Bloomengine B100KHB User manual

User Guide
■ Main Unit
Product Name
Model Name
Operation Modes
Power Consumption
Water Tank Capacity
Dimensions
Weight
Usage Environment
Alert Function
Bloomengine Vision / Bloomengine Color
B100KHB / B100KHC
Manual, Auto Modes
1w~14w
Max. 40oz / 1.2L
W 8.3 × D 8.3 × H 13.4 (inch)
29lb / 1.3kg (tank empty)
For indoor use only, For use in the US
Water level alert
■ AC Adaptor
Rated Input Voltage
Rated Frequency
Rated Output Voltage
Cord Length
AC100~240V
50/60Hz
DC12V
Approx. 47inch
Specification
1. Download the Bloomengine App.
If you have it already, please update the App.
2. Launch the app to pair with Bloomengine.
3. Please permit all access settings to ensure
you can use every function of the App.
※ When the pairing is complete, you can control
lighting and pump settings.
Before Use
■ Get the App
Before Use
Specification
Package Contents
Names of Parts
Preparation
Watering
Repotting
Operating Modes
For Your Safety
If Problems Occurs
Warranty
Quality Warranty
1
1
2
2
3
4
4
5
6
8
9
10
1. You need to activate the Wi-Fi function of
your smartphone for interworking.
■ Pairing
App Store
Download on the
Google Play
Get it on
Contents
1
Rated Secondary
Current 2A
※ Please use only the included adapter.
B100KHB / B100KHC
(Vision) (Color)

● Control Panel
Front
Seed Package Contents
Compressed
Soil Seeds Liquid
Fertilizer
1
Caution :
The safety instructions are part of the product. Before using the product, be sure to read the instructions
and safety instructions carefully. Please keep this manual in a convenient place for future reference.
※ Seed package can be purchased separately in the future. Please check at www.bloomengine.net
(The types and designs of the package components are subject to change without notice.)
Package Content
Names of Parts
Main Unit AC Adaptor Quick Manual Seed Package
● Water Drainage
2
● Window
5
● Main Cable
10
● Cable Connection
11
● Tray
7
● Water Tank
8
● Pot
6
● Full HD Camera
(Bloomengine
Vision Only)
3
● Light Source
(LED, RGB LED)
4
● Water Outlet
9● Power Connection
12
Rear
2
© 2019 Bloomengine Inc. All Rights Reserved
사용설명서
用戶手冊
ユーザ ーマ ニュアル
User Guide
Guía del usuario
B100KHB / B100KHC
(Vision) (Color)
B100KHB / B100KHC

1. Separate the body and window
part for preparation.
4. Put the compressed soil in a
plate with water and wait for a
while(10-15min).
5. Insert the soil which will
absorb the water and expand
in the Bloomengine.
2. Connect the adapter plug to
the main unit.
3. Pour 1 liter of water and liquid
fertilizer slowly into the pot.
6. Flatten the top of the soil
with your finger.
10~15 mins
Preparation
7. Place 2~3 seeds from the
capsules on the soil and
cover them slightly.
8. Put the window on the main
body and connect the main
cable to the socket.
※ Depending on the type of seeds germination rate and indoor environment, the seeds might not bud.
(We recommend using at room temperature 30 degrees or less.)
3

※ After repotting flowers, you can go back to 'Preparation' and grow new plants.
4
1. Depending on the type of
seeds germination rate and
indoor environment, the
seeds might not bud. (We
recommend using at room
temperature 30 degrees or
less.)
2. When the red light appears
for water shortage alert is
on, pour water of about
25oz on the top until the
light changes to green.
Watering
1. When it’s bloom
successfully, and if your
flower is over a certain
size, you have work on
repotting.
2. Open the window and remove
the tray and arrange the roots
of the flowers.
※ CAUTION: Always unplug
the main cable before opening
the window.
3. Carefully hold the stem
of the plant and remove
it with the compressed
soil.
4. Please plant the flower to a
bigger pot.
※ Generally, it takes 3~6
months to plant new seeds. It
may vary due to plant type and
indoor conditions.
Repotting

Manual Mode Button
Water Level Indicator
Auto Mode Indicator
(Indicator Only)
"It is able to control Bloomengine manually without connecting to
smartphone app."
When you turn on the power by touching the button, the LED lights up and
automatically turns off after 10 hours.The pump operates automatically
while the LED light is on. ※ Turning on the manual power turns off after 10
hours, then on and off at the same time from the next day. (Operation time
may be slightly faster or slower due to circuit structure.)
Displays the status of water stored in the water tank. Bloomengine is made
to control the right amount of water needed to grow the plant. When the
red light appears, please supply enough amount of water.
※ CAUTION: If the water shortage indicator lights up for a long time, it may
cause the plant to die or malfunction.
(There may be some difference depending on the user environment)
"It lights when connected to Bloomengine smartphone app."
You can set the lighting of Bloomengine automatically. In this case, the
lighting will automatically turn on depends on the day/night, and the
detailed settings of lighting on/off and pump operation can be set in the
smartphone application. ※ Detailed menu and functions of Application can
be checked on the smartphone after installation.
Enough
(21~80%)
Shortage
(Less than 20%)
Flashing
Excessive
(81~100%)
FlashingLight on
Operating Modes
5
“You can adjust the lighting color to your preference.”
Detailed settings can be set in the smartphone application.
"It is able to check your plants in real time."
The integrated Full HD camera shows your plant's real-time
status by capturing a photo. You can select the time-lapse
function to record the unbelievable moments of your plant
growing during each stage.
Colored mood light
(Bloomengine Color & Vison
Both Available)
Built-in Full HD Camera
(Bloomengine Vision Only)
Only available in applications

1. If you continue to pour water even after green blinking (80% or
more) during water supply, water may flow out to the water outlet.
2. Be careful not to let an excessive amount of water (more than 30oz)
at the same time when watering. There is a risk of malfunction.
3. Use only tap water to prevent malfunction. Do not use the following
types of liquid. Doing so damages the product: Hot water over 40
degrees as well as water that contains chemicals, fragrance, well
water, aroma oil, detergent or alkaline ionized water.
4. Place it in a proper position to prevent it from falling over by your
pets.
5. Place the product on a flat, stable surface so that it will not fall over.
6. When moving the unit, be careful not to overflow the water.
7. Do not lift the top of the main unit during operation. It may cause
malfunction.
8. Do not place objects on top of the unit. This may result in damage to
the product.
9. Do not pull on the AC adapter cord. Damage to the cord may cause
electric shock or short circuit.
10. Do not use on carpets or in an unstable place. If it falls, water may
flow and cause electric shock or fire.
11. Be careful not to cover the ventilation openings with curtains or the
like covering the product. It may cause malfunction or breakdown.
12. Do not use under a table or desk. Air circulation may not be smooth.
13. If any abnormality occurs, discontinue use and ask for an inspection.
Please contact the place of purchase or the Bloom Engine Customer
Service Center for inspection requests.
For Your Safety
■ Safety Precautions
6

1. This product is designed for use in the USA only. Do not use overseas.
2. Push the AC adapter firmly to the end. There is a danger of electric shock, short circuit or fire.
3. Do not use the product outside of 100 to 240V AC. There is a risk of malfunction or fire.
4. Do not use any other AC adapter. Doing so may cause malfunction or fire.
5. If the product falls, discontinue use, unplug the AC adapter from the wall outlet, and have it checked.
Please contact the place of purchase or the Bloomengine Customer Service Center for inspection
requests.
6. Do not pull or connect the AC adapter with wet hands. There is a danger of electric shock or injury.
7. Be sure to turn off the power when you throw away water. If you turn off the power without shutting
off the power supply, water may get inside the unit, causing a malfunction or electric shock.
8. Do not allow children to use the product on their own, and use it in a place out of the reach of children.
There is a risk of injury or electric shock.
9. Be careful not to use children's toys for windows or trays. There is a risk of unexpected injury.
10. When raising indoors such as dogs or cats, be careful not to let your pet bite off this product or the
power cord. It may cause fire or breakdown.
11. Do not disassemble or modify it. It may cause malfunction or fire.
12. Do not insert needles or clips into the water supply. There is a danger of electric shock.
13. Do not place objects on the unit or sit on the unit. There is a risk of falling and injuries.
14. When moving the unit, unplug the AC adapter from the wall outlet and move it so that it does not
overflow.
15. Do not use on carpets or in an unstable place. If it falls, water may flow and cause electric shock or fire.
16. Do not install near any appliances such as TVs or heating appliances. If water falls on the product, it
may cause a fire or electric shock.
For Your Safety
■ Caution
7

If Problems Occur
■ Troubleshooting
2-1) This is not a fault. It works automatically at a set time.
▶ The pump will work intermittently to provide adequate moisture for the plant. If this is not a
malfunction, but the pump does not stop working or does not work, contact the Bloomengine
Customer Support Center.
2. The pump works all the sudden.
3-1) This is not a fault. The power of the fan is automatically activated so that the plant can breathe.
▶ The fan will run while the power is connected to the plant for the growth and growth of the
plant. However, if the fan noise is too loud, please contact the Bloomengine Customer Support
Center.
3. Fan turns off.
1-1) Is the AC adapter connected to the wall outlet correctly?
▶ Connect the AC adapter correctly to the wall outlet.
1-2) Is the AC adapter plug properly connected to the main unit?
▶ Connect the AC adapter plug correctly to the main unit.
1-3) Is the earth leakage breaker at the place of use turned down?
▶ Please check the electric facilities such as the earth leakage breaker at the place of use.
1-4) Is the connection cable properly connected to the cable socket?
▶ Connect the connection cable correctly to the cable socket.
1-5) If it’s on auto mode, is it the time when lighting will not operate?
▶ If you want to change the LED status, touch the manual button or cancel the auto mode in the
app and change to the manual mode.
1. LED does not turn on.
8

Warranty
■ Warrenty and After-Sales Service
For more information on repair, handling and maintenance, or if you have any further questions, please
ontact the Bloomengine Customer Support Center.
■ Handling of Personal Information
1. Please make sure that the "Warranty Period" is written on the warranty card.
2. The warranty period is one year from the date of purchase. If you need to repair the product, please
contact the Bloomengine customer support center. The product will be repaired under the conditions
specified in the warranty.
3. If you need to repair the product after the expiration of the warranty period, please contact the
Bloomengine Customer Support Center. If repair is possible and the function of the product is restor-
able, we will repair the product for you at your request.
4. The maintenance period of repair parts for this product is 5 years after the product is discontinued.
Repair parts are the parts necessary to maintain the functions of this product.
5. In case of malfunction, attempting to disassemble or repair the product yourself is very dangerous.
Never attempt to disassemble or repair the product yourself.
6. Consumables (such as seeds) included with this product are not covered by the warranty.
1.󰼿Bloomengine Inc. (hereinafter “Bloomengine”) may use personal information for customer service and
repairs, and may keep a record of the inquiries.
2. Bloomengine will not disclose personal information to third parties, except in the following cases:
2-1) When repairs or confirmation of repairs is entrusted to third parties.
2-2) In cases pursuant to the provisions of laws and regulations.
3. For inquiries on personal information, please contact the Bloomengine Customer Support Center.
■ Correct Disposal of this Product
When disposing of this product, please classify it as [Electric, Electronic appliances] and recycle it.The
materials used in this product are recyclable materials.
ㅤㅤㅤㅤ* Product
ㅤㅤㅤㅤDispose of this product at the time of disposal.
ㅤㅤㅤㅤ* Packaging material
ㅤㅤㅤㅤPackaging materials are recyclable. Please separate and dispose at the time of disposal.
■ Bloomengine Customer Support Center
[email protected]
9

Quality Warranty
Product Name
Model Name
Product Serial Number
Date of Purchase
Place of Purchase
Warranty Period
Bloomengine Vision / Bloomengine Color
B100KHB (Vision) / B100KHC (Color)
1 year from date of purchase
Company Name
Address
E-mail
Tel.
Bloomengine Inc.
(01849) #302 Seoul Startup Didimteo, Dongil-ro-174-gil 27, Nowon-gu SEOUL KOREA
[email protected]
[phone]
※ Please fill in the blank space when purchasing the product.
■ Service Regulation
1.󰼿If defects are discovered within the warranty period, we will pay for replacement and transportation
costs. (In case of transportation, please follow our instructions.
2. In the case of damage or breakdown of the product by the customer, repair and transportation costs
may be charged.
3. Please contact our customer center for any damage or defect that occurs during transportation. (Please
contact us for damage/defects during transportation within 15 days after receipt of the product.
■ Exchange, Return / Refund
1. Order cancellation, return, and refund is not available for custom-made items.
2. No return or refund will be made if genuine product modification or other work is done by the user
without prior consultation with the head office.
3. You will be charged for the cancellation of your order within 7 days of receipt. (If the product is older
than 7 days after receipt, it can not be exchanged or refunded.)
■ Case of refund or exchange is not available
1. If the product is lost or damaged due to your own responsibility (except when you have damaged the
packaging etc. to check the contents of the product)
2. If the value of the product is significantly reduced by your use or consumption.
3. If the value of the product is significantly reduced to the point where resale is difficult due to the pas-
sage of time.
■ Setting the warranty period
Warranty period can be applied for one year (12 months) from the date of purchase of the product. (War-
ranty period is not applied when lost warranty.) After the warranty period, repair and shipping costs may
be charged.
10
※ The contents of this manual may be changed in part or in whole without prior notice.

Quality Warranty
FCC Information
This device complies with part 15 of the FCC Results. Operation is subject to the following two
conditions :
(1) This Device may not cause harmful interface, and
(2) This device must accept any interference received, including interference that
may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for CLASS B digital
device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try
correct the interference by one or more of the following measures:
1.1. Reorient or relocate the receiving antenna.
1.2. Increase the separation between the equipment and receiver.
1.3. Connect the equipment into an outlet on a circuit different from that to which receiver is
connected.
1.4. Consult the dealer or experienced radio/TV technician for help.
WARNING
Changes or modifications not expressly approved by the manufacturer could void the user’s
authority to operate the equipment.
IMPORTANT NOTE:
FCC RF Radiation Exposure Statement:
This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with a minimum distance of 20
centimeters between the radiator and your body. This transmitter must not be co-located or
operating in conjunction with any other antenna or transmitter.
11
