Bosch rexroth BODAS DI4 10 Series User manual

Instruction manual
RE95289-01-B/2021-10-12, EN
BODAS displays
DI4 series 10
DI3 series 10 and 11

© BoschRexrothAG2021. All rights reserved,
also regarding any disposal, exploitation,
reproduction, editing, distribution, as well as
in the event of applications for industrial
property rights.
The data specified within only serves
todescribe the product. No statements
concerning acertain condition or suitability
for acertain application can be derived from
our information. The information given does
not release the user from the obligation of
own judgment and verification. It must be
remembered that our products are subject
to anatural process of wear and aging.
The cover shows an example application.
The product delivered may differ from
the image on the cover.
The original instruction manual was
created in German.

RE95289-01-B/2021-10-12, BoschRexrothAG
Contents | BODAS displays 3/40
Contents
1 About this documentation ........................................................................ 5
1.1 Validity of the documentation ......................................................................5
1.2 Required and supplementary documentation...............................................5
1.3 Representation of information......................................................................5
1.3.1 Safety instructions .......................................................................................5
1.3.2 Symbols .......................................................................................................6
1.3.3 Designations ................................................................................................7
1.3.4 Abbreviations ...............................................................................................7
2 Safety instructions ................................................................................... 8
2.1 About this chapter........................................................................................8
2.2 Intended use ................................................................................................8
2.3 Improper use................................................................................................8
2.4 Personnel qualifications ...............................................................................9
2.5 General safety instructions ..........................................................................9
2.6 Product-specific safety instructions ...........................................................12
2.7 Personal protective equipment...................................................................12
3 General instructions on property damage and product damage.............. 13
4 Scope of delivery.................................................................................... 14
4.1 Scope of delivery DI4 .................................................................................14
4.2 Scope of delivery DI3 .................................................................................15
5 About this product ................................................................................. 16
5.1 Product description DI4 .............................................................................16
5.2 Product description DI3 .............................................................................18
5.2.1 BODAS DCT 1.0 / 2.0 (Display Configuration Tool) ....................................19
5.2.2 BODAS DCT library ....................................................................................19
5.3 Identification of DI4 ...................................................................................21
5.4 Identification of DI3 ...................................................................................22
6 Transport and storage ............................................................................ 23
6.1 Storing the BODAS display.........................................................................23
7 Installation............................................................................................. 24
7.1 Unpacking ..................................................................................................24
7.2 Installation conditions................................................................................24
7.3 Installing the BODAS display......................................................................25
7.3.1 Preparation ................................................................................................25
7.3.2 Installing the BODAS display DI4 ...............................................................25
7.3.3 Installing the BODAS display DI3 ...............................................................27
7.3.4 Information on wiring and circuitry ............................................................30
7.3.5 Electrically connecting the BODAS display.................................................31
8 Commissioning....................................................................................... 32
9 Operation ............................................................................................... 33
9.1 Programming of DI4 ...................................................................................33
9.2 Programming of DI3 ...................................................................................34

4/40 BODAS displays | Contents
BoschRexrothAG, RE95289-01-B/2021-10-12
10 Maintenance and repair.......................................................................... 35
10.1 Cleaning and care ......................................................................................35
10.2 Inspection and maintenance ......................................................................35
10.3 Repair ........................................................................................................35
11 Removal and replacement ...................................................................... 36
12 Disposal ................................................................................................. 36
13 Extension and conversion....................................................................... 36
14 Technical data ........................................................................................ 37
15 Alphabetical index ................................................................................. 38

RE95289-01-B/2021-10-12, BoschRexrothAG
About this documentation | BODAS displays 5/40
1 About this documentation
1.1 Validity of the documentation
This documentation applies to the following products:
• BODAS display DI4, series 10
• BODAS display DI3, series 10 and 11
This documentation is intended for machine/system manufacturers,
assemblers and service engineers.
This documentation contains important information on the safe and proper transport,
installation, commissioning, operation, maintenance, disassembly and simple
troubleshooting of the product.
▶ Read this documentation completely, in particular chapter2 "Safety instructions"
on page8 and chapter 3 "General instructions on property damage and
product damage" on page13 before you start working with the product.
1.2 Required and supplementary documentation
▶ Only commission the product if the documentation marked with the
book symbol is available to you and you have understood and observed it.
Table 1: Required and supplementary documentation
Title Document number Document type
BODAS display DI4, series 10
Contains the permissible technical data,
ports, main dimensions and circuit diagrams
of standard versions.
95272 Data sheet
BODAS display DI3, series 10 and 11
Contains the permissible technical data,
ports, main dimensions and circuit diagrams
of standard versions.
95270 Data sheet
1.3 Representation of information
Uniform safety instructions, symbols, terms and abbreviations are used throughout
this documentation to ensure safe and proper use of the product. For clarification,
they are explained in the sections below.
1.3.1 Safety instructions
This documentation contains safety instructions in chapter2.6
"Product-specific safety instructions" on page12 and in chapter3
"General instructions on property damage and product damage" on page13,
as well as before asequence of actions or an instruction for action involving
arisk of personal injury and property damage. Always follow the measures for
danger prevention associated with the use of this product.

6/40 BODAS displays | About this documentation
BoschRexrothAG, RE95289-01-B/2021-10-12
Safety instructions are set out as follows:
SIGNAL WORD
Type and source of danger!
Consequences of non-compliance
▶ Danger prevention measures
•Warning sign: draws attention to the danger
•Signal word: identifies the degree of the danger
•Type and source of danger: indicates the type and source of the danger
•Consequences: describes the consequences of non-compliance
•Precautions: states how the danger can be avoided
Table 2: Hazard classes as defined in ANSI Z535.6
Warning sign, signal word Meaning
DANGER Identifies adangerous situation that will result in death
or serious injury if it is not avoided.
WARNING Identifies adangerous situation that may result in death
or serious injury if it is not avoided.
CAUTION Identifies adangerous situation that may result in minor to
moderate injury if it is not avoided.
NOTICE Property damage: The product or surrounding area may be
damaged.
1.3.2 Symbols
The following symbols indicate notices that are not safety-relevant but increase
understanding of the documentation.
Table 3: Meaning of symbols
Symbol Meaning
If this information is disregarded, the product cannot be used and/or
operated to its full extent.
▶ Single, independent action
1.
2.
3.
Numbered instruction:
The numbers indicate that the actions must be completed in order.

RE95289-01-B/2021-10-12, BoschRexrothAG
About this documentation | BODAS displays 7/40
1.3.3 Designations
This documentation uses the following designations:
Table 4: Designations
Designation Meaning
DI4 BODAS display DI4, series 10
DI3 BODAS display DI3, series 10 and 11
The designations "product" or "display" are used as the generic term for the
"BODAS display".
1.3.4 Abbreviations
This documentation uses the following abbreviations:
Table 5: Abbreviations
Abbreviation Meaning
ANSI American National Standards Institute is an organization that coordinates
the development of voluntary standards in the United States
CAN Controller Area Network
CODESYS Controller Development System
PEE Pressure Equalizing Element
DCT Display Configuration Tool
EMC Electromagnetic compatibility
EN European Norm (standard)
ESD Electrostatic discharge
NTSC National Television Systems Committee
OEM Original Equipment Manufacturer
PAL Phase Alternation Line
PC Personal Computer
RE Rexroth document in the English language
USB Universal Serial Bus
VGA Video Graphics Array

8/40 BODAS displays | Safety instructions
BoschRexrothAG, RE95289-01-B/2021-10-12
2 Safety instructions
2.1 About this chapter
The product has been manufactured in accordance with generally accepted
engineering standards. There is still, however, adanger of personal injury
or property damage if this chapter and the safety instructions in this documentation
are not observed.
▶ Read this documentation completely and thoroughly before working with
the product.
▶ Keep this documentation in alocation where it is accessible to all users at
all times.
▶ Always include the required documentation when passing the product on to
third parties.
2.2 Intended use
The BODAS display is designed for use in mobile working machines with
12 or 24 volt electrical battery system unless any restrictions/limitations
regarding specific areas of application are specified in the applicable data sheet,
see Table 1 "Required and supplementary documentation" on page5.
▶ Generally, the BODAS display must be operated within the operating ranges
specified and approved in the respective datasheet, see Table 1 "Required and
supplementary documentation" on page 5, particularly with regard to voltage,
temperature, vibration, shock and other described environmental influences.
The specified limits must not have apermanent effect.
▶ Its use outside of these specified and approved boundary conditions may
result in danger to life and/or cause damage to components which could result
in sequential damage to the mobile working machine.
▶ The DI4 display is resistant to the following media:
Cleaning agents, NPK fertilizer (nitrogen, phosphor and potassium),
RME (rape methyl ester), gasoline, diesel
▶ The DI3 display is resistant to the following media:
Cleaner solvent, interior cleaner, glass cleaner, coffee, cola, denaturedalcohol
NOTICE! The compatibility of the display DI4 compared to other media can be
evaluated. Please contact your local contact person. You can find their contact
information at https://addresses.boschrexroth.com
The product is intended only for professional use and not for private use.
Intended use includes having fully read and understood this documentation,
especially chapter 2 "Safety instructions" on page 8.
2.3 Improper use
Any use other than that described as intended use is considered improper.
BoschRexrothAG is not liable for damage resulting from improper use.
The user is solely responsible for any risks arising from improper use.
The following foreseeable forms of faulty usage are also considered improper
(this list is not exhaustive):
• Use outside the operating parameters approved in the data sheet.
• The BODAS display is not suitable for use in safety-relevant functions.
DI4
DI3

RE95289-01-B/2021-10-12, BoschRexrothAG
Safety instructions | BODAS displays 9/40
• The BODAS display or the operating elements in the device (softkeys, hardkeys,
push/turn controls) must not be used to control the movements of amachine.
• Do not assign safety-related functions to the function buttons or the push-turn
control of the display. Separate switches are always to be used to control
safety-relevant functions, e.g.emergency off switch for immediate or controlled
stoppageof the system.
• Make sure that the display configuration does not lead to safety-critical display
failures or display malfunctions of the complete system in the event of failure
or malfunction. This type of system behavior may lead to danger to life and/or
cause much damage to property.
• Use in potentially explosive areas is not permitted.
2.4 Personnel qualifications
The activities described in this documentation require basic knowledge of
mechanics and electronics/electrics, as well as knowledge of technical terms
associated with those fields. In order to ensure safe use, these activities should only
be performed by skilled personnel or an instructed person under the direction and
supervision of skilled personnel.
Skilled personnel refers to persons who possess the professional training,
knowledge and experience, as well as the understanding of the regulations relevant
to the work to be done that are necessary to recognize possible dangers and
take the appropriate safety measures. Skilled personnel must follow the rules
relevant to their field and have the necessary expert knowledge of mechatronics
and electronics.
Expert knowledge means, for instance:
• Being able to read and fully understand electric circuit diagrams,
• in particular, fully understanding the relationships with regard to safety devices,
• as well as to carry out the wiring of electronic components correctly and
• regarding the function and interaction of electronic and mechanical components.
System developments, installations and commissioning of electronic systems must
always be carried out by trained and experienced specialists who are sufficiently
familiar with both the components used and the complete system.
BoschRexroth offers training support for specialized fields.
You can find an overview of the training contents on the Internet at:
www.boschrexroth.com/training.
2.5 General safety instructions
• Observe the country-specific accident prevention and environmental protection
regulations.
• Observe the safety regulations of the country in which the product is used/operated.
• Use Rexroth products only when they are in good working order.
• Do not install, operate, disassemble or maintain Rexroth products if under
the influence of alcohol, drugs or medication that may affect your reaction time.
• Only use approved accessories and original spare parts from Rexroth in order to
exclude hazards to persons due to unsuitable spare parts.
• Observe the technical data and ambient conditions specified in the product
documentation.
• If unsuitable products are installed or used in applications that are of relevance
to safety, unexpected operating conditions may occur in the application,

10/40 BODAS displays | Safety instructions
BoschRexrothAG, RE95289-01-B/2021-10-12
which could result in personal injury or property damage. For this reason,
only use the product in safety-relevant applications if this use is expressly
indicated and approved in the product documentation, e.g.in safety-related parts
of acontrol system (functional safety).
• Only commission the product if it has been determined that the end product
(e.g.machinery/system) in which the Rexroth products are installed complies with
the country-specific provisions, safety regulations and standards for the application.
• Use tools appropriate for the work being performed and wear appropriate
protective clothing to prevent punctures and cuts (e.g.when removing protective
covers, disassembly).
• The display contains electronic components and may thus be damaged
by electrostatic discharge. Comply with the handling regulations
for electronically sensitive components, see respective data sheet
(Table 1 "Required and supplementary documentation" on page 5).
• The proposed circuits do not imply any technical liability for the system on the part
of BoschRexroth.
• Working on the PC with BODAS DCT (for DI3) and the CODESYS development
environment (for DI4) in combination with acontrol unit or display in amachine or
vehicle is only permissible during commissioning of the machine or during service
operations. Appropriate safety measures must be provided against hazards caused
by unexpected operating conditions.
• Changing parameters or loading (flash-programming) software onto the
BODAS display may only be performed by trained and experienced specialists who
are suitably familiarized with both the components used and the complete system.
• When performing flashing, the user is responsible for ensuring that the software
to be flashed is compatible with the BODAS display hardware and the vehicle
configuration.
• Any unexpected reset of the display DI4 can be caused by a watchdog fault.
This safety mechanism can be triggered by overloading, a device malfunction
or power supply loss. The cause must be determined and corrected before the
device/system is used again.
• A consistently high load on the bus is to be avoided. Validation of the occurring
bus load must be performed by the OEM for the complete system.
• Faulty programming of the BODAS display may lead to potential hazards in
the running operation of the machine. It is the responsibility of the machine
manufacturer to identify hazards of this type in ahazard analysis and to bring them
to the attention of the end user. BoschRexroth shall assume no liability for dangers
of this kind.
• The display firmware and/or the board support package must be installed and
removed by BoschRexroth or by the authorized partner concerned in order to
uphold the warranty.
• On delivery, any plug-in connections that are not used are sealed with protective
caps. If mating connectors are not installed on the customer side, the provided
protective caps must be used. (tighten by hand, make sure that O-ring is in place)
(for DI4 only).
• Opening the BODAS display or modifying or repairing the display is prohibited.
Modification or repairs to the wiring could result in dangerous malfunctions.
Repair work on the BODAS display may only be carried out by BoschRexroth
or by suitable contracting partners.
• Make sure that the BODAS display configuration does not lead to safety-critical
malfunctions of the complete system in the event of failure or malfunction.

RE95289-01-B/2021-10-12, BoschRexrothAG
Safety instructions | BODAS displays 11/40
This type of system behavior may lead to danger to life and/or cause much
damage to property.
• Make sure that the product has been tested by sufficient validation within the
complete system, taking into account all possible combined ambient conditions
and considering both normal use and misuse.
• When using cameras in conjunction with the BODAS display DI3 video
or BODAS display DI4, please note that the picture display can cause
distortion, depending on the curvature of the camera lens (fish-eye effect).
Increased processor workload can lead to delays in image response times.
Please note these boundary conditions when planning and using your system.
• Video picture interference may occur when operating the display with NTSC
cameras in rooms with 50Hz lighting. This is not adevice fault.
• Only trained and experienced specialists who are adequately familiar with
both the components used and the complete system should implement system
developments or install and commission electronic systems for controlling
hydraulic drives.
• When commissioning the BODAS display or using the BODAS-service functionality
supported by the DI4 device, unforeseeable hazards may occur at the machine.
Before commissioning or using the BODAS-service functionality at DI4, it must be
ensured that the vehicle and the hydraulic system are in asafe condition.
Use of the BODAS-service function for flashing of DI4 or RC control units is only
permitted when the machine is stopped and in case of service.
• Make sure that nobody is in the machine’s danger zone.
• Do not use defective components or components which are not in aproper
working order. If components fail or exhibit amalfunction, repairs must be
carried out immediately.
• Compressed air must not be blown into the openings of the device (explosion risk).
• The back and the front glass of the display in particular may become hot during
operation. There is arisk of burns.
• Noise hazards may occur through the integrated loudspeakers or with using the
audio out signal, particularly at ashort distance from the speaker. The complete
system must be designed and verified to ensure that no health hazard is possible,
even at themaximum level.
• The brightness of the key lighting and the display DI4 as well as status LEDs and
the encoder lighting must be selected in such a way that no dangerous blinding
effects can occur. This can be done via manual setting of the levels or by using the
light level sensor at the display DI4. A time-delayed adjustment of the lighting level
must be ensured when the light level sensor is used.
• The device must be taken out of service immediately if asmoke/vapor emission
fault status is observed.

12/40 BODAS displays | Safety instructions
BoschRexrothAG, RE95289-01-B/2021-10-12
2.6 Product-specific safety instructions
The following safety instructions apply to chapters 6 to 13.
WARNING
Unsecured machine!
Risk of death or serious injury when working on unsecured machines!
Property damage!
▶ Switch off the relevant machine part and secure it against reactivation
according to the parameters by the machine manufacturer.
CAUTION
Improper cable and line routing!
Risk of stumbling and property damage! Improper routing of cables and lines
can cause arisk of stumbling as well as damage to equipment and components,
e.g.due to lines and connectors being torn off.
▶ Always install cables and lines in away that nobody can fall over them,
that they are not bend or twisted, do not chafe on edges and are not guided
through ducts with sharp edges without sufficient protection.
2.7 Personal protective equipment
The personal protective equipment is the responsibility of the user of the product.
Observe the safety regulations in your country.
All pieces of personal protective equipment should be intact.

RE95289-01-B/2021-10-12, BoschRexrothAG
General instructions on property damage and product damage | BODAS displays 13/40
3 General instructions on property
damage and product damage
The following instructions apply to chapters 6 to 13.
NOTICE
Environmental pollution due to incorrect disposal!
Careless disposal of the product and the packaging material could lead to
environmental pollution!
▶ Dispose of the product and packaging in accordance with the national
regulations in your country.
Electrical voltage!
Property damage due to electrical voltage!
▶ Always disconnect the voltage supply to the relevant machine/system part
before installing the product and/or connecting or disconnecting the connector.
Secure the machine/system against being turned back on.
The warranty exclusively applies to the delivered configuration.
The warranty will be voided if the product is incorrectly installed, commissioned or
operated, or if it is used or handled improperly.

14/40 BODAS displays | Scope of delivery
BoschRexrothAG, RE95289-01-B/2021-10-12
4 Scope of delivery
4.1 Scope of delivery DI4
1
Fig. 1: Display DI3DI4
Included in the scope of delivery:
• BODAS display DI4(1)

RE95289-01-B/2021-10-12, BoschRexrothAG
Scope of delivery | BODAS displays 15/40
4.2 Scope of delivery DI3
1
Fig. 2: Display DI3
Included in the scope of delivery:
• BODAS display DI3(1)

16/40 BODAS displays | About this product
BoschRexrothAG, RE95289-01-B/2021-10-12
5 About this product
5.1 Product description DI4
With the BODAS display DI4, BoschRexroth is offering afreely programmable
high-resolution color display with apowerful 32 bit processor and adisplay
diagonal of 7".
Depending on the programming, the display enables, for example, process variables,
static and dynamic graphic elements and the operation of machine functions to be
displayed on one central unit.
The robust display DI4 has been developed specifically for use in mobile working
machines and satisfies corresponding protection requirements regarding
ambient temperatures, impermeability, shock and vibration and electromagnetic
compatibility (EMC). It is intended for installation or assembly in the driver's cab
and offers excellent readability, even in sunlight and harsh climatic conditions.
The brightness of the lighting is adjustable. An ambient light sensor automatically
adjusts the backlighting. The color and brightness of the keys, the push-turn control
and the icons can be changed and can be adapted to the machine manufacturer's
individual design.
12 freely programmable function buttons are available for user input and menu
navigation (softkeys) . The display features an ergonomically arranged central
push-turn control for fast navigation on and between the different screens or menus
for easy adjustment of values. The display also has two other function buttons
(hardkeys), which can have fixed functionality occupancy (such as cancel, main menu)
assigned to them comprehensively across projects. In the PRO variant, acapacitive
touch screen is also available. The front the displays has an anti-fog layer to avoid
fogging in case of rapid temperature fluctuations.
The application-specific representation of screen pages, context menus,
graphic elements and video signals is provided by the CODESYS programming
environment. The integrated LEDs and the loudspeakers can be used as enhanced
status indicators.
The display can read and process analog or digital input signals directly and can also
control 2 digital live outputs.
The BODAS display is intended for use in 12 V or 24 V electrical battery systems.
The internal real-time clock is buffered against supply voltage interruption
(approx. 500 h). Communication with the BODAS controllers of the current series
and other electronic assembly groups in the machine takes place via CAN bus.
The PRO variant of the display DI4 is also equipped with an Ethernet interface,
which is routed via aseparate external connector.
The displays DI4 can be flashed via CAN bus using aBODAS-service tool or
preferably at ahigher speed via USB or Ethernet (PRO version).
The DI4 displays can also be used for gateway access to the BODAS controllers to be
used as diagnostics and service interfaces for configuration and flashing of software
on the BODAS-RC control units or the display DI4 itself. The parameters that are
stored in the BODAS controllers can be read, changed and written back to the
BODAS via the DI4 CAN interface. The representation of the active and stored errors
of aBODAS controller and the resetting of the error are possible via the DI4 using
the BODAS-service function.

RE95289-01-B/2021-10-12, BoschRexrothAG
About this product | BODAS displays 17/40
The video interface allows direct connection of two PAL or NTSC video sources
(e.g.BODAS color video cameras by BoschRexroth). The video signals transmitted
from the cameras can be shown on the display as superimposed images
(picture in-picture) or as full-screen, depending on the user interface configuration.
The Professional WebVisu variant includes the WebVisu extension for CODESYS.
WebVisu serves for visualization of the user interfaces of the CODESYS application of
the DI4 in the web browser. An Internet gateway secured on the customer side can,
for example, be used to realize aremote diagnosis in the DI4 via CODESYS WebVisu.
The DI4 is freely programmable with the CODESYS V3.5 development environment
by 3S-Smart Software Solutions GmbH.
This standard tool is extended by aproduct-specific BoschRexroth software
package. A project planning template, libraries, the license documentation and
ademo project in which core functions have been applied to help you get started
are included, as is specific online help.
Each display pagecan be freely designed by the user on aPC in terms of the
layout, arrangement and number of elements. CODESYS TargetVisu allows the easy
integration of predefined or freely designed items and bitmaps (such as customer
logos, dashboard instruments, diagrams, etc.) in display faces designed by the user.
The development environment of 3S and other DI4-specific software packages are
available from BoschRexroth.
The dynamic input parameters, which are analog, digital or based on the
(J1939 and proprietary) CAN protocol, such as speed values, temperature,
settings, etc. can be assigned to the relevant elements by the CODESYS
development environment.
The designed surfaces are shown on the PC during the definition process,
so that there is no need to download the configuration file to the display.
The customer-specific programming, configuration and menu navigation can be easily
simulated and tested on the PC.
Typical applications include driving and operating state indicator,
system parametrization and diagnostics.
Programming

18/40 BODAS displays | About this product
BoschRexrothAG, RE95289-01-B/2021-10-12
5.2 Product description DI3
With the BODAS display series DI3, BoschRexroth offers freely configurable and
high-resolution VGA color displays with apowerful integrated 32-bit graphics
processor for use in mobile working machines. The BODAS displays DI3 can be used
for displaying alphanumeric elements, process variables and operating conditions,
as well as static and dynamic graphic elements,such as pointer instruments and
menus, for example.
The robust displays have been specifically developed for use in mobile working
machines and meet the relevant safety requirements with regard to ambient
temperatures, impermeability, resistance to shock and vibration, as well as
electromagnetic compatibility (EMC). The displays are intended for installation
or mounting in the cab and provide excellent readability, even in sunlight or adverse
climatic conditions thanks to the low-reflection real glass panel with anti-fog
coating and the sun shield integrated into the case frame.
The BODAS displays DI3 are intended for direct connection to a12V or 24V
on-board voltage network. The internal real-time clock with calendar function is
retentive in case of supply voltage interruption. The contrast of the display and
the brightness of the double backlighting can be adjusted. Communication with
the BODAS controllers of the current series and other electronic assembly groups
in the machine takes place via CAN bus. All electrical connections are combined
in one connector.
The display version with video interface also allows for the direct connection
of one or two video sources in accordance with the PAL or NTSC standard
(e.g.BODAS color video cameras by BoschRexroth) for workspace or monitoring
at reverse drive direction. The voltage supply for the camera is supplied directly
through the display (can be configured to 7V, 9V or 12V using the DCT tool).
The video signals transmitted from the cameras can be shown on the display
as superimposed images (picture in-picture) or as full-screen, depending on the user
interface configuration.
For the operator input and menu navigation, six freely programmable function
buttons, developed according to ergonomic considerations, are integrated into the
housing of the BODAS display DI3. The displays also have an ergonomically designed
central rotary control (jogdial) for navigating quickly on and between the different
screen pages and menus or for changing the settings.
The application-specific display of screen pages, context menus, graphic elements,
and video signals, etc., is freely defined by the user using the Windows-based
PC configuration tool BODAS DCT 1.0 / 2.0 (Display Configuration Tool) and is
transmitted by downloading onto the integrated flash memory of the BODAS display
DI3. The BODAS display DI3 has an additional function in that it can be used as
adiagnosis and service interface for aBODAS system configuration.
For this, the parameter settings that are stored in the BODAS controllers RC
can also be read out, changed and written back via the DI3 CAN interface.
Providing the BODAS controllers RC used are equipped with aCAN diagnostics
interface, no additional tool is required for the diagnosis/parameterization of the
application when aDI3 is used.

RE95289-01-B/2021-10-12, BoschRexrothAG
About this product | BODAS displays 19/40
5.2.1 BODAS DCT 1.0 / 2.0 (Display Configuration Tool)
The Rexroth software tool BODAS DCT (Display Configuration Tool) offers the user
aWindows-based user interface for the easy and customer-specific configuration of
• Device settings
• Graphic display pages (e.g.dashboard)
• Fonts
• Parametrization and diagnosis pages
• Menus
• Dialog boxes/pop-ups
• Alarm messages
• Video pages (DI3 video only)
Each display pagecan be freely designed by the user on aPC in terms of the
layout, arrangement and number of elements. Prior knowledge or knowledge of
programming is not required.
The BODAS DCT enables the easy integration of predefined or freely designed
items and bitmaps (suchas customer logos, dashboard instruments, diagrams, etc.)
in the display faces designed by the user.
The dynamic input parameters based on the CAN protocol(J1939 and proprietary),
such as speed values, temperatures, and settings, etc. can be directly assigned to
the respective indicator elements using the BODAS DCT.
The entire definition and assignment process is graphically supported and enables
the desired input variables to be implemented and displayed within the shortest
time on the BODAS display DI3. The designed surfaces are shown on the PC during
the definition process, so that there is no need to download the configuration file to
the display.
The configuration designed by the customer is converted and flashed on the
BODAS display DI3 at the touch of abutton.
5.2.2 BODAS DCT library
The library provided offers the BODAS DCT user the option to use aset of
predefined graphic elements to design the display pages, in order to create
arunning system in the shortest time.
A list of available library elements is shown below:
• Dashboard instruments (e.g.temperature, rotational speed, speed, fill level)
in gauge orbar graph format
• Value fields
• Table elements
• Rectangles, lines, circles
• Pictograms
• Text fields
• Dialog boxes/pop-ups

20/40 BODAS displays | About this product
BoschRexrothAG, RE95289-01-B/2021-10-12
Optional with DI3 video:
– Connection of 2 video sources in
accordance with PAL or NTSC standard
DCT
Configuration
file
BODAS DCT 1.0 / DCT 2.0
(Display Configuration Tool)
BODAS controller RC
Connection of the display to CAN bus
Information available for:
– Engine speed
– Temperature
– Engine control unit status
– Other system statuses for gearbox, hydraulics, etc.
BODAS
display DI3
Fig. 3: Typical system configuration (with optional connection of two video sources)
This manual suits for next models
2
Table of contents
Other Bosch Monitor manuals

Bosch
Bosch UMS-20 Series User manual

Bosch
Bosch Rego 1000 User manual

Bosch
Bosch UML-172-90 User manual

Bosch
Bosch LTC-2917-91 User manual

Bosch
Bosch 42RTH User manual

Bosch
Bosch LTC2821/91 User manual

Bosch
Bosch MON170CL User manual

Bosch
Bosch UML-19P-90 User manual

Bosch
Bosch 27ST220L User manual

Bosch
Bosch LTC 2910/90 User manual

Bosch
Bosch Rexroth ctrlX HMI DE0015 User manual

Bosch
Bosch Glasses CM-G 22" User manual

Bosch
Bosch DDU 10 User manual

Bosch
Bosch UML-19P-90 User manual

Bosch
Bosch UML-151 User manual

Bosch
Bosch UML-223-90 User manual

Bosch
Bosch UML-151 User manual

Bosch
Bosch MON172CL20 User manual

Bosch
Bosch UML-202 User manual

Bosch
Bosch LTC 2814/90 Series User manual
