Important
Update to the ProMatrix Overview
The PM3000 now includes balanced & unbalanced line level outputs.
Outputs: 0 dBV balanced outputs via screw
terminal strips (all channels);
0 dBV unbalanced outputs via RCA
jacks (all channels)
Maximum Output: 15 dBV into 600Ωbalanced
Maximum Gain: 17.7 dB (Vol. control @ 25)
Input Sensitivities: Aux Input: 100mVRMS to 2.5VRMS
Mic Inputs: 750µVRMS (no ALC)
Tel Input: 170mVRMS
Input Impedance: Aux Input: 50k ohms unbalanced
Mic Inputs: 200 ohms balanced
Tel Input: 600 ohms transformer-
balanced
Frequency Response
& Distortion
(20 Hz to 20 kHz): Aux Inputs: 20 Hz to 20 kHz
+/-2 dB<0.1% THD+N
Mic Inputs: 100 Hz to10 kHz
+/-2 dB<0.1% THD+N
Signal To Noise
(20 Hz to 20 kHz): Aux Inputs: -70 dBr
Mic Inputs: -55 dBr
Tel Input: -55 dBr
Volume Control: 25 step digital
Tone Controls: Bass: +/-10 dB @ 50 Hz in 15 steps
Treble: +/-10 dB @ 15 kHz in 15
steps
Phantom Power Supply: 13V DC switchable, all mic inputs
Power Consumption: 120V AC @ .25A,
240V AC @ .15A
Dimensions: 17" W x 5-1/2" H x 8-1/2" D
Weight: 12 lb.
50 Spring Street, Ramsey, NJ 07446, U.S.A.
Tel: [phone]; Fax: [phone]; www.bogen.com
Specifications
Specifications subject to change.
Part No. 54-6699-01R2
Addendum to 54-9109-01
Printed in U.S.A. 0212
