Bluestream C66 User manual

C66/88
User Manual
RevA0_C66/C88_User_Manual_051120

C66/88 USER MANUAL
www.blustream.com.au |www.blustream.co.uk02
Surge Protection Device
Recommended
This product contains sensitive
electrical components that may be
damaged by electrical spikes, surges,
electric shock, lightning strikes, etc.
Use of surge protection systems is
highly recommended in order to
protect and extend the life of your
equipment.
Contents
Thank you for purchasing
this product.
For optimum performance and safety,
please read these instructions care-
fully before connecting, operating or
adjusting this product. Please keep this
manual for future reference.
Introduction 03
Features 03
C66 Panel Descriptions 04
C88 Panel Descriptions 05
EDID Management 06
Front Panel Control 07
Infrared (IR) Control 07
CEC Control 07
Terminating CAT Cables for use with HDBT 08
Understanding the HDBaseT™ Status LED’s 08
Web GUI Control 09-16
Remote Control Description 17
IR Commands 17-18
Specifications 19
Package Contents 19
Maintenance 19
RS-232 Config & Telnet Commands 20-22
Web-GUI Firmware Update 23-24
MCU Firmware Update 25-26
Certifications 27
Schematic 28
Notes 29-30

C66/88 USER MANUAL
contact: [e-mail] |[e-mail] 03
Our Contractor 6x6 and 8x8 HDBaseT™ Matrix products oer unprecedented
performance and value for the custom installation market. The C66 & C88 are
4K HDCP 2.2 Matrices deliveringHDMI, bi-directional IR and PoC up to lengths of
70m over a single CAT cable. The Matrix also provide advanced features including
simultaneous HDBaseT™ / HDMI on output 1 and a web browser interface module
for control and configuration of the Matrix.
Introduction
FEATURES:
• Advanced HDBaseT™ technology oering uncompressed video and audio with zero latency
• Features 6 / 8 x HDMI inputs which can be independently routed to 6 / 8 x HDBaseT™ outputs
• Output 1 features simultaneous HDMI and HDBaseT™ output
• Extends HDMI up to a distance of 70m over single CAT cable
• Supports 4K UHD video up to 40m (3840 x 2160 @30Hz 4:4:4, 4096 x 2160 @24Hz 4:4:4, and 4K @60Hz 4:2:0)
• Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K
• Supports all known HDMI audio formats including Dolby TrueHD, Dolby Atmos, Dolby Digital Plus and DTS-HD
Master Audio transmission
• Web interface module for control and configuration of the Matrix
• Supports bi-directional IR on all HDBaseT™ outputs
• Supplied with Blustream IR Receivers and Emitters
• Control via front panel, IR, RS-232 and TCP/IP
• Supports PoC (Power over Cable) to power compatible HDBaseT™ Receivers
• 3rd party drivers available for major control systems
• Advanced EDID management
• HDCP 2.2 compliant

C66/88 USER MANUAL
www.blustream.com.au |www.blustream.co.uk04
Front Panel Description (C66)
1IR Receiver - Built in IR sensor for IR pass through
2Output LCD - Shows the currently selected output
3Output Up / Down Button - Press to adjust the selected output up or down
4Input Up / Down Button - Press to adjust the selected input up or down
5Input LCD - Shows the currently selected input
1 3 4 52
1IR Control Input - 3.5mm stereo connector to connect to Blustream IR receiver for IR control of the matrix
2TCP/IP - RJ45 connector for TCP/IP and Web GUI control of the matrix
3RS-232 - DB9 connector for RS-232 control of the matrix
4IR Receiver Output - 3.5mm mono connector to connect to Blustream IR emitter. Used for local Source control
5IR Receiver Input - 3.5mm stereo connector to connect to Blustream IR receiver. Used to extend IR from matrix to
HDBaseT™ Outputs 1-6
6HDMI Inputs - connect to source devices
7HDMI Output - connect to display device
8HDBaseT™ Outputs - RJ45 HDBaseT ™ port to connect to the HDBaseT ™ input port of the compatible Blustream
HDBaseT™ receiver
9IEC Power socket - use supplied IEC power cable
Rear Panel Description (C66)
6 7 8 9
1 2 3 4 5

C66/88 USER MANUAL
contact: [e-mail] |[e-mail] 05
Front Panel Description (C88)
1IR Receiver - Built in IR sensor for IR remote control of matrix
2Output LCD - Shows the currently selected output
3Output Up / Down Button - Press to adjust the selected output up or down
4Input Up / Down Button - Press to adjust the selected input up or down
5Input LCD - Shows the currently selected input
1IR Control Input - 3.5mm stereo connector to connect to Blustream IR receiver for IR control of the matrix
2TCP/IP - RJ45 connector for TCP/IP and Web GUI control of the matrix
3RS-232 - DB9 connector for RS-232 control of the matrix, and RS-232 pass-through
4IR Emitter Outputs - 3.5mm mono connector to connect to Blustream IR emitter. Used for local source control
5IR Receiver Inputs - 3.5mm stereo connector to connect to Blustream IR receiver. Used to extend IR from matrix to
HDBaseT™ outputs 1-8
6HDMI Inputs - connect to source devices
7HDMI Output - connect to display device or AVR
8HDBaseT™ Outputs - RJ45 HDBaseT™ port to connect to the HDBaseT™ input port of the compatible Blustream
HDBaseT™ receiver
9IEC Power socket - use supplied IEC power cable
Rear Panel Description (C88)
1 3 4 52
4
6 7 8 9
1 2 3 4 5

C66/88 USER MANUAL
www.blustream.com.au |www.blustream.co.uk06
EDID Management
EDID (Extended Display Identification Data) is a data structure that is used between a display and a source. This data
is used by the source to find out what audio and video resolutions are supported by the display. By pre-determining
the video resolution and audio format of the source and display device you can reduce the time needed for EDID hand
shaking thus making switching quicker and more reliable.
Configuration of the EDID settings for each input can be achieved using the following RS-232 commands to specify the
required EDID:
EDIDxxDFzz
Where xx = Input: 00 refers to ALL inputs; 01-08 = specific input
zz = EDID as shown below
zz = 00 : HDMI 1080p@60Hz, Audio 2ch PCM (default)
01 : HDMI 1080p@60Hz, Audio 5.1ch DTS/DOLBY
02 : HDMI 1080p@60Hz, Audio 7.1ch DTS/DOLBY/HD
03 : HDMI 1080i@60Hz, Audio 2ch PCM
04 : HDMI 1080i@60Hz, Audio 5.1ch DTS/DOLBY
05 : HDMI 1080i@60Hz, Audio 7.1ch DTS/DOLBY/HD
06 : HDMI 1080p@60Hz/3D, Audio 2ch PCM
07 : HDMI 1080p@60Hz/3D, Audio 5.1ch DTS/DOLBY
08 : HDMI 1080p@60Hz/3D, Audio 7.1ch DTS/DOLBY/HD
09 : HDMI 4K@30Hz 4:4:4/4K@60Hz 4:2:0, Audio 2ch PCM
10 : HDMI 4K@30Hz 4:4:4/4K@60Hz 4:2:0, Audio 5.1ch DTS/DOLBY
11 : HDMI 4K@30Hz 4:4:4/4K@60Hz 4:2:0, Audio 7.1ch DTS/DOLBY/HD
12 : HDMI 4K@60Hz 4:2:0, Audio 2ch PCM
13 : HDMI 4K@60Hz 4:2:0, Audio 5.1ch DTS/DOLBY
14 : HDMI 4K@60Hz 4:2:0, Audio 7.1ch DTS/DOLBY/HD
15 : DVI 1280x1024@60Hz, Audio None
16 : DVI 1920x1080@60Hz, Audio None
17 : DVI 1920x1200@60Hz, Audio None
18 : HDMI 1920x1200@60Hz, Audio 2ch PCM/6ch PCM
19 : User EDID 1
20 : User EDID 2

C66/88 USER MANUAL
contact: [e-mail] |[e-mail] 07
The Blustream range of matrix products include Matrix control via IR.
IMPORTANT: Blustream Infrared products are all 5V and NOT compatible with alternative manufacturers
Infrared solutions. When using third party 12V IR control solutions please use the Blustream IRCAB cable for IR
conversion.
IR Receiver - IRR
Blustream 5V IR receiver to receive
an IR signal for control of the matrix.
IR Control Cable - IRCAB
Blustream IR Control cable 3.5mm Mono to
3.5mm Stereo for linking third party control
solutions to Blustream products.
Compatible with 12V IR 3 party products.
Please Note: cable is directional as
indicated.
IR Receiver - Stereo 3.5mm
Infrared (IR) Control
Signal
5V
Ground
The front panel buttons are used to individually amend the input / output structure of the matrix. Using the Output
Up / Down buttons, first select the desired output, then using the Input Up / Down buttons, select the source
device to switch to. Clicking the Input Up / Down buttons scrolls through the Input / Output numbers sequentially
from 1 - 8 then back to 1.
The Output Up / Down buttons scroll from 1 - 8 then ‘A’ for All, before returning to output 1. Selecting ‘A’: will switch
all outputs to the selected Input.
The front panel buttons can be used for other control features:
• Input Up - press and hold for 3 seconds to power o the matrix (press to power on when in standby mode)
• Output Down - press and hold for 10 seconds to turn on/o front panel button lock
• Output Up - press and hold for 3 seconds to set PTP mode (output 1 = input 1, output 2 = input 2 etc)
Front Panel Control
The Matrix features CEC control of source devices and displays via the products web GUI and RS-232. It is possible to
send CEC commands such as power on / o, input selection as well as volume volume up or down.
Please see the RS-232 command list at the end of this document for a full list of CEC commands available.
Please note: CEC is subject to the support of standardised codes for the sources and displays connected to the Matrix.
CEC Control

C66/88 USER MANUAL
www.blustream.com.au |www.blustream.co.uk08
Terminating CAT Cable for use with HDBaseT™
It is important that the interconnecting CAT cable between Blustream HDBaseT™ products is terminated using the
correct RJ45 pin configuration. The link CAT cable MUST be a ‘straight’ (pin-to-pin) CAT cable, and it is advised that this
is wired to the T568B wiring standard as this format is less prone to EMI (Electro-Magnetic Interference).
When installing CAT cables it is advised that you use the best possible CAT cable quality. HDMI distribution products
will only work if used with CAT5e standard cable or above. Blustream recommends using a CAT6 cable (or better) for
installations, especially when running longer distances, in areas of high EMI, or for 4K signal distribution. It is advised
that using any method of patch panel, wall plate, or join within the CAT cable is avoided as these can add degradation
to the signal. Blustream also recommend using RJ45 connectors that are recommended for use with the choice of CAT
cable.
RJ45 Wiring -
T568B
Understanding the HDBaseT™ Status LED’s
The matrix includes status LED indicators on the HDBaseT™ RJ45 ports to show all connections are active, and to help
diagnose potential connectivity issues.
Understanding the Status Lights - C66 / C88:
• The yellow HDBaseT™ status link light will be OFF when there is no HDBaseT™ link established with a Blustream
HDBaseT™ receiver
• The yellow HDBaseT™ status link light will be ON when there is a HDBaseT™ link established with a Blusream
HDBaseT™ receiver
• The green HDBaseT™ link light will be OFF when there is no video signal being transmitted between the matrix and
Blustream HDBaseT™ receiver
• The green HDBaseT™ link light will be ON when a there is a HDCP enabled video signal being transmitted between
the matrix and Blustream HDBaseT™ receiver
• The green HDBaseT™ link light will BLINK when there is a video signal with no HDCP being transmitted between the
matrix and HDBaseT™ receiver
The link lights will only serve as an indication to the connectivity between matrix and HDBaseT™ receiver unit.
The LED’s will not indicate a termination, bandwidth, interference or cable length issues on a CAT cable run. Blustream
always recommend qualifying / verifying / certifying a CAT cable run for suitability prior to the installation of HDBaseT™
equipment.

C66/88 USER MANUAL
contact: [e-mail] |[e-mail] 09
This following pages take you through the operation of this Matrix’s Web GUI. You must connect the TCP/IP RJ45 socket
to your local network in order to access the products Web GUI.
By default the matrix is set to DHCP, however if a DHCP server (eg: network router) is not installed the matrix IP address
will revert to below details:
Default IP Address is: 192.168.0.200 Default Username is: blustream Default Password is: 1234
The Web GUI supports multiple users along with multiple user permissions as follows:
Guest Account - This account does not require a user to login. The Guest account can only change sources for each
zone. Guest access can be changed by the Admin, limiting inputs or outputs as necessary.
User Accounts - 7x User accounts can be utilised, each with individual login details. User accounts can be assigned
permissions to specific areas and functions. A User must log in to make use of these functions.
Admin Account - This account allows full access to all functions of the Matrix as well as assigning users with
permissions.
Guest Control Page
The Guest Control Page allows a guest user to change inputs for each zone without needing to be logged into the
matrix. Simply select the square that corresponds with the input and zone you wish to change.
There is also a power button on the lower right corner to turn the Matrix on or o.
Web GUI Control

C66/88 USER MANUAL
www.blustream.com.au |www.blustream.co.uk10
Login Page
The Login Page allows a user or admin to login and access additional functionality.
This page also shows you the current firmware version of both the matrix and Web GUI.
User Control Page
A logged in User or Admin Control Page allows a user to change inputs for each zone. Simply select the square that
corresponds with the input and zone you wish to change.
A User or Admin also has the ability to Save or Recall preconfigured Presets. A Saved Preset will store the specified
input to output configuration, and allow you to Recall the configuration when required.
There is also a power button on the lower right corner to turn the Matrix on or o.

C66/88 USER MANUAL
contact: [e-mail] |[e-mail] 11
Configuration Page - Input
The Configuration Page allows you to configure settings to do with both inputs and outputs on the matrix.
You can select the configuration for either Input or Output at the top of the page.
Within the Input Page, you can enter a Name for each input as well as specify an EDID from the drop down menu.
Configuration Page - Output
The Output Page allows us to change settings specific to the outputs of the matrix.
You can enter a Name as well as turn PoC (Power Over Cable) on or o for each output.

C66/88 USER MANUAL
www.blustream.com.au |www.blustream.co.uk12
CEC Page - Input
The CEC Page allows you to send pre-defined or user-defined CEC commands to any Input or Output in the matrix.
You can choose between Input, Output and User-defined sections at the top of the page.
On the CEC Input Page, you must specify a specific input to send the CEC command out of. Press the icon of the
command you wish to send at it will be transmitted to the source device connected to the specified input.
Note CEC is subject to the support of the sources and displays connected to the matrix.
CEC Page - Output
On the CEC Output Page, you must specify a specific output to send the CEC command out of. Press the icon of the
command you wish to send at it will be transmitted to the display device connected to the specified output.
Note CEC is subject to the support of the sources and displays connected to the matrix.

C66/88 USER MANUAL
contact: [e-mail] |[e-mail] 13
RS-232 Page - Local
The RS-232 Page allows you to send commands either out of the local RS-232 port on the matrix itself, or via HDBT and
out of a compatible HDBT Receiver connceted to a display. If the Local radio box is selected, RS-232 commands will be
sent out of the DB9 serial port at the rear of the matrix. Baud rate and terminator command as well as Hex or ASCII can
be selected.

C66/88 USER MANUAL
www.blustream.com.au |www.blustream.co.uk14
RS-232 Page - HDBT
The RS-232 HDBT Page allows you to remotely control devices connected via DB9 serial to remote HDBT Receivers
independently. It is also possible to automate the display on, input select and display o process via RS-232 for each
HDBT output, when the Matrix is turned on.
If RS-232 On is enabled, the Display On, Display Input Select, User Commands 1, 2, and 3 are all sent out of the
corresponding HDBT Receiver, when the Matrix is turned on.
If RS-232 O is enabled, the User O Command will be sent out of the corresponding HDBT Receiver, when the Matrix is
turned o.
You can also specify the Baud Rate and Command Ending (eg: new line, carriage return) to the match the RS-232
device connected to the HDBT Receiver.

C66/88 USER MANUAL
contact: [e-mail] |[e-mail] 15
Upgrade Firmware Page
The Upgrade Firmware Page allows you to upgrade the MCU firmware of the Matrix via the web GUI. Simply press
Browse and select the appropriate firmware file from your computer. Clicking Submit will send the firmware file to the
Matrix and begin the upgrade process. The upgrade process will take several minutes to complete.
Network Page
The Network Page allows you to specify the TCP/IP network port settings. You can choose from Static IP or DHCP, as
well as specific a fixed IP Address, Subnet Mask and Gateway. It is also possible to change or disable the Telnet port.

C66/88 USER MANUAL
www.blustream.com.au |www.blustream.co.uk16
Admin Page
The Admin Page allows the admin to configure up to 8 users including a guest user. Each user can adjust their
password via this page as well.
The Admin, or Users who have been given Admin permissions, are able to allocate permissions to Users. These
permissions include allowing or disallow access to each page in the Web GUI, as well as allowing or disallowing access
to each input or output in the Matrix.
The Admin Page also allows you to lock or unlock the Front Panel of the matrix as well as Factory Reset the Matrix.

C66/88 USER MANUAL
contact: [e-mail] |[e-mail] 17
IR Commands NEC Customer Code = 1898
Advanced Matrix features are not available via IR commands
COMMAND NEC HEX
POWER
TOGGLE 0x14 0000 0069 0000 002a 0150 00a8 0015 0015 0015 0015 0015 0015 0015 003f 0015 003f 0015 0015 0015 0015 0015 003f 0015 0015 0015 0015 0015 0015
0015 003f 0015 003f 0015 0015 0015 0015 0015 0015 0015 0015 0015 0015 0015 003f 0015 0015 0015 003f 0015 0015 0015 0015 0015 0015 0015 003f 0015
003f 0015 0015 0015 003f 0015 0015 0015 003f 0015 003f 0015 003f 0015 05d3
OUTPUT 1 0x09 0000 0069 0000 002a 0150 00a8 0015 0015 0015 0015 0015 0015 0015 003f 0015 003f 0015 0015 0015 0015 0015 003f 0015 0015 0015 0015 0015 0015
0015 003f 0015 003f 0015 0015 0015 0015 0015 0015 0015 003f 0015 0015 0015 0015 0015 003f 0015 0015 0015 0015 0015 0015 0015 0015 0015 0015
0015 003f 0015 003f 0015 0015 0015 003f 0015 003f 0015 003f 0015 003f 0015 05d3
OUTPUT 2 0x1d 0000 0069 0000 002a 0150 00a8 0015 0015 0015 0015 0015 0015 0015 003f 0015 003f 0015 0015 0015 0015 0015 003f 0015 0015 0015 0015 0015 0015
0015 003f 0015 003f 0015 0015 0015 0015 0015 0015 0015 003f 0015 0015 0015 003f 0015 003f 0015 003f 0015 0015 0015 0015 0015 0015 0015 0015 0015
003f 0015 0015 0015 0015 0015 0015 0015 003f 0015 003f 0015 003f 0015 05d3
OUTPUT 3 0x1f 0000 0069 0000 002a 0150 00a8 0015 0015 0015 0015 0015 0015 0015 003f 0015 003f 0015 0015 0015 0015 0015 003f 0015 0015 0015 0015 0015 0015
0015 003f 0015 003f 0015 0015 0015 0015 0015 0015 0015 003f 0015 003f 0015 003f 0015 003f 0015 003f 0015 0015 0015 0015 0015 0015 0015 0015 0015
0015 0015 0015 0015 0015 0015 0015 0015 003f 0015 003f 0015 003f 0015 05d3
OUTPUT 4 0x0d 0000 0069 0000 002a 0150 00a8 0015 0015 0015 0015 0015 0015 0015 003f 0015 003f 0015 0015 0015 0015 0015 003f 0015 0015 0015 0015 0015 0015
0015 003f 0015 003f 0015 0015 0015 0015 0015 0015 0015 003f 0015 0015 0015 003f 0015 003f 0015 0015 0015 0015 0015 0015 0015 0015 0015 0015 0015
003f 0015 0015 0015 0015 0015 003f 0015 003f 0015 003f 0015 003f 0015 05d3
OUTPUT 5 0x19 0000 0069 0000 002a 0150 00a8 0015 0015 0015 0015 0015 0015 0015 003f 0015 003f 0015 0015 0015 0015 0015 003f 0015 0015 0015 0015 0015 0015
0015 003f 0015 003f 0015 0015 0015 0015 0015 0015 0015 003f 0015 0015 0015 0015 0015 003f 0015 003f 0015 0015 0015 0015 0015 0015 0015 0015 0015
003f 0015 003f 0015 0015 0015 0015 0015 003f 0015 003f 0015 003f 0015 05d3
OUTPUT 6 0x1b 0000 0069 0000 002a 0150 00a8 0015 0015 0015 0015 0015 0015 0015 003f 0015 003f 0015 0015 0015 0015 0015 003f 0015 0015 0015 0015 0015 0015
0015 003f 0015 003f 0015 0015 0015 0015 0015 0015 0015 003f 0015 003f 0015 0015 0015 003f 0015 003f 0015 0015 0015 0015 0015 0015 0015 0015 0015
0015 0015 003f 0015 0015 0015 0015 0015 003f 0015 003f 0015 003f 0015 05d3
OUTPUT 7 0x11 0000 0069 0000 002a 0150 00a8 0015 0015 0015 0015 0015 0015 0015 003f 0015 003f 0015 0015 0015 0015 0015 003f 0015 0015 0015 0015 0015 0015
0015 003f 0015 003f 0015 0015 0015 0015 0015 0015 0015 003f 0015 0015 0015 0015 0015 0015 0015 003f 0015 0015 0015 0015 0015 0015 0015 0015
0015 003f 0015 003f 0015 003f 0015 0015 0015 003f 0015 003f 0015 003f 0015 05d3
OUTPUT 8 0x15 0000 0069 0000 002a 0150 00a8 0015 0015 0015 0015 0015 0015 0015 003f 0015 003f 0015 0015 0015 0015 0015 003f 0015 0015 0015 0015 0015 0015
0015 003f 0015 003f 0015 0015 0015 0015 0015 0015 0015 003f 0015 0015 0015 003f 0015 0015 0015 003f 0015 0015 0015 0015 0015 0015 0015 0015 0015
003f 0015 0015 0015 003f 0015 0015 0015 003f 0015 003f 0015 003f 0015 05d3
OUTPUT ALL 0x17 0000 006D 0000 0022 0157 00AC 0016 0016 0016 0016 0016 0016 0016 003F 0016 003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016
0016 003F 0016 003F 0016 0016 0016 0016 0016 003F 0016 003F 0016 003F 0016 003F 0016 0016 0016 003F 0016 0016 0016 0016 0016 0016 0016 0016
0016 0016 0016 0016 0016 003F 0016 0016 0016 003F 0016 003F 0016 003F 0016 0689
OUTPUT
PTP 0x12 0000 006D 0000 0022 0157 00AC 0016 0016 0016 0016 0016 0016 0016 003F 0016 003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016
0016 003F 0016 003F 0016 0016 0016 0016 0016 003F 0016 0016 0016 003F 0016 0016 0016 0016 0016 003F 0016 0016 0016 0016 0016 0016 0016 003F
0016 0016 0016 003F 0016 003F 0016 0016 0016 003F 0016 003F 0016 003F 0016 0689
INPUT 1 0x50 0000 0069 0000 002a 0150 00a8 0015 0015 0015 0015 0015 0015 0015 003f 0015 003f 0015 0015 0015 0015 0015 003f 0015 0015 0015 0015 0015 0015
0015 003f 0015 003f 0015 0015 0015 0015 0015 0015 0015 0015 0015 0015 0015 0015 0015 0015 0015 003f 0015 0015 0015 003f 0015 0015 0015 003f 0015
003f 0015 003f 0015 003f 0015 0015 0015 003f 0015 0015 0015 003f 0015 05d3
INPUT 2 0x55 0000 0069 0000 002a 0150 00a8 0015 0015 0015 0015 0015 0015 0015 003f 0015 003f 0015 0015 0015 0015 0015 003f 0015 0015 0015 0015 0015 0015
0015 003f 0015 003f 0015 0015 0015 0015 0015 0015 0015 003f 0015 0015 0015 003f 0015 0015 0015 003f 0015 0015 0015 003f 0015 0015 0015 0015 0015
003f 0015 0015 0015 003f 0015 0015 0015 003f 0015 0015 0015 003f 0015 05d3
INPUT 3 0x48 0000 0069 0000 002a 0150 00a8 0015 0015 0015 0015 0015 0015 0015 003f 0015 003f 0015 0015 0015 0015 0015 003f 0015 0015 0015 0015 0015 0015
0015 003f 0015 003f 0015 0015 0015 0015 0015 0015 0015 0015 0015 0015 0015 0015 0015 003f 0015 0015 0015 0015 0015 003f 0015 0015 0015 003f 0015
003f 0015 003f 0015 0015 0015 003f 0015 003f 0015 0015 0015 003f 0015 05d3
Remote Control Description
OUTPUT AND INPUT SELECTION
A
Select the zone Output you wish to change the source on
(numbers 1-8 correspond to the zone outputs 1-8).
BSelect the source Input you wish to change the selected zone to
(numbers 1-8 correspond to the source inputs 1-8)
Note: Press the PTP button If you wish to instantly mirror all inputs
and outputs (example - input 1 to output 1, input 2 to output 2 etc).
A
B

C66/88 USER MANUAL
www.blustream.com.au |www.blustream.co.uk18
COMMAND NEC HEX
INPUT 4 0x4a 0000 0069 0000 002a 0150 00a8 0015 0015 0015 0015 0015 0015 0015 003f 0015 003f 0015 0015 0015 0015 0015 003f 0015 0015 0015 0015 0015 0015
0015 003f 0015 003f 0015 0015 0015 0015 0015 0015 0015 0015 0015 003f 0015 0015 0015 003f 0015 0015 0015 0015 0015 003f 0015 0015 0015 003f 0015
0015 0015 003f 0015 0015 0015 003f 0015 003f 0015 0015 0015 003f 0015 05d3
INPUT 5 0x5e 0000 0069 0000 002a 0150 00a8 0015 0015 0015 0015 0015 0015 0015 003f 0015 003f 0015 0015 0015 0015 0015 003f 0015 0015 0015 0015 0015 0015
0015 003f 0015 003f 0015 0015 0015 0015 0015 0015 0015 0015 0015 003f 0015 003f 0015 003f 0015 003f 0015 0015 0015 003f 0015 0015 0015 003f 0015
0015 0015 0015 0015 0015 0015 0015 0015 003f 0015 0015 0015 003f 0015 05d3
INPUT 6 0x06 0000 0069 0000 002a 0150 00a8 0015 0015 0015 0015 0015 0015 0015 003f 0015 003f 0015 0015 0015 0015 0015 003f 0015 0015 0015 0015 0015 0015
0015 003f 0015 003f 0015 0015 0015 0015 0015 0015 0015 0015 0015 003f 0015 003f 0015 0015 0015 0015 0015 0015 0015 0015 0015 0015 0015 003f 0015
0015 0015 0015 0015 003f 0015 003f 0015 003f 0015 003f 0015 003f 0015 05d3
INPUT 7 0x05 0000 0069 0000 002a 0150 00a8 0015 0015 0015 0015 0015 0015 0015 003f 0015 003f 0015 0015 0015 0015 0015 003f 0015 0015 0015 0015 0015 0015
0015 003f 0015 003f 0015 0015 0015 0015 0015 0015 0015 003f 0015 0015 0015 003f 0015 0015 0015 0015 0015 0015 0015 0015 0015 0015 0015 0015
0015 003f 0015 0015 0015 003f 0015 003f 0015 003f 0015 003f 0015 003f 0015 05d3
INPUT 8 0x03 0000 0069 0000 002a 0150 00a8 0015 0015 0015 0015 0015 0015 0015 003f 0015 003f 0015 0015 0015 0015 0015 003f 0015 0015 0015 0015 0015 0015
0015 003f 0015 003f 0015 0015 0015 0015 0015 0015 0015 003f 0015 003f 0015 0015 0015 0015 0015 0015 0015 0015 0015 0015 0015 0015 0015 0015
0015 0015 0015 003f 0015 003f 0015 003f 0015 003f 0015 003f 0015 003f 0015 05d3
INPUT ALL 0x47 0000 006D 0000 0022 0157 00AC 0016 0016 0016 0016 0016 0016 0016 003F 0016 003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016
0016 003F 0016 003F 0016 0016 0016 0016 0016 003F 0016 003F 0016 003F 0016 003F 0016 0016 0016 0016 0016 0016 0016 003F 0016 0016 0016 0016
0016 0016 0016 0016 0016 003F 0016 003F 0016 003F 0016 0016 0016 003F 0016 0689
INPUT
DOWN 0x07 0000 006D 0000 0022 0157 00AC 0016 0016 0016 0016 0016 0016 0016 003F 0016 003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016
0016 003F 0016 003F 0016 0016 0016 0016 0016 003F 0016 003F 0016 003F 0016 003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016
0016 0016 0016 0016 0016 003F 0016 003F 0016 003F 0016 003F 0016 003F 0016 0689
INPUT UP 0x40 0000 006D 0000 0022 0157 00AC 0016 0016 0016 0016 0016 0016 0016 003F 0016 003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016
0016 003F 0016 003F 0016 0016 0016 0016 0016 003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 003F 0016 0016 0016 003F
0016 003F 0016 003F 0016 003F 0016 003F 0016 003F 0016 0016 0016 003F 0016 0689
1080i 0x18 0000 006D 0000 0022 0157 00AC 0016 0016 0016 0016 0016 0016 0016 003F 0016 003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016
0016 003F 0016 003F 0016 0016 0016 0016 0016 003F 0016 0016 0016 0016 0016 0016 0016 003F 0016 003F 0016 0016 0016 0016 0016 0016 0016 003F
0016 003F 0016 003F 0016 0016 0016 0016 0016 003F 0016 003F 0016 003F 0016 0689
1080p 0x44 0000 006D 0000 0022 0157 00AC 0016 0016 0016 0016 0016 0016 0016 003F 0016 003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016
0016 003F 0016 003F 0016 0016 0016 0016 0016 003F 0016 0016 0016 0016 0016 003F 0016 0016 0016 0016 0016 0016 0016 003F 0016 0016 0016 003F
0016 003F 0016 0016 0016 003F 0016 003F 0016 003F 0016 0016 0016 003F 0016 0689
3D 0x0f 0000 006D 0000 0022 0157 00AC 0016 0016 0016 0016 0016 0016 0016 003F 0016 003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016
0016 003F 0016 003F 0016 0016 0016 0016 0016 003F 0016 0016 0016 0016 0016 003F 0016 0016 0016 0016 0016 0016 0016 003F 0016 0016 0016 003F
0016 003F 0016 0016 0016 003F 0016 003F 0016 003F 0016 0016 0016 003F 0016 0689
4K 0x51 0000 006D 0000 0022 0157 00AC 0016 0016 0016 0016 0016 0016 0016 003F 0016 003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016
0016 003F 0016 003F 0016 0016 0016 0016 0016 003F 0016 003F 0016 0016 0016 0016 0016 0016 0016 003F 0016 0016 0016 003F 0016 0016 0016 0016
0016 003F 0016 003F 0016 003F 0016 0016 0016 003F 0016 0016 0016 003F 0016v0689
2.0ch
AUDIO 0x0a 0000 006D 0000 0022 0157 00AC 0016 0016 0016 0016 0016 0016 0016 003F 0016 003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016
0016 003F 0016 003F 0016 0016 0016 0016 0016 003F 0016 0016 0016 003F 0016 0016 0016 003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 003F
0016 0016 0016 003F 0016 0016 0016 003F 0016 003F 0016 003F 0016 003F 0016 0689
5.1ch
AUDIO 0x1e 0000 006D 0000 0022 0157 00AC 0016 0016 0016 0016 0016 0016 0016 003F 0016 003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016
0016 003F 0016 003F 0016 0016 0016 0016 0016 003F 0016 0016 0016 003F 0016 003F 0016 003F 0016 003F 0016 0016 0016 0016 0016 0016 0016 003F
0016 0016 0016 0016 0016 0016 0016 0016 0016 003F 0016 003F 0016 003F 0016 0689
7.1ch
AUDIO 0x0e 0000 006D 0000 0022 0157 00AC 0016 0016 0016 0016 0016 0016 0016 003F 0016 003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016
0016 003F 0016 003F 0016 0016 0016 0016 0016 003F 0016 0016 0016 003F 0016 003F 0016 003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 003F
0016 0016 0016 0016 0016 0016 0016 003F 0016 003F 0016 003F 0016 003F 0016 0689
COPY EDID 0x1a 0000 006D 0000 0022 0157 00AC 0016 0016 0016 0016 0016 0016 0016 003F 0016 003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016
0016 003F 0016 003F 0016 0016 0016 0016 0016 003F 0016 0016 0016 003F 0016 0016 0016 003F 0016 003F 0016 0016 0016 0016 0016 0016 0016 003F
0016 0016 0016 003F 0016 0016 0016 0016 0016 003F 0016 003F 0016 003F 0016 0689
USER 1 0x53 0000 006D 0000 0022 0157 00AC 0016 0016 0016 0016 0016 0016 0016 003F 0016 003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016
0016 003F 0016 003F 0016 0016 0016 0016 0016 003F 0016 003F 0016 003F 0016 0016 0016 0016 0016 003F 0016 0016 0016 003F 0016 0016 0016 0016
0016 0016 0016 003F 0016 003F 0016 0016 0016 003F 0016 0016 0016 003F 0016 0689
USER 2 0x52 0000 006D 0000 0022 0157 00AC 0016 0016 0016 0016 0016 0016 0016 003F 0016 003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016
0016 003F 0016 003F 0016 0016 0016 0016 0016 003F 0016 0016 0016 003F 0016 0016 0016 0016 0016 003F 0016 0016 0016 003F 0016 0016 0016 003F
0016 0016 0016 003F 0016 003F 0016 0016 0016 003F 0016 0016 0016 003F 0016 0689
USER 3 0x01 0000 006D 0000 0022 0157 00AC 0016 0016 0016 0016 0016 0016 0016 003F 0016 003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016
0016 003F 0016 003F 0016 0016 0016 0016 0016 003F 0016 003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016
0016 003F 0016 003F 0016 003F 0016 003F 0016 003F 0016 003F 0016 003F 0016 0689
USER 4 0x45 0000 006D 0000 0022 0157 00AC 0016 0016 0016 0016 0016 0016 0016 003F 0016 003F 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016 0016
0016 003F 0016 003F 0016 0016 0016 0016 0016 003F 0016 003F 0016 0016 0016 003F 0016 0016 0016 0016 0016 0016 0016 003F 0016 0016 0016 0016
0016 003F 0016 0016 0016 003F 0016 003F 0016 003F 0016 0016 0016 003F 0016 0689
IR Commands

C66/88 USER MANUAL
contact: [e-mail] |[e-mail] 19
Package Contents
Specifications
C66
• 1 x C66
• 1 x Rack Mounting Kit
• 1 x Remote Control
• 6 x IR Emitters
• 7 x IR Receivers
• 1 x Serial Cable - DB9 to DB9
• 1 x IR Control Cable - 3.5mm-3.5mm Cable
• 1 x Quick Reference Guide
• IEC Power Cable(s)
Maintenance
Clean this unit with a so, dry cloth. Never use alcohol, paint thinner or benzene to clean this unit.
NOTE: Specifications are subject to change without notice. Weights and dimensions are approximate.
C66 / C88
• Video Input Connectors: 6 / 8 x HDMI Type A, 19-pin, female
• Video Output Connectors: 1 x HDMI Type A, 19-pin, female, 6 / 8 x HDBaseT™ RJ45 connectors
• RS-232 Serial Port: 1 x DB-9, female
• IR Input Ports: 7 / 9 x 3.5mm stereo jack
• IR Output Ports: 6 / 8 x 3.5mm mono jack
• Rack Mountable: 1U rack height, rack ears included
• Casing Dimensions (W x H x D): 437mm x 44mm x 377mm (without feet)
• Dimensions (W x H x D): 437mm x 53mm x 384mm (with feet and connections)
• Shipping Weight: 5.0kg
• Operating Temperature: 32°F to 104°F (-5°C to +55°C)
• Storage Temperature: -4°F to 140°F (-25°C to +70°C)
• Power Supply: Internal 100-240V AC
C88
• 1 x C88
• 1 x Rack Mounting Kit
• 1 x Remote Control
• 8 x IR Emitters
• 9 x IR Receivers
• 1 x Serial Cable - DB9 to DB9
• 1 x IR Control Cable - 3.5mm-3.5mm Cable
• 1 x Quick Reference Guide
• IEC Power Cable(s)

C66/88 USER MANUAL
www.blustream.com.au |www.blustream.co.uk20
RS-232 Configuration and Telnet Commands
The Blustream matrix can be controlled via serial and TCP/IP.
The RS-232 port is used for configuration and control of the product, as well as pass through of RS-232 commands to a
compatible Blustream HDBaseT™ receiver.
The default RS-232 communication settings are:
Baud Rate: 57600
Data Bit: 8
Stop Bit: 1
Parity Bit: none
The following pages list all available serial commands.
Commonly used Serial Commands
There are several commands that are commonly used for control and testing:
STATUS Status will give feedback on matrix such as zones on, type of connection etc...
PON Power on
POFF Power o
OUTxxON (xx is the zone number you wish to turn on)
Example:- OUT01ON (This would turn output one back on)
OUTxxFRyy (xx is the zone out, yy is the input)
Example:- OUT01FR04 (This would switch output 1 to source input 4)
Common Mistakes
• Carriage return – Some programs do not require the carriage return where as other will not work unless sent
directly aer the string. In the case of some Terminal soware the token <CR> is used to execute a carriage return.
Depending on the program you are using this token maybe dierent. Some other examples that other control systems
deploy include \r or 0D (in hex)
• Spaces – Blustream commands do not require space between commands unless specified. There may be some
programs that require spacing in order to work.
- How the string should look is as follows OUT01ON
- How the string may look if spaces are required: OUT{Space}01{Space}ON
• Baud rate or other serial protocol settings not correct
