BORK M782 User manual

M 782

MEAT GRINDER M782
USER MANUAL

3
INTELLECTUAL AUTOMATIC REVERSE FUNCTION
The first meat grinder on the market, which activates the reverse function
automatically in cases when there are difficulties with meat transfer.
Thisaspect not only eliminates the need to carry out manual operations, but also
reliably protects the motor from breakage.
SMART LOCK UNIQUE MOUNTING SYSTEM
The structural features ensure absence of looseness and vibration during operation:
after assembly, the device can be installed in thebase reliably applying a single
push. The electromagnetic sensor will notallow thedevice to be turned on before
installation. The screw metal connection element provides high performance levels.
My 
Register your BORK equipment in your account on the bork.ru website.
You will get quick access to instructions, accessories, spare parts and reminders
for consumables replacement.

4 5
THREE OPERATION SPEEDS
For processing of different products depending on their juiciness: 1stspeed – bird
meat, fish, berries; 2nd speed – pork, turkey; 3rdspeed– beef, lamb meat.
LOW NOISE LEVEL
The motor runs so quietly that it is possible to use the device without
anydistraction of other people.
Nozzle assembly
Tray
Pusher
Loading unit
Display
Rotary switch for operating modes selection
— button for nozzle removal
Motor unit
Speed selection / language selection button
Rubber supports

6 7
Stuffing grate keeper
Screw
3 mm 4 mm 7 mm
Grates Blade
The 3 mm grate is recommended for cooking of pates and fillings
forvarious fish and meat snacks.
The 4 mm grate is recommended for grinding of beef, lamb
andpoultry meat, as well as vegetables, solid and semi-solid
cheeses.
The 7 mm grate is recommended for stuffing of home-made
sausages, cooking of pork minced meat, as well as for grinding
ofdried fruits, solid and semi-solid cheeses. Pusher Tool for grate cleaning
Screwdriver for unscrewing of the stuffing
grate keeper
Roll blade
Shredder blade Grater blade
Vegetable nozzle holder Vegetable cutter
Vegetable pusher
First attachment set for sausages
Second attachment set for sausages

9
CONTROL PANEL
— launching of the reverse system
— turning the meat grinder off
— turning the meat grinder on
— button for nozzle removal
— speed selection /
language selection button
Prior to the first use, flush the screw blade, meat
nozzle, tray, grates and pusher in running water
anddry them.
ASSEMBLY
• The meat grinder shall be disconnected from mains.
• Install the screw into the nozzle of the meat grinder.
• Put the roll blade on the screw, placing cutting
edges outwards.
• Install the blade, placing cutting edges outwards.
• Install the grate on the screw: small, medium
orlarge, depending on the stuffing consistency
youwant to achieve.
Make sure that the nozzle projection coincides
withthegrateslot.
Tighten the stuffing grate in a clockwise direction.
Apply the SMART LOCK system in order toinstall
theassembly nozzle into the meat grinder, using
a single push procedure, until itissues a characteristic
click. Place the tray ontop
ofthe nozzle assembly.
Disassembly
Disconnect the meat grinder from mains before
disassembly.
Press the button , in order to detach thenozzle
and remove the nozzle.
Unscrew the stuffing grate lock counter-clockwise
using a special tool.
Remove the blade, grate and screw.

10 11
VEGETABLE CUTTER
• Insert necessary blades for the grater or the shredder
intothe unit for vegetables loading.
• Install the blade holder by turning it to the right .
• Apply the SMART LOCK system, using a single push procedure,
install the vegetable nozzle into the meat grinder until it issues
a characteristic click.
First attachment set for sausages
Lock piece for mincing lattice
Second attachment set for sausages

12 13
USING THE HEADS
Use a natural shell: pork or lamb casings.
Rinsetheshell in the running water from the outside
and inside, fill water for 5–7 minutes toget rid
ofexcess salt and ensure elasticity.
• Install the necessary heads onto the screw feed
according to the diagram.
• Tighten the lock piece firmly and place thefeed tray
on the meat feed part.
• Attach the sausage casing to the head mounted
onthe meat grinder.
• Use plunger to feed chopped meat or minced
meat to the feed part, in portions.
Control thefilling ofthecasing, holding it by hand.
Head for kibbeh
Used for cooking kebabs and sausages.
Head for sausage
Designed for preparing home-made sausages.
OPERATION
• Prepare meat for processing: remove bones,
gristles, sinews and carry out slicing.
• Install the nozzle assembly into the meat grinder.
• Connect the meat grinder to mains.
• The display will show the following information:
If the nozzle assembly is not installed in the mincing
machine or is installed partially, then the display will
show the following information:
• Turn the switch to the position in order toactivate
the meat grinder.
• Select the desired speed by pressing the
button. The default setting is 2nd. The display will
provide the following information:
— 1st speed;
— 2nd speed;
— 3rd speed;
• Supply meat to the loading unit in portions.
It shall be prohibited to push products
intotheloading unit using any foreign objects.
Applya special pusher, if necessary.
• Turn the switch to the position in order tostop
the motor.
THREE OPERATION SPEEDS
Availability of 3 speeds in the meat grinder allows
selection of a specific speed for each type of meat:
1st speed – bird meat, fish, berries; 2nd speed–
pork, turkey; 3rd speed – beef, lamb.

14 15
AUTOMATIC REVERSE FUNCTION
The AUTOMATIC REVERSE FUNCTION isenabled
automatically when there aredifficulties with meat
transfer. This function not only eliminates the need
to carry out operations manually, but also reliably
protects the motor from breakage. The AUTOMATIC
REVERSE FUNCTION is enabled automatically
ifthescrew stops rotating during operation
ofthe meat grinder. The AUTOMATIC REVERSE
FUNCTION n isenabled one time.
The display will show the following:
The meat grinder will stop operation andthedisplay
will show the following information if the reason
for blockage is not eliminated after turning
theAUTOMATIC REVERSE FUNCTION on:
• Turn the switch to the position  .
• Remove the nozzle by pressing the button .
• Unscrew the lock of the stuffing grate
inthecounter-clockwise direction.
• Disassemble and clean all removable parts.
ENERGY SAVING MODE
The meat grinder will automatically switch
totheenergy-saving mode if its control means
arenotactivated within 3 minutes.
The display brightness will decrease andthedisplay
will show the following information:
• Press the button or turn the switch
toanyposition in order to exit the power saving
mode.
LANGUAGE SELECTION
• Make sure that the switch is in the position
inorder to select the necessary language.
• Press and hold the butto for 3 seconds.
• The display will show the current language.
• The selected language will be displayed each time
after button pressing:
– Russian;
– English;
– German;
– Italian.
• The device will save the selected language settings
automatically after 4 seconds.
CLEANING
• Prior to cleaning: disconnect the meat grinder
frommains (see the «Disassembly» section).
• Rinse all detachable parts thoroughly withrunning
water using a mild detergent. Rinse them withwater
and wipe with a soft dry cloth.
• The outer part of the meat grinder body shall
bewiped with a damp cloth moistened withsoapy
water and cleaned with a soft dry cloth.
• Use a special cleaning tool for faster andmore
convenient cleaning of grates.
• After cleaning, it is necessary to grease blades
andgrates with vegetable oil.
The blades and grates for stuffing shall bewiped
dry to prevent appearance of rust.
Do not wash the loading compartment
andremovable parts in the dishwasher.
ANODIZED COATING CARE
Do not use tools with abrasive particles, citric acid,
hard sponges and wire brushes inthecleaning
process.
Chemically aggressive compounds,
alkalinedetergents have a destructive effect
ontheanodized surface.

16 17
SAFETY MEASURES
• Prior to the meat grinder operation: carefully read
and save this manual to be able to refer toitinfuture.
• Prior to the first use: flush all removable parts
ofthemeat grinder.
• Prior to device operation: make sure that
characteristics of mains correspond to those
indicated on the product label.
• Connect the device only to a grounded
outlet (the manufacturer (person authorized
by themanufacturer) does not assume any
responsibility for damage in case of absence
of grounding, made in accordance with local
regulations).
• Grates for stuffing, blades, fixing means andscrew
tend to have natural wear, sotheterm of their
operation depends onfrequency and accuracy
ofuse.
• Do not allow clothing, hair, fingers, etc. tocome
incontact with the meat grinder. Such contact can
be hazardous to health.
• The device is not intended for use by persons
(including children) with limited touch orintellectual
capabilities, as well as individuals characterized
byinsufficient experience and knowledge.
• Keep the meat grinder body clean. In thecourse
of cleaning: follow the instructions, provided
inthe«Cleaning» section.
• Install the device on a dry flat surface only.
• Always disconnect the meat grinder from mains
after use, prior to assembly, disassembly andbefore
cleaning.
• Prior to switching the power supply on, makesure
that the device is assembled according
toinstructions provided in the «Assembly» section.
• Do not immerse the meat grinder housing with
themotor or the power cord into water.
• Do not wash these elements using the tap water.
Do not allow moisture ingress into themotor
compartment.
• In the course of the meat grinder operation itshall
be forbidden to push products using fingers
orother foreign objects – apply the pusher
supplied in the kit.
• Do not touch moving parts of the meat grinder
during its operation.
• Do not leave the meat grinder unattended.
• Do not overload the meat grinder. Stop the meat
grinder immediately in case of clogging and clean
the screw and blade from remnants of products.
• Do not use the meat grinder for frozen food
processing.
• It shall be forbidden to grind bones, nuts and other
solid products in the meat grinder.
• Meat products shall firstly be separated from
bones, gristles, sinews and veins.
• Do not allow foreign bodies and liquid toenter
thehousing of the device, since such measure can
lead to damage.
• Do not wash the loading compartment
andremovable parts in the dishwasher.
• When disconnecting the device from mains:
donotpull the cord, rather pulling the plug.
• Store the device in a clean, dry and cool place out
of the reach of children.
• The blades and grates for stuffing shall be wiped
dry to prevent appearance of rust.
• This device is designed for application in home
conditions.
• Do not remove or damage the nameplate with
information about the device and its serial number.
They are necessary for accurate identification
ofthedevice in the event ofa malfunction.
• Transportation of the device is allowed only
intheoriginal packaging, as well as in a fixed
position.
• Dispose the device in accordance
andincompliance with requirements of the national
legislation, implemented currently.
CORRECTIVE MEASURES
• In case of a fault the device shall be stopped
immediately and sent to your nearest BORK service
centre for testing, replacement orrepair.
• For safety reasons, all procedures on repair
andmaintenance of the device shall be performed
only in authorized BORK service centres.
Addresses and telephone numbers of service
centres can be found on the sit bork.ru orusing
thephone number 8 800 500 88 99.

* The nominal power can vary and depends on many parameters: type of meat (product), density, temperature, humidity, consistency
** The maximum power of the motor is electronically limited to 700 watts (±10%)
18
EQUIPMENT KIT
Meat grinder: 1 pc.
Blade: 1 pc.
Screw: 1 pc.
Roll blade: 1 pc.
Grate: 3 pc.
Stuffing grate keeper: 1 pc.
Screwdriver for unscrewing of the stuffing
grate keeper: 1 pc.
Tool for grate cleaning: 1 pc.
Tip: 1 pc.
Pusher: 1 pc.
User manual with the warranty card: 1 pc.
Set for a grater and shredder
Vegetable cutter: 1 pc.
Vegetable pusher: 1 pc.
Grater blade: 1 pc.
Shredder blade: 1 pc.
Set of heads
First set for sausage: 3 pcs.
Second set for sausage: 2 pcs.
Attention! Due to continuous product improvement
we reserve the right tomake changes in design,
packaging andspecifications of the device.
The latest version of this manual canbechecked
onthe website bork.ru.
SPECIFICATIONS
Voltage: 230 V
Frequency: 50 Hz
Rated power: 350 W *
Maximum power: 2200 W **
Sound level: <70 dB
Dimensions (H
× W × D): 395 × 191 × 320 mm
Weight: 8.4 kg
Made in China.
Information about the product purpose:
thedevice is intended for grinding of meat, fish,
vegetables inthe course of stuffing cooking.
Special conditions for sale have not been established.
Dear customers, if you have any questions related to purchase, operation and maintenance of BORK equipment, you can use the phone number
8 800 500 88 99 (Information support service).

PLATINUM COLLECTION

INFORMATION ABOUT CERTIFICATION
The product is certified.
WARRANTY CARD
The BORK company provides a one-year warranty from the date of purchase of this product The service life determined by BORK representatives for this product amounts to 3 years from the date
of sale, provided that the product is used in accordance with rules and recommendations set out in the operating manual attached to it and applicable technical standards.
In order to avoid misunderstandings, we ask you kindly to carefully study the user manual, terms
of the warranty, check correctness of the warranty card. The warranty card is valid ifa user
has a correct and legible specification of the following information: model, serial number
oftheproduct, date of sale, clearly visible seals of the seller, buyer's signature. The model
andserial number ontheproduct shall comply with those indicated in the warranty card.
The warranty shall be deemed null and void if any of these conditions are violated and when
data, specified in the warranty card, is altered, deleted or overwritten. If the date of sale can
notbeestablished in accordance the warranty period and lifetime shall be calculated from
thedateofproduct manufacture in accordance with the Consumer Protection Act.
Product MEAT GRINDER The date of manufacture is encoded in the serial number, for example
1st and 2nd characters – week of manufacture; 3rd and 4th characters – year of manufacture;
last 5 characters – serial number.
The product is tested, completed and has no mechanical damage.
The customer agrees with terms of the warranty and service agreement.
Customer signature Seller signature
Model M782
Sserial number
Date of purchase
Information
on the seller company
(name, legal address)
Name and address of the manufacturer (person authorized by the manufacturer), importer and information intended to contact with them is indicated on packaging of the product.
Stamp here

TERMS OF SERVICE
The manufacturer reserves the right to refuse satisfaction of customer demands for warranties in case of non-compliance with operating conditions, terms of installation of the product,
intentional or careless actions of the purchaser (customer) or a third party, which caused damage to the product.
The warranty does not cover:
• elements, characterized by natural wear and tear. Thus, normal wear and tear includes
consequences of product application which caused deterioration of the technical condition
and appearance due to prolonged use of this product.
The warranty does not cover products with the damage caused by:
• improper operation, careless handling, improper storage, improper connection, failure
toobserve supplied operating instructions;
• contact with foreign objects, substances, liquids, insects or animals, which takes place inside
the unit s housing;
• impact of high and low ambient temperatures on heat sensitive parts of the product;
• mechanical effects;
• improper repair and any other intervention, which resulted in changes in the product design;
• application of the product with industrial and/or commercial purposes;
• damage of the power cord;
• application of detergents, not provided in the manual;
• application of non-standard (non-original) consumables, accessories, spare parts;
• connection to mains with a voltage value other than that specified in instructions
foruseofthe product or non-correspondence with state standards of the Russian
Federation;
• force majeure circumstances (fire, flood, lightning).
Replacement of faulty parts of the product (parts, components, assembly units) during
the warranty period shall not lead to establishment of a new warranty period for the entire
product, or a part replaced.
Service centre address
LLC «Premium Service», Moscow, Bolshaya Sadovaya 10.
Current information on availability of service centres in your area can be found on the site
www.bork.ru or using the phone number 8 800 500 88 99.
