Boscam VISION GS909 User manual
SIZE:285x210mm 折叠尺寸：105X73mm
128g铜版纸黑白印刷折页。
01 05
04
02
03 07
06
02
07
09
Thanks for choosing this product, please read the manual carefully before using.
一、Graphic Instruction
一、Graphic Instruction and specification
二、Operation
三、Packing list
目 录
VISION
Operating Instructions
M: long press in/ out of menu, short press confirm
Power: Long press on/off
Right button: right option and up option in
the menu
Left button: option left and down
CH: short press to frequency adjustment
Antenna：connector
Switch return button: short press to switch 2D to 3D, long
press to head chasing, return menu
2D
3D
FPV
CH
M
2D
3D
FPV
CH
M
5.8G
5.8G
二、Operation
5.8 Ghz Head wearable receiver, 2inch LCD display
Antenna: external SMA plug
Power button: turning on/off
CH button: adjusting the channels
M button: menu
Left button: adjusting for left and down options
Right button: adjusting for right and up options
FPV button: short press for 2D and 3D mode, long press for turning on/off head
tracking (need to be collocated with dual cameras)
Battery: internal 1250mA lithium battery
Charging indicator: red on for charging, red off for fully charged
Charging port 1: micro USD+5V, charging current: 500mA
Charging port 2: DC3.5+12V, charging current: 240mA
Charging time: about 150 minutes
Using time: about 120 minutes
DC IN AV IN
ABEF
Double lens
1 using 3.6mm 60° color lens
2 resolutions: 720*480
3 Dimension of sensor: 1/3
4 storage temperature：-40-70°
Connecting to the double transmitter, supply video signal
lens
Connecting to the brushless cradle head, to achieve head control
3D Display
DC7-19V IN Connecting to the double lens ( 5V supply )
Video output
Video input
DV3.5 12V charge
USB Micro 5V charge
Detachable battery
GS 909
GS 909
TS 606
CM 808
Monitor: Dual 2inch
TFT LCD display
Resolution: 960*240
Brightness: adjustable
Contrast: Adjustable
View angles: vertical
Antenna: external
Working condition: -10℃~ + 65 ℃
2D channels: Dual 5.8Ghz input,
4 bands 32 channels optional
3D channels: 4 channels optional
Power: 650mA @3.7V(max)
1、To ensure if the battery is fully charged, device could not be turned on if battery runs low
2、Long press the power button to turn it on.
3、The AV out of 3D lens connects AV in of transmitter by the cables
4、Transmitter DC-IN connects to the 7-19V power, when the transmitter does not turn on or
frequency non-correspondence with the receiver, the screen shows blue screen;
When the transmitter turns on and frequency correspondence with the receiver,
short press the change frequency, 3D model can be switched 4channel (A B E F),
2D model can be switched 48channel.
5、Long press to power on 3D goggles, turns to 3D model (switch&back buttom can be
switched among 3D, 2D and FPV model), and set the frequency as same as the transmitter's.
current “S”
CH
S
M
SIZE:285x210mm 折叠尺寸：105X73mm
128g铜版纸黑白印刷折页。
CM 808
09
08
5865
5733
5705
5740 5760 5780 5800 5820 5840 5860 5880
5685 5665 5645 5885 5905 5925 5945
5752 5771 5790 5809 5828 5847 5886
5845 5825 5805 5785 5765 5745 5725
5658
G
S
5695 5732 5769 5806 5843 5880 5917
5390 5425 5460 5495 5530 5565 5600 5635
2D/3D Goggle Dual Lens
Transmitter USB Charge
三、packing list
ABEF
6、 3D Frequency
7、 2D Frequency
11
10
Manual Antenna
Video Output/Input Power cable
FPV cable Dual Transmitting AV cable
Dual Transmitting power cable
