Silhouette TITAN DESIGN Assembly instructions

Instructions for ASSEMBLY and DISASSEMBLY of
Temple Inclination
TITAN DESIGN

1. DISASSEMBLING THE TEMPLE
Place disassembly stick as close as possible
to the inside of the hinge.
(pictured red disassembly tool AC 336 not
currently available)
Fold temple and press together directly
behind disassembly stick.
(pictured red disassembly tool AC 336 not
currently available)
AC 336
(P 0000 11 0336 0000)

2. ASSEMBLING OF TEMPLE
Support temple firmly by placing on the edge of
a flat surface.
NOTE: Place pressure only on flat surface, not
on
lens fixation or decoration part.
Place opening of hook and decoration part
in the same position.

3. ASSEMBLING OF TEMPLE
Press in hook on hinge from the top down.

4. ADJUSTMENT OF INCLINATION
Hold lens fixation firmly.
TIP: Use universal mounting pliers for extra
support.
1. Open temple up entirely
2. Incline trim area
3. Hold temple with decoration part firmly.
