bolid S2000-IP-03 User manual

ANALOG ADDRESSABLE
RATE-OF-RISE AND FIXED TEMPERATURE DETECTOR
IP 101-55-A1R “S2000-IP-03”
USER’S MANUAL

3
TABLE OF CONTENTS
1 Description and Operation ................................................................................................ 5
1.1 Product Purpose ........................................................................................................... 5
1.2 Specifications............................................................................................................... 6
1.3 Scope of Delivery......................................................................................................... 7
1.4 Arrangement and Operation ......................................................................................... 7
1.5 Measuring Instruments, Tools, and Accessories ........................................................... 8
1.6 Marking ....................................................................................................................... 8
1.7 Packing ........................................................................................................................ 8
2 Intended Use..................................................................................................................... 9
2.1 Operating Restrictions.................................................................................................. 9
2.2 Preparing for Use ......................................................................................................... 9
2.2.1 Safety Measures During Preparation ........................................................................ 9
2.2.2 Design ..................................................................................................................... 9
2.2.3 Mounting ............................................................................................................... 11
2.2.4 Wiring ................................................................................................................... 12
2.2.5 How to Open the Detector...................................................................................... 12
2.2.6 Indication............................................................................................................... 12
2.2.7 Programming the Detector ..................................................................................... 13
2.3 Operating the Detector ............................................................................................... 14
2.3.1 Testing Operability ................................................................................................ 14
2.3.2 Extreme Situation Actions ..................................................................................... 14
2.3.3 Troubleshooting..................................................................................................... 14
3 Maintenance ................................................................................................................... 15
3.1 General ...................................................................................................................... 15
3.2 Safety Precautions...................................................................................................... 15
3.3 Maintenance Procedures............................................................................................. 15
3.4 Testing Operability .................................................................................................... 15
3.5 Technical Examination............................................................................................... 16
3.6 Preservation (Depreservation, Represervation)........................................................... 16
4 Repair............................................................................................................................. 16
5 Storage ........................................................................................................................... 16
6 Transporting ................................................................................................................... 16
7 Disposal ......................................................................................................................... 17
8 Manufacturer Warranty................................................................................................... 17
9 Certification Information ................................................................................................ 17

4
This User’s Manual explains the principles of operating S2000-IP-03 Analog Addressable
Rate-of-Rise and Fixed Temperature Detector of the software version 1.10.
Only the personnel who have studied this manual are allowed to operation activities. All
activities on mounting, programming and commissioning shall be performed in compliance with the
requirements of the regulatory documentation in force at the place of operation.
List of abbreviations:
FACP: Fire Alarm Control Panel;
ISS: Integrated Security System;
PL: Polling Loop.

5
1Description and Operation
1.1 Product Purpose
1.1.1 S2000-IP-03 Analog Addressable Rate-of-Rise and Fixed Temperature Detector (hereinafter
referred to as the detector) is to be used in fire detection and fire alarm systems to protect premises
against fires by monitoring the rate of ambient temperature rise and to generate fire alarms
automatically.
1.1.2 The detector is meant to operate under a polling loop controller S2000-KDL, S2000-KDL-2I,
S2000-KDL-2I Rev.01, or S2000-KDL-S as a part of an Orion ISS. The detector is powered and
communicates data over the multiplex addressable polling loop (hereinafter referred to as PL).
1.1.3 The detector is intended for round-the-clock operation.
1.1.4 The detector is classed as a restorable, regularly maintainable product.
1.1.5 The detector’s design doesn’t imply operating it in aggressive and dusty environments or in ex-
hazardous premises.

6
1.2 Specifications
Table 1.2.1
Parameter Value
1.2.1 Power supply voltage (via Polling Loop) 8 V through 11 V
1.2.2 Consumed current 0.6 mA max
1.2.3 Number of detectors within a Polling Loop 127 max
1.2.4 Maximum active resistance of polling loop wires 100 ohms max
1.2.5 Minimum insulation resistance between polling loop wires 50k ohms min
1.2.6 Start-up Time 60 s max
1.2.7 Detector Class A1R
1.2.8 Fixed Temperature (factory setting) +54°С
1.2.9 Heat detection accuracy ± 1.5°С
1.2.10 Enclosure protection degree as per GOST 14254-2015 IP41
1.2.11 Resistance to mechanical exposure as per OST 25 1099-83 Arrangement Category III
1.2.12 Vibration exposure:
- Frequency range
- Max acceleration
1-35 Hz
0.5 g
1.2.13 Environmental category as per OST 25 1099-83 О3
1.2.14 Operating temperature Minus 30°Сto +55°С
1.2.15 Relative humidity Up to 95 % at +40 °C
1.2.16 Weight 0.2 kg max
1.2.17 Overall dimensions:
- Diameter
- Height
100 mm max
47 mm max
1.2.18 Non-stop operation Round-the-clock
1.2.19 MTBF 80,000 hours min
1.2.20 Reliability (10 years) 0.98758
1.2.21 Expected service life 10 years
1.2.22 In terms of immunity to electromagnetic interference, the detector meets the requirements of
Test Severity Level III as per the relevant standards listed in Appendix ‘Б’ to GOST R 53325-2012.
1.2.23 The detector passes the industrial interference standards prescribed for Class ‘Б’ equipment as
per GOST R 30805.22.

7
1.3 Scope of Delivery
The detectors are delivered in group packages, being packed in ten pieces.
The standard delivery is shown in Table 1.3.1.
Table 1.3.1
Item Quantity
S2000-IP-03 Detector (body) 10 pcs.
S2000-IP-03 Detector Base 10 pcs.
Accessory Kit:
Dust Cover
Address Label
MK-2 Recessed Mounting Kit*
MK-3 Recessed Mounting Kit*
Protection Wire Cage*
10 pcs.
10 pcs.
—
—
—
Documentation
S2000-IP-03 Analog Addressable Rate-of-Rise and Fixed Temperature Detector
Operations Manual 1pc.
* – Supplied by separate order
1.4 Arrangement and Operation
1.4.1 The detector comprises a printed circuit board, an assembled detector body, and a mounting
base.
The printed circuit board integrates a microcontroller, a thermal resistor, a tact switch, and a
LED.
On the detector body cover there is a pushable lightpipe conducive to the LED; pressing on the
lightpipe transmits effort to the button.
The microcontroller registers ambient temperature in degrees centigrade based on the resistance
of the thermal resistor. Through processing the data received from the thermal resistor, with the
growth of their values and exceeding the threshold the microcontroller issues alarms.
The microcontroller via the LED indicates the detector status and also can receive light beams
emitted by a laser test unit.
Exposing lightpipe to the laser light beam or pressing on it is required for some manipulations
with the detector described in the section “2 Intended Use”.
System Sensor remote test units, Astra-942 Laser Tester from the TEKO Company, or OT-1
Optical Tester from the RUBEZH Company are acceptable to be used as remote laser testers.
1.4.2 The detector supports DPLS_v2.xx protocol and provides measuring of the addressable loop
voltage at the point where it is connected.
1.4.3 The detector can operate in one of the following modes:
−Norm: The temperature value varies within the normal range;
−Fire Alarm: The temperature value has exceeded the preset fire threshold or is detected
to rise at a high rate;
−Fault: The thermal resistor has failed;
−Test: Sending a test event in case of a manual operation (pressing on the lightpipe or
lighting the lightpipe with a laser tester beam);
−Programming: a Set Device Address command has been received via the polling loop
from the polling loop controller;

8
−Startup: The detector has been fed from the PL controller, but no request on the detector
address has yet been received.
1.5 Measuring Instruments, Tools, and Accessories
While mounting, commissioning, and maintaining the detector please use the instruments, tools,
and accessories shown in Table 1.5.1.
Table 1.5.1
Instrument Specifications
Digital multimeter AC/DC voltage up to 500 V, AC/DC current up to 5 A, resistance up to
2 MOhm
Flat head screwdriver 3.0
×
50 mm
Cross slot screwdriver 2
×
100 mm
Side-cutting pliers 160 mm
Pliers 160 mm
1.6 Marking
1.6.1 Every detector has a marking applied to the rear side of its body.
1.6.2 The marking contains the company logo, the detector’s name, its decimal number, factory
number, the year and quarter of production, and conformity marks.
1.6.3 Sealing the detector is not provided.
1.7 Packing
The detectors along with accessory kit and operation documentation are packaged in a
cardboard box.

9
2Intended Use
2.1 Operating Restrictions
The design of the detector doesn’t imply operating it in aggressive and dusty environments and
in explosion and fire hazardous premises.
Correct performance of the detector cannot be guaranteed if its electromagnetic environment
does not meet the operation conditions defined in Section 1.2 of this manual.
2.2 Preparing for Use
2.2.1 Safety Measures During Preparation
–The design of the detector meets the requirements of electrical and fire safety including
emergency operation in accordance with Russian Standards GOST 12.2.007.0-75 and
GOST 12.1.004-91;
–The detector has no circuits under a hazardous voltage;
–Do SHUT OFF power from the detector before mounting, installing, and maintaining this one;
–Mounting and maintenance of the detector shall be carried out by persons with the second or
higher accident prevention qualification level.
2.2.2 Design
Figure 2.2.2.1 represents the appearance of the detector.
Figure 2.2.2.1

10
Overall dimensions are shown in Figure 2.2.2.2 (the side view) and Figure 2.2.2.3 (the bottom
view).
Figure 2.2.2.2
68.4*
1
6,4
*
5
*
2
3
5
6
Figure 2.2.2.3

11
Mounting dimensions are shown in Figure 2.2.2.4.
Figure 2.2.2.4
2.2.3 Mounting
While considering mounting location for the detectors, please be guided by actual national
codes and mounting rules for fire detectors - for example, by the code of practice “СП
484.1311500.2020”, in particular by the requirements shown in the table 1.
Supervised Room Height, m Detection Area Radius, m
Up to 3.5 3.55
More than 3.5 to 6.0 inclusive 3.20
More than 6.0 to 9.0 inclusive 2.85
If it is not possible to install detectors on a flat slab, these ones can be suspended by steel ropes
(strings) or installed on walls, columns and other bearing building structures as per Clause 6.6.9 of
the code of practice “СП 484.1311500.2020”.
Mounting kits MK-2 or MK-3 (supplied per a separate order) can be used for attaching the
detectors to a suspended ceiling.
To provide mechanical protection for the detector, a Protection Wire Cage can be used, which is
to be supplied separately.
For mounting the detector, the base plate supplied is to be used (see Figure 2.2.3.1).
Figure 2.2.3.1
Warning!
To install the detector into the base plate, align the guide on the detector with the
short guide on the base plate. Then turn the detector clockwise until the detector guide
is aligned with the guide 2 as shown in Figure 2.2.3.1.
Mounting and dismounting the detector shall be carried out with its power being
off.
1: Base Plate
2: Alignment Guide
