bmcm ZU-PW Series User manual

ZU-PW10W, ZU-PW70W
Power supply units for bmcm hardware
Well supplied.
The power supply units of the ZU-PW series pro-
vide a low voltage in the amount of 12V (ZU-
PW10W) and 24V (ZU-PW70W) to supply
bmcm devices.
Clearly safe.
Due to the galvanic isolation of the DC supply
voltage from the 230V AC power line, measure-
ment hardware and the PC are perfectly pro-
tected.
Get connected.
The power supply units are delivered with a stan-
dard screw coupling. The assignment of the con-
nector goes with all bmcm devices that are sup-
plied by low voltage. If using a device without a
low voltage connector (e.g. AP8a), the screw
coupling must be removed from the power sup-
ply.
Functional diagram

ZU-PW10W, ZU-PW70W
1Installation
First connect the ZU-PW10W or ZU-PW70W to the power supply plug of the bmcm device. Attach the IEC
cord of ZU-PW10W to the power supply and then plug the wall power supply or the mains plug into the
socket outlet. An LED indicates the operation of the ZU-PW10W.
!
To avoid damages, power must not exceed 20W (ZU-PW10W) or 85W (ZU-PW70W) at the maximum!
2Assignment of the low voltage connector
The figure on the right illustrates the assignment of the 3-pin DIN coupling.
!
If the device to be supplied does not feature a low voltage connector (e.g. AP2, AP8a, BP2), the screw
coupling has to be removed. In this case, the cable is directly connected to the device. Check for cor-
rect polarity!
3Important notes for using ZU-PW10W, ZU-PW70W
•ZU-PW10W und ZU-PW70W generate a low voltage electrically isolated from the mains for the supply of bmcm
devices. Please comply with the respective regulations!
•Only use non-solvent detergents for cleaning. The product is designed to be maintenance-free.
•The product must not be used for safety-relevant tasks. With the use of the product, the customer becomes manu-
facturer by law and is therefore fully responsible for the proper installation and use of the product. In the case of
improper use and/or unauthorized interference, our warranty ceases and any warranty claim is excluded.
Do not dispose of the product in the domestic waste or at any waste collection places. It has to be either duly dis-
posed according to the WEEE directive or can be returned to bmcm at your own expense.
4Technical data
ZU-PW10W ZU-PW/0W
Power IN: 200-240VAC, max. 20VA 90-260VAC, max. 85VA
Power OUT: 12W: 12VDC, ±20%, 1A, unregulated 70W: 24VDC, ±5%, 2.92A, regulated
Ground potential: 2VAC max. 3VAC
DC line: 1.75m long 1m long
Type of power supply: linear plug power supply, no overload protection! switching power supply, overload-proof
Accessories: -- power cable 2m
Use for bmcm hardware: AAB-II, AP2, AP8a, BP2, BP2-BOX, BP16,
LAN-AD16f, meM-LOG-SE
AMS42, AMS84, AMS42-USB, AMS84-USB,
AMS42-LAN16f, AMS84-LAN16f
CE standards: EN61000-6-1, EN61000-6-3, EN61010-1; for decl. of conformity (PDF) visit www.bmcm.de
ElektroG // ear registration: RoHS and WEEE compliant // WEEE Reg.-No. DE75472248
Temperature ranges: operating and storage temperature -25..70°C
Relative humidity: 0-90% (not condensing)
Warranty: 2 years from date of purchase at bmcm, claims for damages resulting from improper use excluded
Manufacturer: BMC Messsysteme GmbH. Subject to change due to technical improvements. Errors and printing errors excepted. 01/04/2012
