Blueair Classic 200 series User manual

Blueair Classic 200 series
User Manual | Korisnički priručnik
English | Hrvatski

2

3
Before using Blueair Classic 200 series, please read this user manual carefully.
Contents
General 4
Overview of unit 5
Adjusting fan (air flow) speed 5
Safety information 6
Placing the unit 8
Getting started 8
Control panel and touch buttons 9
Blueair Friend mobile app settings 10
Filters 11
Changing the filters 12
Care and Maintenance 13
Classic 280i/290i/205 technical specifications 14
English
Note:
There may be local variations of this model.

4
General
Blueair 200 series
Blueair 200 series air purifiers are Wi-Fi enabled
and are available in two models. The 280i/290i
models have built-in sensors for PM2.5, VOC,
temperature/humidity, and the 205 models with
no built-in sensors.
Adjustments to the air purifiers can be made
manually anywhere and at any time, either via
the touch buttons on the control panel located
under the flip-up lid, or remotely via the Blueair
FriendTM mobile app.
The air purifier can also be automatically
regulated based on the air quality readings from
the built-in sensors (280i/290i), or the optional
external air quality monitor Blueair AwareTM (205)
For more information on how to use your air
purifier together with the Blueair Aware air
quality monitor, please see the Blueair Aware
owner’s manual and the support information.
205 model280i/290i model
Wi-Fi FILTER AUTO PM 2.5VOC
Wi-Fi
FILTER

5
2
1
3
6
10
45
9
8
7
Adjusting fan (air flow) speed
Please refer to the table below to see the dierent options available for controlling your air purifier.
Overview of unit
Maximum speed is recommended for fast initial cleaning, during the day or when the air is heavily
polluted. Minimum speed is recommended for nighttime use.
1. Control panel
2. Blue LED
3. Front cover
4. 280i/290i left view with
sensor holes
5. 205, 280i/290i right view
6. Air outlet
7. Air inlet (back view)
8. Particle filter, or
9. SmokestopTM filter
10. Welcome kit
- welcome card
- user manual
Control options 280i/290i 205
Manual control via touch buttons on control panel
Remotely via the Blueair Friend mobile app.
Automode based on air quality readings from the built in
sensors. This function may be activated either via the
touch button on the control panel or via the Blueair
Friend mobile app.
Automode based on air quality readings from the external
air quality monitor Blueair Aware. This function is
activated via the Blueair Friend mobile app.
Min Speed 1
Speed 2
Max Speed 3 Min Speed 1
Speed 2
Max Speed 3

6
Safety information
The Blueair 205 and 280i/290i air purifiers are electrical appliances. Please read the safety
instructions before use and take the necessary precautions to reduce the risk of fire, electric shock
or injury.
The Blueair Limited Warranty applies only if the unit is used according to these instructions.
WARNING: Indicates a hazardous situation that, if not avoided, could result in death or
serious injury.
CAUTION: Indicates a hazardous situation that, if not avoided, could result in minor or
moderate injury.
General
WARNING: To avoid a hazard, a damaged supply cable must always be replaced by the
manufacturer, service agent or similarly qualified person.
Use the grounded power cable provided with your Blueair air purifier unit to plug directly
into an appropriate, grounded electrical outlet. (Refer to the rating label on your unit)
Do not alter the plug in any way.
Intended use
CAUTION: Supervise children to ensure that they do not play with the appliance.
This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety.
Hereby, Blueair AB, declares that the radio equipment type YXXZ-CC is in compliance with
Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the
following internet address: www.blueair.com/customer-support

7
WARNING: Changes or modifications to this unit not expressly approved by the party responsi-
ble for compliance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications.
FCC ID: 2AEX3-2XXZ-CC
IC: 20267-205
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined
by turning the equipment o and on, the user is encouraged to try to correct the interference by one
or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit dierent from that to which the receiver
is connected.
Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
1. this device may not cause harmful interference, and
2. this device must accept any interference received, including interference that may cause
undesired operation.
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject
to thefollowing two conditions: (1) this device may not cause interference, and (2) this device must
acceptany interference, including interference that may cause undesired operation of the device.
This Class B digital apparatus complies with Canadian ICES-003.
FCC RF Radiation Exposure Statement Caution: This Transmitter must be installed to provide a
separation distance of at least 20 cm from all persons.

8
4 ins
10 cm
Place the unit in a location where air can
circulate freely in, out and around the unit.
Do not place the unit closer than 4” (10 cm)
from another object.
Do not place the unit directly on or against
soft furnishings such as bedding or linen.
Do not place the unit near sources of heat,
such as radiators, fireplaces or ovens.
Do not place the unit near wet areas, such
as bathrooms or laundry rooms where it
may come into contact with water.
Do not place the unit outdoors
Step 1
Plug the fixed power cable into a
grounded wall outlet. If you have a unit
with a removable power cable, then
plug the cable firmly and completely
into the recessed power cable socket
located at the bottom of the unit
before plugging the other end of the
power cable into a grounded wall
outlet.
Step 2
Download the Blueair Friend mobile app to your smartphone from your app store (Apple App Store
or Google Play).
Step 3
Connect your unit to your Blueair Friend mobile app. Start the app and follow the instructions.
After connecting your air purifier to the Blueair Friend mobile app, you can use the app to control
the unit remotely and adjust settings.
Getting started
Connecting your air purifier - 280i/290i and 205
Follow the instructions below to connect your air purifier to your Blueair Friend mobile app. You can
then enable remote control.
Placing the unit
FILTER
Wi-Fi
Blinking
Blinking
Wi-Fi FILTER AUTO VOC PM2.5
Open the flip-up lid and press the airflow speed touch button. When the Wi-Fi symbol starts to blink,
the air purifier can be paired with the Blueair Friend mobile app.

9
Control panel and touch buttons
The control panel and touch buttons are located under the flip-up lid (see Step 2 “Starting up the
unit”). A grey circle around a touch button indicates that it is inactive. When the unit is turned on, all
touch buttons except the air flow speed control button, dim down after 20 seconds. Tap the control
panel and the touch buttons will light up again.
Status “blinking” - no connection.
Wi-Fi ready to be connected.
Wi-Fi
Status grey - OFF (no Wi-Fi)
Air flow speed control
Status grey - OFF
Status blue and all bars are grey -
the power cable is plugged in.
Status grey and blue
Wi-Fi connected
Filter
Status grey and blue -no replacement
filter currently needed.
Status orange - replace filter and
reset by pressing down for 5 seconds.
Status 1 blue bar - minimum speed
Status 2 blue bars - medium speed
Status 3 blue bars - maximum speed
Classic 205 control panel touch buttons
Wi-Fi
FILTER

10
Blueair Friend mobile app settings
Please note that you must first add your air purifier unit to the Blueair Friend mobile app before you
can control the following settings via the app:
Adjust airflow speed
Changes the fan speed between speed 1, 2 and 3.
Adjust LED intensity
Changes the LED intensity for those lamps that are visible.
Child lock
Regulates your ability to control the air purifier unit via the control panel on the unit.
Auto mode
Automatically controls the fan speed based on readings either from the built-in sensors
(“i” models only), or from the external air quality monitor Blueair Aware.
Night mode
Allows the activation/deactivation of certain settings at specific times.
Auto speed
Status circle blue - unit is on
Status symbol grey - Auto speed OFF
Status symbol blue - Auto speed ON
PM2.5 indicator
Status blue - from excellent to
moderate pollution levels.
Status orange - from slight to high
pollution levels
VOC indicator
Status blue - from excellent to
moderate pollution levels
Status orange - from slight to high
pollution levels
Classic 280i/290i control panel touch buttons
See Blueair Friend mobile app for further information regarding pollution and threshold
levels
Wi-Fi AUTOFILTER PM 2.5 VOC

11
Filters
General information
The unit is delivered with one HEPASilentTM filter already installed.
Particle filters remove:
Carbon based filters remove all the above pollutants, plus:
SmokeVOC ChemicalsCooking
odors
IMPORTANT! Use only genuine Blueair filters to ensure proper function of your unit and to
qualify for full warranty coverage.
Blueair filter subscription program
This convenient service is available in some countries – contact your local Blueair retailer to find out
if you can join.
Model number
Serial number
Retailer’s name
Retailer’s address
Date of purchase Telephone number
Filter checklist
To make it easy to find the right filter in the future, please fill in the customer record below and keep
this user manual for reference. The model number and serial number of this product can be found
on the rating label on the bottom of the unit.
DustPM2.5 Pet danderMold Dust mitesBacteria/
Virus
Pollen

12
Changing the filters
Step 2
Remove the filter.
Step 1
Open the back door.
Step 4
Insert the
replacement Blueair
filter.
Step 3
Vacuum inside the
unit with a soft brush
attachment.
Step 5
Close the back door,
plug in the unit and
turn on.
The unit is now ready
for use.
IMPORTANT!
Always turn o and disconnect the unit from the supply mains before changing filters, cleaning
or carrying out maintenance procedures..
Status orange - replace filter and
reset by pressing down for 5 seconds.

13
Care and maintenance
We recommend routine cleaning in order to keep your unit in top condition.
When changing filters
1. Wipe clean the underside of the lid after removal.
2. Vacuum the air inlet grille from the inside using a soft brush and/or other suitable attachment.
3. Vacuum the small air inlets with a soft brush attachment.
General
1. Wipe the exterior of the unit with a soft, clean, damp cloth.
2. Never clean with gasoline, chemical solvents or corrosive material as these agents may damage
the surface.
3. Do not allow foreign objects to enter the ventilation or exhaust openings. This may cause
electric shock or damage the unit.
4. Do not try to repair or adjust any of the electrical or mechanical functions on your Blueair unit
yourself. Contact your local dealer or Blueair for warranty information.
Environment protection:
Let’s protect the environment!
Our products and packaging are sustainably designed and made from recyclable materials. Do not
discard the filter or the product with household waste. Bring it to the nearest ocial waste recycling
service.
Help and support
If you have questions about Blueair Classic series, please visit www.blueair.com or contact your local
Blueair retailer.
Warranty information
The Blueair Limited Warranty applies only if the unit is used according to the instructions in this
manual.

14
Classic 280i/290i/205 technical specifications*
CADR (cfm)**:
Room size 279 sq.ft. (26 m2)
Air Changes per Hour *** 5
Airflow (Speed 1-2-3) 75-140-220 cfm
Size (HxWxD): 21 x 17 x 9 in. (533 x 432 x 209 mm)
Product weight: 24 lbs (11 kg)
Energy consumption
(Speed 1-2-3)****
20-60-80 W
Operating frequency: 2412-2472 MHz
Output power: 13.63 dBm
Sound pressure levels (Speed 1-2-3) 32-44-56 dB(A)
Filter replacement indicator Yes
Speed control options 1-2-3, non-touch, smartphone (Automode)
1-2-3, non-touch, smartphone
Air quality sensors Built-in sensors for VOC, PM2.5, temperature and humidity
No sensors - optional use with Blueair Aware
The entire unit can be recycled.
External network issues aecting the product performance are beyond the control of Blueair. Please contact your
Internet service provider for assistance.
*
**
***
****
Specifications based on U.S. models (120 VAC, 60 Hz with particle filter)
The CADR indicates how much filtered air is delivered (airflow) by the air purifier operating at the
highestsetting, and how well the system removes tobacco smoke, dust and pollen pollutants from the
air(eciency). Tests are performed in accordance with ANSI/AHAM AC-1. The maximum possible CADR
ratings according to this standard are: Tobacco Smoke: 450 cfm. / Dust: 400 cfm. / Pollen: 450 cfm.
Air changes per hour are calculated on the recommended room size, assuming 8-foot (2.4 m) ceilings.
Forsmaller rooms, the air changes per hour will increase.
The available electrical power voltage and frequency aects the power consumption of the unit.
Thepower consumption might therefore be dierent from the stated value.
280i/290i
205
280i/290i
205
Dust Pollen
Smoke
200 200180

15
Prije upotrebe proizvoda iz serije Blueair Classic 200 pažljivo pročitajte ovaj korisnički priručnik.
Sadržaj
Općenito 16
Pregled jedinice 17
Podešavanje brzine ventilatora (protoka zraka) 17
Sigurnosne upute 18
Postavljanje jedinice 20
Upute za početak rada 20
Upravljačka ploča idodirne tipke 21
Postavke mobilne aplikacije Blueair Friend app 22
Filtri 23
Promjena filtara 24
Zaštita iodržavanje 25
Tehničke specifikacije uređaja Classic 280i/290i/205 26
Hrvatski
Napomena:
Mogu postojati lokalne varijante ovog modela.

16
Općenito
Serija Blueair 200
Pročišćivači zraka iz serije Blueair 200 imaju
funkciju Wi-Fi idostupni su udva modela.
Modeli 280i/290i imaju ugrađene senzore
zaPM2,5 iHOS te temperaturu/vlažnost,
dokmodeli 205 nemaju ugrađene senzore.
Podešavanje pročišćivača zraka može se napraviti
ručno bilo gdje iubilo kojem trenutku, ili putem
dodirnih tipki na upravljačkoj ploči smještenoj
ispod preklopnog poklopca ili na daljinu putem
mobilne aplikacije Blueair FriendTM app.
Pročišćivač zraka također se može automatski
regulirati na temelju očitanja kvalitete zraka
izugrađenih senzora (280i/290i) ili dodatnog
vanjskog monitora za kvalitetu zraka Blueair
AwareTM (205)
Za više informacija otome kako upotrebljavati
pročišćivač zraka zajedno smonitorom kvalitete
zraka Blueair Aware pročitajte korisnički
priručnik iinformacije opodršci.
Model 205Model 280i/290i
Wi-Fi FILTER AUTO PM 2.5VOC
Wi-Fi
FILTER

17
2
1
3
6
10
45
9
8
7
Podešavanje brzine ventilatora (protoka zraka)
Provjerite tablicu unastavku za različite opcije dostupne za upravljanje pročišćivačem zraka.
Pregled jedinice
Maksimalna brzina preporučuje se za brzo početno čišćenje, tijekom dana ili kada je zrak jako
zagađen. Minimalna brzina preporučuje se za upotrebu tijekom noći.
1. Upravljačka ploča
2. Plavo LED svjetlo
3. Prednji poklopac
4. Prikaz modela 280i/290i
slijeve bočne strane
sotvorima senzora
5. Prikaz modela 205, 280i/
290i sdesne bočne strane
6. Izlazni otvor zraka
7. Ulazni otvor zraka
(prikazstraga)
8. Filtar čestica ili
9. filtar SmokestopTM
10. Komplet dobrodošlice
– kartica dobrodošlice
– korisnički priručnik
Opcije upravljanja 280i/290i 205
Ručno upravljanje putem dodirnih tipki na upravljačkoj ploči
Na daljinu putem mobilne aplikacije Blueair Friend app.
Automatski način koji se temelji na očitanjima kvalitete zraka
iz ugrađenih senzora. Tu je funkciju moguće aktivirati putem
dodirne tipke na upravljačkoj ploči ili putem mobilne
aplikacije Blueair Friend app.
Automatski način temelji se na očitanjima kvalitete zraka
svanjskog monitora kvalitete zraka Blueair Aware. Ta se
funkcija aktivira putem mobilne aplikacije Blueair Friend app.
Min Speed 1
Speed 2
Max Speed 3 Min Speed 1
Speed 2
Max Speed 3

18
Sigurnosne upute
Blueair 205 i280i/290i pročišćivači zraka električni su uređaji. Pročitajte sigurnosne upute prije upotrebe
ipoduzmite potrebne mjere opreza kako biste smanjili rizik od požara, strujnog udara ili ozljeda.
Ograničeno jamstvo društva Blueair primjenjuje se samo ako se jedinica upotrebljava uskladu sovim
uputama.
UPOZORENJE: Ukazuje na opasnu situaciju koja bi, ako se ne izbjegne,
mogla rezultirati smrću ili teškim ozljedama.
OPREZ: Ukazuje na opasnu situaciju koja bi, ako se ne izbjegne,
moglarezultirati blagim ili umjerenim ozljedama.
Općenito
• UPOZORENJE: Kako bi se izbjegla opasnost, oštećeni kabel za napajanje
uvijekmora zamijeniti proizvođač, servisni agent ili druga kvalificirana osoba.
• Upotrebljavajte uzemljeni kabel za napajanje koji ste dobili sBlueair
pročišćivačem zraka da biste ga izravno priključili uodgovarajuću uzemljenu
električnu utičnicu. (Provjerite oznaku energetske učinkovitosti na jedinici)
• Nemojte mijenjati utikač ni na koji način.
Namjena
• OPREZ: Pripazite da se djeca ne bi igrala uređajem.
• Ovaj uređaj nije namijenjen osobama (uključujući djeci) sa smanjenim fizičkim,
osjetilnim ili mentalnim sposobnostima ili nedostatkom iskustva iznanja osim
ako su pod nadzorom ili su dobili upute koje se odnose na upotrebu uređaja
od osobe koja je odgovorna za njihovu sigurnost.
Ovim putem Blueair AB izjavljuje da je vrsta radijske opreme YXXZ-CC uskladu sDirektivom
2014/53/EU. Cjeloviti tekst EU izjave osukladnosti dostupan je na web stranici unastavku:
www.blueair.com/customer-support

19
FCC ID: 2AEX3-2XXZ-CC
IC: 20267-205
UPOZORENJE: Promjene ili izmjene ove jedinice koje nije izričito odobrila strana odgovorna
zausklađenost mogle bi lišiti korisnika prava na upravljanje opremom.
NAPOMENA: Ova je oprema testirana iutvrđeno je da udovoljava ograničenjima za digitalni
uređaj klase B, uskladu sčlankom 15. FCC pravila. Ta su ograničenja osmišljena kako bi pružila
razumnu zaštitu od štetnih smetnji uinstalacijama ustambenim objektima. Ova oprema stvara,
koristi izrači radiofrekvencijsku energiju. Ako oprema nije postavljena ikorištena uskladu
suputama, može uzrokovati štetne smetnje uradiokomunikaciji.
Međutim, nema jamstva da do smetnji neće doći kod određenog načina postavljanja opreme.
Akoova oprema uzrokuje štetne smetnje na radijskom ili televizijskom prijemu, što se može utvrditi
isključivanjem iuključivanjem opreme, korisnika se potiče da pokuša ispraviti smetnje poduzimanjem
jedne ili više mjera opisanih unastavku:
• preusmjeriti ili premjestiti prijamnu antenu
• povećati udaljenost između opreme iprijamnika
• uključiti opremu uutičnicu koja nije na istom strujnom krugu kao ona ukoju
jeuključenprijamnik
• posavjetovati se strgovcem ili iskusnim serviserom radijskih/TV prijamnika.
Ovaj uređaj uskladu je sčlankom 15. FCC pravila. Njegov rad podliježe sljedećim dvama uvjetima:
1. ovaj uređaj ne smije uzrokovati štetne smetnje i
2. ovaj uređaj mora prihvatiti sve primljene smetnje, uključujući smetnje koje mogu
uzrokovati neželjeni rad.
Ovaj je uređaj uskladu je sRSS standardom ili standardima izuzetima od licence Industry Canada.
Njegov rad podliježe sljedećim dvama uvjetima: (1) ovaj uređaj ne smije uzrokovati smetnje i(2) ovaj
uređaj mora prihvatiti sve smetnje, uključujući smetnje koje mogu uzrokovati neželjeni rad uređaja.
Ovaj digitalni uređaj klase Buskladu je skanadskim standardom ICES-003.
FCC RF Izjava oizloženosti zračenju Oprez: Ovaj odašiljač mora biti postavljen tako da je udaljen
najmanje 20 cm od svih osoba.

20
4 ins
10 cm
1. korak
Priključite fiksni kabel za napajanje
uuzemljenu zidnu utičnicu. Ako imate
jedinicu sodstranjivim kabelom za
napajanje, priključite kabel čvrsto
iupotpunosti uuvučenu utičnicu za
kabel za napajanje koja se nalazi na
donjoj strani jedinice prije priključivanja
drugog kraja kabela za napajanje
uuzemljenu zidnu utičnicu.
2. korak
Preuzmite mobilnu aplikaciju Blueair Friend app na svoj pametni telefon iz trgovine aplikacijama
(AppleApp Store ili Google Play).
3. korak
Povežite svoju jedinicu smobilnom aplikacijom Blueair Friend app. Pokrenite aplikaciju islijedite upute.
Nakon povezivanja pročišćivača zraka smobilnom aplikacijom Blueair Friend app, možete upotrijebiti
aplikaciju za daljinsko upravljanje jedinicom ipodešavanje postavki.
Upute za početak rada
Povezivanje pročišćivača zraka – 280i/290i i205
Slijedite upute unastavku kako biste pročišćivač zraka povezali smobilnom aplikacijom
Blueair Friend app. Nakon toga možete omogućiti daljinsko upravljanje.
Postavljanje jedinice
FILTER
Wi-Fi
Blinking
Blinking
Wi-Fi FILTER AUTO VOC PM2.5
Otvorite preklopni poklopac ipritisnite dodirnu tipku brzine protoka zraka. Kada Wi-Fi simbol počne
treptati, pročišćivač zraka može se upariti smobilnom aplikacijom Blueair Friend app.
Postavite jedinicu na mjesto na kojem
zrak može slobodno cirkulirati uuređaju
te izvan ioko njega.
Nemojte postavljati jedinicu na udaljenost
manju od 4 inča (10 cm) od drugog objekta.
Ne stavljajte jedinicu izravno na namještaj od
tkanine ili posteljinu ine naslanjajte je na njih.
Ne ostavljajte jedinicu ublizini izvora topline,
kao što su radijatori, kamini ili pećnice.
Ne ostavljajte jedinicu ublizini vlažnih
okruženja, kao što su kupaonice ili praonice
rublja, ukojima može doći udodir svodom.
Ne ostavljajte jedinicu na otvorenom
