Bosch Tassimo Series TAS60GB User manual

my way
TAS60xxGB
en Instruction manual

en Safety instructions
en At a glance
en Troubleshooting
1English

a
ba
b
a
d
c
b
a
d
a
b
c
e
f
bc
d
g
4
3
1 2
5
a
ba
b
a
d
c
b
a
d
a
b
c
e
f
bc
d
g
4
3
1 2
5

en Risk of electric shock!
en Risk of burns!

1
en
Important safety information
Please read parts 1 and 2 of
these manuals carefully before
using the product and keep
them for future reference.
Passthemon to all users.
This appliance may be used
by children aged 8 years and
older and by persons with
reduced physical, sensory or
mental capabilities or who lack
experience and / or knowledge
if they are supervised or have
been given instruction in the
safe use of the appliance and
have understood the dangers
involved. Children may not play
with the appliance.
Cleaning and user maintenance
shall not be made by children
unless they are older than
8years and supervised.
Keep children under 8 years of
age away from the appliance
and connecting cable and
do not allow them to use the
appliance.
For optimum results, fi ll the
tank only with cool, fresh,
non-carbonated water each
day.
Do not use chemically softened
water.
Never leave the appliance
unattended while it is in
operation!
Intended use
This appliance is intended for
domestic use only.
Only use the appliance indoors
at room temperature and up to
2000 m above sea level.
Safety instructions

2
en
WRisk of electric shock!
■Operate and connect
the appliance only
in accordance with
theinstructions given on the
nameplate.
■The appliance may only
be connected to a power
supply with alternating
current via a correctly
installed socket with
earthing. Ensure that the
protective conductor system
of the domestic supply has
been correctly installed.
■Before cleaning the
appliance, pull out the
mains plug.
■Only use your TASSIMO
appliance if the power cable
and appliance show no signs
of damage.
■Disconnect the appliance
from the mains as soon as a
fault is detected.
■Any repairs, such
as replacing a damaged
power cable, may only be
carried out by our Customer
Services team in order to
avoid potential danger.
■Never immerse the
appliance or power cable in
water.
■Avoid spillage on the
connector.
WRisk of burns!
■Never attempt to open
the brewing unit during
operation. Pleasenote that
any escaping liquids will
be very hot. TheTDISC,
the piercing unit and the
beverage outlet may be
very hot immediately after
brewing. Allow to cool fi rst.
■Do not use TDISCs that are
damaged.
■Only use each TDISC once.
WRisk of injury!
■A misuse of the appliance
can potentially lead to injury.
■Under no circumstances you
should drink the descaling
liquid.
WRisk of suff ocation!
■Do not allow children to play
with packaging material.
WCaution!
■Cleaning surfaces which
come into contact with
foodstuff s! Please note
the special information on
cleaning in the illustrated
instructions.
Safety instructions

3
en
At a glance
Before reading on, please unfold the
illustrations page at the start of the
booklet.
1 Control panel
a Start / Stop button with
statusdisplayY
b Display/buttons for
drinkintensityn
c Display/button for
drink temperature Z
d Display/buttons for drink size N
e Display/buttons for saving and
calling up individual settings À
f Display “Fill water tank” R
g Display/button „Descale“ Q
2 Removable water tank
a Lid with handle (removable)
b max mark
c “Descaling” Qmark
d Float
3 Brewing unit
a Lid
b TDISC support (removable)
c TDISC piercing unit with beverage
outlet (removable)
d TDISC reading window
4 Storage compartment
a Orange Service TDISC
b Brief cleaning / descaling
instructions
5 Cup stand
(removable and height adjustable)
a Drip gate
b Drip tray
Info
Bosch is the manufacturer of the
TASSIMO machine. Therefore, it cannot
provide any delivery guarantee for the
TASSIMO T DISCs.
TASSIMO TDISCs are available from
specialist retailers.
Visit www.tassimo.com to discover the
large variety of beverages available.
Hereyou can discover and order the
right TASSIMO accessories online.
Accessories
Accessories Order number
Retail Customer
service
Descaling
tablets
TCZ6004 –
Orange Service
TDISC
– 00576837
www.bosch-home.com
www.tassimo.com
Disposal
Dispose of packaging in an environmen-
tally-friendly manner. This appliance
islabelled in accordance with European
Directive 2012/19/EU concerning used
electrical and electronic appliances
(waste electrical and electronic
equipment – WEEE). The guideline
determines the framework for the
returnand recycling of used appliances
as applicable throughout the EU.
Please ask your specialist retailer about
current disposal facilities.

4
en
Troubleshooting
The following table contains solutions to problems or faults which may occur during
operation of the appliance and that can be easily rectified at home. If you are not
satisfied with the solutions provided here, please contact our Customer Service
department.
Further customer service information can also be found online:
www.bosch-home.com
www.tassimo.com
Problem Cause Solution
No LED is lit. The appliance is in idle
mode.
Press Start / Stop button.
The controls do not
respond to touch.
Technical fault. Unplug the mains plug. Wait for approx.
5minutes. Re-insert the mains plug into the
socket.
The control panel is
dirty.
Unplug the mains plug. Clean the display
elements/controls with a soft, damp cloth. Re-
insert the mains plug into the socket.
The appliance is not
working and none of
the display elements
are lighting.
The appliance has no
power supply.
Check to see whether the appliance is
connected to the mains.
The brewing starts,
however there is no
beverage dispensed.
The water tank is not
inserted correctly.
Check that the water tank is correctly inserted.
The water tank was
removed during the
brewing stage or there
is air in the system.
Start the cleaning process with the orange
Service TDISC. Please refer here to the section
First Time Use, Steps 2 – 14.
The float in the water
tank is stuck.
Clean the water tank and free the float.
The brewing will not
start.
No TDISC inserted. Check that a TDISC has been inserted.
The appliance does
not recognise the
TDISC bar code.
The displays/buttons
for drink intensity,
drink temperature and
drink size are flashing.
Clean the TDISC reading window with a soft,
damp cloth.
Smooth out the foil of the TDISC with your
finger so that the bar code can be read.
Use a new TDISC.
If the problem persists, contact the TASSIMO
careline.
The brewing unit is not
closed properly.
Clean the brewing unit with a soft, damp cloth,
paying particular attention to the lid area.
The appliance was not
plugged in when the
TDISC was inserted.
Check that the appliance is plugged into the
power supply before inserting the TDISC.

5
en
Problem Cause Solution
The brewing unit
cannot be closed.
The piercing unit
and/or the TDISC
support have not been
correctly inserted.
Press the piercing unit into its holder using
both thumbs and check the position of the
TDISC support.
The TDISC has
not been correctly
inserted.
Replace the damaged TDISC with a new one.
Place the TDISC with the printed side facing
downwards so that the tab is resting in the
intended slot.
The brewing unit is not
closed properly.
Clean the brewing unit with a soft, damp cloth,
paying particular attention to the lid area.
Press the lid down until it audibly clicks into
place.
The brewing unit
cannot be opened.
The brewing unit is
still locked.
Only open the brewing unit when the status
display Y has stopped flashing and remains lit
continuously.
Unplug the mains plug. If the brewing unit stays
locked, contact the TASSIMO careline.
Fill water tank R
lightsup.
There is not enough
water in the water
tank.
Fill the tank with cold, fresh water as far as the
max mark. Reinsert the water tank.
Fill water tankRlights
up even though there
is enough water in the
water tank.
The float in the water
tank is stuck.
Clean the water tank and free the float.
The water tank is not
inserted correctly.
Check that the water tank is correctly inserted.
Fill water tank R
and Descale Q
are flashing simulta-
neously and it is not
possible to prepare
drinks.
There is a fault on the
machine.
Unplug the mains plug. Please contact the
TASSIMO careline.
Descale Qlights up
or starts flashing.
The appliance needs
to be descaled.
Descale the appliance. Please refer here to the
section Descaling.
Descale Qlights up
or starts flashing even
though decalcified
water has been used.
Even decalcified water
contains low amounts
of calcium carbonate.
Descale the appliance. Please refer here to the
section Descaling.
The quality of
the crema has
deteriorated.
The beverage outlet is
sticky or dirty.
Clean the beverage outlet. Please refer here to
the section Cleaning.
Clean the brewing unit with the orange Service
TDISC. Please refer here to the section
Cleaning.
Build-up of limescale
in the appliance.
Descale the appliance. Please refer here to the
section Descaling.
Troubleshooting

6
en
Problem Cause Solution
Water is dripping from
the brewing unit.
The TDISC is
damaged or leaky.
The TDISC has not
been pierced correctly.
Do not use TDISCs that are damaged.
Only use each TDISC once.
Wait until the brewing stage has come to
an end and the appliance has cooled down.
Remove the TDISC and clean the brewing unit.
Please refer here to the section Cleaning.
The piercing unit has
not been inserted
correctly.
Press the piercing unit into its holder using
both thumbs (until an audible click is heard).
On the surface below
the cup stand there is
water.
This is condensation. Condensation may appear and is not caused
by any fault with the appliance. Wipe the water
away with a cloth.
The beverage quantity
does not meet your
requirements.
The TDISC bar
code provides the
recommended volume
for every beverage
selected. This
volume can also be
adapted to personal
requirements.
Use the drink size buttons (N–N–O)to set
your individual drink volume before you begin
brewing.
Reduced quantity:
During the brewing process, press the
Start / Stop button to interrupt this stage.
Increased quantity:
Press and hold the Start / Stop button until the
required beverage quantity has been reached.
Build-up of limescale
in the appliance
could cause reduced
quantity.
Descale the appliance. Please refer here to the
section Descaling.
The orange Service
TDISC is damaged or
lost.
The following accessories can be
obtained via Bosch customer service,
www.bosch-home.com and www.tassimo.com
(see the end of this instruction manual for
contact details): Orange Service TDISC (item
no.00576837), descalingtabs (item no.
TCZ6004)
Descaling tabs are
required.
Not all the settings
(drink intensity n,
drink temperature Z
or drink size N) are
available.
There are different
setting options
depending on the type
of drink.
Troubleshooting

7
Guarantee
Customer Service
en Guarantee
The guarantee conditions for this appliance are as
defined by our representative in the country in which
it is sold. Details regarding these conditions can be
obtained from the dealer from whom the appliance
was purchased. The bill of sale or receipt must be
produced when making any claim under the terms of
this guarantee.
GB Great Britain
BSH Home Appliances Ltd.
Grand Union House
Old Wolverton Road
Wolverton
Milton Keynes MK12 5PT
To arrange an engineer visit, to order spare parts and
accessories or for product advice please visit
www.bosch-home.co.uk
Or call
Tel.: [phone]*
* Calls are charged at the basic rate, please check
with your telephone service provider for exact
charges

GB TASSIMO careline
For information, questions or locations of authorised Bosch service centres nearest you, please
contact TASSIMO:
Phone: [phone]
www.tassimo.co.uk
www.bosch-home.com
www.tassimo.com
Infoline
8001 050 660 04/17www.tassimo.com
