BORK S810 User manual

OPERATING MANUAL
JUICER
S810

32
JUICER AND BLENDER ON A SINGLE BASE
S810 professional juicers give you an opportunity to buy two devices for the
price of one. The 1,800 W motor helps efficiently mill products and extract juice
at high speed. The combination of two devices in one multi-functional casing
saves the kitchen space and expands the range of options.
DESCRIPTION DESCRIPTION
SAFETY AND RELIABILITY
The juicer safe operation is assured by the smooth start of the motor,
activation of the emergency stop system when the lock cover is opened, and
overheating protection. The motor wear is minimized through the use of cast
metal casing and forced cooling.

54
CONFIGURATION
TWO PROTECTION SYSTEMS
MOTOR PROTECTION FROM OVERLOADING
The appliance is fit with the automatic safety device, which protects the motor
from failure during operation. If the motor is overheated, the protection will
automatically switch off the appliance. In this case unplug the appliance and
wait until the motor cools down. Then press the automatic safety button located
on the base of the appliance.
ELECTRONIC PROTECTION
In case the motor stops, the START / STOP button will be lit red, and the
electronic protection device will automatically switch off the motor. In this case
unplug the appliance and let it cool down during 15 minutes. This can be caused
by too big amount of simultaneously processed fruit or vegetables or their
excessively big size.

76
CONFIGURATION OF THE JUICER
CONFIGURATION OF THE JUICER
84 mm wide feed chute
Juicer’s lid
3,5 l pulp container
START / STOP button
Pusher for products
Block
Filter cup
Base with motor
Speed control

98
CONFIGURATION OF THE JUICER
Fine mesh filter
With titanium nitride blades coating
Brush to clean the filter
5 EXTRACTION SPEEDS
Use low speeds (1–3) to juice soft and watery
products and high speeds (4, 5) to juice solid
products.
OPERATION
USED FRUIT SPEED
Apples 5
Apricots (without kernels) 2
Beet root (peeled) 5
Blackberry 1
Broccoli 4
Brussels sprouts 5
Cabbage 4
Carrots 5
Cauliflower 4
Celery 5
Cucumber 4
Fennel 5
Tomato 1
USED FRUIT SPEED
Виноград 1
Киви (очищенное) 2
Манго (очищенное, без кос точки) 2
Дыня (очищенная) 1
Нектарины (без косточек) 2
Апельсины (очищенные) 3
Персики (без косточки) 2
Твердые груши (без черенка) 5
Мягкие груши (без черенка) 2
Ананасы 5
Сливы (без косточки) 2
Малина 1
Арбуз (очищенный) 1
1,2 l juice jar
with froth separator

1110
OPERATION
OPERATION
Step 1. Set the filter cup on the base with the
motor.
Step 2. Set the filter by aligning arrows on the
filter with arrows on the filter drive.
Note. Make sure that the filter is safely fixed inside
the filter cup.
Step 3. Set the juicer’s lid on the filter cup.
Step 4. Lift the lid block in the vertical position
until you hear a click.
Step 5. Insert the pusher for products into the feed
chute.
Step 6. Set the pulp container slightly declining it.
Advice. To minimize cleaning put a plastic bag
inside the pulp container in advance.
Step 7. Place the juice jar under the juicer’s nose.
Cover the jar with the lid.
Step 8. Plug in the juicer. Select the desired
extraction speed (1–5) and switch on the juicer.
Note. Ice, pulse, Smoothie modes can be set only if
the appliance is assembled as a blender.
Advice. Extract juice slightly pressing the
products with the pusher.
Advice. Clean the filter after each use of the juicer
with the help of the brush included in the set.
NOZZLE FOR EXTRACTION IN A GLASS
You can use any dish instead of the juice jar.
The nozzle for extraction in a glass will prevent
splashing during extraction. It also has the “drop
stop” function. For that purpose turn the nozzle
with its nose up.

1312
• Juice only fresh products.
• To receive maximally useful juice use seasonal
products.
• Before juicing wash the products.
• Before juicing of products with solid or
uneatable skin, such as mango, guava, melon,
watermelon or pineapple, peel them.
• Citrus juice is tastier if fruit are peeled.
• You can juice products with solid seeds or
kernels, such as nectarines, peaches, mango,
apricots, plums and cherries, after preliminary
removal of kernels.
• Add some lemon juice into apple juice, so that it
did not get dark.
• When you make cocktails from vegetables
or fruit with different textures start with the
softest ones.
• To juice vegetable herbs, cuttings and green
leaf vegetables turn them into a dense batch or
put between other products. Juice them at low
speed.
USAGE OF PULP
After juicing you receive pulp with a lot of fibers
and cellulose, which also contain nutrients
necessary in our everyday ration. There are
different ways to use pulp, but you should do it
only in the day of juicing to avoid destruction of
vitamins.
You can use pulp to stuff other products and add
it in baked puddings and soups. Fruit pulp can be
baked or used as a cake filling.
Note. The content of juice can range depending
on the variety or ripeness of one and the same
products.
RECOMMENDATIONS
RECOMMENDATIONS

1514
DESCRIPTION OF THE BLENDER CONFIGURATION OF THE BLENDER
1,5 l glass container
KINETIX blade system
Internal removable lid
Lid with auxiliary ring
Block
Base with motor
Speed control
Lid
1,5 l glass container
KINETIX blade system
START / STOP button

1716
SMOOTHIE MODE
In the SMOOTHIE mode the blender first operates
at a constant speed (as in the BLEND mode), and
then impulsively (as in the ICE mode). The blender
operates for 60 seconds in the SMOOTHIE mode.
Advice. Use the mode to make drinks and
ice-cream, as well as whipped cream and milk
shakes.
PULSE INTENSIVE PROCESSING MODE
The Pulse mode suits for solid products, for
example, nuts. In this mode the blender operates at
the maximum speed.
Note. Hold down the Start / Stop button to receive
the desired result.
ICE CRUSHING MODE
In the Ice mode the blender operates impulsively
at the average speed during 60 seconds.
Advice. The amount of ice, which can be placed in
the blender for crushing, comprises 1 standard
250 g tray.
DESCRIPTION OF THE BLDENDER
USAGE OF THE BLENDER
Step 1. Set the blender’s container.
Step 2. Fill the container with products and close
it tightly with the lid.
Note. The container’s filling level must not exceed
the Max mark.
Step 3. Insert the transparent internal lid in the
main lid of the blender and turn it clockwise to fix.
Note. To add ingredients during blending take off the
internal lid.
Step 4. Plug in the blender, set the desired
operation speed (1–5) or automatic mode (ICE,
SMOOTHIE, PULSE) and switch on the blender.
DESCRIPTION OF THE BLDENDER
5 SPEEDS
Select the optimal speed:
1 MIX
2 CHOP
3 BLEND
4 LIQUIFY
5 PUREE
Caution! To prevent wear of the motor the
blender will automatically stop after two minutes
of continuous operation. To continue operation
press the START / STOP button.

1918
MAINTENANCE AND CLEANING
Advice. To facilitate cleaning of the juicer
preliminary switch on speed 5 and fill the feed
chute with a glass of water.
CLEANING OF THE BLADE SET
Turn the blade set counterclockwise on the bottom
part of the blender’s container using the key for the
blade set and carefully extract the blades. Wash
the blades, the container and the lid in warm soapy
water. To remove food remnants use a sponge or a
wooden blade.
Advice. To facilitate cleaning of the blender pour
some water into the blender’s container, add a
drop of a cleaning agent and switch on for several
seconds. Then rinse with clean water.
Note. You can wash the juicer’s lid, filter cup for
juicing, pulp container, juice jar, lids, blades and
the blender’s container in the dishwasher.
Caution! Before cleaning always unplug the
appliance.
CLEANING OF THE CASING’S EXTERNAL
PART
First wipe the external part of the casing with a
wet napkin soaked in a soapy solution and then
wipe with a soft napkin or use a special agent for
cleaning of metal surfaces.
CLEANING OF THE FILTER
After each use carefully wash the filter with the
brush included in the set. After washing look
though the filter to make sure that the filter holes
are not blocked.
SAFETY PRECAUTIONS
• Keep this operating manual.
• Keep the appliance’s casing clean.
• During cleaning observe the instructions
specified in section “Maintenance and
Cleaning”.
• Put the appliance only on a dr y even surface.
• Do not set the appliance in a close proximity to
sources of heat.
• Before operation make sure that the appliance
is correctly assembled.
• When you use the appliance, the lid block must
be in the vertical position and fixed to a click.
• Use the juicer only to make juices from
vegetables, fruit or berries.
• Use the blender only to blend liquids and food
products.
• Fruit with large kernels can be used for juicing
only after removal of kernels.
• Never immerse the base with the motor, the
power cord or the plug of the power cord into
water.
• Exercise caution, the blades in the filter base
are very sharp.
• Always unplug the appliance after usage, as
well as before assembly, dismantling, cleaning
and storage.
• Upon detection of any damages immediately
suspend operation of the appliance and bring it
to the nearest ser vice center for testing, repair
or replacement.
Caution! For safety reasons all operations on
repair and maintenance of the appliance shall be
performed only by authorized representatives of
BORK certified service centers.

20
SPECIFICATIONS
Frequency: 50 Hz
Power: 1800 W
Weight: 9,28 kg
Caution! The manufacturer reserves the right
to make changes to specifications as a result of
continuous product updating without additional
notice thereon.
CONFIGURATION
Base with the motor: 1 pc.
Filter cup: 1 pc.
Fine mesh filter: 1 pc.
Juicer’s lid: 1 pc.
Pusher: 1 pc.
Juice jar: 1 pc.
Pulp container: 1 pc.
Brush to clean the filter: 1 pc.
Blender’s nozzle: 1 pc.
Nozzle for extraction in a glass: 1 pc.
Key for the blade set: 1 pc.
Operating manual with guarantee card: 1 pc.
