Bluegrass Playgrounds 90015501 Series Instruction sheet

INSTALLATION GUIDELINES
MODEL NUMBER: 90015501XX
DATE: 05/04/2009
Page 1
5” ARCH SWING FRAME
8’ - 1 BAY
#90015501XX
PRE-INSTALLATION CHECK:
Compare all items received to the packing list. Notify your local sales representative immediately if any
parts are missing or damaged.
We are not responsible for items discovered missing
after 72 hours from time of delivery!
Before beginning installation, make sure that you have read and understand the Installation Introduction
manual that was supplied to you. If you did not receive a copy, or if you have a question regarding
anything covered in this manual, contact your local sales representative.
USER GROUP: 2 - 12
RECOMMENDED CREW: 2 people
TOOLS REQUIRED:
1/4” Allen Head Tool
Level
Tape measure
Auger / Post hole digger / Shovel
High speed 3/8” electric drill w/clutch
NOTE: Use of any other driver may result in damage to tool
and/or hardware!
INSTALLATION TIME: 1 Hour
CONCRETE REQUIRED: 14.12 Cubic Feet
NOTE: Concrete must have a minimum rating of 2,500 psi and
must be mixed per manufacturer’s recommendations.
NOTE:
Swing chains and seats are sold separately.

MODEL NUMBER: 90015501XX
DATE: 05/04/2009
Page 2
INSTALLATION GUIDELINES
STEP 1
Refer to PLAN VIEW and FOOTING LAYOUT to locate position of swing frame.
Detail A Top Bar
STEP 2
Excavate footing as shown in FOOTING LAYOUT and FOOTING DETAIL. Place a 2” spacer block in
the bottom of each hole.
STEP 3
Select arched swing frame ends, top bar and four set screws. Set swing frame ends into place in footing
holes and brace into position. Slide top bar over swing frame end stubs and hold top bar in place with
pre-drilled holes and nuts at the 6:00 position. Secure using two set screws. Repeat for other end (see
Detail A).
STEP 4
Verify that swing frame is level and plumb in footings and that it is at correct height. NOTE: Center of top
rail needs to be 96” above nished surfacing. Pour concrete in footings to correct level. NOTE: Concrete
must have a minimum rating of 2,500 psi and must be mixed per manufacturer’s recommendations. Fill
remainder of hole with dirt. Allow concrete to harden for at least 48 hours before use! For safety reasons,
do not attach swing chains or seats to swing frame until playground is ready to open. NOTE: Swing seats
and chains sold separately.
Arched Swing
Frame End
Set Screw
1/2”x3/4”

INSTALLATION GUIDELINES
MODEL NUMBER: 90015501XX
DATE: 05/04/2009
Page 3
ELEVATION VIEW

MODEL NUMBER: 90015501XX
DATE: 05/04/2009
Page 4
INSTALLATION GUIDELINES
FOOTING LAYOUT and USE ZONE
FOOTING ELEVATION
