Booster BDVM-8360UBT User manual

THE PERFECT SOUND
BDVM-8360UBT
MANUALDE INSTALAÇÃO DO PROPRIETÁRIO
DVD com Receptor Multimídia
3 "True Color TFT widescreen

BDVM-8360UBT ÍNDICE
Índice……………...….……………………………………….………………………………….……….. 1
Acessórios…………….………………………………………………………………………………….. 2
Precausões….……..….……………………………………….……………………………………….….3
Notas de instalação ……………………………………………………………………………..….. 4 –5
Remoção e Instalação do painel frontal……………………………………………………………….6
Conexão dos Cabos…………….. ………………………………………………………………………7
Control Locations –Receiver……………………………………………………………………………8
General Operation …………………………………………………………………………………….9 - 12
Control Locations –Remote ………………………………………………………………………13- 16
Changing The Battery……………………………………………………………………………………17
Multimedia Set Up Menu…………………………………………………………………………...18 - 21
USB, SD/MMC Operation …………………………………………………………………………..22 –23
Bluetooth Operation…………………………………………………………………………………24 - 27
Specification………………………………………………………………………………………… 28 - 29
Please read all instructions carefully before attempting to install or operate.
Due to its technical nature, it is highlyrecommendedthat your BOOSTER BDVM-8350MP is
installed by a professional installer of an authorized dealer. This product is only for use in
vehicles with 12V DC negative ground only.
Toget the bestfrom your product, understand its capabilities and avoid all possible risks, we
recommend that you take time to read this manual very carefully before handling the
product.
–1 –

BDVM-8360UBT Accessory
Accessory
Package contains the following accessories for installation and operation of the unit.
The Unit
Note:
Product image may varyfrom the actual delivery..
–2 –
1x Mounting Bracket
1xAssemble Bar
1xScrew B15x16
4xBolt M5
1x Nut M5
1xFlat washer
1x Spring washer
2x Unit ejection bars
1x UNIT IR-Remote Control with
one CR2025 3Voltcell battery.
User Manual.
1xfront panel protection case
1xAV-IN Cable

BDVM-8360UBT Precautions
Precautions
Load one disc with the label side facing upwards and make sure you do not touch the data side
with your fingers.
Pressthe[OPEN]buttonontheunittoopenandfolddownthefaceplateforloadingorunloading a
disc.
Press the [EJECT] button in case there is already a disc inside the unit.
Gently load a disc inside the unit and do not apply any force to the disc, it will automatically be
loaded. Once the disc is inside the unit, close the faceplate again.
Note:
●Finger prints and dust on the disc surface can affect the sound quality. Clean the discs regularly
with a soft cotton cloth from the disc center to the outside of the disc but do not clean in circular
motions.
●Do not use any kind of solvent, such as diluting agent, gasoline, liquid detergent, gasoline liquid
detergent antistatic aerosol usedfor vinyl, this may cause serious disc damage.
●Keep discs away from direct sunlight or any heat source.
●Do not stick any paper or stickers on a disc.
●Only use 12cm and round discs, do not insert any other type or size of discs.
●If a 12cm CD/DVD is ejected but not removed within 15 seconds, it will be reloaded automatically,
but will not resume playing.
Once the disc is loaded, the unit will automatically start reading the disk and it will take a few seconds to
download the disc initial data, thereafter the unit will start playing the disc.
Note: When the unit is on standby and a disc is loaded/ unloaded, the unit will turn ON
automatically.
–3 –

BDVM-8360UBT Notes on Installation
Notes on Installation
If your car is fitted with a one (1x) DIN size opening for a car audio system, you can install the Car Radio
according these steps.
Note: Unit should be installed horizontallyin an angle less than 30°.
1) Insert the mounting bracket into the 1X DIN opening of your dashboard
2) Bend the mounting tabs outwards with a screwdriver, to tighten and fix
the mounting bracket in its place
3) Connect the M5 Bolt to the rear of the unit
4) Check electrical connections as described earlier
(either an ISOconnection or separate wiring)
5) Insert the ISO connector into the unit
6) Push the unit into the mounting bracket until you
hear a click
7) Move the assemble bar (metal strip with holes) over the M5 bolt
and use the M5 nut to tighten the assemble bar.
8) Use the screw Bt5x20 to fix the other side of the assemble bar to the car body
9) Place the front rim over the unit to finish the installation.
–4 –
NOTE: Before
installing the unit,
please remove the
two screws.

BDVM-8360UBT INSTALLATION
Notes on Installation
Note: Step 7 and 8 are only possible when you can reach the back of the unit inside the
dashboard.
Note: Please observe the following safety instructions for the connection of the device:
- Read the entire installation section before connecting the device.
- Disconnect the negative pole of the vehicle battery for the duration of the installation.
- Observe the safety instructions by the vehicle manufacturer during this task.
- If you need to drill holes for the installation, make sure that no parts of the vehicle are damaged.
- The cross section of the positive and negative cable may not be less than 2.5 mm².
- Do not connect any of the vehicle‟s plugs and cables to the radio unless you have the appropriate
specialized knowledge of this process!
- Depending on the build of your vehicle, the installation may deviate from this description.
- We do not assume any liability for damages caused by faulty installations or connections, nor any
subsequent damages.
- We recommend that you have the device installed by a specialized company. Then you will have
created the prerequisites for a problem-free functioning of the device. If at any point during the
installationyou are unsurethat youcan correctlyconnectthe device by yourself, contact a specialist.
Afaulty installation may cause damages to the device and the vehicle electronics.
–5 –
To remove the unit, CAREFULLY remove the
front rim (do not use force, else the connection
pins of the rim will break off) and place the two
extraction keys into the left and right side of the
unit until they click in place and pull the unit
gently out of the dashboard.

BDVM-8360UBT INSTALLATION
Removing and Attaching the Faceplate
Removing
Open the front to min 45 degrees or to its fold down position. Gently press the right side towards the left
and gently remove the faceplate by pulling it towards you.
Attaching
Gently place the left side of the front onto the locking pin, then gently click the right side onto the locking
pin and close the front until you hear a click.
CAUTION: DO NOT insert the control panel into the right side. It can damage the control panel. Never
use force or a tight grip onto the buttons or the information display when removing or attaching the
Control Panel. The control panel can easily be damaged by shocks. To avoid damage or potential theft
remove the Control panel, place it into the protective case and be careful not to drop it or subject it to
strong shocks. The rear connector that connects between the main unit and the control panel is an
extremely important part. Be careful not to damage it by pressing on it with fingernails, pens,
screwdrivers, etc.
–6 –

BDVM-8360UBTWire Connection Diagram
Wire Connection Diagram
Makesureyouhave goodchassisground.Agoodgroundconnectionwilleliminatemostelectricalnoise
problems. A good chassis ground requires a tight connection to the vehicle‟s metal chassis. The area
around the ground connection should be clean, bare metal without rust, paint, plastic, dust, or dirt for a
good electrical connection.
INCORRECT WIRING OR OPERATION WILL VOID THE WARRAN
Caution: Do not interchange the connection of the wiring!!!
Forsomecarmodels you mayneed to modifywiring of thesupplied powercord.Contact yourauthorized
car dealer before installing this unit.
Remark: When you back a car, screen display switch to Rear Camera automatically
–7 –

BDVM-8360UBTControl Locations –Receive
Control Locations –Receiver
–8 –
1. POWER/MUTE
2. MENU
3. BAND/ACCEPT CALL
4. VOLUME KNOB /OK
5. DSP
6. AS/PS
7. IR SENSOR
8. OPEN
9. SEEK -
10. SEEK+
11. MODE
12. MEM/PLAY/PAUSE/REJECT
CALL
13. TFT LCD DISPLAY
14. AV IN
15. USB SOCKET
16. SD CARD SLOT
17. DISC EJECT
18. ANTI-THEFT LED
19. DISC SLOT
20. RESET
21. MIC

BDVM-8360UBTGENERAL OPERATION
General Operation
Power /MUTE button Press the power button to switch the unit ON. Long press again to switch
it OFF. Press the button briefly to Mute. Please note that the volume will
be muted on all audio output connectors. The MUTE icon will be seen on
the information display. To resume playing press the button briefly again.
Volume KNOB/OK Adjust the volume level by turning the knob clockwise to increase or
counterclockwise to decrease.
Press OK button to confirm a selection or setting.
Programming Preset Search a station by Manual or Automatic Tuning. When the desired
station and frequency is found, press the MEM button, now press►►
▌▌◄◄ to choose preset 1-6, then press the VOLbutton to confirm and
press MEM button to store the station. To store the found station in
memory with the remote control, press the desired preset number (1-6)
and hold pressed till you hear a beep, the station is now stored. This
sequence can be repeated for every available BAND. Just press the
BAND button to select the next available band and repeat the above
sequence.
Selecting Preset Stations Select the desired BAND. Now press the ►►▌button or the ▌◄◄
button to choose the station, or on the remote control choose a preset
station number (1-6)
▌◄◄ / ►►▌
Automatic Station search
In TUNER mode press and hold button ►►▌(frequency increase) or
▌◄◄ (frequency decrease) button on the front panel or the remote
press it, to search a station automatically. The frequency search will stop
when a station is found or when the buttons are pressed again.
Next track
While a song or track or title is playing press the (NEXT ►►▌) button to
skip to the next track. No sound will be reproduced during this operation.
Previous track
While a song or track or title is playing press the (PREVIOUS ▌◄◄)
button to skip to the previous track. No sound will be reproduced during
this operation.
Fast Forward
While a song or track or title is playing press and hold the ►►▌button
for longer than 2 seconds to Fast Forward (FFWD) within the current
track. No sound will be reproduced during this operation.
Fast Reverse
While a song or track or title is playing press and hold the ▌◄◄ button
for longer than 2 seconds to Fast Reverse (FREV) within the current
track. No sound will be reproduced during this operation.
–9 –
Station

BDVM-8360UBT GENERAL OPERATION
General Operation
AS (Auto Store) / AS (Auto Store): In tuner mode, Press theAS/PS on the panel or
PS (Preset Scan) RPT/P.SCN button on the remote and hold for 2 seconds to store radio
station‟s with the best reception to the preset buttons automatically.
PS (Preset Scan): In tuner mode, press this button to scan the preset
memorized station, each preset scan for 5 seconds. Press again to stop
operation.
Band / Press the Band button to select your frequency band of choice in the
following sequence:
FM 1 → FM 2→ FM 3 → AM → FM 1 When a newfrequency band is
selected, the last chosen frequency/ station of that frequency band will
be heard.
In BT mode this button functions as the Call pick up button (see
Bluetooth Chapter).
MEM//PLAY/PAUSE/ In Radio mode,,see Program Preset Stations.
In Multimedia mode ( DVD, USB, SD), press it to start or pause the
playback. Press and hold the button for 2 seconds to stop the playback.
In Bluetooth mode: Hang up or Reject call. ( See Bluetooth Chapter).
Mode Press the Mode button to toggle between the available audio sources in
the following sequence: Radio →DISC→USB→CARD→Bluetooth
→AV IN →Radio. Selections only available ifmedia is inserted.
DSP Press the DSP button to choose sound effect in the sequence of
FLAT→CLASSICS→POP→ROCK→DSP OFF
Menu Press the MENU button to enter into the settings mode. Press the MENU
to return to settings list.
In Radio mode, the MENU will display:
1)AUDIO => 2) EXPERT => 3) CLOCK
InAV IN/DVD/SD/USB mode, the MENU will display:
1) AUDIO => 2) PICTURE => 3) EXPERT => 4) CLOCK
AUDIO MENU
–10 –
BASS
Support 10 levels. Default level is 0.
TREBLE
Support 10 levels. Default level is 0.
BALANCE
Support10 levelsforeachleftandrightchannel.
Default is left equal to right.
FADER
Support 10 levels for each front and rear
channel. Default is front equalto rear.
EQ DSP
OFF
FLAT→CLASSICS→POP→ROCK→DSP OFF

BDVM-8360UBTGENERAL OPERATION
General Operation
PICTURE MENU
RED
Adjust level of red color. Support 50 levels.
Default level is 25.
GREEN
Adjust level of green color. Support 50 levels.
Default level is 25
BLUE
Adjust level of blue color. Support 50 levels.
Default level is 25.
BRIGHTNESS
Adjust level of screen brightness. Support 50
levels. Default level is 25
CONTRAST
Adjust level of screen contrast. Support 50
levels. Default level is 25.
SHARPNESS
Adjust level of screen sharpness. Support 15
levels. Default level is 10
SCREEN
Adjust screensize: 16:9→4:3→FULL
COLOR
RESET
Resume colordefault status. (Select YES or NO,
and press the ENTER button to confirm “YES”)
EXPERT MENU
DX
Set search radio station by DX or LOCALmode.
DX→LOCAL
STEREO
Set radio audio at STEREO or MONO mode,
STEREO→MONO
BEEP
Set press keys„ sound. 2ND→ALL→OFF
LOUD
Set loudness on or off. OFF→ON
SUBWOOFER
Set subwoofer on or off .OFF→ON
BACKLIGHT
Set OSD BACKLIGHT: HIGHT→LOW →MID
OSD
COLOR
Set OSD COLOR: VIOLET→LIGHT BLUE→
DARK BLUE
CLOCK MENU
CLOCK
Set CLOCK display time ON or OFF
CLOCK
HOUR
Set 24Hour format or 12Hour format
CLOCK
ADJUST
Set CLOCKADJUSTtime
–11–

BDVM-8360UBTGENERAL OPERATION
General Operation
AV IN Connect an optional AV cable to your external AV device (such as a video
camera), then press the MODE button to switch to the AV mode. Note: If
there is no external video input, the TFT displays “NO VIDEO SIGNAL”.
Subwoofer Connect the subwoofer to the unit using sub output (see wiring
connection). Press MENU button, choose EXPERT and set subwoofer
ON to enable subwoofer.
Back View Camera Thisunit isequippedwithbackviewcameraoutput.Thecameraisusedto
observe the situation behind the vehicle when you are backing the car.
Please connect your back view camera with the back car video input.And
connect the reverse wire for back a car with the rear gear light. Rear view
camera picture will be enabled when you are backing the car.
Auto switch to video To promotesafety, certain functions are disabled unless the parking brake
is on. TheUnit is designedtodetect parked status and must be connected
to the power supply side of the parking brake switch. When playing a
movie file in a driving car, a warning screen will be displayed on the
screen.Whenthecarisplacedonthehandbrake,thescreen willswitchto
video automatically. Improper connection or use of his connection may
violateapplicable lawand may result in serious injury ordamage. To avoid
the risk of damage and injury and the potential violation of applicable laws,
this unit is not for use with a video screen that is visible to the driver. Also,
other video displays should not be in a location where it is a visible
distraction to the driver. In some countries or states the viewing of images
on a displayinside a vehicle even by persons other than thedriver may be
illegal. Where such regulations apply, they must be obeyed and this unit's
movie features should not be used. Note: The supplier waves any and all
liability when these guidelines and warnings arenot followed.
–12–

BDVM-8360UBT REMOTE CONTROL OPERATION
Control Locations –Remote Handset
–13–
1. MODE
2. POWER ON-OFF
3. BAND / RANDOM
4. ENTER / CONFIRM
5. LEFT, RIGHT, UP, DOWN
navigation arrows
6. ST/MO
7. * SIGN (In Bluetooth Mode) /
PROGRAM (in Multimedia Mode) /
LOC (in Radio Mode)
8. # SIGN (In Bluetooth Mode) REPEAT
(in Multimedia Mode) / PRESET
SCAN (in Radio Mode)
9. BACKWARD/
FAST BACKWARD/ TUNE DOWN
10. LOUD
11. OSD
12. STOP / PBC
13. NUMBERS 0-9
14. PLAY / PAUSE
15. MUTE
16. MAIN MENU /
MEDIAFILE MENU
17. SUB TITLE
18. MEDIAFILE SETUP
19. ANGLE
20. INTRO SCAN
21. VOLUME PLUS
22. REPEAT A-B / ZOOM
23. SELECT MENU
24. FORWARD/
FAST FORWARD/
TUNE UP
25. VOLUME MINUS
26 AUDIO / GOTO
27. CALL ACCEPT
28. HANG UP / REJECT CALL

BDVM-8360UBT REMOTE CONTROL OPERATION
Control Locations –Remote
1. MODE button Press it toselectthe mode: Radio, DISC (if thereis a disc in unit),USB (if
there is a USB device in the unit), CARD (if there is a SD/SDHC card in
the unit), BLUETOOTH (if the connection is ok) andAV IN.
2. POWER power on or off
3. BAND/ RDM button In Radio mode, press to change radio band (FM1->FM2->FM3->-AM).
In Media file mode, press to play randomly.
4. ENTER button Press it to confirm a selection or setting.
5. Cursor / / / Use the / / / buttons to select a menu item, title, track or
buttons to shownext frame.
6. ST/MO button In FM mode press ST/MO button to select STERO or MONO sound
reception.
7. PROG/LOC/ * button Press this button to enter the program search menu and use the
up/down/left/rightcursorbuttonstoselectaposition. Pressadigitbuttons
to enter the number (To enter a number larger than 9, e.g. 123: press
digit buttons 1, and then press 2, then press 3.). For Multimedia File,
select title and chapter number or select track number. For a USB/SD
with mixed files, select folder and file number. Press the PLAY/ PAUSE
button to play, or move the cursor to select PLAY and press ENTER to
play. If you want to delete the list, move the cursor to CLEAR, press
ENTER to delete the entire list set before.
In radio mode, Press LOC buttononremote control to select reception of
local stations or DX for distance stations.
InBLUETOOTH mode, pressittomakea* symbol, long press it tomake
a + symbol.
8. P.SCN/ RPT/# button In SD/USB mode, press to repeat REP 1 (repeat the current playing file)
=> REP DIR (repeat current folder) => REP ALL (repeat all folders) =>
REP OFF.
In Movie file (DVD) mode, press to start repeat Title, Repeat Chapter;
RepeatALL
In Radio mode: PS (Preset Scan): Press toscanall preset stations inthe
memoryof the current band and stay on each memory stations for about
5 seconds.
AS (Auto Save): Long press to save the stations with good reception
automatically in the current band and scan each station for about 5
seconds. To stopAS, press the button again.
In Bluetooth mode: Press to make a # symbol.
–14–

BDVM-8360UBT REMOTE CONTROL OPERATION
Control Locations –Remote
9 / 24. / buttons InMoviefileoraudiofilemode, Press buttontorestart atrack, pressit
twice to skip to the previous track. Press button to skip to the next
track. Press and hold or button for two seconds to activate fast
forward (FF) or fast reverse (REW) search in a track.
In RADIO mode, press or button to start automatic searching,
push and hold for two seconds to start manual searching. button
Frequency up, button Frequency down.
10. LOUD button Press button on remote control to set LOUD ON/OFF.
11. OSD button In SD or USB mode, short press to show inserted USB/SD card icon.
Press and hold the OSD button for 2 seconds to show the USB/SD card
information, such as: Number of track, Current track time elapsed =>
Current track time remain => Total tracks time elapsed => Total tracks
time remain.
12. STOP/PBC button Press it to Stop playback from the current position, press it again to final
stop to the very beginning. Press PLAY/PAUSE button to play again.
Press and hold for two seconds to set PBC on/ off for VCD Discs.
13. Digit 0-9 buttons In radio mode, select the desired preset station in the current band (0-6);
In MULTIMEDIAmode, select track/song/titlenumber.
In BLUETOOTH mode, input ”0-9” telephone number
14. PLAY/PAUSE button In Multimedia mode, press it to pause playback, press again to resume
15. MUTE button Short press this button to mute the volume output, press it again to
resume volume.
16. MENU button Press ittoshowthemainunit setupmenu, Press theUPorDOWNarrow
to move to the next selection. Press the ENTER button to go to the
selection, then press the LEFT or RIGHT arrow to decrease or increase
the value or press the ENTER button to change the selection. In
Multimedia mode with recorded DVDfiles or DVD discs,
Press and hold the MENU button to activate the menu list on the screen.
Choose the desired item and press the ENTER button to confirm the
selected item and start playing; on front panel, press the OK button to
confirm the selecteditem and start playing.(Available only if therecorded
DVDfile or DVD disc has this function).
17. SUB-T button Press it to select the subtitle language (Available only with a recorded
DVD file or DVD disc with subtitle function).
18. SETUP button In Multimedia mode press it to enter the Multimedia setup menu.
–15–

BDVM-8360UBTREMOTE CONTROL OPERATION
Control Locations –Remote
19. ANGLE Button Press it repeatedly to change the viewing angle (Available only with a
recorded DVD file or DVD disc that has this function).
20. INT Button Press it to activate the intro function. Youcan play the beginningof every
track for 10 seconds in sequence.
21. VOL+ button Press to adjust volume level up.
22. A-B/ZOOM button During playback, press it at the starting point of section you want to
repeat (A), press this button again at the ending point of the section you
want to repeat (B), section A-B repeating starts. Press it again to cancel
theA-B repeat function.
Press it and hold fortwo seconds in Moviemode tozoom the image in or
out in the sequence of ZOOM 2-> ZOOM 3-> ZOOM 4-> ZOOM 1/2->
ZOOM 1/3-> ZOOM 1/4->ZOOM OFF.
23.SEL button Press it to enter the AUDIO menu. Press the UP or DOWN arrow to
move to the next selection. Press the ENTER button to go to the
selection then press the LEFT or RIGHT arrow to decrease or increase
the value.
24. See point 9.
25. VOL- button Press to adjust volume level down.
26. AUDIO/GOTO button In recorded DVD file or DVD disc mode press it to select the audio
language.
In DVD mode press and hold for two seconds to go into the set
chapter/track/time directly, press left/right button to choose the item and
go to the item.
27. Button In Bluetooth mode, press to make a call after keyed-in a phone number
or accept an incoming call.
28. Button Press to reject a call or hang up while calling only if the BLUETOOTH is
connected. InBLUETOOTHNUMBERDIALmode,shortpressit toclear
an inputted number one by one, press it and hold for 3 or 4 seconds or
clear all the inputted numbers at once.
–16 –

BDVM-8360UBTChanging the Battery
Changing the 1. Press the catch and at the same time pull out the battery tray.
2. Insert the 1 xlithium battery, type CR 2025 3V battery withthe stamped
(+) mark facing upward. Insert the battery tray into the remote control.
Warning:
Store the battery where children cannot reach. If a child accidentally
swallowsthebattery,consultadoctorimmediately. Donotrecharge,short,
disassemble or heat the battery or dispose it infire. Donot exposeor bring
into contact the battery with other metallic materials. Doing this may cause
the battery to give off heat, crack or start a fire. When throwing away or
saving the battery, wrap it in tape and insulate; otherwise, the battery may
give off heat, crack or start a fire.
Note:
Please remove the safety plastic on the battery compartment before
first using the remote control. Otherwise the remote control won‟t
operate properly.
The distance may vary according to the brightness of ambient light.
If the remote is not used for an extended period of time, remove the
battery to prevent possible damage from battery leakage and
corrosion.
Do not place any objects between the remote control unit and the
sensor on the unit.
Do not drop the remote control onto the floor; it will damage it beyond
repair.
Do not use the remote control unit, while simultaneously operating
the remote control unit of any other equipment; they may interfere
resulting in improper operation.
Thebatterynormally last for about one year although depending how
often the remote control is used. If the remote control unit isn‟t
working even when it is operated near the unit, replace the battery
with a new battery of the same make and use only a lithium cell
battery type: CR2025 (3V).
Disposal of the battery Please consider that you as an end consumer are obligated to return
discarded batteries that are hazardous waste to a distributor or a
redemption site intended for this purpose by a public waste management
facility.
–17–
Battery

BDVM-8360UBTMultimedia Set Up Menu
Multimedia Set Up Menu
Whenin Multimedia mode,press the SETUPbutton on the remote control to enter the Multimedia player
setup menu to setup the Multimedia player operation setting. Press SETUP button to enter into the
system settings main menu; press the left or right arrow buttons to move to the highlighted menu item
and select one of the Setup Pages:
Press SETUP and then ENTER to enter into setup menu.
SYSTEM setup [1] TV SYSTEM:
Selectthismenu item toset up your preferredvideooutputformat. PALis
commonly used in Europe, NTSC is commonly used in the USA and
Japan.Auto is commonly used.PAL60 is occasionally used.
[2] AUTO PLAY setup:
Whenplaying a DVDdiscandyoucansettingAUTO PLAYONOROFF,
[3] VIDEO setup:
Check Video out type from this menu item.
[4] TV Type:
Set TFT screen mode to the correct ratio:
Three screen ratio modes are available, Normal/PS (4:3 Pan Scan),
Normal/LB (4:3 Letterbox) and Wide (16:9). Different disc formats will
displaydifferent images depending this settingandthe screen size used.
[5] Password:
The password for this unit is initially set to factory default 0000. If you
want to change your password, you need to enter the old password first
andconfirm it, andenter a newpassword andconfirm.WARNING: if you
forget your password, there is no possibility to reset the password again.
Do not forget your password and writeit down or storethe password ina
safe place.
[6] Rating / PARENTAL SETUP.
For DVD discs which support the USA rating system, setting up rating
control can prevent children from watching content that might not be
suitable for their age. You are asked to enter the password when you
change the rating setting. The default password is 0000.
–18 –

BDVM-8360UBTMultimedia Set Up Menu
Control Locations –Remote
[7] Default setup:
With this option you can clear all your setup and resume default setup.
LANGUAGE setup
[1]. OSD language setting:
With this option you can select the language for your On Screen Display
(OSD).
[2].Audio Lang setting:
With this option you can select the preferred language for the audio
output. When the selected language is recorded on the Multimedia files
or DVD (not all Multimedia files or DVD‟s have multiple languages
recorded) then this language will automatically be played. If not, the first
language recorded on the Multimedia file or DVD is played.
–19 –
Code
Description
1.NONE
Kid safe
2.G
GeneralAudiences –ALLages admitted
3.PG
PARENTAL GUIDANCE
SUGGESTED-Some material may not be
suitable for children
4.PG-13
PARENTS STRONGLY CAUTIONED-Some
material may be inappropriate for children
under 13
5.PG-R
Restricted, under 17 requires accompanying
parent or adult guardian.
6.R
RESTRICTED-Under 17 requires
accompanying parent or adult guardian
7.NC-17
NO ONE 17AND UNDERADMITTED
8.Adult
Above 17Admitted
Table of contents
Other Booster Car Receiver manuals
