Bosch Use and Care Manual:
NGT/NGP

Questions?
1-800-944-2904
www.boschappliances.com
5551 McFadden Ave.
Huntington Beach, CA 92649
We look forward to hearing from you!

Table of Contents
Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
About the Cooktop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Parts and Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Sealed Burners . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Burner Caps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Burner Grates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Burner Control Knobs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Using the Cooktop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Before Using the Cooktop for the First Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Normal Operation (Electronic Ignition/Reignition) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
In the Event of a Power Failure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Typical Flame Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Getting the Most Out Of Your Cooktop . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Cooking Techniques (For Best Results) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Proper Cookware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Cookware Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Proper Cookware Practices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Cooking Chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Care and Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Daily Cleaning Practices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Cleaning Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Before Calling for Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Data Plate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
For Authorized Service or Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
What Is Covered - Full One Year Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
What Is Not Covered . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Warranty Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Model Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

English 1
IMPORTANT SAFETY INSTRUCTIONS
READ AND SAVE THESE INSTRUCTIONS
Important Safety
Instructions
WARNING: Read all instructions before using this appliance. To
reduce the risk of fire, electric shock, or injury to persons, take these
precautions:
General Safety
• This appliance is intended for normal family household use only. See the
Warranty. If you have any questions, contact the manufacturer.
• Always have a working smoke detector near the kitchen.
• Never use the cooktop to warm or heat a room.
• Children should not be left alone or unattended in an area where appliances
are in use. They should never be allowed to sit or stand on any part of the
appliance.
• When children become old enough to use the cooktop, they must be
instructed in safe practices.
• Do not store items of interest to children above or at the back of the cooktop .
• Do not store flammable materials on or near the cooktop.
• In the event that personal clothing catches fire, drop and roll immediately to
extinguish flames.
• Never let clothing, potholders, or other flammable materials come in contact
with hot burners or hot burner grates.
• Do not clean the cooktop while it is still hot. Some cleaners produce noxious
fumes when applied to a hot surface.
• Smother flames from food fires other than grease fires with baking soda.
Never use water on cooking fires.
• Do not allow aluminum foil, plastic, paper or cloth to come in contact with a
hot burner or grate. Do not allow pans to boil dry.
• Have the cooktop installed and grounded by a qualified technician.
• Do not repair or replace any part of the appliance unless specifically recom-
mended in this manual. All other servicing should be referred to a qualified
technician.
• Do not use aluminum foil to line any part of the cooktop.
• If the cooktop is near a window, be certain that curtains or any other window
covering do not blow over or near the burners; they could catch on fire.
• When using the cooktop: Do not touch the burner grates or the immediate sur-
rounding area.
• Use only dry potholders; moist or damp potholders on hot surfaces may
cause burns from steam.
• Never leave the cooktop unattended when in use. Boilovers cause smoking,
and greasy spillovers may ignite.
• Always position handles of utensils inward so they do not extend over adja-
cent work areas, burners, or the edge of the cooktop.
• Wear proper apparel. Loose fitting garments or hanging sleeves should never
be worn while cooking.
• Use only certain types of glass, heatproof glass, ceramic, earthenware, or
other glazed utensils that are suitable for cooktop use.
• Leave the hood ventilator on when flambéing food.
• Smother flames from a grease fire with a close-fitting lid, cookie sheet, or
other metal tray, then turn off the gas burner. Be careful to prevent burns. If
the flames do not go out immediately, evacuate and call the fire department.
• Do not use water, including wet dishcloths or towels on grease fires. A violent
steam explosion may result.
• Never pick up a flaming pan. You may be burned.

English 2
WARNING: To avoid electrical shock hazard, before servicing the
cooktop, switch power off at the service panel and lock the panel to
prevent the power from being switched on accidentally.
Fire Extinguishers
Use an extinguisher only if:
• You know you have a Class ABC extinguisher and you know how to operate
it.
• The fire is small and contained in the area where it started.
• The fire department is being called.
• You can fight the fire with your back to an exit.
Gas Appliance Safety
Gas Cooking Safety
• During cooking, set the burner control so that the flame heats only the bottom
of the pan and does not extend beyond the bottom of the pan.
• Take care that drafts like those from fans or forced air vents do not blow flam-
mable material toward the flames or push the flames so that they extend
beyond the edges of the pan.
• Have the cooktop installed and grounded by a qualified technician. Have the
installer show you where the gas shut-off valve is located.
• For proper lighting and performance of burners, keep igniters clean and dry.
• In the event that a burner goes out and gas escapes, open a window or a
door. Wait at least 5 minutes before using the cooktop.
• Do not obstruct the flow of combustion and ventilation air.
California Proposition 65
WARNING: Burning gas cooking fuel generates some by-products
which are on the list of substances which are known by the State of
California to cause cancer or reproductive harm. To minimize exposure
to these substances, always operate this unit according to the instruc-
tions contained in this booklet and provide good ventilation.
WARNING: If the information in this manual is not fol-
lowed exactly, a fire or explosion may result causing
property damage, personal injury or death.
Do not store or use combustible materials, gasoline or other flamma-
ble vapors and liquids in the vicinity of this or any other appliance.
• WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch.
• Do not use any phone in your building.
• Immediately call your gas supplier from a neighbor’s phone.
Follow the gas supplier’s instructions.
• If you cannot reach your gas supplier, call fire department.
Installation and service must be performed by a qualified installer,
authorized service agency or the gas supplier.

English 3
About the Cooktop
Parts and Accessories Figure 1 - Parts
* Key numbers 1-7 also correspond to the control knob location for the burner.
Table 1: Features Key
# Location BTU Rate
1 Left Rear 9,100
2 Right Rear - 30" 11,000
3 Right Rear-36" 9,100
4 Left Front 12,500 - NGT Model
15,000 - NGP Model
5 Right Front-30", Simmer Burner 6,500/950
6 Center Front-36", Simmer Burner 6,500/950
7 Center Rear-36" 11,000
8 Serial Number/Data Plate
30" Models
36" Models
1
1
1
1
2
2
3
3
4
44
4
5
5
66
7
7
8
8

English 4
Sealed Burners Your new cooktop has sealed gas burners. There are no burner parts under the
cooktop to clean, disassemble or adjust. Your cooktop has two different burner
cap sizes, large and medium. Match the pan to the size burner.
Burner Caps The burner cap is porcelainized steel. On the underside of the cap is one locator
which must fit into the corresponding notch on the burner base. If the burner cap
is not placed correctly, the burner may not light or the flame may not burn com-
pletely or correctly.
Figure 2 - Burner Cap
WARNING: To prevent flare-ups do not use the cooktop without all
burner caps and all burner grates properly positioned.
Burner Grates The position of each double grate is labeled on the underside edge of the grate as
shown in the figure below.
Figure 3 - Burner Grates
30" (76cm) Models have two universal grates. Position the straight side in the cen-
ter. They are interchangeable by rotating 180°.
36" (91cm) Models have one side grate, one center grate and one single grate.
Position the grates on the cooktop as illustrated above.
BURNER BASE
Igniter
Locator
Ports
Porcelain
Enamel Cap
BURNER CAP
Notch
Universal -
30”models
only
Side Center
Single -
36”models
only

English 5
WARNING: To prevent flare-ups all grates must be properly posi-
tioned on the cooktop whenever the cooktop is in use. Each of the four
feet must be placed into the corresponding dimples in the cooktop. Do
not use a grate if the rubber feet are missing or damaged.
Burner Control Knobs The standard burner controls have an infinite number of heat settings with no
fixed positions.
Figure 4 - Burner Control Knob
To operate: Select the appropriate control knob, push down and turn counter-
clockwise to the desired flame size. Turn OFF by turning the control knob clock-
wise to OFF.
A rubber grommet is located under each control knob.
To remove knob and grommet: With burner in the OFF position, gently lift knob
up and off. Gently pull grommet toward center and lift out.
WARNING: To avoid electric shock, do not reach through opening
into rough-in box.
To replace grommet and knob: Replace grommet by placing center groove
around cooktop. The rubber grommet should be firmly attached around the cook-
top opening. Place the control knob indicator line at the OFF position; press down
firmly.
Using the Cooktop
Before Using the Cooktop
for the First Time
• Remove all packing materials and literature from the cooktop surface.
• While cool, wipe with a clean, damp sponge and dry.
• There may be a slight odor during the first several uses; this is normal and will
disappear.
• Optimum cooking results depend on the proper cookware being selected and
used. (See Proper Cookware.)
• Read all safety precautions and Use and Care Manual information prior to
operating.
LO
HI
OFF

English 6
Operation
Normal Operation
(Electronic Ignition/Reignition) The cooktop uses electronic igniters to light the burners. There is no pilot light.
Each burner has its own igniter. If a burner flame blows out during use, the burner
will automatically reignite.
CAUTION: All igniters spark when any single burner is turned ON or
the reignition system is activated. Do not touch any of the burners
when the cooktop is in use.
The ignitor should be clean and dry for proper operation.
• Avoid getting water or food on the igniter.
• If the igniter is wet or soiled, it may spark without igniting the burner, or even
spark continuously when a flame is present.
NOTE: If the burner does not light within 4 seconds, turn the burner off. Check to
see that the cap is positioned correctly on the burner base and the igniter is clean
and dry. If a burner still fails to ignite, see Before Calling for Service.
In the Event of a Power Failure In the event of a power failure, the burners can be ignited manually.
If the cooktop is being used when a power failure occurs, turn all the burner con-
trol knobs to the OFF position. The burners can then be ignited manually by hold-
ing a match at the ports and turning the control knob to the HI position. Wait until
the flame is burning all the way around the burner before adjusting the flame to
the desired height.
CAUTION: The reignition feature will not work in the event of a
power failure.
Typical Flame Characteristics The burner flame should be blue in color and stable with no yellow tips, excessive
noise or fluttering. It should burn completely around the burner cap.
Foreign particles in the gas line may cause an orange flame during initial use. This
should disappear with use. Check burner cap to make sure port holes are not
obstructed. If the ports are clogged, see Before Calling for Service.
NOTE: An audible “pop” may be heard when the burner is turned off manually.
The “popping” may be louder with LP gas than with natural gas. This is normal.
Yellow Flames:
Further adjustment is required.
Yellow Tips on Outer Cones:
Normal for LP Gas.
Soft Blue Flames:
Normal for Natural Gas.
If the flame is completely or mostly yellow, verify that the regulator is set for the
correct fuel. After adjustment, retest.
Some yellow streaking is normal during the initial start-up. Allow unit to operate
