Bosch Glasses CM-G 22" User manual

Glasses CM-G 22˝
en Operating instructions
7 620 310 073

2| en
7 620 310 073 | 09.2020 Robert Bosch GmbH
CE approval
The Glasses CM-G 22˝ has been tested according to the
regulatory requirements of the European Union (EU) in
accordance with the 2014/30/EU standard, and meets
all the requirements for the CE label.
The complete text of the EU Declaration of Conformity is
available at this internet address:
www.bosch-professional-systems.com
Specific to US:
The users manual or instruction manual for an intentio-
nal or unintentional radiator shall caution the user that
changes or modifications not expressly approved by the
party responsible for compliance could void the user‘s
authority to operate the equipment.
This device complies with Part 15 of the FCC Rules [and
with RSS-GEN of Industry Canada].
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired
operation.
Changes or modifications made to this equipment not
expressly approved by (manufacturer name) may void
the authorization to operate this equipment.
Responsible Party – U.S. Contact Information:
Robert Bosch LLC
15000 Haggerty Road
Plymouth, MI 48170
Road safety
Make sure that your ability to drive is not
impaired and your vision is not blocked by the
device or the wiring connected to it.
Risk of electrical shock or fire
If you disassemble the device, it might result in
electrical shock or fire.
Do not open the device.
Malfunctions
Do not use the device if you notice any
malfunctions such as poor video quality.
Continued use of a malfunctioning system may
result in accidents, fire or electrical shock.
Contents | Important information
Contents
2 Important information
2 Agreed product use
2 CE approval
3 Installation notes
3 Switching on/off
3 Settings
3 Technical data
4 Device drawings
Important information
Before using the device, please read these instructions
carefully and familiarize yourself with the device. Keep
these instructions in your vehicle for later reference.
Changes or modifications not expressly approved by the
party responsible for compliance could void the user‘s
authority to operate the equipment.
Agreed product use
The device has been designed for operation in a
commercial vehicle with a 24 V electrical system.
The device must not be operated in any other environ-
ment or in an intended environment that is compromi-
sed e.g. by damage or malfunction.

en | 3
7 620 310 073 | 09.2020Robert Bosch GmbH
en
Important information | Switching on/off | Settings | Technical data
Installation notes
Important note:
The installation of the monitor requires the
adapter cable 7 620 280 125 (to be obtained
separately).
Important note:
The monitor may only be attached to one of
these holders:
fFixed holder for roof mount
(7 620 340 031)
fFixed holder for wall mount
(7 620 340 033)
fSwivel holder (7 620 340 032)
Please carefully observe the installation
instructions of the respective holder.
Note:
Please also observe the information given in
the device drawings at the end of this docu-
ment.
Please observe the following installation notes:
fDo not exert external force onto the frame and
visible surface of the LCD.
fDo not exceed the maximum length of the device‘s
supply cables.
fThe device‘s supply cable must provide a minimum
cross sectional area of 1.5 mm2.
fObserve the minimum bending radius of the
device‘s supply cables.
fEnsure that the device‘s supply cables are pro-
tected against sharp edges.
fMount the device or its holder respectively only to a
stiff surface with enough stability for the system.
fOnly use suitable screws and washers for mounting
the device to the holder.
fObserve the required thread reach and torque.
fAir convection and ventilation must be ensured. Do
not cover the ventilation holes.
Switching on/off
The device is automatically switched on or off by the
Coach Infotainment system of your Vehicle.
Settings
The monitor provides setting options (via Center
CM-C 19) for:
fBrightness
fContrast
fGamma correction
fAspect ratio (3 modes for autoscaling of 16:9 and
4:3 picture sources)
fReset to factory settings
Note:
Please refer to the user manual of the Center
CM-C 19 for information about making settings
for the connected monitor.
Technical data
Power Supply 24 V (17 V – 36 V)
Current consumption
In operation 5 A
Max. current < 10 A
Standby current max. 100 μA
Diagonal display size 21“ ±1.5“
Resolution 1920 x 1080 pixels
Contrast ratio 1000 : 1
Luminance Min. 250 cd/m2
Screen format 16:10, 16:9
Viewing angle ±80° in all directions
Backlight LED
Flash memory 2 Gbits
Operating frequency 60 Hz
Network interface OABR | 2 ports | speed rate:
100 Mbits/s full duplex
Operating temperature -25 °C to +65 °C
Storage temperature -25 °C to +75 °C
Dimensions (L x W x H) 537 x 329 x 51 mm
Weight Approx. 3.5 kg
Certification CE, UN ECE R10,
UN ECE R118
Subject to changes!

4| en
7 620 310 073 | 09.2020 Robert Bosch GmbH
Device drawings
Device drawings

en | 5
7 620 310 073 | 09.2020Robert Bosch GmbH
en
Device drawings
The Glasses CM-G 22" documentation consists of:
- 7620 310 073 Technical customer documentation (TCD)
- User Manual (this document)
- TCD drawing
Together, all documents form the complete product documentation. Please note that
all documented regulations and constrains have to be complied with when installing
this product into coaches.

Robert Bosch GmbH
Robert-Bosch-Platz 1
70839 Gerlingen
Germany
www.bosch-professional-systems.com
09/20 – CVO/PRM-CM
