BONFIGLIOLI DGM MPM User manual

Operating manual for DGM Modular | DOC02389740-0006 | 2021-07 | V1.70 EN 1

2 Operating manual for DGM Modular | DOC02389740-0006 | 2021-07 | V1.70 EN

Operating manual for DGM Modular | DOC02389740-0006 | 2021-07 | V1.70 EN
3

4
Operating manual for DGM Modular | DOC02389740-0006 | 2021-07 | V1.70 EN
Summary
1. General information......................................................5
1.1 Information about documentation....................................5
1.1.1 Other applicable documents............................................5
1.1.2 Storing the documentation ..............................................5
1.2 Notes in this manual........................................................5
1.2.1 Warnings ........................................................................5
1.2.2 Warning symbols used....................................................6
1.2.3 Signal words...................................................................6
1.2.4 Information notes............................................................6
1.3 Symbols used in this manual...........................................6
1.4 Labels on the drive controller..........................................7
1.5 Qualified staff..................................................................7
1.6 Proper use......................................................................7
1.7 Responsibility..................................................................8
1.8 CE marking.....................................................................8
1.9 Safety instructions...........................................................8
1.9.1 General information ........................................................8
1.9.2 Transport & storage ........................................................9
1.9.3 Information about commissioning....................................9
1.9.4 Instructions concerning operation..................................10
1.9.5 Maintenance and inspection..........................................11
1.9.6 Repairs.........................................................................11
2. Overview of the drive controller.................................12
2.1 Model description..........................................................12
2.2 Scope of delivery ..........................................................14
2.2.1 Sizes A-C......................................................................14
2.2.2 Size D...........................................................................14
2.3 MMI*/connecting cable PIN assignment.......................15
2.4 Description of DGM Modular drive controller.................15
3. Installation...................................................................16
3.1 Safety instructions for installation..................................16
3.2 Recommended preliminary fuses / line protection .........16
3.3 Installation requirements...............................................17
3.3.1 Suitable ambient conditions ..........................................17
3.3.2 Suitable installation location for the motor-integrated drive
controller.......................................................................18
3.3.3 Wiring instructions.........................................................19
3.3.4 Preventing electromagnetic interferences......................21
3.4 Installing the drive controller integrated in the motor......21
3.4.1 Mechanical installation..................................................21
3.4.2 Power connection .........................................................25
3.4.3 Connections for brake resistor.......................................28
3.4.4 Connection using Harting plug......................................29
3.4.5 PHOENIX Quickon connection......................................30
3.4.6 Connection via main switch...........................................30
3.4.7 Mains supply connection variant with brake module, size
A...................................................................................31
3.4.8 Connection of mechanical brake to brake module.........31
3.4.9 Connection diagram (IO module option)........................32
3.4.10 Basic fieldbus integrated on DGM Modular ...................33
3.4.11 IO module / assignment of plugs (option)......................34
3.5 Installing the wall-mounted drive controller....................36
3.5.1 Suitable installation location for wall mounting...............36
3.5.2 Mechanical installation of sizes A - C............................36
3.5.3 Mechanical installation of size D ...................................41
4. Commissioning...........................................................46
4.1 Safety instructions for commissioning ...........................46
4.2 Communication.............................................................46
4.3 Block diagram...............................................................48
4.4 Commissioning steps....................................................49
4.4.1 Commissioning using the PC ........................................49
4.4.2 Commissioning using PC, combined with MMI option....50
5.
Parameter....................................................................51
5.1 Safety instructions for working with parameters.............51
5.2 General information on parameters...............................51
5.2.1 Explanation of operating modes....................................51
5.2.2 Structure of the parameter tables..................................52
5.3 Application parameters..................................................53
5.3.1 Basic parameter............................................................53
5.3.2 Fixed frequency ............................................................57
5.3.3 Analogue inputs............................................................58
5.3.4 Digital inputs.................................................................59
5.3.5 Digital outputs...............................................................60
5.3.6 Virtual output.................................................................61
5.3.7 External error................................................................62
5.3.8 Motor current limit .........................................................63
5.3.9 Blocking detection.........................................................63
5.3.10 Additional functions.......................................................64
5.3.11 MMI parameter..............................................................65
5.3.12 Fieldbus........................................................................66
5.3.13 Torque control / limit......................................................67
5.4 Performance parameters...............................................69
5.4.1 Drive type......................................................................69
5.4.2 Motor data.....................................................................69
5.4.3 I2t..................................................................................72
5.4.4 Switching frequency......................................................73
5.4.5 Controller data ..............................................................74
5.4.6 Quadratic characteristic curve.......................................77
5.5 Activation of brake module............................................78
6. Error detection and troubleshooting..........................82
6.1 List of the LED flash codes for error recognition ............82
6.2 List of errors and system errors.....................................83
7. Disassembly and disposal..........................................86
7.1 Drive controller disassembly..........................................86
7.2 Information on correct disposal......................................86
8. Technical data.............................................................87
8.1 General data.................................................................87
8.1.1 General technical data for 400V devices .......................87
8.1.2 Specification of interfaces..............................................89
8.2 Derating of output power...............................................89
8.2.1 Derating due to increased ambient temperature............90
8.2.2 Derating due to installation altitude................................91
8.2.3 Derating due to switching frequency..............................92
9. Optional accessories..................................................92
9.1 MMI handheld controller including a 3 m RJ9 connection
cable with M12 plug ......................................................92
9.2 PC communication cable USB on M12/RS485 plug
(converter integrated)....................................................92
10. Approvals, standards and guidelines........................93
10.1 EMC limit classes..........................................................93
10.2 Classification acc. to IEC/EN 61800-3 ..........................93
10.3 Harmonics currents and grid impedance for devices > 16
A and ≤75 A.................................................................93
10.4 Standards and guidelines..............................................93
10.5 UL approval ..................................................................94
10.5.1 UL Specification (English version).................................94
10.5.2 Homologation CL (Version en française).......................95
11. Quickstart guide..........................................................96
11.1 Quickstart guide............................................................96
11.2 Quickstart guide for synchronous motors.......................97
12. Index............................................................................98

Operating manual for DGM Modular | DOC02389740-0006 | 2021-07 | V1.70 EN
5
1. General information
Thank you for choosing an DGM Modular drive controller
from Bonfiglioli S.p.A.
Our DGM Modular line of drive controllers is designed to
be universally usable with all common motor types.
1.1 Information about documentation
The following information explains how to navigate
through the documentation.
Read this manual carefully in its entirety. It contains
important information for operating the DGM Modular.
We assume no liability for any damage resulting from non-
observance of this manual.
This manual is an integral part of the product and applies
exclusively to the DGM Modular from Bonfiglioli S.p.A.
Provide the operator of the system with this manual so it is
available when needed.
1.1.1 Other applicable documents
This refers to all manuals that describe how to operate the
drive controller system and any other manuals for the
equipment used.
1.1.2 Storing the documentation
Store this operating manual and all other applicable
documents carefully so they are available when needed.
1.2 Notes in this manual
1.2.1 Warnings
The warnings refer to life-threatening dangers. Serious injuries possibly resulting in death may occur.
Each warning consists of the following elements:
Fig. 1: Structure of the warnings
1 Warning symbol
2 Signal word
3 Type of danger and its source
4 Possible consequence(s) of failure to comply
5 Corrective actions
DANGER!
Risk of death due to electrical shock!
Death or serious injury!
De-energise drive controller and secure it against being restarted.

General information
6
Operating manual for DGM Modular | DOC02389740-0006 | 2021-07 | V1.70 EN
1.2.2 Warning symbols used
Symbol
Meaning
Danger
Danger due to electrical shock and
discharge
Danger due to electromagnetic fields
1.2.3 Signal words
Signal words are used to identify the severity of the
danger.
DANGER
Indicates a direct hazard with a high level of risk, which, if
not avoided, will result in death or serious injury.
WARNING
Indicates a hazard with a moderate level of risk, which, if
not avoided, will result in death or serious injury.
CAUTION
Indicates a hazard with a low level of risk, which, if not
avoided, may result in minor or slight injury or property
damage.
1.2.4 Information notes
Information notes contain important instructions for the
installation and problem-free operation of the drive
controller. These must be followed at all times. The
information notes also point out that failure to observe
instructions may result in damage to property or financial
loss.
Fig. 2: Example of an information note
Symbols within the information notes
Symbol
Meaning
Important information
Damage to property possible
Other notes
Symbol
Meaning
INFORMATION
Enlarged view
1.3 Symbols used in this manual
Symbol
Meaning
1., 1., 3.
…
Consecutive steps in a handling
instruction
➔
Effect of a handling instruction
✓
Final result of a handling instruction
◼
List
Fig. 3: Symbols and icons used
Abbreviations used
Abbreviation
Explanation
Tab.
Table
Fig.
Figure
It.
Item
Ch.
Chapter
IMPORTANT INFORMATION
The drive controller may only be assembled, operated,
maintained and installed by trained and qualified staff.

Operating manual for DGM Modular | DOC02389740-0006 | 2021-07 | V1.70 EN
7
1.4 Labels on the drive controller
Fig. 4: Labels on the drive controller
Signs and labels are affixed to the drive controller. These may not be altered or removed.
1.5 Qualified staff
In the context of this operating manual, qualified staff
refers to electronics specialists who are familiar with the
installation, assembly, commissioning and operation of the
drive controller and the dangers involved, and whose
specialist training and knowledge of relevant standards
and regulations provide them with the necessary abilities.
1.6 Proper use
If the device is installed in a machine, drive controllers
may not be commissioned (i.e. intended operation may not
begin) until it has been determined that the machine
complies with the regulations of EC Directive 2006/42/EC
(Machinery Directive); DIN EN 60204-1; VDE 0113-1 must
be observed.
Commissioning (i.e. beginning intended operation) is only
permitted if the EMC Directive (2014/30/EU) is complied
with.
The harmonised standards of DIN EN 50178; VDE 0160
must be applied for this drive controller along with DIN EN
61439-1/DIN EN 61439-2; VDE 0660-600.
This drive controller may not be operated in areas where
there is a danger of explosion!
Repairs may only be performed by authorised repair
bodies.
Independent and unauthorised intervention may result in
death, injury or property damage. The warranty provided
by Bonfiglioli will be invalidated in such cases.
IMPORTANT INFORMATION
◼
External mechanical loads on the housing are not
permitted!
◼
Using drive controllers in equipment that is not
fixed is considered as an exceptional
environmental condition and is only permitted if
allowed by the standards and guidelines applicable
on site.
Symbol
Meaning
Danger due to electrical shock and
discharge
Danger due to electrical shock and
discharge. Wait two minutes (discharge
time of the capacitors) after shut-down
Symbol
Meaning
Additional earth connection
Observe and read operating manual

General information
8
Operating manual for DGM Modular | DOC02389740-0006 | 2021-07 | V1.70 EN
1.7 Responsibility
As a basic principle, electronic devices are not fail-safe.
The operator and/or the contractor setting up the machine
or system is responsible for ensuring that the drive
switches to a safe state if the device fails.
The “Electrical equipment of machines” section in DIN EN
60204-1; VDE 0113-1, “Safety of machinery” describes the
safety requirements for electrical control units. These are
provided for the safety of people and machines and must
be observed in order to retain the functional capability of
the machine or system.
An emergency stop feature does not have to result in the
voltage supply to the drive being switched off. To avoid
dangerous situations, it may be useful for individual drives
to remain operational or for specific safety procedures to
be initiated.
The effectiveness of emergency stop measures is
evaluated by means of a risk assessment for the machine
or system and its electrical equipment and is determined
by selecting a circuit category according to DIN EN 13849
“Safety of machinery – Safety-related parts of control
systems”.
1.8 CE marking
Bonfiglioli Riduttori S.p.A. hereby declares that the drive
controller described in this document complies with the
basic requirements and other relevant conditions of the
directives listed below.
◼Directive 2014/30/EU
(on the approximation of the laws of the Member
States relating to electromagnetic compatibility
(EMC)).
◼Directive 2014/35/EU
(on the harmonisation of the laws of the Member
States relating to the making available on the market
of electrical equipment designed for use within certain
voltage limits –in short: Low Voltage Directive).
◼Directive 2011/65/EU
(Restriction of the use of certain hazardous
substances in electrical and electronic equipment, in
short: RoHS Directive)
◼Directive 2014/53/EU
(relating to the making available on the market of
radio equipment and repealing Directive 1999/5/EC)
1.9 Safety instructions
The following warnings, precautionary measures and
information are provided for your safety and serve to
prevent damage to the drive controller and the
components connected to it.
This chapter contains warnings and information that are
universally applicable when handling drive controllers.
They are split into General information, Transport &
storage and Disassembly & disposal.
Specific warnings and comments that apply to specific
activities can be found at the start of the appropriate
chapters and are repeated or added to at various critical
points in these chapters.
Please read this information carefully as it is provided for
your personal safety and will also prolong the life of the
drive controller and connected devices.
1.9.1 General information
IMPORTANT INFORMATION
◼
Carefully read this operating manual and the
warning signs affixed to the drive controller before
installation and commissioning. Make sure that all
warning signs on the drive controller are legible;
replace any missing or damaged signs.
They contain important information on the
installation and operation of the drive controller.
Note the information in the "Important information"
chapter.
Bonfiglioli Riduttori S.p.A. assumes no liability for
damages arising from the non-observance of this
operating manual.
This operating manual is an integral part of the
product. It applies exclusively to the drive
controller from Bonfiglioli Riduttori S.p.A..
Keep the operating manual close to the drive
controller so it is easily accessible to all users.
◼
The drive controller can only be operated safely if
the required environmental conditions listed in the
“Suitable environmental conditions” chapter are
met.

Operating manual for DGM Modular | DOC02389740-0006 | 2021-07 | V1.70 EN
9
1.9.2 Transport & storage
1.9.3 Information about commissioning
DANGER!
Risk of death due to electrical shock!
Death or serious injury!
De-energise drive controller and secure it
against being restarted.
DANGER!
Risk of death due to electrical shock!
Death or serious injury!
Always ground the device in accordance with
DIN EN 61140; VDE 0140, NEC and other
relevant standards.
The drive controller must be grounded with
the motor according to relevant regulations.
Non-compliance may result in death or
serious injury.
If spring elements are not used when
assembling the adapter plate, there must be
an extra connection between the motor and
drive controller to produce a correct
protective conductor connection.
DANGER!
Risk of death due to fire or electrical
shock!
Death or serious injury!
Always use the drive controller as intended.
Do not modify the drive controller.
Only use spare parts and accessories sold or
recommended by the manufacturer.
During assembly, ensure a sufficient distance
from neighbouring parts.
CAUTION!
Risk of burns from hot surfaces!
Serious burns to the skin from hot
surfaces!
Allow the drive controller's cooling
elements to cool sufficiently.
IMPORTANT INFORMATION
◼
If different voltages are used (e.g. +24 V/230 V),
crossing cable runs are not permitted under any
circumstances. The operator must also ensure
compliance with the applicable regulations
(e.g. double or reinforced insulation acc. to DIN EN
61800-5-1).
◼
The drive controller contains components
susceptible to electrical discharge.
These may be destroyed through improper
handling. Therefore, precautionary measures
against electrostatic charges must be taken when
work is performed on these components.
DAMAGE TO PROPERTY POSSIBLE
◼
Risk of damage to drive controller!
◼
Risk of damage to drive controller from improper
transport, storage, installation and assembly!
◼
In general, transport the drive controller correctly in
its original packaging on a pallet.
◼
Always store the drive controller properly.
◼
Only allow qualified staff to undertake installation
and assembly.
DANGER!
Risk of death due to revolving mechanical
parts!
Death or serious injury!
De-energise drive controller and secure it
against being restarted.
DANGER!
Risk of death due to electrical shock!
Death or serious injury!
De-energise drive controller and secure it
against being restarted.
The following terminals may lead to
dangerous currents even when the motor is
not running:
◼Supply terminals X1: L1, L2, L3
◼Motor connection terminals X2: U, V, W
◼Connecting terminals X6, X7: Relay
contacts for relays 1 and 2

General information
10
Operating manual for DGM Modular | DOC02389740-0006 | 2021-07 | V1.70 EN
1.9.4 Instructions concerning operation
IMPORTANT INFORMATION
◼
Only use mains connections with hardwiring.
◼
Ground the drive controller in accordance with DIN
EN 61140; VDE 0140-1.
◼
The DGM Modular may have touch currents
of > 3.5 mA.
In accordance with DIN EN 61800-5-1, an extra
protective grounding conductor of the same cross-
section as the original protective grounding
conductor should therefore be fitted. A second
protective grounding conductor can be connected
under the mains supply (position marked with a
ground symbol) on the outside of the device. A M6
x 12 screw (4.0 Nm torque)
suitable for this connection is provided with the
adapter plate.
◼
If three-phase frequency converters are used,
the use of conventional type A FI protection
switches RCDs (residual current-operated
protective devices) are not permissible as
protection against direct or indirect contact.
According to DIN VDE 0160 and EN 50178, the FI
protection switch must be universal current
sensitive (RCD type B).
IMPORTANT INFORMATION
Observe the following instructions during operation:
◼
The drive controller runs at high voltages.
◼
When electrical devices are operated, some of
their parts are always subject to dangerous
voltage.
◼
Emergency stop equipment according to DIN EN
60204-1; VDE 0113-1:2007-06 must function in all
the control device's operating modes. Resetting
the emergency stop equipment may not result in
uncontrolled or undefined restarting.
◼
In order to ensure safe disconnection from the
mains, the mains cable has to be fully
disconnected from the drive controller in a
synchronous manner.
◼
For devices of size D (11 to 30 kW), a pause of at
least 1 to 2 minutes must be observed between
consecutive mains activations
◼
A pause of at least 3 sec. must be observed
between consecutive mains activations for devices
with three-phase feed-in in sizes A - C (0.55 to 11
kW).
◼
Certain parameter settings may result in the drive
controller restarting automatically after the supply
voltage has failed.
DAMAGE TO PROPERTY POSSIBLE
If the information is not observed, the drive controller
could be damaged and destroyed during subsequent
commissioning.
Observe the following instructions during operation:
◼
The motor parameters, especially the I2t settings,
have to be configured properly to provide proper
motor overload protection.
◼
The drive controller has internal motor overload
protection. See parameters 33.010 and 33.011.
I2t is ON by default. Motor overload protection can
also be ensured via an external PTC.
◼
The drive controller must not be used as
"Emergency stop equipment"
(see DIN EN 60204-1; VDE 0113-1:2007-06).
DANGER!
Risk of death due to electrical shock!
Death or serious injury!
De-energise drive controller and secure it
against being restarted.
DANGER!
Risk of death due to revolving mechanical
parts!
Death or serious injury!
De-energise drive controller and secure it
against being restarted.

Operating manual for DGM Modular | DOC02389740-0006 | 2021-07 | V1.70 EN
11
1.9.5 Maintenance and inspection
The drive controllers may only be maintained and
inspected by electricians with recognised training. Unless
explicitly described in this operating manual, changes to
hardware and software may only be undertaken by
Bonfiglioli experts or persons authorised by Bonfiglioli
Riduttori S.p.A..
Cleaning the drive controllers
Drive controllers are maintenance-free if operated as
intended. If the air contains dust, the cooling ribs of the
motor and drive controller have to be cleaned regularly. If
devices are fitted with integrated fans, we would
recommend cleaning with compressed air.
Measurement of insulation resistance on
control part
An insulation test on the control card's input terminals is
not permitted.
Measurement of insulation resistance on
power stack
The power stack of an DGM Modular is tested with 2.02
kV in the course of series testing.
Should the insulation resistance have to be measured
during a system test, this can be done under the following
conditions:
◼an insulation test can be undertaken for the power
stack alone,
◼to avoid excessively high voltages, all the DGM
Modular's connection cables must be disconnected
before testing.
◼a 500 V DC insulation tester should be used.
Fig. 5: Insulation measurement on the power stack
Pressure test on an DGM Modular
1.9.6 Repairs
IMPORTANT INFORMATION
A pressure test is not permitted on a standard DGM
Modular.
DAMAGE TO PROPERTY POSSIBLE
If the information is not observed, the drive controller
could be damaged and destroyed during subsequent
commissioning.
◼
Repairs to the drive controller may only be
performed by the Bonfiglioli Service department.
Test object
DC insulation tester
Ground
DANGER!
Risk of death due to electrical shock!
Death or serious injury!
De-energise drive controller and secure it
against being restarted.
Danger due to electrical shock and
discharge. Wait two minutes (discharge
time of the capacitors) after shut-down.

Overview of the drive controller
12
Operating manual for DGM Modular | DOC02389740-0006 | 2021-07 | V1.70 EN
2. Overview of the drive controller
2.1 Model description
Sizes A - B
DGN-MPM
Inver Type
Recommended motor rating
A
B
PT03
0.55 kW
X
PT04
0.75 kW
X
PT05
1.10 kW
X
PT06
1.50 kW
X
PT46
2.20 kW (Low duty)
X
PT07
2,20 kW
X
PT08
3.00 kW
X
PT09
4.00 kW
X
PT49
5.50 kW (Low duty)
X
Power-conducting plate –Brake chopper
A
B
BC01
Without brake chopper
X
X
BC02
With brake chopper
X
X
Application PCB –I/0 Support
A
B
MS00
With I/O support Module
X
X
MS90
Without I/O support Module
X
X
Housing type –External lid
A
B
EL01
Passive cooling, potentiometer
X
X
EL02
Passive cooling
X
X
EL44
Passive cooling + Brake chopper + internal Brake resistor + Potentiometer
X
X
EL45
Passive cooling + Brake chopper + internal Brake resistor
X
X
EL50
Passive cooling, Harting, 2x M12 I/O + Potentiometer
X
X
EL51
Passive cooling, Harting, 2x M12 I/O
X
X
EL52
Passive cooling , Phoenix Quickon, 2x M12 I/O + Potentiometer
X
X
EL53
Passive cooling , Phoenix Quickon, 2x M12 I/O
X
X
EL54
Passive cooling, Harting, 2x M12 I/O + Brake chopper + internal Brake resistor + Potentiometer
X
X
EL55
Passive cooling, Harting, 2x M12 I/O + Brake chopper + internal Brake resistor
X
X
EL56
Passive cooling, Phoenix Quickon, 2x M12 I/O + Brake chopper + internal Brake resistor + Potent.
X
X
EL57
Passive cooling , Phoenix Quickon, 2x M12 I/O + Brake chopper + internal Brake resistor
X
X
Cover type
A
B
CV01
Without cover variant
X
X
CV05
Display and Man machine interface
X
X
CV11
Main switch
X
X
CV15
Main switch + Display and Man Machine Interface
X
X
Optional module –Brake rectifier module
A
B
BR00
Without rectifier module
X
X
BR10
Without rectifier module + Main switch
X
X
BR13
Rectifier module for FD brake + Main switch (Not with ETHERNET fieldbus)
X
X
BR30
Rectifier module for FD brake
X
X
IO module
A
B
IU00
Without IO module
X
X
IU01
IO module
X
X
IU03
I/O Module + M12 MMI plug
X
X
IU13
I/O Module + M12 MMI plug + STO
X
X
IU23
I/O Module + M12 MMI plug + ETHERNET*
X
X
IU33
I/O Module + M12 MMI plug + ETHERNET* + STO
X
X
DGM-MPM
PTxx
BCxx
MSxx
ELxx
CVxx
BRxx
IUxx
* ETHERNET = ProfiNET + EtherCAT + ETHERNET/IP + SERCOS

Operating manual for DGM Modular | DOC02389740-0006 | 2021-07 | V1.70 EN
13
Sizes C - D
DGN-MPM
Inver Type
Recommended motor rating
A
B
PT10
5.50 kW
X
PT11
7.50 kW
X
PT51
11.00 kW (Low duty)
X
PT12
11.00 kW
X
PT13
15.00 kW
X
PT14
18.50 kW
X
PT15
22.00 kW
X
PT55
30.00 kW (Low duty)
X
Power-conducting plate –Brake chopper
A
B
BC01
Without brake chopper
X
X
BC02
With brake chopper
X
X
Application PCB –I/0 Support
A
B
MS00
With I/O support Module
X
X
MS90
Without I/O support Module
X
X
Housing type –External lid
A
B
EL01
Passive cooling + Potentiometer
X
EL02
Passivecooling
X
EL06
Active cooling + Potentiometer
X
X
EL09
Active cooling
X
X
EL44
Passive cooling + Brake chopper + internal Brake resistor + Potentiometer
X
EL45
Passive cooling + Brake chopper + internal Brake resistor
X
EL52
Passive cooling, Phoenix Quickon, 2x M12 I/O + Potentiometer
X
EL53
Passive cooling, Phoenix Quickon, 2x M12 I/O
X
EL56
Passive cooling, Phoenix Quickon, 2x M12 I/O + Brake chopper + internal Brake resistor + Potent.
X
EL57
Passive cooling, Phoenix Quickon, 2x M12 I/O + Brake chopper + internal Brake resistor
X
EL61
Active cooling + Brake chopper + internal Brake resistor + Potentiometer
X
X
EL62
Active cooling + Brake chopper + internal Brake resistor
X
X
EL63
Active cooling, 2x M12 I/O + Potentiometer
X
EL64
Active cooling, 2x M12 I/O
X
EL65
Active cooling, 2x M12 I/O + Brake chopper + internal Brake resistor + Potentiometer
X
EL66
Active cooling, 2x M12 I/O + Brake chopper + internal Brake resistor
X
X
Cover type
A
B
CV01
Without cover variant
X
X
CV05
Display and Man machine interface
X
X
CV11
Main switch
X
X
CV15
Main switch + Display and Man Machine Interface
X
X
Optional module –Brake rectifier module
A
B
BR00
Without rectifier module
X
X
BR10
Without rectifier module + Main switch
X
X
BR13
Rectifier module for FD brake + Main switch (Not with ETHERNET fieldbus)
X
X
BR30
Rectifier module for FD brake
X
X
IO module
A
B
IU00
Without IO module
X
X
IU01
IO module
X
X
IU03
I/O Module + M12 MMI plug
X
X
IU13
I/O Module + M12 MMI plug + STO
X
X
IU23
I/O Module + M12 MMI plug + ETHERNET*
X
X
IU33
I/O Module + M12 MMI plug + ETHERNET* + STO
X
X
DGM-MPM
PTxx
BCxx
MSxx
ELxx
CVxx
BRxx
IUxx
* ETHERNET = ProfiNET + EtherCAT + ETHERNET/IP + SERCOS

Overview of the drive controller
14
Operating manual for DGM Modular | DOC02389740-0006 | 2021-07 | V1.70 EN
2.2 Scope of delivery
2.2.1 Sizes A-C
Compare the scope of delivery of your product with that
provided below.
Fig. 6: Scope of delivery
2.2.2 Size D
Fig. 7: Scope of delivery, size D
Key
Drive controller article number
1
Drive controller (variant)
2
Adapter plate with terminal
(not part of the scope of delivery)
3
Seal (not part of the scope of delivery)
Adapter plate article number
4
Motor
(not part of the scope of delivery)
5
Operating manual
Key
Drive controller article number
1
Drive controller (variant)
2
Cup
3
Poly bag containing seals, screws and shims
4
Operating manual

Operating manual for DGM Modular | DOC02389740-0006 | 2021-07 | V1.70 EN
15
2.3 MMI*/connecting cable
PIN assignment
Fig. 8: M12 plug PIN assignment
Description: Round plug (plug) 4-pin M12
A-coded
M12 plug
assignment
Signal
1
24 V
2
RS485 - A
3
GND
4
RS485 - B
* Man-machine interface
Fig. 9: RJ9 plug connector
Pin
Signal
1
yellow
2
green
3
Red
4
brown
Attention: The colours may vary!
2.4 Description of DGM Modular drive controller
The DGM Modular drive controller is a device for the speed control of three-phase AC motors.
The drive controller can be integrated in the motor (with the standard adapter plate) or fitted close to the motor (with the
wall mounting adapter plate).
The permitted ambient temperatures specified in the technical data refer to operation at nominal load.
In many cases, higher temperatures may be permitted after a detailed technical analysis.
These have to be approved by Bonfiglioli Riduttori S.p.A. on a case-by-case basis.

Installation
16
Operating manual for DGM Modular | DOC02389740-0006 | 2021-07 | V1.70 EN
3. Installation
3.1 Safety instructions for installation
3.2 Recommended preliminary fuses / line protection
DGM Modular
Size A
3 x 400 V AC
Size B
3 x 400 V AC
Rated motor speed
up to 1.5 kW
2.2 kW LD
up to 4 kW
5.5 kW LD
Line current
3.3 A
3.9 A
7.9 A
9.3 A
Line current
(overload 60 s)
4.95 A
4.3 A
11.85 A
10.2 A
Line current
(overload 3 s)
6.6 A
5.85 A
15.8 A
14 A
Line circuit breaker -
recommendation
C 10
C 16
Characteristics C = line circuit breaker tripping between 6 –10 times In
The cross-section of the supply line must be designed according to the transfer category
and maximum permitted current. The contractor commissioning the device must ensure
protection for the power line.
DANGER!
Risk of death due to revolving mechanical parts!
Death or serious injury!
De-energise drive controller and secure it against being restarted.
Only allow appropriately qualified staff to install the drive controller.
Only use staff who are trained in mounting, installation, commissioning and handling.
Always ground the device in accordance with DIN EN 61140; VDE 0140, NEC and other relevant
standards.
The drive controller must be grounded with the motor according to relevant regulations. Non-
compliance may result in death or serious injury.
If spring elements are not used when assembling the adapter plate, there must be an extra connection
between the motor and drive controller to produce a correct protective conductor connection
Unused open cable ends in the motor connection box must be insulated.
Use suitable line circuit breakers with the prescribed nominal current between the mains and drive
controller.
Mains connections must be hardwired.

Operating manual for DGM Modular | DOC02389740-0006 | 2021-07 | V1.70 EN
17
DGM Modular
Size C
3 x 400 V AC
Size D
3 x 400 V AC
Rated motor speed
up to 7.5 kW
11 kW LD
up to 22 kW
30 kW LD
Line current
13.8 A
18.3 A
38.2 A
49.8 A
Line current
(overload 60 s)
20.7 A
20.13 A
57.3 A
54.8 A
Line current
(overload 3 s)
27.6 A
27.5 A
76.4 A
74.7 A
Line circuit breaker -
recommendation
C 32
C 80
Characteristics C = line circuit breaker tripping between 6 –10 times In
The cross-section of the supply line must be designed according to the transfer category
and maximum permitted current. The contractor commissioning the device must ensure
protection for the power line.
3.3 Installation requirements
3.3.1 Suitable ambient conditions
Conditions
Values
Altitude of the installation location:
up to 1000 m above sea level / over 1000 m with reduced
performance
(1% per 100 m) (max. 2000 m), see chapter 8.2
Ambient temperature:
- 40 °C to + 50 °C
(different ambient temperatures may be possible in individual cases),
see chapter 8.2
Relative air humidity
≤96 %, condensation not permitted.
Resistance to vibration and shock:
DIN EN 60721-3-3 3M7 (5 –200 Hz, 3g)
Electromagnetic compatibility:
Immune to interference acc. to DIN EN 61800-3
Cooling:
Surface cooling:
sizes A to C: free convection;
Tab. 1: Ambient conditions
◼Ensure that the housing type (protection class) is suitable for the operating environment:
- Ensure that the seal between the motor and the adapter plate is inserted correctly.
- All unused cable screw connections must be sealed.
- Check that the cover of the drive controller is closed and bolted down tightly.
- Size A –C (4 x M4 x 28) 2 Nm,
- Size D (4 x M6 x 28) 4 Nm
Although the drive controller can, in principle, be painted
later on, the user must nevertheless check the material
compatibility of the intended paint. The DGM Modular is supplied in RAL 9005 (black) as
standard.
Disassembling the circuit boards (even for the purpose of
painting the housing sections) renders the warranty void!
Mounting points and sealing surfaces must be kept free of
paint for purposes of EMC and grounding!
DAMAGE TO PROPERTY POSSIBLE
Failure to comply with the information may result in
damage to the drive controller!
When attaching a cover with integrated foil keypad, be
absolutely sure that the flat ribbon cable is not pinched.
DAMAGE TO PROPERTY POSSIBLE
Failure to comply with this requirement may eventually
result in the loss of the protection class (particularly in
respect to seals and fibre-optic elements).

Installation
18
Operating manual for DGM Modular | DOC02389740-0006 | 2021-07 | V1.70 EN
3.3.2 Suitable installation location for the motor-integrated drive controller
Ensure that the motor with a motor-integrated drive controller is only installed and operated if aligned as shown in the
following diagram.
Fig. 10: Motor installation location/permitted alignments
IMPORTANT INFORMATION
Ensure that no condensate from the motor can enter the drive controller during and after installation.

Operating manual for DGM Modular | DOC02389740-0006 | 2021-07 | V1.70 EN
19
3.3.3 Wiring instructions
Connection overview (sizes A - C)
Sizes A - C
X1 mains
The terminals for the mains cable are located inside the drive controller. The DGM Modular also has the
option of being equipped with terminals for connecting a brake resistor.
Depending on the variant, the assignment and position of the terminals may differ.
Core end sleeves with plastic collars and lugs are recommended.
Terminals:
Spring force connection
(slot screwdriver, max. width 2.5 mm)
Conductor cross-section, rigid
min. 0.2 mm²
max. 10 mm²
Conductor cross-section, flexible
min. 0.2 mm²
max. 6 mm
Conductor cross-section, flexible with core end sleeve
without plastic sleeve
min. 0.25 mm²
max. 6 mm
Conductor cross-section, flexible with core end sleeve with
plastic sleeve
min. 0.25 mm²
max. 4 mm
2 conductors of the same cross-section, flexible with TWIN-
AEH with plastic sleeve
min. 0.25 mm²
max. 1.5 mm
AWG/kcmil conductor cross-section according to UL/CUL
min. 24
max. 8
Length of stripped insulation:
15 mm
Mounting temperature:
-5°C to +100°C
Sizes B - C
Size A

Installation
20
Operating manual for DGM Modular | DOC02389740-0006 | 2021-07 | V1.70 EN
Connection overview (size D)
Size D
X1 mains / X4 motor
+ B - brake resistor
The terminals for the mains cable are located inside the drive controller. The DGM Modular also has the
option of being equipped with terminals for connecting a brake resistor. The configuration may vary
depending on the version.
Core end sleeves with plastic collars and lugs are recommended.
Torque min. 2.5 Nm / max. 4.5 Nm
Conductor cross-section:
rigid min. 0.5 mm² / rigid max. 35 mm²
Conductor cross-section, flexible:
min. 0.5 mm² / max. 25 mm²
Conductor cross-section, flexible with core
end sleeve without plastic collar
min. 1 mm²
max. 25 mm²
Conductor cross-section, flexible with core
end sleeves with plastic sleeve
min. 1.5 mm²
max. 25 mm²
AWG / kcmil conductor cross-section
according to UL/CUL
min 20
max. 2
2 conductors of the same cross-section, rigid
min. 0.5 mm²
max. 6 mm²
2 conductors of the same cross-section,
flexible
min. 0.5 mm²
max. 6 mm²
2 conductors of the same cross-section,
flexible with AEH without plastic sleeve
min. 0.5 mm²
max. 4 mm²
2 conductors of the same cross-section,
flexible with TWIN-AEH with plastic sleeve
min. 0.5 mm²
max. 6 mm²
AWG according to UL/CUL
min. 20
max. 2
