Blodgett KLS-30E User guide

Project
Item No.
Quantity
Model KLS-30E - 30 gallon (114 litres) electric tri-leg stationary kettle
CONSTRUCTION
304 stainless steel construction
316 stainless steel liner
2/3 jacketed with factory sealed distilled water enclosure
Hemispherical design on bottom of kettle for superior heat circulation
Three stainless steel legs fitted with four hole adjustable flanged feet for
securing to floor
Stainless steel control housing
Removable elements
OPERATION
Electrically self-generated closed steam system
Integrally mounted controls
Power switch
Thermostat
Cook indicator light
Pressure gauge
Safety valve
Low water light
Low water shut off
165-285°F (74-140°C) temperature range
STANDARD FEATURES
Manual control
2” tangent draw off
Hinged cover
Perforated strainer disc for draw off
Stainless steel faucet bracket
Standard voltage options
208 VAC, 3 phase, 60 Hz
240 VAC, 3 phase, 60 Hz
208 VAC, 1 phase, 60 Hz
240 VAC, 1 phase, 60 Hz
Eighteen months parts and labor warranty*
* For all international markets, contact your local distributor.
BLODGETT
44 Lakeside Avenue, Burlington, VT 05401
Toll Free: [phone] • Phone: [phone] • Fax: [phone]
OPTIONS AND ACCESSORIES
(AT ADDITIONAL CHARGE)
Voltage options
220 VAC, 1 phase, 50/60 Hz
220 VAC, 3 phase, 50/60 Hz
380 VAC, 3 phase, 50/60 Hz
415 VAC, 3 phase, 50/60 Hz
480 VAC, 3 phase, 50/60 Hz
220/380 VAC, 3 phase, 4 wire
240/415 VAC, 3 phase, 4 wire
600 VAC, 3 phase, 60 Hz
Faucets
Single pantry faucet with swing spout
Double pantry faucet with swing spout
Covers
Spring assist hinged stainless steel cover
Draw Off valves and accessories
3” (76mm) draw off valve
2” (50mm) dairy valve
3” (76mm) dairy valve
Etched markings
Gallons
Litres
Correctional package
Tri-basket assembly
Graduated measuring strip
Strainer hook
KLS-30E
Electric Tri-Leg Stationary Kettle
KLS-30E TRI-LEG STATIONARY KETTLE

BLODGETT
44 Lakeside Avenue, Burlington, VT 05401
Toll Free: [phone] • Phone: [phone] • Fax: [phone]
KLS-30E TRI-LEG STATIONARY KETTLE
SHORT FORM SPECIFICATIONS
Provide Blodgett model KLS-30E (30 gallon) electrically heated tri-leg stationary kettle. The unit shall have a double wall interior to form a steam jacket around the lower 2/3 of the kettle.
The jacket enclosure shall contain distilled water which is factory sealed. The bottom of the kettle shall be of hemispherical design for superior heat circulation. The kettle shall be sup-
ported on stainless steel legs fitted with 4 hole adjustable flanged feet for securing to floor. Construction shall be of all welded satin finish 304 stainless steel. The interior shall be stain-
less steel type 316 for high acid content cooking. The controls shall be integrally mounted and shall include a power switch, thermostat with range of 165-285°F (74-140°C), a cook indi-
cator light, pressure gauge, safety valve, low water light and low water shut off. The elements shall be removable. Unit shall have a 2” draw off valve. Unit shall have hinged, stainless
steel domed cover. Unit shall be ASME code stamped and National Board registered. Provide options and accessories as indicated.
MAXIMUM INPUT:
KLS-30E 15 kW
POWER CONNECTION:
208VAC 1 phase 60 Hz 72.1 amps
220VAC 1 phase 60 Hz 68.2 amps
240VAC 1 phase 60 Hz 62.5 amps
208VAC 3 phase 60 Hz 41.7 amps
220VAC 3 phase 60 Hz 39.4 amps
240VAC 3 phase 60 Hz 36.1 amps
480VAC 3 phase 60 Hz 18.0 amps
Printed in U.S.A. NOTE: FOR COMMERCIAL USE ONLY
NOTE: The company reserves the right to make substitutions of components without prior notice.
APPROVAL/STAMP
P/N S00074 Rev B (9/04)
MAXIMUM PRESSURE:
KLS-30E 50 PSI (345 kPa)
SHIPPING INFORMATION:
Approx. Weight:
KLS-30E 190 lbs. (86 kg)
