OF CONTENTS
1. Getting Started 3
What’s In The Box? 3
Getting It Out Of The Box 3
Powering Up! 3
Getting A Hold Of Us 3
Safety Instructions 4
2. Meet the HYPE™ 150 5
Main Features 5
DMX Quick Reference 5
HYPE™ 150 Pin-Up Picture 6
Rear Connections 6
3. Setup 7
Fuse Replacement 7
Connecting A Bunch of HYPE™ 150 Fixtures 7
Data/DMX Cabling 7
Cable Connectors 8
3-Pin??? 5-Pin??? Huh?!? 8
Take It To The Next Level: Setting Up DMX Control 8
Mounting & Rigging 9
Securing the Fixture 9
4. Operating Adjustments 10
The Control Panel 10
Control Panel Menu Structure 11
Starting DMX Address 11
DMX Channel Mode 11
Auto & Sound Active Modes 11
Dimming Curves 11
DMX Values In-Depth 12
Gobo and Color Wheels 13
5. Appendix 14
Keeping Your HYPE™ 150 As Good As New 14
Returns (Gasp!) 14
Shipping Issues 14
Tech Specs! 15
Dimensional Drawings 15

Page 3
Hype™ 150 User Manual Rev. A © 2022 Blizzard Lighting, LLC
1. GETTING STARTED
What’s In The Box?
• HYPE™ 150 Moving Head
• Power Cord
• 2x Mounting Brackets
• This Lovely User Manual
Getting It Out Of The Box
Congratulations on purchasing the HYPE™ 150. Now that you’ve got your xture, you
should carefully unpack the box and check the contents to ensure that all parts are present
and in good condition. If anything looks as if it has been damaged in transit, notify the
shipper immediately and keep the packing material for inspection. Again, please save the
carton and all packing materials. If a xture must be returned to the factory, it is important
that the xture be returned in the original factory box and packing.
Powering Up!
All xtures must be powered directly o a switched circuit and cannot be run o a
rheostat (variable resistor) or dimmer circuit, even if the rheostat or dimmer
channel is used solely for a 0% to 100% switch.
AC Voltage Switch - Not all xtures have a voltage select switch, so please verify that the
xture you receive is suitable for your local power supply. See the label on the xture or
refer to the xture’s specications chart for more information. A xture’s listed current
rating is its average current draw under normal conditions. Check the xture or device
carefully to make sure that if a voltage selection switch exists that it is set to the correct
line voltage you will use.
Warning! Verify that the voltage select switch on your unit matches the line
voltage applied. Damage to your xture may result if the line voltage applied does
not match the voltage indicated on the voltage selector switch. All xtures must
be connected to circuits with a suitable Ground (Earthing).
Getting A Hold Of Us
If something is wrong, please just visit our website at www.blizzardpro.com/
support and open a support ticket. We’ll be happy to help, honest.
Disclaimer: The information contained in this document are subject to change without notice. Blizzard
Lighting™ assumes no responsibility or liability for any errors or omissions that may appear in this user
manual. We reserve the right to update the existing, or create a new document to correct any errors or
omissions. You can download the latest version of this document from www.blizzardpro.com.
Author: Date: Last Edited: Date:
J. Thomas 3/20/2022 J. Thomas 8/9/2022

Page 4
Hype™ 150 User Manual Rev. A © 2022 Blizzard Lighting, LLC
Please read these instructions carefully. They include
important information about the installation, usage and
maintenance of this product.
Safety Instructions
• Please keep this User Guide for future use. If you sell the unit to someone
else, be sure that they also receive this User Guide.
• ALWAYS make sure that you are connecting to the proper voltage, and that
the line voltage you are connecting to is not higher than that stated on the de-
cal or rear panel of the xture.
• This product is intended for indoor use only.
• To prevent risk of re or shock, do not expose xture to rain or moisture.
• Make sure there are no ammable materials close to the unit while operating.
• The unit must be installed in a location with adequate ventilation, at least
20in (50cm) from adjacent surfaces. Be sure that no ventilation slots are
blocked.
• ALWAYS disconnect from the power source before servicing or replacing fuse
and be sure to replace with same fuse size and type.
• ALWAYS secure xture using a safety chain. NEVER carry the xture by its
head. Use its carrying handles.
• DO NOT operate at ambient temperatures higher than 104°F (40°C).
• In the event of a serious operating problem, stop using the unit immediately.
NEVER try to repair the unit by yourself. Repairs carried out by unskilled people
can lead to damage or malfunction. Please contact the nearest authorized tech-
nical assistance center. Always use the same type spare parts.
• NEVER connect the device to a dimmer pack.
• Make sure the power cord is never crimped or damaged.
• Never disconnect the power cord by pulling or tugging on the cord.
• Avoid direct eye exposure to the light source while it is on.
Caution! There are no user serviceable parts inside the unit. Do not open the
housing or attempt any repairs yourself. In the unlikely event your unit may
require service, please open a support ticket at www.blizzardpro.com/support.

Page 5
Hype™ 150 User Manual Rev. A © 2022 Blizzard Lighting, LLC
2. MEET THE HYPE™ 150
Main Features
• 150W, 8500K white LED light source, 50,000 hours
• Pan: 540°/tilt: 270° (8-16 bit resolution)
• Optional pan/tilt invert function
• Smooth linear dimming & electronic focus (0%-100%)
• 16° beam angle
• Rotating gobo wheel with 6 gobos +open
• Static gobo wheel with 8 gobos +open
• Color wheel with 7 colors plus +open & split colors
• +5V USB to power SoC-It™ wireless unit (not included)
• Bidirectional rainbow color eects
• 3-facet circular prism with variable speed and direction
• Built-in auto & sound active programs
• 1-15Hz strobe eects
• 3/5-pin XLR male and female DMX in/out
• powerCON™ TRUE1 compatible power input/output
Control
• Protocol: USITT DMX-512, RDM
• DMX Channels: 12/15-channels
• 4-button control panel with colored LCD display
• Operating modes: DMX512, M/S, auto, and sound active
DMX Quick Reference (12/15-Channel Modes)
12CH 15CH What it does
11Pan
-- 2 Fine Pan (16-bit)
2 3 Tilt
-- 4 Fine Tilt (16-bit)
3 5 Pan/Tilt Speed
4 6 Dimmer (0% - 100%)
5 7 Strobe
6 8 Color Wheel
-- 9 Color Split
7 10 Gobo Wheel (static)
8 11 Gobo Wheel (rotating)
9 12 Gobo Rotation
10 13 Focus (0% - 100%)
11 14 Prism
12 15 Reset
