Bluetti EB70 User manual

716Wh Portable Power Station
USER QUICK GUIDE
Please observe the following instructions to ensure safety use:
USER QUICK GUIDE
Safety Instructions
DO NOT attempt to replace the internal battery with anything other than authorized
replacement battery by yourself.
01
DO NOT operate in wet conditions, let unit dry completely before using.
02
Ensure proper ventilation while in use and do not obstruct fan openings on use. Inadequate
ventilation may cause damage to the power station.
03
DO NOT stack anything on top of the power station in storage or in use, vibration and impact
may lead to poor connection to hardware inside.
04
DO NOT insert foreign objects into outputs or ventilation holes.
05
DO NOT place the power station near heat sources like furnace or ambient heater.
06
The power station generates the same potentially lethal AC power as household wall outlet,
please take carefully and keep children away from it.
07
Please read this manual before use and follow the guidance. Keep this manual for future reference.
Detailed user manual please access: WWW.BLUETTI.COM
AC Rated Power Typical
Capacity
Battery Type Net Weight Dimensions Storage Ambient
Temperature
Working Environment
Humidity
Discharge
Temperature
700W
(1400W Surge)
716Wh LiFe-PO4 Around 21.38lbs/9.7KG
(The weight may subject
to slightlyn change without
notice)
320*217*222mm
(12.6*8.5*8.7 inches)
0-45℃/32-113℉10-90% -20-40℃/
-4-104℉
Charge
Temperature
0-40℃/
32-104℉
General Specs
AC USB
*2
Type-C
*2
Cigarette Lighter
*1
5521
*2
Wireless Charging Pad
*2
*4 100-120VAC
*2 220-240VAC
5VDC,3A Max.100W
5/9/12/15/20VDC, 3A;
20VDC, 5A
(emark chip built-in )
12VDC,10A,
120W
5W/7.5W
10W/15W
Output Specs
10Wh
Estimated Charging Time
716Wh × DOD × η ÷ (the current load power W) = available time（unit: hrs/times）
Smart Phone
Around 50-60 Times
10Wh
Note: DOD indicates Depth of Discharge, η indicates inverter efficiency, DOD=90%, η=90%.
LED Light Bulb
Around 20-30 Hrs
20W
Around 7-8 Hrs
75W
Television Electronic Tools
Around 7-8 Hrs
80W
Refrigerator
Around 6-7 Hrs
90W
Slow Cooker
Around 2-3 Hrs
200W
Car Charging AC Charging Solar
Charging
Generator
Charging
Battery
Charging
Input Specs
12-28V 200W
About 4.1-4.6 hours
About 4.1-4.6 Hours
@24V
About 7.8-8.3 Hours
@12V
About 4.1-4.6
Hours @24V
About 7.8-8.3
Hours @12V
Certificate
Inspector:
QC:

LCD Screen Guide
1
Power Station
2
AC Adapter
What`s in the box
5
User Manual
6
Warranty Card
716Wh Portable Power Station
User Manual
Pleaseread this manual before use and follow its guidance. Keep this manual for future reference.
Detaileduser manual please access: WWW.BLUETTI.COM
3
Car Charging Cable
4
Solar Charging Cable
QUICK GUIDE
Charging Port
01
LCD Screen
02
Wireless Charging Pad
03
LED Lamp Button
04
LED Lamp
05
DC Power Button
06
USB-C Port
07
USB-A Port
08
DC 5521 Output Port
09
Cigarette Lighter Port
10
AC Power Button
11
AC Outlet
12
USER QUICK GUIDE USER QUICK GUIDE
a
defgh
bc
a. ECO-Mode Icon
b. Battery Capacity
c. Input Power
d. Alert Icon for low
Voltage
e. Alert Icon for Temperature
Anomaly
f. Output Power
g. Alert Icon for Overload
h. Alert Icon for Short Circuit
1
6 7 8910 11 12
3
24 5
Charging by solar panels
Connecting Cable PV+
Connecting Cable PV- Solar Panel Male Pole
Solar Panel Female Pole
Charging Plug
(7909)
Solar PanelPower Station
Charging Port
To Enter Settings Mode: Turn “AC” mode to the off position.
Press “AC” and “DC” buttons at same time for 2 seconds to enter
“Settings” mode.
01
To Change Frequency Setting: Once in “Settings” mode,
press the “AC” button to switch frequency of the AC output
ports to either 50 or 60 Hz depending on your location.
02
Eco Mode: Once in “Settings” mode, press the “DC” button to
turn ON / OFF the ECO mode.
03
Exit Settings Mode: Long press the “AC” and “DC” buttons at
the same time for 2 seconds to save and exit the settings mode.
04
Frequently Asked Questions
Dry, non-abrasive cloths to wipe will be perfect. The power station is a versatile tool for various
adventures, simple cleaning would be required from time to time to keep the unit in a good condition.
A
How do I clean for power station?
1
Please place the power station in a dry and cool place at the recommended temperature. Do not expose
the power station to humid environment. If you want to store it for a long time, please charge the
battery to 80% every 6 months to extend the battery lifetime. Remind to turn off the unit before storing.
A
How to store my power station?
2
Please place your after-sale requirement as the warranty card written to the platform where you order
the product.
A
How to claim the warranty?
4
AStep1: You need to figure out the amount of power your devices require. Some research may be taken
on internet search or the user guide of your device shall suffice.
Step 2: Check the rated power of certain port on power station. For example, if the AC output port
generates 2000W of power and your device requires over 2000W for a extended period of time, the
power station will turn itself off.
How do I know whether my device will work with the power station?
3
ECO Mode:
Turn off the unit while the power of AC output is less than
10W in 4 hours for power saving.
How to operate on power station to turn ON/OFF ECO Mode\
and change the working frequency:
