Project
Item No.
Quantity
Model KTT-6E - 6 gallon (23 litres) electric tilting kettle
Model KTT-10E - 10 gallon (38 litres) electric tilting kettle
Model KTT-12E - 12 gallon (45 litres) electric tilting kettle
CONSTRUCTION
Water resistant construction
304 stainless steel construction
316 stainless steel interior cooking surface for added corrosion
resistance
2/3 jacketed with factory sealed distilled water enclosure
Hemispherical design on bottom of kettle for superior heat circulation
Stainless steel control housing
Concealed mounting lugs for bolting unit to counter top
OPERATION
Electrically self-generated closed steam system
Integrally mounted controls
Power switch
Thermostat
Cook indicator light
Pressure gauge
Safety valve
Low water light
Low water shut off
165-285°F (75-140°C) temperature range
STANDARD FEATURES
Removable elements
Removable operating handle with heat proof knob
“Clean Lock” holds kettle in cooking position or 105° for ease of
cleaning
Manual control
Mounts to countertop (optional stand available)
Stainless steel faucet bracket
Standard voltage options
208 VAC, 1 or 3 phase, 60 hz
240 VAC, 1 or 3 phase, 60 hz
One year parts and labor warranty*
* For all international markets, contact your local distributor.
BLODGETT
44 Lakeside Avenue, Burlington, VT 05401
Toll Free: [phone] • Phone: [phone] • Fax: [phone]
OPTIONS AND ACCESSORIES
(AT ADDITIONAL CHARGE)
Voltage options
220 VAC, 1 phase, 60 hz
220 VAC, 3 phase, 60 hz
380 VAC, 3 phase, 60 hz
415 VAC, 3 phase, 60 hz
480 VAC, 3 phase, 60 hz
415/240 VAC, 3 phase, 4 wire, 60 hz
380/220 VAC, 3 phase, 4 wire, 60 hz
600 VAC, 3 phase, 60 hz
Faucets
Single pantry faucet with swing spout
Double pantry faucet with swing spout
Etched markings
Gallons
Litres
18” (46 mm) high stainless steel stand with sliding
drawer and stationary drain
One piece stainless steel lift off cover
Stainless steel perforated basket
Graduated measuring strip
Pour strainer
KTT-E
Electric Table Top Tilting Kettle
KTT-E TABLE TOP TILTING KETTLE
KTT-10E shown

BLODGETT
44 Lakeside Avenue, Burlington, VT 05401
Toll Free: [phone] • Phone: [phone] • Fax: [phone]
KTT-E TABLE TOP TILTING KETTLE
SHORT FORM SPECIFICATIONS
Provide Blodgett model KTT-6E (6 gallon), KTT-10E (10 gallon), or KTT-12E (12 gallon) electrically heated counter tilting kettle. The unit shall have a double wall interior to form a steam
jacket around the lower 2/3 of the kettle. The jacket enclosure shall contain distilled water which is factory sealed. The bottom of the kettle shall be of hemispherical design for superior
heat circulation. The unit base shall include the kettle mounting lugs condealed inside a rectangular enslosure and a stainless steel mechanism housing. The unit shall have a removable
operating handle with heat proof knob mounted on the right. Construction shall be of all welded satin finish 304 stainless steel. The interior cooking surface shall be 316 stainless steel.
The controls shall be integrally mounted, water resistant, and shall include a power switch, thermostat with range of 165-285°F (75-140°C), a cook indicator light, pressure gauge, safe-
ty valve, low water light and low water shut off. Unit shall be ASME constructed and National Board registered. Provide options and accessories as indicated.
MAXIMUM INPUT:
KTT-6E 7.5 kW
KTT-10E 12 kW
KTT-12E 12 kW
POWER CONNECTION:
Refer to data plate.
Printed in U.S.A. NOTE: FOR COMMERCIAL USE ONLY
NOTE: The company reserves the right to make substitutions of components without prior notice.
APPROVAL/STAMP
P/N S00011 Rev E (12/06)
MAXIMUM PRESSURE:
All models 50 PSI (345 kPa)
SHIPPING INFORMATION:
Approx. Weight:
KTT-6E 155 lbs. (70 kg)
KTT-10E 205 lbs. (93 kg)
KTT-12E 220 lbs. (100 kg)
MODEL A B C D E F G H J K L
KTT-6E 12[305] 14.38[365] 24[610] 33.5[851] 15.25[387] 22.25[565] 4.5[114] 27[686] 4.25[108] 12.38[314] 10[254]
KTT-10E 16[406] 15[381] 26[660] 34.88[886] 17.25[438] 26.25[667] 4.62[117] 28[711] 6.12[156] 14.75[375] 12.75[324]
KTT-12E 16[406] 17[432] 28[711] 36.88[937] 17.25[438] 26.25[667] 4.12[105] 30[762] 6.12[156] 14.75[375] 12.75[324]
AMPS PER LINE
KW PHASE 208V 220V 240V 380V 415V 480V
7.5 1 36.0 34.1 31.3 N/A N/A N/A
3 20.8 19.7 18.1 11.4 10.4 9.0
12 1 57.6 54.6 50.0 N/A N/A N/A
3 33.3 31.5 28.9 18.3 16.7 14.5
