Bluetti EB70 User manual

EB70 716Wh Portable Power Station
Please read this manual carefully before operating and keep it handy for future reference.

User Manual
Please read this manual carefully before operating and keep it handy for future reference.

CONTENTS
1. BRIEF INTRODUCTION
2. ABBREVIATIONS
3. SAFETY INSTRUCTIONS
4. PACKAGE LIST
5. KEY FEATURES
6. GETTING STARTED
7. LCD SCREEN GUIDE
8. CHARGING
8.1 Charging with AC wall outlet
8.2 Charging with solar panel
8.3 Charging with car
8.4 Charging with generator
8.5 Charging with lead-acid battery
9. APPLICATION
10. TECHNICAL SPECIFICATIONS
11. PRODUCT GUIDELINE
12. FAQS (Frequently Asked Questions)
13. DECLARATION
.............................................................................................01
........................................................................................................01
..........................................................................................02
...........................................................................................................03
.........................................................................................................04
..................................................................................................05
.................................................................................................05
................................................................................................................06
..................................................................................................06
.......................................................................................................07
...................................................................................................................07
.........................................................................................................08
..............................................................................................08
.............................................................................................................09
...............................................................................09
............................................................................................12
........................................................................13
.........................................................................................................14

Just Power on
1. BRIEF INTRODUCTION
2. ABBREVIATIONS
The EB70 portable power station was born from ultimate innovation and
mature technologies. It features the 800W/1000W power inverter and 716Wh
LiFePO4 battery pack, enough to power your essentials on the road or during
power outages, but it is surprisingly compact with 12.6*8.5*8.7inch dimension
and 21.4lbs lightweight. Moreover, taking fast charging into consideration,
the EB70 now holds brilliant dual super-fast 100W PD3.0 USB-C ports to get
your Type-C electrical devices charged simultaneously. Besides, the EB70 also
supports ECO Mode that the AC power will automatically turn off over 4 hours
low(≤10W) or no load to save power drain.
Overall the BLUETTI EB70 is an optimal portable power station choice with a
great feature set for your backup or outdoor needs.
MPPT: Maximum Power Point Tracking
SOC: State of Charge
AC: Alternating Current
DC: Direct Current
PV: Solar Panel(s) Charging (Photovoltaic)
T200S: 200W AC Adapter
DOD: Depth of Discharge
ECO: A power-saving setting for the EB70. When it is on, the AC power will
automatically turn off over 4 hours low(≤10W) or no load to save power drain.
- 01 -

BLUETTI
3. SAFETY INSTRUCTIONS
Kindly Note: Please read and understand all safety instructions before
using the EB70 portable power station. If damage occurs due to failure to
follow instructions, the warranty does not apply.
- 02 -
DO keep the EB70 power station away from the fire and heat.
DO operate the EB70 in a dry and well-ventilated place. If it gets moisturized
or damp, please dry it thoroughly before using it.
Be sure to check all materials before using the EB70. In case of any abnormality
such as breakage, crack, leakage, or AC line breakage, please stop using the
equipment immediately.
DO NOT use wet hands to touch the equipment and connector plug. It may
cause electric shock or other hazards.
DO NOT use metal to contact the AC interfaces. It may cause electric shock,
high temperature, fire, and other hazards.
DO NOT obstruct fan openings to ensure proper ventilation in use.
Otherwise, permanent damage to the EB70 may occur.
DO NOT move the EB70 in use since vibrations and sudden impacts may
lead to poor connections to the hardware inside.
Please read and fully understand the operation instructions of the electrical
appliances to be connected. Failure to operate the electrical products properly
may result in accidents or injuries.
Please use the original charger and cables only designed for the EB70. The
company is not liable for the damage caused by third-party equipment,
which may invalidate your warranty.
Please use the EB70 power station carefully and keep children away from it.
WARNING: In case of fire, ONLY dry powder fire extinguisher works.
WARNING: DO NOT insert foreign objects into any ports of the EB70 (AC, DC,
or ventilation holes). The power station generates the same potentially lethal
AC power as a household wall outlet.
WARNING: It is hazardous for anyone other than the authorized person to carry
out any service or repair operation involving replacing the internal battery or
other equipment components.

Just Power on
4. PACKAGE LIST
Please kindly check all the accessories are complete. The package list includes
the BLUETTI EB70 Portable Power Station, T200S AC Adapter & Charging
Cable, Car Charging Cable, PV Charging Cable, User Manual, Warranty Card, and
QC certificate.
- 03 -
2
AC Adapter
5
User Manual
6
Warranty Card
7
Certificate of QC PASS
3
Car Charging Cable
4
Solar Charging Cable
1
Power Station

BLUETTI
5. KEY FEATURES
- 04 -
1
6 7 8910 11 12
3
24 5
QUICK GUIDE
Charging Port
01
LCD Screen
02
Wireless Charging Pad
03
LED Lamp Button
04
LED Lamp
05
DC Power Button
06
USB-C Port
07
USB-A Port
08
DC 5521 Output Port
09
Cigarette Lighter Port
10
AC Power Button
11
AC Outlet
12

Just Power on
6. GETTING STARTED
7. LCD SCREEN GUIDE
- 05 -
The BLUETTI EB70 has separate AC and DC power buttons. Press either of
them to startup or shut down the specified port area.
(1) Turn on AC/DC: short press the AC/DC power button; both the indicator light
and LCD screen will be on, and the LCD screen will be off several seconds later.
(2) Turn off AC/DC: press and hold the AC/DC power button for several seconds,
and the indicator light and the LCD screen will be off.
(3) Setting Mode: press and hold both AC and DC power buttons at the same
time to turn it on, and the frequency indicator will flash.
(4) ECO Mode: under 'setting mode', press the DC power button to turn it on/off.
(5) Frequency Setting: under 'setting mode', press the AC power button to
switch the frequency of AC output ports to either 50HZ or 60HZ, depending on
your location.
a
f
bc
degh
a. ECO-Mode Icon
b. Battery Capacity
c. Input Power
d. Alert Icon for low Voltage
e. Alert Icon for Temperature
Anomaly
f. Output Power
g. Alert Icon for Overload
h. Alert Icon for Short Circuit

BLUETTI
- 06 -
8. CHARGING
The EB70 supports AC, Solar, Car, Generator, and Lead-acid battery five
charging methods.
Connect the adapter input plug to the wall outlet, the other end to the
AC charging input port of EB70. The equipment comes with a built-in
advanced control circuit. When it is fully charged(Approx. 4-5hrs), it will
stop charging automatically.
Normal Startup
Normal Shutdown
Overload
Short Circuit
ECO Mode Start
ECO Mode Close
Low Battery
High/Low Temperature
The LCD screen turns on.
The LCD screen turns off.
'OVERLOAD' on the LCD screen flashes.
'SHORT' on the LCD screen flashes.
'ECO' displays on the LCD screen.
'ECO' disappears on the LCD screen.
The battery icon on the LCD screen flashes.
'TEMP' on the LCD screen flashes.
LCD Screen Status Explanation
AC outlet
T200S 200W Adapter
8.1 Charging with AC wall outlet

Just Power on
- 07 -
Connect the solar panels(in series or parallel) with the open-circuit voltage
range: 12-28V. Then connect the solar panel to EB70 via the solar charging
cable. When charging with solar panels, the max input current and power are
8A and 200W, respectively. Also, when it is fully charged(Approx. 4-5hrs), it will
stop charging automatically.
8.2 Charging with solar panel
Connect the EB70 to the vehicle 12V cigarette lighter port via the car
charging cable. Again, when the equipment is fully charged(Approx. 7-8hrs),
it will stop charging automatically.
8.3 Charging with car
Connecting Cable
Connecting Cable
MC4 Connectors
Solar PanelPower Station
Charging Port
Charging Plug
(7909)
Solar Panel Female Pole
Solar Panel Male Pole

BLUETTI
- 08 -
Connect the AC adapter input plug to the generator and the output plug to
the AC charging port of EB70. As the same again, when it is fully charged
(Approx. 4-5hrs), it will stop charging automatically.
8.4 Charging with generator
Connect the EB70 with a lead-acid battery via the charging cable. Last same,
when it is fully charged(Approx. 4-5hrs), it will stop charging automatically.
8.5 Charging with lead-acid battery
Car Charging Cable
AC Adapter
Lead-acid Battery Charging Cable

Just Power on
9. APPLICATION
- 09 -
Kindly Note: All the below statistics are based on the laboratories. Actual results
may vary depending on environment, usage, and firmware version.
10. TECHNICAL SPECIFICATIONS
Model No.
Battery Capacity
Battery Cell Type
Dimensions
Weight
Operating Temperature
Recharging Temperature
Working Humidity
BLUETTI EB70
716Wh / 32,000mAh @22.4V
LiFePO4 (2500+ Life Cycles)
12.6 x 8.5 x 8.7 in. / 320 x 216 x 221 mm
21.4 lb / 9.7 kg
32-104°F / 0-40°C
-4°F-104°F / -20°C-40°C
10-90%
716Wh×DOD×η÷ (the current load power W) = availabletime（unit: hrs/times）
Note：DODindicatesDepth of Discharge, ηindicates inverter efficiency, DOD=90% ,η=90%.
10Wh
Smart Phone
Around 50-60 Times
LED Light Bulb
Around 20-30 Hrs
20W
Around 7-8 Hrs
75W
Television
Electronic Tools
Around 7-8 Hrs
80W
Refrigerator
Around 6-7 Hrs
90W
Slow Cooker
Around 2-3 Hrs
200W
10Wh

BLUETTI
- 11 -
100-120V
220-240V
1400W
50-60HZ
800W
1000W
Rated Output Power
Surge
Frequency
Ports
Cigarette Lighter
DC5521*2
USB-A *2
USB-C PD3.0 *2
Wireless Charging Pad
Kindly Note: Please place your phone( if wireless charging supported) on the wireless
charging pad horizontally.
Voltage
12V
12V
5V
Current
10A
10A
3A
AC Output* 4
DC Output
US/JP
EU/UK/AU
200W
12-28V
8A
4-5 hrs
Input Power
Open Circuit Voltage (OCV)
Current
Estimated Time
Solar Input
200W Max
12V-28V
8A Max
4-5 hrs
Input Power
Voltage
Current
Estimated Time
T200S Adapter/Generator/Lead-acid Charging
100W Max (5V/3A, 9V/3A, 12V/3A, 15V/3A, 20V/3A, 20V/5A)
15W Max

Just Power on
- 12 -
11. PRODUCT GUIDELINE
If an output over-current, overload, or short circuit occurs, the EB70 will
turn off the corresponding output port. Then it will automatically start again
(at an interval of 20S). Suppose there is still an over-current, overload, or short
circuit; the equipment will lock the output ports and then need manual
troubleshooting and restart again. If the outputs repeatedly stop, turn the
equipment off. Please get in touch with the seller or maintenance personnel
for professional help.
When the battery level drops to 0%, the AC and DC outputs will automatically
turn off. Please check the battery level before using the AC/DC output to
maintain long battery life. If the battery level drops to 20% or less, it is advised
to recharge the equipment first.
The EB70 supports pass-through charging, and please keep the equipment
laid flat during use, charging, and discharging.
Note: It is not suggested to apply the EB70 to charge some radios or video
players.
12V-24V
8A Max
12V: 7-8 hrs; 24V: 4-5 hrs
Input Voltage
Current
Estimated Time
Car Charging
Note：PV Input, T200S AC Adapter/Generator/Lead-acid Charging share the same
Aviation Port.
Most electrical appliances on the market apply to the specifications of the
12V/10A, cigarette lighter, USB-A, and USB-C output ports of BLUETTI EB70S.
But, there are still charging of some appliances that generate an excessive
instantaneous inrush current may activate the over-current protection.
The EB70S applies to home appliances with 800W or less output power.
Though the rated output power is under 800W, overload protection will still
be activated if the appliance generates a massive instantaneous start-up
power. Therefore, it is recommended to apply the EB70S to the electrical
equipment with lower-rated power.

BLUETTI
- 13 -
12. FAQS (FREQUENTLY ASKED QUESTIONS)
What devices can be charged/powered by BLUETTI EB70?
For the EB70, the maximum output power is 800W(US/JP) or 1000W
(EU/UK/AU), so please make sure the total power of your devices doesn't
exceed the figures, or the inverter will shut itself down.
Friendly Note: For some devices with a motor/compressor built inside, the
instant startup power maybe 2-4 times more than the rated power, which
may exceed the upper limit of the EB70.
How long will the EB70 power my device?
Working time(estimation)=716Wh×DOD×η÷ (operating power of your
device)
Kindly Note: DOD indicates Depth of Discharge, ηindicates inverter efficiency,
and the unit of device operating power in Watts. DOD=90% , η=90%.
The actual working time may vary under different situations.
What kind of solar panel can charge this EB70?
The solar panel must meet:
1) Open Circuit Voltage (OCV) between 12V-28V;
2) Equipped with MC4 Connector. If your panel has an Anderson connector,
please purchase Anderson to MC4 cable separately.
Friendly Note: The actual charging time depends on the weather, solar
condition, and the angle of the solar panels.
Can it charge and discharge simultaneously?
Yes, the EB70 supports pass-through charging. It features the premium
LiFePO4 battery and the advanced Battery Management System, so
please feel free to use it in a way that better suits your needs.
What does the ECO Mode mean, and can I turn it off?
Under ECO Mode(Default Setting), the AC power will automatically turn off
over 4 hours low(≤10W) or no load to save power drain. If you would like to
turn it off, please enter the ‘setting mode’ and switch ON/OFF. We hope
this design will benefit our users, especially CPAP users.
How can I clean the EB70 power station?
Dry and non-abrasive cloths to wipe will be perfect. The EB70 is a versatile
tool for various adventures, simple cleaning from time to time is necessary
to keep the equipment in good condition.
Q1:
A:
Q2:
A:
Q3:
A:
Q4:
A:
Q5:
A:
Q6:
A:

13. DECLARATION
Please note that specifications and appearance are subject to improvement
without prior notice.
The company shall not be liable for any damage caused by force majeure, such
as fires, typhoons, floods, earthquakes, or the user's intentional negligence,
misuse, or other abnormal conditions.
The company shall not be liable for any accidents or damages caused by failure
to follow the precautions in the instruction manual.
The company shall not be liable for any failures caused by the use of uncertified
accessories.
This product is NOT suitable for appliances requiring demanding power reliability
and safety, such as aerospace, trunk communication, nuclear control, and medi-
cal equipment. Please confirm the applicability of this product in advance.
