bObsweep SW603001 User manual

OWNER’S MANUAL
How to employ your intelligent floor cleaner
bObi Classic™ | Model SW603001

Congratulations on your new intelligent floor cleaner! bObi is now at your
service. To see bObi at her best, please read the Quick Start Guide and this
manual thoroughly. Welcome to the bObsweep family and happy cleaning!
If you have any questions or concerns, feel free to contact our helpful team at
[email protected] or 1-888-549-8847 for support in the US & Canada.
Our business hours are Monday – Friday 9 am – 5 pm, PST.
Congratulations!

ChargingGet bObi
Ready to Clean
Remote Control
Box ContentsImportant Safety
Instructions
Anatomy
1711 22
64 7
Parts &
Maintenance
Warranty
& FAQs
Cleaning Schedule Troubleshooting
& Home Checkup
End User
License Agreement
38
73
27 54
79

Basic safety precautions should always be followed, including the following:
•To protect against electrical shock, do not immerse any part of bObi — with the exception of her
mopping cloth — into water or other liquids. bObi’s dustbin may be washed with water only once
her motor has been removed.
• Turn bObi OFF and unplug her from outlet when she is not in use and before conducting
maintenance.
•If bObi, her remote control, charging station, or blOck (not included) has been damaged, do
not operate them. Contact our customer care center at [email protected].
•Do not handle bObi, her remote control, blOck (not included), or her charging station with wet
hands; use only on dry surfaces.
•Do not use bObi outdoors.
•bObi is not intended for use by persons (including children) with reduced physical or mental
capabilities, or lack of experience and knowledge, unless under the close supervision of a
person responsible for their safety.
•Do not pull or carry the charging station by the cord, use the cord as a handle, close a door
on the cord, or pull the cord around sharp edges or corners. Keep the cord away from heated
surfaces. To unplug the cord grasp the plug, not the cord.
•Do not mutilate or incinerate the battery, as it will explode at high temperatures.
•Leaks from battery cells can occur under extreme usage or temperature conditions. If the liquid
gets on skin, wash quickly with water. If the liquid gets into the eyes, flush them immediately
with clean water for a minimum of 10 minutes, and seek medical attention.
•Do not dispose of your battery in fire. Old batteries should be recycled safely (check with your
local recycler).
•Do not attempt to open the charging station. Repairs on the station should only be carried out
by our qualified customer care center.
•Do not expose bObi, her remote control, or charging station to temperatures higher than 113° F
(45° C), moisture, or humidity.
•Do not let bObi pick up toxic materials (chlorine bleach, ammonia, drain cleaner, etc.).
• Do not let bObi pick up anything that is burning or smoking, such as cigarettes, matches, or
hot ashes. Do not use bObi to pick up flammable or combustible liquids such as gasoline, nor
use her in areas where they may be present.
• Do not use bObi in an enclosed space filled with vapors given off by oil-based paint, paint
thinner, moth-proofing substances, flammable dust, or other explosive or toxic vapors.
Important Safety Instructions

• bObi is composed of electronic components that in rare and unintended cases can cause
hazards of heating, fire, and other malfunctions. Furthermore, because bObi is capable of
and intended for autonomous movement and cleaning, her use poses the risk of collision with
property, pets, and persons and unintended removal of articles, such as small valuables,
jewelry, or hair of persons or pets lying on the floor, among others.
•Do not look directly into the UV light.
•Do not use bObi for other than intended usage.
Declaration of Conformity
This device complies with Part 15 of the FCC rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
The manufacturer is not responsible for any radio or TV interference caused by unauthorized
modifications or change to this equipment. Such modifications or change could void the user’s
authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that inter-
ference will not occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.

1
2
34
5
6
789
10 11
12
13
14
15 16
Box Contents
1bObi Classic
2Charging Station
3Spare Main Brush
4Charging Adapter
5Remote Control
6Screwdriver
7Spare Side Brush
8Cleaning Tool
9Pack of Screws
10 Blindfold Stickers
11 Mini-Mop Attachment
12 2 Microfiber Mopping Cloths
13 Spare HEPA Filter
14 Owner’s Manual, Quick Start Guide, Warranty Card
15 Syncing Tool
16 2 Spare Main Brush Holders

7
1
2
3
5
6
7
8
4
Anatomy
Top View
1Cover
2Touchscreen Buttons
3Transmitter
4Charging Indicator
5Touch Sensors
6Wall Sensors
7Charging Inlet
8Power Switch
Anatomy

8
RL
1
2
5
4
6
7 78
9
10
3
Bottom View
1 Main Brush
2 Rubber Brush
3 Dustbin
4 Right Wheel
5 Left Wheel
6 Side Brush
7 Edge Sensors
8 Front Wheel
9 UV Light
10 Battery

9
1
2
1Charging Station
2Remote Control

10
2 31
Touchscreen Buttons
1 GO!
bObi will clean on her default cleaning mode
2 JUICE
bObi will search for her charging station to refuel
3 WAFFLE
bObi will clean a localized mess

Get bObi
Ready to Clean
Install the Battery 12
First Charge 13
First Clean 15
Touchscreen Buttons 16

12
Before bObi’s first clean, you must install her battery. Make sure bObi’s power
switch is turned OFF.
Install bObi’s Battery
Remove the battery cover
using a Phillips head
screwdriver.
Plug the battery in at the
circuit junction. Tuck the
wire into the side of the
compartment and slide
the battery in.
Replace the cover and
retighten the screws.
1 2 3
After installing bObi’s battery, charge bObi for 8 hours before first use.

13
Charge bObi
Plug the charging adapter into the side
of the charging station. The station’s
blue power light will turn on.
Place bObi on her charging station with
the metal nodes on her front resting
against the plates on her station.
bObi will chirp, her lights will flash, and the center light will blink to
indicate that she is charging. The other lights will disappear.
1 2
The center light on
bObi will remain
solid when she’s
fully charged and
ready to clean.

14
Alternatively, you may charge bObi by plugging the charging adapter into the
inlet above her power switch.

15
bObi is now ready to clean!
Flip her power switch ON, and press the GO! button on her cover or remote.
bObi will clean on her default setting.
If bObi is left idle with her power switch ON, her screen will go blank and she
will enter standby mode. To wake bObi, tap her touchscreen. To fully power off
bObi, flip her power switch OFF.
bObi’s First Clean
Clear the area of small
items and cords before
asking bObi to clean.

There are three touchscreen buttons on bObi: GO!, JUICE, and WAFFLE.
These buttons do not work while bObi is on her charging station. To use these
buttons, you must first remove bObi from her charging station.
Alternatively, you can use bObi’s remote to select her cleaning modes without
needing to remove her from her charging station.
Touchscreen Buttons
GO!
GO! is bObi’s default cleaning mode. bObi will clean a large area until her
battery reaches 15% capacity, and then she will return to her charging station.
JUICE
JUICE tells bObi to return to her charging station. bObi will not vacuum while
in JUICE mode.
WAFFLE
WAFFLE can be used to clean up small spills of dry substances. bObi will clean
an area of 10 square feet (1 square meter) for about 1 – 3 minutes before she
stops and enters standby mode.

Charging
Placement 18
Auto Charging 19
Manual Charging 21

2 ft (0.5 m)
2 ft (0.5 m)
10 ft (3 m)
•Position bObi’s charging station against a wall on a hard, flat surface.
•Make sure that there is at least 10 feet (3 m) of open space in front of the
charging station and 2 feet (0.5 m) on either side of the station.
Secure bObi’s charging adapter behind her station so the cord does not
get in her way while she is cleaning.
Charging Station Placement

19
bObi automatically searches for her charging station when her battery reaches
15% capacity. She will chirp, stop vacuuming, and display JUICE on her cover
while searching. When bObi detects her charging station, she will line herself
up, dock, and begin to charge. If bObi has trouble finding her station, you likely
need to sync the station.
To sync the charging station:
Auto Charging
Flip bObi’s power switch
OFF.
Plug the adapter into the
charging station.
Use the syncing tool that
came in bObi’s box to
press the sync button on
the back of the station.
1 2 3

Direct bObi to her charging station at
any time by pressing the JUICE button
on her cover or remote.
To prolong bObi’s
battery life, ip her
power switch OFF
when not in use.
While still pressing the sync button, flip
bObi’s power switch ON.
bObi will chirp twice to let you know the
sync was successful.
4 5
