Blueview CCT Color Controllable TN-5050 User manual

TN-5050
CCT/COLOR CONTROLLABLE SERIES
Voltage
(DCV) Power (W/m)
24 17.3
Other Parameters
Model No.
Model No. Quantity
(pcs)
Product
Size
(mm)
Max Run
(Single feed)
(m)
Min Cuttable
lengt(mm)
Luminous
Flux
(lm/m)
Ra
Color
Temperature/
Wavelength
(nm)
Light Color
TN-5050-72-24-RGB
TN-5050-72-24-RGB 72 5000*10 5 83
120° 130 -- --
-- --
-- --
120°
120°
415
102
615-625
515-525
460-470
R
G
B
Beam Angle
-25~+60℃-25~+70℃
Working
Temperature
Storage
Temperature
NOTE:
NOTE:
Test environment temperature : 25±2°C.
The above data is typical values. The actual data of each single product may differ from the typical values. The
data is subject to change without notice.
Different color temperature will make luminous ux different.
Single feed only. The max series connection is related to the working current of LED.
Power is the total power of three RGB LEDs.
Optical & Electrical Parameters
Efcacy
(lm/w)

TN-5050
CCT/COLOR CONTROLLABLE SERIES
Length vs. Power vs. Voltage Drop
17.3240.721
241.442
242.163
242.884
243.65
69.1
34.6
86.4
51.8
23.85 0.09
0.42
0.74
1.26
1.78
23.41
23.09
22.54
21.96
23.94
23.80
23.83
23.74
23.83
--
--
--
--
--
Rated Voltage
(DC V)
Rated Current
(A)
Working
Length
(m)
Rated Power
(W)
Power
Supply
Voltage at the
end
(DC V)
Voltage at the
beginning
(DC V)
Voltage Drop
(DC V)
Prole Drawing
Unit mm
NOTE:Please ask the sales for detail drawing.
502 [19.76]
10 [0.39]
84.2 [3.31] 83.3 [3.28]

TN-5050
CCT/COLOR CONTROLLABLE SERIES
Luminous Intensity Distribution Diagram
AVERAGE BEAM ANGLE(50%)：113.3°C0/180,112.8°
Unit：cd
C90/270,113.8°

TN-5050
CCT/COLOR CONTROLLABLE SERIES
Average Beam Angle
Luminous Flux output：536.6lm
1cm 720398,2506756lx 3.01cm
6.03cm
9.04cm
12.05cm
15.07cm
18.08cm
21.09cm
24.10cm
27.12cm
30.13cm
180099,626689lx
80044,278528lx
45025,156672lx
28816,100270lx
20011,69632lx
14702,51158lx
11256,39168lx
8894,30948lx
7204,25068lx
Height Eavg，Emax Beam Angle：112.85° Diameter
2cm
3cm
4cm
5cm
6cm
7cm
8cm
9cm
10cm
The above data are tested with three lights on.
Please ask the sales for other colors and specications.
Note:

TN-5050
CCT/COLOR CONTROLLABLE SERIES
Label the reel; Put the packed static
shielding bag into
carton box;
Seal the carton box; Label the box; Use packing belt to
pack. Add edge
protectors if necessary.
Put reel, accessory bag
and desiccant together
into static shielding bag;
Seal and label the static
shielding bag;
1 4
5 6 7
23
Model No.
50000*10 550*400*340 5 100 11.1(1±10%) 18.3(1±10%)
Product Size（mm) Carton Size（mm) Meter/Reel Reel/Carton Net Weight(kg) Gross Weight(kg)
Packaging information
5m per reel, packed in a static shielding bag.
The above quantity and weight are only for the illustrated packaging method. There will be differences
in the quantity and weight with other packaging methods.
Note:
1.Products and Tools
Clips
LED power supplyFN-5050
Electric iron Diagonal pliers Electric drill
Self-tapping screw Electrical tape
Packaging
Installation
TN-5050-72-24-RGB

TN-5050
CCT/COLOR CONTROLLABLE SERIES
2.Installation Methods and Steps
By self adhesive tape
Install with clips
Peel away the self
adhesive tape on the
rear.
Clean the mounting
surface
Peel away the self
adhesive tape on the
rear.
Evenly arrange the
strips with appropriate
space in the light box.
Stick the strips on the
signage accordingly
Connect the strips
with compatible power
supply
Cut off the excess
part based on the
installation position.
Connect main line to
power supply.
Evenly arrange the
strips with appropriate
space in the light box
Use soldering iron
for welding if need
connection.
Attentions
Before installation, check that the product parameters are consistent with the requirements (Seeing product specicationsor
product labels)
Load voltage, current, power and power supply should be matched with the product.
Follow the instructions of wiring diagram (rst connect the load and then the power supply) to avoid short circuit.
Make sure the correct connection of positive and negative poles between led module and power supply. Otherwise, the light
will not be on.
Make sure the power cord rmly screwed into the terminal and it should not be pulled out by hands.
The terminal should have insulation,waterproof and anti-corrosive treatment

TN-5050
CCT/COLOR CONTROLLABLE SERIES
Quick Guide Warning
Problems
All LEDs can
not light on.
LEDs can not
light on partly.
Brightness of
LED
is inconsistent
tor insufcient.
LED icker.
Automatic power protection
from the open or short
circuit in output of the power
supply. Fix the short circuit problem.
Correctly connection
Check the power supply
system to x it.
Replace with more powerful
power
Make sure led module working
voltage within ±5% of standard
voltage, or keep balance by
circuit power consumption.
Repair should be operated by a qualied technician, if the external circuit or main line of this product is damaged.
The parameters given in this manual are typical values and for reference only.
All illustrations and drawings in this manual are for reference.
This product is subject to change without notice.
LED lighting products belongs to electronic products, please do recycling treatment according to the relevant WEEE directives.
Reduce the quantities in
series connection to meet
requirement.
Fix the short circuit problem.
Wrong connection of power
supply.
Some switching mode power
supplies are not powered.
Power supply line error.
Mistaken wire connection of
some of products
Power overloaded.
Connection point fault. Remove bad connection point.
Replace a new power supply.
Please follow the instructions
Power supply circuit
excessive consumption.
Excessive quantities in series
connection
Switching power supply
failure.
Wrong Installation or use of
products
Reasons
No electric supply.
Solutions Do not disassemble or retrot the light. Do not touch the surface of the
light with a sharp object.
Do not do live-line working during installation,especially for high voltage
product.
Do not use any organic chemical solvents.
Use neutral glass adhesive to x this product and it needs to be dried 4
hours in the open environment after operation.
Treat the ends and the circuit connection points that are not connected
to the main line with insulation,waterproof, and anti-corrosion in the
installation.
Use 20AWG (0.5mm2 or thicker core wire to avoid adverse
consequences caused by overheating, if the power cable need to
lengthen.
Make sure the input voltage meets the requirements and lines are
connected correctly before lighting on.This product is as backlight of
signage, and do not use as general lighting.Series connection within the
max run.
The length of the power cable between the power supply and the led
strip should not exceed 2 meters.Otherwise, large circuit loss will lead
to inconsistent brightness
Installation, maintenance and repair should be operated by a qualied
technician.
Statements and Recycling
Statements:
Recycling:
Common Faults and Troubleshoot
