Blodgett CB24E-10K User manual

Project
Item No.
Quantity
Model CB24E-6K (One 6 gallon direct steam kettle on a 24” electric
boiler base)
Model CB24E-10K (One 10 gallon direct steam kettle on a 24” electric
boiler base)
KETTLES
Water resistant, 304 stainless steel construction
316 stainless steel interior cooking surface for corrosion resistance
2/3 jacketed, hemispherical design on bottom for superior heat circulation
Tilt mechanism permits kettle to tilt forward past 90° to empty
Tubular stainless steel legs containing steam control valve and conden-
sate return pipes
Reversible operating handle with heat proof knob
ELECTRIC BOILER BASE
24 kW electric boiler base
Full perimeter painted angle iron frame
Reinforced counter and boiler mountings
Stainless steel exterior
Hinged door(s) with magnetic latch
6” (152 mm) stainless steel legs with adjustable bullet feet on front and
adjustable flanged feet on rear
All piping is confined within cabinet
Automatic water level control
Automatic boiler blowdown
Pressure gauge
Water gauge glass
Pressure control with pressure safety control
Safety relief valve
Cathodic protector
Steam trap
On/Off switch with indicator light
Split water lines
CSD-1 secondary low water cut off
STANDARD FEATURES
Deck mount hot and cold faucet with riser
3"(76mm) deep sinks with splash guard and grates
Standard voltage options
208 VAC, 3 phase, 60 Hz
208 VAC, 1 phase, 60 Hz (24kW only)
240 VAC, 3 phase, 60 Hz
240 VAC, 1 phase, 60 Hz (24kW only)
Startup inspection service by factory autorized service agent
One year parts and labor warranty*
* For all international markets, contact your local distributor
BLODGETT
www.blodgett.com
44 Lakeside Avenue, Burlington, VT 05401 • Toll Free: [phone] • Phone: [phone] • Fax: [phone]
OPTIONS AND ACCESSORIES
(AT ADDITIONAL CHARGE)
Voltage Options
220 VAC, 3 phase, 60 Hz
380 VAC, 3 phase, 60 Hz
415 VAC, 3 phase, 60 Hz
480 VAC, 3 phase, 60 Hz
415/240 VAC, 3 phase, 4 wire
380/220 VAC, 3 phase, 4 wire
600 VAC, 3 phase, 60 Hz
Increased Rating Options
36 kW
42 kW
48 kW
Etched kettle markings
Gallon markings
Litre markings
Correctional package
Pressure reducing valve
Stainless steel back panel
Steam take off kit
Water in “Y” strainer
Ball float trap
Pour lip strainer
One piece stainless steel lift off cover
Lift out perforated basket
Graduated measuring strip
One year extended warranty
CB24E-K
One Direct Steam Kettle
on a 24” Electric Boiler Base
CB24E-K ELECTRIC BOILER BASE WITH KETTLE

BLODGETT
www.blodgett.com
44 Lakeside Avenue, Burlington, VT 05401 • Toll Free: [phone] • Phone: [phone] • Fax: [phone]
CB24E-K
SHORT FORM SPECIFICATIONS
Provide Blodgett model CB24E-6K, one 6 gallon direct steam kettle on a 24” wide electric boiler base, CB24E-10K, one 10 gallon direct steam kettle on a 24” wide electric boiler base.
The kettle shall have a double wall interior to form a steam jacket around the lower 2/3 of the kettle. The bottom of the kettle shall be of hemispherical design for superior heat circulation.
Steam control valve mounted in leg. The tubular stainless steel mounting legs shall have the steam supply and condensate return pipes completely concealed within the leg memebers.
The sealed stainless steel tilt mechanism bearings shall permit the kettle to tilt forward 90° for complete emptying. A removeable operating handle with heat proof knob shall be mounted
on the left or right. Unit shall have a single support leg with nylon insert. Construction shall be all welded satin finish 304 stainless steel with a 316 stainless steel liner.
The boiler shall be 24 kW, 24” wide electric steam boiler cabinet. Polished stainless steel cabinet base shall be of modular design to match other Blodgett steam equipment. Unit shall
have 6” (152mm) stainless steel legs, adjustable bullet feet on front and adjustable flanged feet on rear, reinforced stainless steel counter top and hinged door with magnetic latch. All pip-
ing shall be confined within the cabinet. Unit shall be automatically filled with water and brought to pressure when power switch is turned on. Cold water condenser shall automatically
condense exhausted steam in water before releasing it to drain. Boiler controls shall include automatic water level, pressure gauge, water gauge glass, pressure control with pressure
safety control, safety relief valve, cathodic protector and CSD-1 secondary low water cut off.
Unit shall have a hot and cold water faucet with control valves, 3" (76 mm) deep sink with drain and splash guard.
Kettles and boiler shall be ASME code stamped and National Board registered. Provide options and accessories as indicated.
Printed in U.S.A. NOTE: FOR COMMERCIAL USE ONLY
NOTE: The company reserves the right to make
substitutions of components without prior notice.
DIMENSIONS
ABCMODEL UNITS
CB24E-6K
CB24E-10K
inches
mm
inches
mm
12
305
16
406
14.5
368
15
381
66.13
1680
65.13
1654
S
C
D
Field wire electrical connection to be as specified
on rating plate.
DRAIN: 2” IPS piped to open floor drain. No solid
STEAM TAKE-OFF CONNECTION: 3/4” IPS optional to
operate adjacent equipment
COLD WATER: condensing drain and water faucet, 3/8"
O.D. tubing at 25-50 PSI (170-345 kPa)
GENERATOR WATER:
)
3/8" O.D.
tubing at 25-50 PSI (170-345 kPa
HOT WATER:
)
3/8" O.D. tubing at 25-50
PSI (170-345 kPa
G
NOTE: SPLASH GUARD NOT SHOWN ON FRONT VIEW
DIMENSIONS ARE IN INCHES [MM]
REAR FLANGED
FOOT DETAIL
7/16" [11mm] HOLES
ON 2.5 [63] B.C.
2 EQUALLY SPACED
Ø
SH
C
D
G
ØA
B
6 [152]
5.75 [146]
6 [152]
8.75 [222]
23 [584]
32 [813]
C
28.87 [733]
H
D
C
S
H
G
33 [838]
24 [610]
12
[305]
9 [229]
10.5
[267]
2.5
[64]
11.12
[283]
3.38 [86]
29.25 [743]
2.75 [70]
5 [127]
8.75 2227]
3.5 [89]
APPROVAL/STAMP
P/N S00093 Rev C (5/06)
WATER SUPPLY:
Water quality is a major factor affecting the performance of your steamer. If you are
unsure of water quality, consult a local water treatment specialist and have the water
analyzed. Your water supply must be within these general guidelines:
Total dissolved solids: Less than 60 PPM Total alkalinity: Less than 20 PPM
Silica: Less than 13 PPM Chlorine: Less than 1.5 PPM
pH Factor: 7.0 - 8.5
Water which fails to meet these standards should be treated by installation of a water
conditioner. Failure or malfunction of this steamer due to poor water quality is not cov-
ered under warranty.
WATER & DRAIN CONNECTIONS:
Drain 2” (51mm) IPS piped to open floor drain. No solid connection.
24” length before open air opening (no bends or elbows)
Cold Water 3/8” (10mm) tubing at 25-50 PSI (170-345 kPa)
Steam Take Off 3/4” IPS optional to operate adjacent equipment
SHIPPING INFORMATION:
Approx. Weight:
CB24E-6K 450 lbs. (204 kg)
CB24E-10K 470 lbs. (213 kg)
ELECTRICAL CHARACTERISTICS
kW PH
AMPS PER LINE
208V 220V 240V 380V 415V 480V 600V
24 1 115.4 109.1 100 n/a n/a n/a n/a
3 66.6 63 57.7 36.5 33.4 28.9 23.1
36 3 99.9 94.5 86.6 54.7 50.1 43.3 34.6
42 3 116.6 110.2 101 63.8 58.4 50.5 40.5
48 3 n/a n/a 115.5 72.9 66.8 57.7 46.2
