OWNER’S MANUAL
Installation & Operation
Rev1 05/2019
Power Bob Elite

Headboard Bracket Installaon Guide () ……………… 11
Table Of Contents
Customer Service Toll Free: 1-844-696-6886
Safety & Warranty Warnings ……………………………………………… 01
Parts List……………………………………………………………………………… 02
Preparatory Work ……………………………………………………………… 03


…………………………………………………………………………………………… 06


Electronics Quick Reference Guide & Synchronizing Two




Customer Service Toll Free: 1-844-696-6886
Safety & Warranty Warnings
—01—

Customer Service Toll Free: 1-844-696-6886
—02—
Parts List
All electronics and components that need to be installed are located in boxes under the foundation or
attached to the frame. Before discarding the packing materials, ensure that all the parts are accounted for.
PARTS LIST
OPTIONAL EQUIPMENT/PART (NOT INCLUDED)
Socket and Wrench 1/2'' (13mm)
HEADBOARD BRACKET COMPONENTS
(2) (2) T-Brackets (8) Bolts M8*16 (4) Nuts (4) Washers
Headboard
Brackets
(1) AC Power Cord (3)AAA Batteries
(1) Sync Cord
(TXL/SCK Only)
(1)
Power Supply with
Battery Backup Box
9V 9V
(optional)
9V
(1)Remote Control
HEAD
TV
1 2
Z-G
SNORE
FOOT
(1)
Mattress Retainer
Bar (2 for K/CK)
(6) Adjustable
Legs
(1)Socket Wrench

—03—
Customer Service Toll Free: 1-844-696-6886
Preparatory Work
Remove the red plastic safety lock before unfolding your power foundation.
Open the box lid, move away
the outer packing box.
Take out all the accessories
from the packaging and put
them aside.
HEAD BOARD
1
2
×1
Accessories Box
ACCESSORIES BOX:
×1(2 for K/CK)
Mattress Retainer Bar
×6
Adjustable
Legs
HEAD
TV
1 2
Z-G
SNORE
FOOT
×1
Remote
Control
×1
Sync Cord
（TXL/SCK Only）
×2
Headboard
Brackets
×2
T-Brackets
×8
Bolts
M8*16
×4
Nuts
×1
AC Power Cord
×3
AAA
Batteries
×1
Power Supply
×4
Washers
×1
Socket
Wrench
Remove the red plastic
safety clip.
Turn the locking pin 90°
in counter clockwise
direction.
Remove the folding
locking pin by pulling
upwards.
Red Plastic
Safety Clip
Locking Pin Locking Pin


Customer Service Toll Free: 1-844-696-6886
Standard Power Foundat ion Setup
Two people are required to setup the foundation.
1Install 4 legs, make sure the
legs are tight. 2Remove the bed from the box with a flipping motion, let the bed stand on the 4 legs.
HEAD BOARD
HEAD BOARD
Flip the foot end of the bed from the box
and lay it on top of the head end. 4Install the remaining 2 legs on the
foot end of the bed, make sure the
legs are tight.
Uncoil the DC power cord (connected
to the control box) and put it to the
side of the bed.
3
HEAD BOARD
HEAD BOARD
DC Power Cord
Control Box

—05—
Customer Service Toll Free: 1-844-696-6886
5Make the bed completely flat.
HEAD BOARD
6one side after another.
Install the mattress retainer bar
2
1
DONE!
7Uncoil the AC power cord, connect the DC power cord to the power supply and then connect the
power supply to the AC power source.
Insert the batteries into
the remote control.
HEAD
TV
1 2
Z-G
SNORE
FOOT
AC Power Cord
AC Power Source
DC Power Cord
Power Supply
HEAD BOARD
Standard Power Foundat ion Setup

—06—
Customer Service Toll Free: 1-844-696-6886
Power Foundat 

1Take the bed out of the box, put it on the slat base
, do not install any legs. Uncoil the DC power
cord (connected to the control box)， pull the DC power cord towards the direction of the AC power
source through either the bottom or the side of the bed frame.
DC Power Cord
HEAD BOARD
HEAD BOARD
DC Power Cord
2Make the bed completely flat
with a
flipping motion .3Install the mattress retainer bar one side
after another.
HEAD BOARD
DC Power Cord
2
1
Two people are required to setup the foundation.

4Uncoil the AC power cord, connect the DC power cord to the power supply and then connect the
power supply to the AC power source.
—07—
Customer Service Toll Free: 1-844-696-6886
HEAD
TV
1 2
Z-G
SNORE
FOOT
Insert the batteries into
the remote control.
HEAD BOARD
AC Power Cord
AC Power Source
DC Power Cord
Power Supply
DONE!
Power Foundat 



Customer Service Toll Free: 1-844-696-6886
Electronics Quick Reference Guide
Synchronizing Two Foundations
If simultaneous operation of two foundations is desired, use the sync cord to connect the electronics of
both foundations together.
STEP 1：Unplug foundations from the power source.
STEP 2：Connect the male ends of the sync cord to the female sync plugs of the control boxes (Refer to below illustration).
STEP 3：Plug foundations back into the power source.
STEP 4：Check to ensure all cords are securely attached.Either remote will operate both foundations simultaneously.
Sync Plug
Sync Plug
Control Box 1 Control Box 2
Sync Cord
Control Box 1
HD Motor
LED APP SYN
FT Motor USB Power
HD Motor
LED APP SYN
FT Motor USB Power
Synchronizing Two Foundations
OVERVIEW
USB
Charger
Power Supply
LED
Sync Cord
Head Motor Foot Motor
HD Motor
LED APP SYN
FT Motor USB Power
HEAD
TV
1 2
Z-G
SNORE
FOOT
DC
Power Cord AC
Power Cord
WIRELESS RECEIVER
CB11B
Control Box
Remote Control


ions
Customer Service Toll Free: 1-844-696-6886
REMOTE
ADJUST
This button lifts the head/foot section of the
foundation.
This button lowers the head/foot section of the
foundation.
UNDERNEATH LED LIGHTING
One touch underneath LED lighting on/off.
ONE TOUCH BUTTON
One touch ANTI-SNORE preset position.
SNORE
One touch TV preset position.
TV
One touch ZERO G preset position. ZERO G
adjusts your legs to a higher level than your heart,
helping to relieve pressure of the lower back and
promote circulation.
Z-G
One touch programmable positions.
2
1
One touch flat position.
Lifts and
Lowers Head
Lifts and
Lowers Foot
Under Bed
LED on/off
Home Position
Programmable
Positions
Zero G Preset
Position
Anti-Snore
Preset Position
TV Position
HEAD
TV
1 2
Z-G
SNORE
FOOT

—10—

Customer Service Toll Free: 1-844-696-6886
The original remote that comes in the box is already paired to the foundation. No further action is required.
In the event when the remote is not paired with the foundation, follow the following to pairing instructions.
PAIRING REMOTE
Setting Programmable Position
HEAD
TV
1 2
Z-G
SNORE
FOOT
Adjust the head and foot to your desired position.
To adjust a saved position, repeat step 1 and 2 and the new position will be saved.
Press and hold the LED on/off button first, then press and hold one of the picture programmable
buttons for 5 seconds until you hear a beep sound. The position is then saved.
1 2
STEP 1：
STEP 2：
STEP 3：
Make sure the batteries are good. Replace them when needed.
Unplug the power cord from the power source. If 9V backup batteries
were installed in the power supply, remove them.
Press and hold and simultaneously until the blue backlights
of the remote control are off.
STEP 1：
STEP 2：
STEP 3：
STEP 4：
Plug the power cord back into the power source. You will hear an activation
sound in 2 seconds, indicating the remote is paired to the power foundation.

—11—
Customer Service Toll Free: 1-844-696-6886
Headboard Bracket Installat
Guide (Opt

ion
A 1/2'' (13 mm) socket and 1/2'' (13 mm) wrench are necessary to complete installation.
HEADBOARD BRACKET COMPONENTS
(2) Headboard Brackets (2) T-Brackets (8) Bolts M8*16 (4) Nuts
a)Align the slot hole of the headboard bracket to the sleeve into
which the leg threads. DO NOT OVERTIGHTEN. Too much force
may damage the thread.
b)The headboard bracket has 2 adjustable slots to accommodate
any frame type. Use the bolts and Washers to secure the bracket.
Make sure the bolts are tight.
a)To put the T-Bracket and Headboard Bracket together, you will
need (2) M8×16 bolts and (2) nuts. Slip the bolts through the holes
from T-Bracket to Headboard Bracket with the head of bolt facing
outward. Use the 1/2” (13 mm) socket and 1/2” (13mm) wrench to
tighten the bolts.
You may now connect your headboard to the attachment plates using the remaining short bolts and nuts to secure it to the brackets. The heads of
the bolts will face outward. Use a 1/2” (13mm) socket and 1/2” (13mm) wrench to tighten the bolts.
(4) Washers
12
2
1

—12—
Customer Service Toll Free: 1-844-696-6886
Mobile APP (Optional)
* The effective connection range is ± 10m
8
7
6
5
4
3
2
1
List of Products within the connection range*
Tap the Refresh Button to refresh the Products List
Enter the Settings Page
Back to the Home Screen
9
Serial Number of the control box
Owner’s Manual Page
Troubleshooting
Disconnect from the paired Product
Rename your Power Foundation of your choice
Home Screen
Settings Page
SELECT DEVICE
BED
Refresh
3
1
2
9
SETTINGS
DISCONNECT
Serial Number
5
4
RENAME
OWNER’S MANUAL
6
7
TROUBLESHOOTING
8
APP Home Screen
Device Pairing
Mobile APP is a mobile application to control the Power Foundation with mobile devices. The application is available for both iOS and Android
based smart devices. The Mobile APP uses the latest technology to communicate with your Power Foundation. Make sure your mobile devices has
the pairing function for the APP to work correctly.
GET
+INSTALL
Before you start. Switch on the pairing function on your mobile device. Make sure your Power Foundation is correctly connected and is power-on.
The APP will automatically pair your Power Foundation once you start the APP and does not require additional settings.
General Information
Install the APP
* Remote interface varies in between different Power Foundation models. If you wish
to disconnect from the current paired Power Foundation, Enter the Settings Page and
tap the
Disconnect button.
1
5
4
3
2
6
Enter the Settings Page
Head Lifting function
Head Lowering function
Foot Lifting function
Foot Lowering function
One touch flat Position
12
11
10
9
8
7
Anti-Snore Preset Position
TV Position
Zero G Preset Position
Programmable Position 1
Programmable Position 2
Under Bed Lighting
REMOTE CONTROL
SNORE
TV Z-G
2
1
1
2
8
3 5
4 6
7 9
1110 12
APP Remote Control
POWER BOB

Head and/or Foot lift function has minor interference durling
operation.
Check batteries in remote control, replace with three (3) new AAA
batteries if necessary.
Make sure that you are following the duty cycle of the motors (do
not operate more than [2] minutes in an [18] minute time period or
approximately 10% duty cycle).
Press the lift buttons squarely and accurately.
Remote control may be experiencing common Radio Frequency
Interference from other radio transmitting devices. Wait several
seconds, and then try pressing appropriate button again, See FCC
COMPLIANCE statement on page 1 of this guide.
A clicking noise is heard under the bed when raising or lowering. This is normal. The lift motor relays “click” when they are engaged.
No action is required.
—13—
Customer Service Toll Free: 1-844-696-6886
Troubleshooting
In the event that the power foundation fails to operate, assess the symptoms and possible solutions
provided in the chart below.
SYMPTOMS SOLUTIONS
Remote control illuminates and appears to be operable, but will not
activate bed.
Head or foot section will elevate, but will not return to the horizontal
(flat) position.
No features of the power foundation will activate.
Remote will not illuminate. Replace the batteries in the remote.
Verify that the power cord is plugged into a working, grounded
electrical outlet. Test the outlet by plugging in another working
appliance.
Program the remote control (see the Setting Programmable Positions
and Pairing Remote section of this manual for programming
procedures).
Unplug the power cord, wait 30 seconds and plug back to reset
electronic components.
The electrical outlet may be defective. Test the outlet by plugging in
another working appliance.
Bed mechanism may be obstructed. Elevate bed and check for
obstruction. Remove obstruction.
Head section may be too close to the wall.
Headboard may be too close to the edge of the mattress. Verify
that there is enough distance between the headboard brackets and
mattress. Adjust if required.
