Blue Seal turbofan E26 User manual

-1-
Revision 6/F3503
© Moffat Ltd, April 2005E26 Convection Oven
SERVICE
MANUAL
E26 CONVECTION OVEN

-2-
Revision 6/F3503
© Moffat Ltd, April 2005E26 Convection Oven
WARNING: ALL INSTALLATION AND SERVICE REPAIR WORK MUST BE CARRIED
OUT BY QUALIFIED PERSONS ONLY.

-3-
Revision 6/F3503
© Moffat Ltd, April 2005E26 Convection Oven
CONTENTS
This manual is designed to take a more in depth look at the E26 convection oven for the purpose of
making the unit more understandable to service people.
There are settings explained in this manual that should never require to be adjusted, but for
completeness and those special cases where these settings are required to change, this manual
gives a full explanation as to how, and what effects will result.
SECTION PAGENO.
1. SPECIFICATIONS......................................................................................................... 5
2. INSTALLATION ............................................................................................................ 7
3. OPERATION.................................................................................................................. 8
3.1 Description of Controls
3.2 Explanation of Control System
4. MAINTENANCE............................................................................................................. 10
4.1 Cleaning
4.2 Routine Procedures
5. TROUBLE SHOOTING GUIDE..................................................................................... 11
6. SERVICE PROCEDURES............................................................................................. 13
6.1 Fault Diagnosis
6.2 Access
6.3 Replacement
6.4 Adjustment / Calibration
7. ELECTRICAL SCHEMATIC.......................................................................................... 23
8. ELECTRICAL WIRING DIAGRAM................................................................................ 24
9. SPARE PARTS.............................................................................................................. 26
10. ACCESSORIES / OPTIONS.......................................................................................... 27
IMPORTANT: MAKING ALTERATIONS MAY VOID WARRANTIES AND APPROVALS.

-4-
Revision 6/F3503
© Moffat Ltd, April 2005E26 Convection Oven
11. PARTS DIAGRAM ........................................................................................................ 28
11.1 Main Assembly
11.2 Control Panel Assembly
12. SERVICE CONTACTS.................................................................................................. 31
APPENDIX A. DOUBLE STACKING KIT.............................................................................. 33

-5-
Revision 6/F3503
© Moffat Ltd, April 2005E26 Convection Oven
179 395
668
430
1
45
E
1E
120
791
885
1E
FRONT
PLAN
SIDE
1. SPECIFICATIONS
MODEL: E26
LEGEND
- Electrical connection entry point
Dimensions shown in millimetres.
Dimensions in inches shown in brackets.
885
(34.9)
179
(7.0)
430
(16.9)
45
(1.75)
395
(15.5)
124
(4.9)
791
(31.1)
668
(26.3)

-6-
Revision 6/F3503
© Moffat Ltd, April 2005E26 Convection Oven
LOCATION
To ensure correct ventilation for the motor and
controls the following minimum installation
clearances are to be adhered to:
Top 200mm / 8”
Rear 25mm / 1”
Left-hand side 25mm / 1”
Right-hand side 25mm / 1”
OVEN INTERNAL DIMENSIONS
Width 635 mm / 25”
Height 270 mm /10.5”
Depth 500 mm / 19.5”
Oven Volume 0.14 m³ / 5.0ft³
OVEN RACK SIZE
Width 600 mm
Depth: 400 mm
ELECTRICAL SUPPLY SPECIFICATION
OPTIONS
220Vac, 50/60Hz, 11A, 2.4kW @ 220V
230-240Vac, 50Hz, 10A, 2.4kW @ 240V
ELECTRICAL PLUG SPECIFICATION
REQUIREMENTS
Australia 3-pin 250V 10A, AS/NZ 3112
New Zealand 3-pin 250V 10A, AS/NZ 3112
United Kingdom 3-pin 250V 13A fused, BS
1363A
Other Countries 3-pin 250V 10A minimum, type
to meet country standards

-7-
Revision 6/F3503
© Moffat Ltd, April 2005E26 Convection Oven
RATING PLATE LOCATION
The rating plate for the E26 convection oven
is located at the bottom left corner of the RH
side panel.
It is most important that the oven is installed
correctly and that the operation is correct
before use. Installation shall comply with local
electrical, health and safety requirements.
BEFORE CONNECTION TO POWER
SUPPLY
Unpack and check unit for damage and report
any damage to the carrier and dealer. Report
any deficiencies to your dealer. Check that
the available power supply is correct to that
shown on the rating plate located on the right-
hand side panel.
E26
220Vac, 50/60Hz, 11A, 2.4kW @ 220V
230-240Vac, 50Hz, 10A, 2.4kW @ 240V
LOCATION
To ensure correct ventilation for the motor,
and controls the following minimum
installation clearances are to be adhered to:
Top 200mm / 8”
Rear 25mm / 1”
Left-hand side 25mm / 1”
Right-hand side 25mm / 1”
2. INSTALLATION
WARNING: THIS APPLIANCE MUST BE GROUNDED.
ELECTRICAL CONNECTION
E26 convection ovens are supplied with
pre-fitted cords. Ensure unit is fitted with the
correct cord and plug for the installation.
Refer specifications section.
Should changing of the cord be necessary,
gain access to the electrical connection
terminal block, grounding lug, and strain relief
by removing the back panel (four screws).
Figure 2.1
WARNING: ALL INSTALLATION AND SERVICE REPAIR WORK MUST BE CARRIED
OUT BY QUALIFIED PERSONS ONLY.
Position the oven in its allocated working
position. Use a spirit level to ensure the oven
is level from side to side and front to back. (If
this is not carried out, uneven cooking could
occur). The feet used with bench
mounting are adjustable and will require
adjusting in levelling the unit. It should be
positioned so the operating panel and oven
shelves are easily reachable for loading and
unloading.
BEFORE USE
Operate the oven for about 1 hour at 200°C
(400°F) to remove any fumes or odours which
may be present.
IMPORTANT: THE OVEN VENT
LOCATED ON THE CABINET TOP
MUST NEVER BE OBSTRUCTED.
Rating Plate
Figure 2.2
L1 L2 Ground
Phase Neutral
RED
BROWN
BLACK GREEN/YELLOW
GREEN
WARNING: THIS APPLIANCE MUST
BE GROUNDED / EARTHED
BLACK
BLUE
WHITE

-8-
Revision 6/F3503
© Moffat Ltd, April 2005E26 Convection Oven
4
3
2
1
3.1 DESCRIPTION OF CONTROLS - E26
1. POWER
Depress to switch power on or off (switch
illuminates when power is on).
2. THERMOSTAT
Temperature range 50 - 250°C.
Light illuminates when elements are cycling
ON to maintain set temperature.
3. BAKE TIMER
1 Hour bake timer.
(Light illuminates when “time up” (0) reached,
and buzzer sounds).
4. LIGHT SWITCH
Push switch to activate light.
(Light illuminates while button depressed).
3. OPERATION
NOTE: A full user’s operation manual is supplied with the product and can be used for further
referencing of installation, operation and service.

-9-
Revision 6/F3503
© Moffat Ltd, April 2005E26 Convection Oven
3.2 EXPLANATION OF CONTROL
SYSTEM
The E26 Turbofan convection ovens feature
multi-function operator controls for which a
correct understanding of their operation is
required before carrying out any service or
fault repair work. The control device functions
are explained as follows:
A power switch on the control panel isolates
power to all the controls of the oven. With the
power switch Off all functions of the oven are
inoperable.
With the power switch On (illuminated) power
is directly supplied to the 60 minute bake
timer, door microswitch, temperature control
circuit, fan motor, and the light switch. The
light switch will turn the oven light on when the
door is closed, but only whilst the light switch
is held in.
The door microswitch on the E26 oven
controls the oven light only. Accordingly the
light will come on when the door is opened but
the circulation fan and fan element will remain
on.
The 60 minute timer is a mechanical timer and
can therefore be operated with the oven’s
power switch On or Off. However, only with
the oven’s power switch On will the switch
contacts of the 60 minute timer turn on the
time-up buzzer and illuminate the time-up
indicator on the control panel. The buzzer
and time-up indicator provide indication that
the time setting has run down to zero and at
this point will remain On continuously until the
60 minute timer has been manually set back
to the Off (vertical) position. The 60 minute
timer does not control any other part of the
oven’s operating system as this timer is
independent of the temperature control and
heating system.
The temperature control of these ovens is with
a capillary type thermostat which can be set to
a required cooking temperature.
The E26 has an element coiled around the
circulation fan in the rear of the oven. Power
to the element is provided directly from the
thermostat. The control panel indicator light
above the thermostat knob cycles on and off
with the thermostat to indicate when the
element is on and the oven is heating. In the
‘Off’ position, the element relies on the
thermostatic control to prevent it switching on.
Accordingly, if the oven temperature drops
below approximately 20°C the thermostat and
element may cycle on at this setting.
The following Troubleshooting Guide should
be used to identify any incorrect oven
operation. On correct identification of the
operating fault the Troubleshooting Guide will
make reference to the corrective action
required, or refer to the Fault Diagnosis
section and/or Service section to assist in
correction of the fault.

-10-
Revision 6/F3503
© Moffat Ltd, April 2005E26 Convection Oven
IMPORTANT: THIS UNIT IS NOT
WATER PROOF.
DO NOT USE A WATER JET SPRAY TO
CLEAN INTERIOR OR EXTERIOR OF
THIS UNIT.
WARNING: ALWAYS TURN THE
POWER SUPPLY OFF BEFORE
CLEANING.
EXTERIOR
Clean with a good quality stainless steel
cleaning compound. Harsh abrasive cleaners
may damage the surface.
INTERIOR
Ensure that the oven chamber is cool. Do not
use wire brushes, steel wool or other abrasive
materials. Clean the oven regularly with a
good quality oven cleaner. Take care not to
damage the fan or the tube at the right side of
the oven which controls the thermostat.
OVEN RACKS
To remove, slide out to the stop position, raise
the front edge up, and lift out.
BOTTOM BAFFLE
Slide forward and lift out. When replacing,
ensure tray is pushed fully in to rear of oven.
SIDE RACKS
Loosen rear thumbscrew 2-3 turns. Remove
front thumbscrew and pull rack forward to dis-
engage rear screw then lift out. Replace in
reverse order.
FAN BAFFLE
To remove, undo thumbscrew (counter-
clockwise rotation) at top of baffle and
remove. Lift baffle out from rear of oven by
tilting forward while lifting out of location studs
at baffle base. Replace in reverse order.
4. MAINTENANCE
OVEN SEALS
To remove, hold at their centre point and pull
forward until they unclip. Remove side seals
first, then top and bottom. The seals may be
washed in the sink, but take care not to cut or
damage them. To replace, ensure that the lip
is facing the oven opening. Fit the top and
bottom seals first, then the side seals.
OVEN DOOR GLASS
Clean with conventional glass cleaners
4.1 CLEANING
WARNING: ALL INSTALLATION AND SERVICE REPAIR WORK MUST BE CARRIED
OUT BY QUALIFIED PERSONS ONLY.
4.2 ROUTINE PROCEDURES
DOOR SEALS
Check for deterioration 12 months
ELEMENTS
Check that element resistances
12 months
are correct to their ratings (refer
6.3.9)

-11-
Revision 6/F3503
© Moffat Ltd, April 2005E26 Convection Oven
5. TROUBLE SHOOTING
FAULT POSSIBLE CAUSE REMEDY
THE OVEN DOES NOT
OPERATE / START
The mains isolating switch on
the wall, circuit breaker or fuses
are “off” at the power board.
The power switch on the oven is
off.
Incorrect electrical supply.
(Refer fault diagnosis 6.1.1)
Power switch on unit faulty.
(Refer fault diagnosis 6.1.1)
Turn on.
Depress switch. Switch will
illuminate.
Ensure electrical supply correct.
Replace.
(Refer service section 6.3.4)
FAN DOESN’T OPERATE Fan motor faulty.
(Refer fault diagnosis 6.1.2)
Wiring.
Replace.
(Refer service section 6.3.10)
Check and tighten any loose
wiring.
OVEN LIGHT NOT
ILLUMINATING - DOOR OPEN
OVEN LIGHT NOT
ILLUMINATING - DOOR
CLOSED
Blown bulb.
No power to light.
(Refer fault diagnosis 6.1.3)
Blown bulb.
Light switch faulty.
(Refer fault diagnosis 6.1.4)
Replace.
(Refer service section 6.3.1)
Correct fault.
Replace.
(Refer service section 6.3.1)
Replace.
(Refer service section 6.3.4)
60 MINUTE TIMER WILL NOT
TIME DOWN
60 MINUTE TIMER
INACCURATE BELOW 20
MINUTES
Timer faulty.
Timer not set correctly.
Zero (time up) position not set
correctly.
Replace.
(Refer service section 6.3.6)
For timer settings below 20
minutes, always rotate past 20
minutes, then back to desired
time.
(Refer service section 6.4.3)
60 MINUTE TIMER NO TIME
UP BUZZER
60 MINUTE TIMER NO TIME
UP INDICATOR
Buzzer faulty.
(Refer fault diagnosis 6.1.5)
Timer not switching on buzzer.
(Refer fault diagnosis 6.1.5)
Indicator faulty.
(Refer fault diagnosis 6.1.6)
Replace.
(Refer service section 6.3.5)
Replace.
(Refer service section 6.3.6)
Replace.
(Refer service section 6.3.3)
WARNING: ALL INSTALLATION AND SERVICE REPAIR WORK MUST BE CARRIED
OUT BY QUALIFIED PERSONS ONLY.

-12-
Revision 6/F3503
© Moffat Ltd, April 2005E26 Convection Oven
FAULT POSSIBLE CAUSE REMEDY
NO HEAT No power to thermostat.
(Refer fault diagnosis 6.1.7)
Thermostat faulty.
(Refer fault diagnosis 6.1.7)
Fan element faulty
(Refer fault diagnosis 6.1.10)
Identify fault and correct.
Replace.
(Refer service section 6.3.7)
Correct element fault.
(Refer Fault: Fan Element)
NO TEMPERATURE
CONTROL Thermostat faulty.
(Refer fault diagnosis 6.1.8) Replace. (Refer service section 6.3.7)
SLOW RECOVERY Overloading of oven.
Electrical supply incorrect.
Fan not working.
Thermostat calibration.
(Refer fault diagnosis 6.1.9)
Fan element not working.
Reduce oven loading.
Check supply voltage is as per
rating plate voltage.
Check fan operation.
Correct calibration.
(Refer service section 6.4.1,
6.4.2)
Correct element fault.
(Refer Fault: Fan element)
FAN ELEMENT NOT
WORKING
NO THERMOSTAT HEATING
INDICATOR LIGHT
Element faulty (blown).
(Refer fault diagnosis 6.1.10)
Indicator faulty.
(Refer fault diagnosis 6.1.11)
Replace.
(Refer service section 6.3.8)
Replace.
(Refer service section 6.3.3)
DOOR DOES NOT CLOSE Tray in way of door.
Door seal obstruction.
Door hinges worn.
Door hinge counter brackets
worn.
Correctly position tray in rack.
Correctly install door seal.
(Refer service section 6.3.13)
Replace.
(Refer service section 6.3.15)
Replace.
(Refer service section 6.3.16)
DOOR SEAL LEAKS Door seal damaged.
Door seal incorrectly fitted.
Replace.
(Refer service section 6.3.13)
Correctly install door seal.
(Refer service section 6.3.13)

-13-
Revision 6/F3503
© Moffat Ltd, April 2005E26 Convection Oven
SECTION PAGENO.
6.1 FAULT DIAGNOSIS..............................................................................................................14
6.1.1 Oven Does Not Operate / Start............................................................................14
6.1.2 Fan Does Not Operate.........................................................................................14
6.1.3 Oven Light Not Illuminating—Door Open ............................................................14
6.1.4 Oven Light Not Illuminating—Door Closed..........................................................14
6.1.5 60 Minute Timer No Time Up Buzzer ..................................................................14
6.1.6 60 Minute Timer No Time Up Indicator................................................................15
6.1.7 No Heat................................................................................................................15
6.1.8 No Temperature Control......................................................................................15
6.1.9 Slow Recovery.....................................................................................................15
6.1.10 Fan Element Not Working....................................................................................15
6.1.11 No Thermostat Heating Indicator.........................................................................15
6.2 ACCESS................................................................................................................................16
6.2.1 Control Panel.......................................................................................................16
6.2.2 Service Panel (Rear Panel) .................................................................................16
6.2.3 Baffle....................................................................................................................16
6.2.4 Control Panel (Rear)............................................................................................16
6.3 REPLACEMENT....................................................................................................................17
6.3.1 Light Bulb / Glass.................................................................................................17
6.3.2 Door Microswitch .................................................................................................17
6.3.3 Indicator Neon Light.............................................................................................17
6.3.4 Power / Light Switches.........................................................................................17
6.3.5 Buzzer..................................................................................................................17
6.3.6 Bake Timer...........................................................................................................18
6.3.7 Thermostat...........................................................................................................18
6.3.8 Element................................................................................................................18
6.3.9 Fan.......................................................................................................................18
6.3.10 Motor....................................................................................................................19
6.3.11 Outer Glass..........................................................................................................19
6.3.12 Inner Glass...........................................................................................................19
6.3.13 Door Seals ...........................................................................................................20
6.3.14 Door Handle.........................................................................................................20
6.3.15 Door Hinges.........................................................................................................20
6.3.16 Hinge Counter Brackets.......................................................................................20
6.4 ADJUSTMENT / CALIBRATION ..........................................................................................22
6.4.1 Thermostat Calibration.........................................................................................22
6.4.2 Door Microswitch Adjustment ..............................................................................22
6.4.3 60 Minute Timer Zero Position Adjustment..........................................................22
WARNING: ENSURE POWER SUPPLY IS SWITCHED OFF BEFORE SERVICING.
6. SERVICE PROCEDURES
WARNING: ALL INSTALLATION AND SERVICE REPAIR WORK MUST BE CARRIED
OUT BY QUALIFIED PERSONS ONLY.

-14-
Revision 6/F3503
© Moffat Ltd, April 2005E26 Convection Oven
6.1 FAULT DIAGNOSIS
Incorrect electrical supply
Check that the voltage across phase and
neutral (L1 and L2) terminals of terminal block
is the voltage as stated on the unit’s electrical
rating plate.
If incorrect, check electrical connection of
supply wiring and / or check electrical supply.
6.1.1 OVEN DOES NOT OPERATE / START
Power switch faulty
Check if power switch latches. If the switch
does not latch, then switch is faulty—replace.
With switch latched, check voltage across
terminal one to terminal three or four. If there
is no voltage, check for fault in wiring.
Check voltage across terminal two to terminal
three or four. If there is no voltage, then
switch is faulty—replace.
NOTE: When power switch is latched, it
should illuminate if operating
correctly.
6.1.2 FAN DOESN’T OPERATE
Fan motor faulty
Check the supply voltage across motor
terminals. If there is no voltage then check
the electrical connections of supply wiring.
If voltage is correct then check the oven fan
for free rotation. Remove any obstruction.
If fan is free to spin and the voltage supply is
correct, then the motor is faulty—replace.
6.1.3 OVEN LIGHT NOT ILLUMINATING—
DOOR OPEN
No power to light
Check the supply voltage across lamp
housing terminals at rear of oven. If the
voltage is correct, replace the bulb (if faulty).
If the bulb is OK, check lamp housing.
Replace if faulty.
If there is no voltage, open oven door and
manually depress then release door
microswitch actuator at top right of oven.
Check actuator moves freely under spring
tension of microswitch. If not, free up actuator
and adjust microswitch actuator arm as
required.
Check voltage across micro-switch terminals
to neutral.
6.1.4 OVEN LIGHT NOT ILLUMINATING—
DOOR CLOSED
Light switch faulty
Check voltage to the top terminal of the
switch. If there is no voltage, then check
wiring.
With switch depressed, check voltage at
bottom terminal. If there is no voltage, then
replace the switch.
If voltage is correct, then check wiring to light.
NOTE: Alternately, perform a continuity test
across the terminals with the light
switch depressed.
6.1.5 60 MINUTE TIMER NO TIME UP
BUZZER
Buzzer faulty
With timer in ‘zero’ position, check the buzzer
at bottom of control panel (inside) for voltage
across terminals. If voltage is correct then
buzzer is faulty—replace.
If there is no voltage, then check wiring.
Timer not switching on buzzer
With timer in zero position, check voltage to
the input and output terminal of timer. If there
is no voltage at input terminal then check
wiring.
If no voltage at output terminal then timer is
faulty—replace.
NOTE: Buzzer and time up indicator will
continue until the timer manually switched off
(to vertical position).
Buzzer
Buzzer Terminals
Figure 6.1.1
With the door closed there should be power to
the com terminal and the n.o. terminal.
With the door open there should be power to
the com terminal and the n.c. terminal.
If not, microswitch is faulty—replace.

-15-
Revision 6/F3503
© Moffat Ltd, April 2005E26 Convection Oven
6.1.7 NO HEAT
No power to thermostat
Check voltage to terminal P (top terminal) on
oven thermostat. If there is no voltage then
check wiring.
6.1.6 60 MINUTE TIMER NO TIME UP
INDICATOR
Indicator faulty
With the timer in the zero position, check for
voltage across the indicator light. If correct,
then the indicator light is faulty—replace.
If there is no voltage then check wiring.
Thermostat faulty
Set thermostat to 200°C or 400°F. Check the
voltage out of terminal 1 on the thermostat. If
there is no voltage then the thermostat is
faulty—replace.
If the voltage is correct and the heating light is
on then check all wiring to elements.
6.1.8 NO TEMPERATURE CONTROL
Thermostat faulty
With thermostat in ‘off’ position (knob vertical),
slowly turn thermostat up until heating
indicator just comes on. Wait for heating
indicator to cycle off. If indicator has not
cycled off after 10 minutes then thermostat is
faulty—replace.
NOTE: Thermostat may cycle on and off with
the knob set to the ‘off’ position if the oven
temperature is below 20°C.
6.1.9 SLOW RECOVERY
Thermostat out of calibration
Place an accurate digital thermometer probe
in centre of oven. Set thermostat to 180°C or
355°F. Close the oven door and allow oven
thermostat to cycle on and off twice. Record
oven centre temperature for the next
thermostat on and off cycle. The thermostat
should cycle on and off between 170°C and
205°C or 335°F and 400°F when set to the
above temperature. If oven temperature is
outside these ranges, then the thermostat
requires recalibration.
NOTE: Thermostat cycling span should be
±18°C or 32°F. Under no load conditions the
oven runs slightly hotter than the selected
thermostat temperature.
6.1.10 FAN ELEMENT NOT WORKING
Element faulty (blown)
With the thermostat on and heating check
voltage across fan element terminals at rear
of oven. If the voltage is correct then check
the current draw of element. If there is no
current draw then element is faulty—replace.
NOTE: Correct fan element current draw:
220-240 V: 10A ± 1.5A
Thermostat faulty
If there is no voltage to element terminals then
check voltage is being supplied to fan element
from terminal 1 on the thermostat. If no
voltage at 1 then check for voltage at terminal
P. If power to P (and none to 1), then the
thermostat is faulty—replace.
Indicator faulty
With the thermostat on and heating, check the
voltage across the indicator terminals. If the
voltage is correct then the indicator is faulty—
replace.
If there is no voltage then check wiring.
6.1.11 NO THERMOSTAT HEATING
INDICATOR

-16-
Revision 6/F3503
© Moffat Ltd, April 2005E26 Convection Oven
Four
Screws
6.2 ACCESS
6.2.1 CONTROL PANEL
1) Undo one screw at bottom of control
panel.
1) Undo the four screws holding the panel.
6.2.2 SERVICE (REAR) PANEL
1) Remove trays, racks and bottom tray.
2) Undo thumbscrew (top).
6.2.3 BAFFLE
2) Pull out bottom of control panel and drop
down to disengage tabs at top of control
panel.
Figure 6.2.1
2) Remove panel.
Figure 6.2.2
3) Remove baffle.
Figure 6.2.3
6.2.4 CONTROL PANEL—REAR
Buzzer
Power Switch
Heating Indicator
Thermostat
Bake Time Up
Indicator
Light Switch
Bake Timer
Figure 6.2.4
One Screw
Thumb
screw

-17-
Revision 6/F3503
© Moffat Ltd, April 2005E26 Convection Oven
Two Screws
6.3 REPLACEMENT
6.3.1 LIGHT BULB / GLASS
6.3.2 DOOR MICROSWITCH
1) Unscrew lamp cover.
1) Open oven door.
2) Open control panel (refer 6.2.1).
3) Remove two screws holding microswitch
to bracket.
6.3.3 INDICATOR NEON LIGHT
1) With control panel open (refer 6.2.1)
remove the wires from the back of the
neon.
6.3.4 POWER / LIGHT SWITCHES
1) With control panel open (refer 6.2.1)
remove the wires from the back of the
switch, noting their positions.
Two Screws
6.3.5 BUZZER
1) Remove control panel (refer 6.2.1).
2) Remove two screws holding buzzer to
panel.
4) Transfer wires to new buzzer.
5) Reassemble in reverse order.
Figure 6.3.5
2) Unscrew bulb out of fitting.
3) Screw in replacement bulb.
4) Replace lamp cover
Lamp
Cover
Figure 6.3.1
4) Transfer wires to new micro-switch and
re-assemble.
5) Adjust microswitch (refer 6.4.2).
Figure 6.3.2
2) From back push neon through front of
panel rotating clockwise.
3) Push new neon in from front of panel, and
reconnect wires.
2) From back push switch through front of
panel.
3) Push new switch in from front of panel,
and reconnect wires.
Neon
Wires
Switch
Wires
Figure 6.3.3
Figure 6.3.4

-18-
Revision 6/F3503
© Moffat Ltd, April 2005E26 Convection Oven
Two
Screws
Two Screws
6.3.6 BAKE TIMER
1) Remove bake timer knob by pulling it
firmly away from control panel.
2) Open control panel (refer 6.2.1) and undo
two screws securing timer.
Fan Element
3 Screws
6.3.8 ELEMENT
6.3.7 THERMOSTAT
1) Pull knob off front of thermostat.
2) Open control panel (refer 6.2.1) and undo
two screws securing thermostat.
3) Transfer wires to new timer.
4) Withdraw old timer and insert new timer,
securing with screws.
5) Replace knob.
Two Screws
Figure 6.3.6
5) Withdraw old thermostat phial through
rear of oven.
6) Insert new thermostat.
7) Re-assemble in reverse order.
3) Transfer wires to new thermostat.
4) Remove service panel (refer 6.2.2) and
from inside of oven loosen two screws
holding thermostat phial bracket.
Figure 6.3.7
Figure 6.3.8
1) With service panel and baffle removed
(refer 6.2.2 and 6.2.3) remove the wires
from the element.
2) Unscrew the element from inside the
oven.
3) Pull element carefully to remove.
4) Replace and re-assemble in reverse
order.
Figure 6.3.9
Element Ratings (at room temperature)
230-240V Fan Element 24 ohms ±5%
220V Fan Element 20 ohms ±5%
Centre Nut
6.3.9 FAN
2) Replace and reassemble in reverse order.
NOTE: Reassemble with spacer behind fan.
or
Reassemble with one washer behind
fan, and one washer in front.
Figure 6.3.10
1) With baffle removed (refer 6.2.3) undo the
centre nut.
NOTE: LH thread - Turn clockwise to loosen.
From S/N 250979 Take care with
Spacer.
Up to S/N 250978 Take care not to
lose the two washers.

-19-
Revision 6/F3503
© Moffat Ltd, April 2005E26 Convection Oven
Three Screws
6.3.11 OUTER GLASS6.3.10 MOTOR
1) Remove fan (refer 6.3.9), remove service
panel (refer 6.2.2), and then remove the
wires that go to the motor.
2) Undo the four screws holding the motor
bracket in place (from the outside) and
remove motor assembly.
3) Remove three screws holding motor to
bracket and remove motor. (fig 6.3.11)
4) Replace and re-assemble in reverse
order.
5) Ensure wire connections are correct
(fig 6.3.12 and 6.3.13)
1) Open the oven door.
2) Lock hinges into position by rotating the
hinge locking clip over the hinge locking
notch.
3) Lift door away from the oven and place on
a flat surface.
4) Undo three screws and remove the trim
from the bottom of the door. Carefully
withdraw the glass.
Figure 6.3.11
5) To replace, ensure that the three silicone
rubber seals are in place, one each side
of the door frame and one on bottom
centre. Clean the inside of the glass and
refit, ensuring that the silicone rubber
seals cover the outer edges of the glass.
Refit the bottom trim, and fit the door to
the oven.
Figure 6.3.15
Three Screws
6.3.12 INNER GLASS
1) Remove the outer glass (refer 6.3.11).
2) Undo three screws and remove the top
trim and handle assembly.
Hinge Locking Clip
Hinge Locking
Notch
Figure 6.3.14
Figure 6.3.12
Screws (4)
Phase
Terminal
Earth /
Ground
Neutral
Screws (4)
60 Hz
Terminal
50 Hz
Terminal Earth /
Ground
Neutral
Figure 6.3.13
220 - 240V Motors (from S/N 250979)
220 - 240V Motors (up to S/N 250978)

-20-
Revision 6/F3503
© Moffat Ltd, April 2005E26 Convection Oven
Two Screws
3) Uncrimp the retaining lugs of the window
spacer and remove the spacer and glass.
Retaining
Lugs
Figure 6.3.17
6.3.13 DOOR SEALS
1) Open oven door.
2) To remove, hold at their centre point and
pull forward until they unclip
3) Refit new seals.
Note: Fit top and bottom seals first, with
open side of seal facing
downwards. Fit side seals with
open side facing outwards.
Figure 6.3.16
4) To replace, ensure the silicone rubber seal
has not been displaced. Clean the glass
and refit it. Place the window spacer in
position and crimp the retaining lugs over
to hold the glass in place. Refit outer
glass as above.
Three Screws
6.3.14 DOOR HANDLE
1) Remove the door (refer 6.3.11).
2) Undo three screws and remove the top
trim and handle assembly, taking care not
to dislodge the outer glass.
3) Undo two bolts securing handle to top
trim. Replace handle and reassemble in
reverse order.
6.3.15 DOOR HINGES
1) Remove outer glass (refer 6.3.12).
2) Undo two screws securing hinge assembly
to oven door.
3) Withdraw hinge assembly and replace.
Reassemble in reverse order.
Figure 6.3.19
Two Bolts
6.3.16 HINGE COUNTER BRACKETS
1) Remove door (refer 6.3.12).
2) Remove screws from back of oven
securing wrapper to oven.
Figure 6.3.20
3) Turn oven onto its back and remove three
screws at each side securing wrapper,
and two securing insulation panel.
Figure 6.3.18
